AKYLA HD 20/25/33/40 LV
3. Technical Specifications
Notes: 1. Measured front face temperature.
2. For 33.3 MHz and 40 MHz cameras, additional cooling is required when the ambient temperature is above 20°C.
3. Within 5 to 95% of the saturation exposure. Equals ±4 LSB on a 10-bit scale when gains are above 300.
Table 3-1. Technical Specifications of the AKYLA HD Series of Cameras with 10 µm Sensors
Parameter Symbol Min Typical Max Unit Notes
Number of pixels N
N–1024
2048 –––
Pixel size – – 10 x 10 – µm 100% fill factor
Data rate per CCD – – – 40 MHz –
Gain control G – 100x – – Response time: 500 ms max.
A/D conversions – – 12 – bit –
Supply voltage Vsupp 20 24 36 VDC
Ripple: ±10%, voltage + ripple must
stay within 20 to 36 V
Power consumption – – 12 to 17 26 W –
Weight m – 1.3 – kg Without lens
Operating temperature Top 5–40 °C 41 to 104°F (1)(2)
Storage temperature Tst -10 – 55 °C 14 to 131°F
Humidity, operation – 5 – 85 % Relative, non-condensing
Humidity, storage – 5 – 95 % Relative, non-condensing
Linearity – – 99.6 – % (3)
Photo response non-
uniformity, pixel-to-pixel PRNU – ±2 ±10 % –
Saturation level – – 4095 4095 DU Digital units
Table 3-2. Technical Specifications of the AKYLA HD Series of Cameras with 14 µm Sensors
Parameter Symbol Min Typical Max Unit Notes
Number of pixels N – 1024 – – –
Pixel size – – 14 x 14 – µm 100% fill factor
Data rate per CCD – – – 40 MHz –
Gain control G 12x 100x – – Response time: 500 ms max
A/D conversions – – 12 – bit –
Supply voltage Vsupp 20 24 36 VDC
Ripple: ±10%, voltage + ripple must
stay within 20 to 36 V
Power consumption – – 12 to 17 26 W –
Weight m – 1.3 – kg Without lens
Operating temperature Top 5–35 °C 41 to 95°F(2)
Storage temperature Tst -10 – 55 °C 14 to 131°F
