Audio Note M2 RIAA Technisches Handbuch

M2 Line

PRE AMPLIFIER

OWNERʼS INFORMATION

1) IMPORTANT SAFETY INFORMATION

2) CE DECLARATION OF CONFORMITY

DISPOSAL

POWER REQUIREMENTS

3) INTRODUCTION

4) OVERVIEW

5) UNPACKING AND INSTALLATION

6) CONNECTION

7) OPERATION

9) TECHNICAL SPECIFICATIONS

10) WARRANTY INFORMATION

11) CONTACT INFORMATION

CONTENTS

OTHER SAFETY PRECAUTIONS: -

Never touch the power cord with wet hands.

Always remove the power cord by grasping the plug, not the cable.

Never expose the unit to excessive heat or magnetism.

Never let an inexperienced person repair or reassemble the unit.

Never put anything, especially metal objects, inside the unit.

Never place excessive weight on the unit.

Do not store or operate this unit in areas of high humidity or in close

proximity to water / moisture.

Do not expose or immerse the unit in liquid of any kind.

This product generates high levels of heat. Adequate ventilation must

be provided. Do not restrict airflow through any ventilation slots or

place the unit on any surface that may restrict airflow.

Valve equipment operates at extremely high temperatures;

KEEP OUT OF THE REACH OF CHILDREN AND ANIMALS.!

RISK OF SHOCK OR ELECTROCUTION! INTERNAL OPERATING

VOLTAGES ARE LETHAL!

Do not remove top cover, unless specifically instructed to do so in the user

manual.

This unit contains fuses and other safety components in accordance with

BS60065 requirements.

In the event of failure, replacement fuse or safety component must be of

the same part type and value.

This product must be earthed –ensure that the mains supply cable earth /

ground is correctly connected.

SUCH REPLACEMENT MUST ONLY BE CARRIED OUT BY A

QUALIFIED SERVICE TECHNICIAN.

Do not attempt to replace any fuses without first disconnecting the unit

from the mains electricity supply.

! IMPORTANT SAFETY INFORMATION !

POWER REQUIREMENTS

Power requirements for electrical equipment vary depending on your geographical

location. Please ensure that your unit meets the power requirements in your area.

The power requirement for your unit is marked on the serial number plate, located on

the rear panel.

If you are in doubt, please contact your dealer before plugging the unit into the mains

supply.

CE DECLARATION OF CONFORMITY

DISPOSAL

This product must not be disposed of as normal household waste. To

prevent possible harm to the environment please separate the product

from other waste to ensure that it can be recycled in an environmentally

safe manner. Please contact your retailer or the appropriate local

government office for collection facilities.

We declare under our sole responsibility that this product is in conformity

with the following standards or standardized documents:

BS EN 60065 in accordance with the regulations 73/23/EEC, 89/336/EEC

(from 1 January 1997)

CE 94

Peter Qvortrup,

Director

Audio Note (UK) Limited

25 Montefiore Road

Hove

East Sussex

BN3 1RD

United Kingdom

Tel: +44 (0)1273 220 511

Fax: +44 (0)1273 731 498

Thank you for purchasing this Audio Note (UK) product. With the correct care it

should give you many years of pleasure and enjoyment.

Please take the time to read all of the information in this manual before connecting

your new component to an electrical supply or your system, to ensure both your

safety and satisfaction.

Please note that due to our desire to continually improve products, specifications are

subject to change without notice. Therefore it is important to refer to the manual that

is supplied with your product for the most accurate information; manuals downloaded

from our website or obtained from other sources may no longer fully apply to your

product.

If you have any questions regarding the information contained within this document

or your new component, please feel free to contact us: -

Audio Note (UK) Limited

25 Montefiore Road

Hove

East Sussex

BN3 1RD

United Kingdom

Tel: +44 (0)1273 220 511

Fax: +44 (0)1273 731 498

e-mail: [email protected]o.uk

INTRODUCTION

Congratulations on your purchase of the Audio Note (UK) M2 Line Pre Amplifier.

It has been specifically engineered for sonic performance rather than technical

specification, and fulfills all Audio Note (UK) Level 2 criteria: -

Pure Class A operation

Zero negative feedback

Single Ended circuit topology

Valve rectification

Materials and component quality

It is well known that the accurate reproduction of music, not just sound, requires the

purity of the incoming signal to be preserved. It is therefore not difficult to conclude

that, in order to achieve this goal and to retain the musicality of the original

performance,the complexity of the circuitry itself must be kept to a minimum.

In response to this, the M2 Line Pre Amplifier uses a single-ended, zero feedback

circuit topology. This is simply the most linear design possible, demanding pure

Class A valve operation and removing the need for a phase splitter, which introduces

unnecessary crossover distortion.

In contrast to the majority of the audio industry, we design our circuits with the aim of

minimising non-harmonic and time base anomalies, rather than producing

vanishingly small harmonic or low intermodulation distortion measurements. These

non-harmonic amplitude and time base distortions have a highly perceptible and

adverse affect on the signal waveform, and it is far more important to address these

factors than participate in the increasingly irrelevant numbers game that chases

ʻperfect measured responseʼ.

As a result, the M2 Line was designed for maximum linearity and minimum transient

distortion, and avoids the need for detrimental ʻcorrectiveʼmeasures, such as

inherently error-prone feedback loops.

The M2 Line Pre Amplifier features a 6SN7 line stage and a valve rectified power

supply incorporating a 6X5 and an ECL82.

M2 LINE PRE AMPLIFIER

Please take care when unpacking your M2 Line Pre Amplifier. Choose a clean, clear

location to unpack your unit. Be aware that the Pre Amplifier is quite heavy; before

attempting to unpack or lift the unit, check the weight and if necessary use more than

one person so that it can be moved safely and easily.

We recommend that you retain and carefully store all of the original packing

materials, in case transportation / shipping is required at a later date.

Select a suitable location for the unit. This should be a dry, dust free and level area,

preferably shielded from direct sunlight and free from vibration. Also ensure that the

location is stable and capable of carrying the weight of the unit.

A suitable mains power outlet must be close to the location; power cords must not be

pulled or stretched tightly in an attempt to reach a wall socket. If the power cord will

not easily reach the socket, choose a closer location!

Please ensure that adequate ventilation for the unit is provided, and that airflow

through any ventilation slots in the unit is not restricted. We recommend a distance of

at least 20cm free space is maintained above the unit. Please also remember that

valve equipment operates at extremely high temperatures, so a position that is

inaccessible to children or animals is essential.

UNPACKING AND INSTALLATION

Line inputs Four line inputs are available labeled CD1, CD2,Tuner and Aux. Any

standard ʻline levelʼsource can be connected to these inputs.

Connect the ʻRec-Outʼor ʻLine Outʼsockets on your recording device

to the ʻTape Inʼsockets of the M2 Line, and the ʻTape Outʼsockets to

the ʻRec-Inʼor ʻLine Inʼsockets of your recording device.

Ground Post A ground post is provided for connection to those source components

that also use a separate ground terminal.

Mains The M2 Line Pre Amplifier utilizes an IEC 320 mains inlet socket. Use

the supplied mains cable to connect the unit to the local mains supply.

The mains fuse and a spare is located in the inlet socket fuse drawer.

Special Note –Make sure that all connectionsare tight and clean. For

best results use good quality audio interconnects. Although it is

perfectly acceptable to use cables manufactured by other companies,

for best results and performance, we recommend our own Audio Note

(UK) range of interconnects and loudspeaker cables. For further

information, please consult your nearest Audio Note (UK) dealer, or

alternatively please feel free to contact us directly.

Outputs The M2 Line provides two unbalanced outputs, consisting of two pairs

of colour coded RCA / Single Ended sockets. RED is for RIGHT

channel connection, WHITE is for LEFT channel connection.

RCA The two pairs of RCA / Single Ended outputs are for connection to a

power amplifier and are identical, making them suitable for bi-amping.

CONNECTION

RCA SOCKET,

CENTRE = POSITIVE / SEND.

RCA SOCKET,

SHELL = NEGATIVE / RETURN.

OPERATION

Once all the connections are completed and checked, ensure that the volume control

is at the minimum setting (rotated all the way left).

Ensure that all source components connected to the M2 Line Pre Amplifier are

switched ON. Source components should always be the FIRST components to be

switched on and the LAST components to be switched off.

Ensure that all power amplifiers connected to the M2 Line Pre Amplifier are

switched OFF. Any power amplifiers in use should be the LAST components to be

switched on, and the FIRST components to be switched off.

The above procedure minimizes the possibility of loud noises produced by

components at switch on being passed to the loudspeakers and possibly causing

damage.

Turn on the M2 Line Pre Amplifier by using the rocker switch located on the rear

panel, above the mains inlet IEC socket.

The M2 Line Pre Amplifier requires approximately 45 seconds to initialize before it is

ready for operation.

Input Selector Turn the selector to the source you wish to listen to.

Source / Tape This allows you to switch between the selected source input

and the output of your recording device.

Volume Control This control adjusts the listening level, or loudness. Set as

desired!

Balance Control This control adjusts the relative left/right levels. Use this control

if necessary to equalize the loudness from each speaker.

Feedback

Switches Two feedback switches are located next to the ground terminal

on the rear panel; these are used for matching the output of the

M2 Line to the input of the following power amplifier.

Set the switches to the ʻonʼposition if any of the following

apply: -

The volume control is too sensitive, and output is too high.

If the interconnects between the M2 Line and the following

power amplifier are longer than 3 meters.

If the power amplifier has an input impedance of less than

50KOhms.

When in doubt, choose the setting that provides the best sonic

performance.

NOTE: Always turn the power off before adjusting the feedback switches. Ensure

that both feedback switches are in the same position.

Bedding in The new preamplifier requires about 200 hours of initial use

(called “bedding in”) before the circuitry becomes stable and

optimum performance is realized.

As the preamplifier “beds in” the sound will become

increasingly smoother, detailed and open.

Once the amplifier has “bedded in” a warm up time of

approximately 30 to 45 minutes is required each time the

amplifier is switched on before optimum sonic performance is

reached.

Cleaning No special maintenance is required for the amplifier. Use a

soft, clean lint free cloth to remove any surface marks from the

casework. For finger marks / grease, use a soft, clean lint free

cloth, lightly moistened with a solution of warm water and mild

detergent. Do not use any alcohol or solvent based cleaning

products, as they may damage the finish of the amplifier.

ENSURE THAT THE M2 LINE IS SWITCHED OFF AND

DISCONNECTED FROM THE MAINS ELECTRICITY

SUPPLY BEFORE UNDERTAKING ANY CLEANING.

Valve Life The valves supplied with your M2 Line Premplifier should

provide approximately 5 years of operation. They are specially

selected by us, and should only be replaced with valves of the

same type and specification. Please consult your Audio Note

(UK) dealer should your valves need replacing. Alternatively,

feel free to contact us directly.

OPERATION continued…

Andere Handbücher für M2 RIAA

Inhaltsverzeichnis

Andere Audio Note Verstärker Handbücher

Audio Note

Audio Note COBRA Bedienungsanleitung

Audio Note

Audio Note EL34 Bedienungsanleitung

Audio Note

Audio Note M10 Signature Technisches Handbuch

Audio Note

Audio Note R Zero/II Bedienungsanleitung

Audio Note

Audio Note M2 RIAA Technisches Handbuch

Audio Note

Audio Note M Zero Bedienungsanleitung

Audio Note

Audio Note M1 RIAA Technisches Handbuch

Audio Note

Audio Note RIAA-ZERO PHONO Bedienungsanleitung

Audio Note

Audio Note CONQUEROR Silver Signature Low Gain Technisches Handbuch

Audio Note

Audio Note MEISHU Phone Technisches Handbuch

Audio Note

Audio Note P1 SE Technisches Handbuch

Audio Note

Audio Note SORO Phono SE Signature Technisches Handbuch

Audio Note

Audio Note MEISHU Phono Silver Signature Technisches Handbuch

Audio Note

Audio Note M8 Phono Signature Technisches Handbuch

Audio Note

Audio Note Kassai Bedienungsanleitung

Audio Note

Audio Note R Zero/II Technisches Handbuch

Audio Note

Audio Note JINRO Shochu Technisches Handbuch

Audio Note

Audio Note OTO Phono SE Signature Technisches Handbuch

Audio Note

Audio Note Quest Silver Signature Bedienungsanleitung

Audio Note

Audio Note M5 RIAA Technisches Handbuch

Audio Note

Audio Note M3 Phono Technisches Handbuch

Audio Note

Audio Note SORO Line Technisches Handbuch

Audio Note

Audio Note ONGAKU Technisches Handbuch

Audio Note

Audio Note M1 RIAA Technisches Handbuch

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
