Audio Note P3 Silver Technisches Handbuch

Silver

STEREO POWER AMPLIFIER

OWNER’S INFORMATION

1) IMPORTANT SAFETY INFORMATION

2) CE DECLARATION OF CONFORMITY

DISPOSAL

POWER REQUIREMENTS

3) INTRODUCTION

4) OVERVIEW

5) UNPACKING AND INSTALLATION

6) VALVE INSTALLATION

8) CONNECTION

10) OPERATION

11) TECHNICAL SPECIFICATIONS

12) WARRANTY INFORMATION

13) CONTACT INFORMATION

CONTENTS

UCH REPLACEMENT MUST ONLY BE CARRIED OUT BY A

QUALIFIED SERVICE TECHNICIAN.

Do not attempt to replace any fuses without first disconnecting the unit

from the mains electricity supply.

! IMPORTANT SAFETY INFORMATION !

RISK OF SHOCK OR ELECTROCUTION! INTERNAL OPERATING

VOLTAGES ARE LETHAL!

Do not remove top cover, unless specifically instructed to do so in the user

manual.

This unit contains fuses and other safety components in accordance with

BS60065 requirements.

In the event of failure, replacement fuse or safety component must be of

the same part type and value.

This product generates high levels of heat. Adequate ventilation must

be provided. Do not restrict airflow through any ventilation slots or

place the unit on any surface that may restrict airflow.

Valve equipment operates at extremely high temperatures;

KEEP OUT OF THE REACH OF CHILDREN AND ANIMALS.

Do not store or operate this unit in areas of high humidity or in close

proximity to water / moisture.

Do not expose or immerse the unit in liquid of any kind.

This product must be earthed –ensure that the mains supply cable earth /

ground is correctly connected.

OTHER SAFETY PRECAUTIONS: -

Never touch the power cord with wet hands.

Always remove the power cord by grasping the plug, not the cable.

Never expose the unit to excessive heat or magnetism.

Never let an inexperienced person repair or reassemble the unit.

Never put anything, especially metal objects, inside the unit.

Never place excessive weight on the unit.

POWER REQUIREMENTS

Power requirements for electrical equipment vary depending on your geographical

location. Please ensure that your unit meets the power requirements in your area.

The power requirement for your unit is marked on the serial number plate, located on

the rear panel.

If you are in doubt, please contact your dealer before plugging the unit into the mains

supply.

CE DECLARATION OF CONFORMITY

DISPOSAL

This product must not be disposed of as normal household waste. To

prevent possible harm to the environment please separate the product

from other waste to ensure that it can be recycled in an environmentally

safe manner. Please contact your retailer or the appropriate local

government office for collection facilities.

We declare under our sole responsibility that this product is in conformity

with the following standards or standardized documents:

BS EN 60065 in accordance with the regulations 73/23/EEC, 89/336/EEC

(from 1 January 1997)

CE 94

Peter Qvortrup,

Director

Audio Note (UK) Limited

Viscount House

Star Road, Star Trading Estate

Partridge Green

West Sussex

RH13 8RA

United Kingdom

Tel: +44 (0)1273 830 800

Fax: +44 (0)1273 731 498

Thank you for purchasing this Audio Note (UK) product. With the correct care it

should give you many years of pleasure and enjoyment.

Please take the time to read all of the information in this manual before connecting

your new component to an electrical supply or your system, to ensure both your

safety and satisfaction.

Please note that due to our desire to continually improve products, specifications are

subject to change without notice. Therefore it is important to refer to the manual that

is supplied with your product for the most accurate information; manuals downloaded

from our website or obtained from other sources may no longer fully apply to your

product.

If you have any questions regarding the information contained within this document

or your new component, please feel free to contact us: -

Audio Note (UK) Limited

Viscount House

Star Road, Star Trading Estate

Partridge Green

West Sussex

RH13 8RA

United Kingdom

Tel: +44 (0)1273 830 800

Fax: +44 (0)1273 731 498

e-mail: info@audionote.co.uk

INTRODUCTION

Congratulations on your purchase of the Audio Note (UK) P3 Silver stereo power

amplifier.

It is a Pure Class A Singled Ended amplifier that uses the highly regarded 300B

direct heated triode valve, producing a level of performance that is radically superior

to the vast majority of current designs.

It has been specifically engineered for sonic performance rather than technical

specification, and fulfills all Audio Note (UK) Level 3 criteria: -

Pure Class A operation

Zero Negative Feedback

Single Ended Output Stage

Valve Rectification

Directly Heated Triode operation

Materials and component quality

The Silver version builds upon the already superb performance of the standard

Meishu, and features the following additions: -

Audio Note Silver wiring

Audio Note Copper Foil signal capacitors

Audio Note (UK) Tantalum film resistors

Audio Note (UK) IHiB Double C Core output transformers, with copper primaries and

copper secondaries.

P3 STEREO POWER AMPLIFIER

Please take care when unpacking your P3 Silver amplifier. Choose a clean, clear

location to unpack it, and be aware that the amplifier is very heavy; before attempting

to unpack or lift the unit, check the weight and if necessary use more than one

person so that it can be moved safely and easily.

We recommend that you retain and carefully store all of the original packing

materials, in case transportation / shipping is required at a later date.

Select a suitable location for the amplifier. This should be a dry, dust free and level

area, preferably shielded from direct sunlight and free from vibration. Also ensure

that the location is stable and capable of supporting the weight of the unit.

A suitable mains power outlet must be close to the location; power cords must not be

pulled or stretched tightly in an attempt to reach a wall socket. If the power cord will

not easily reach the socket, choose a closer location!

Please ensure that adequate ventilation for the amplifier is provided, and that airflow

through any ventilation slots in the casework is not restricted. We recommend a

distance of at least 20cm free space is maintained above the amplifiers, and

preferably they should be sited in free space or on the top shelf of your equipment

rack or table. Please also remember that valve equipment operates at extremely high

temperatures, so a position that is inaccessible to any children or animals is

essential.

UNPACKING AND INSTALLATION

The amplifier is shipped without several of its valves installed. It is necessary to

install the valves before operation.

It is essential that the valves are installed correctly or serious damage that is not

covered by the warranty will result. We recommend that your dealer perform

this procedure for you if you are in any way unsure.

FIRSTLY, ENSURE THAT THE AMPLIFIERS IS NOT CONNECTED TO A MAINS

ELECTRICAL SUPPLY, AND THAT THE POWER CORD IS NOT CONNECTED TO

THE AMPLIFIER.

Remove the top cover from the amplifier. There are a total of 20 screws used to

secure this cover.

Now remove the valves that are packed separately and carefully unwrap them. Also

inspect the amplifiers to check that nothing has become damaged or dislodged

during transit.

In the above drawing, the positions of the valves are marked in RED.

VALVE INSTALLATION

300B

valves

5U4GB

valve

Mains Input

Transformer

FRONT OF AMPLIFIER

REAR OF AMPLIFIER

RCA INPUTS

MAINS INPUT

You should find the following valves: -

2 x 300B output valves

1 x 5U4GB rectifier valve

Once again, please understand that it is absolutely vital these valves are fitted

correctly.

Looking from the front of the amplifier install the 300B valves first. Inspect a 300B

and you will notice that two of the metal pins located at the bottom of the valve are

larger than the other two; this is to help ensure that the valve can only be inserted

one way.

Now examine the large valve sockets located at the rear of the central circuit board

of the amplifier (refer to drawing on previous page). You will notice that two of the

four holes in each valve socket are larger than the others. Line up the large pins on

the bases of the 300B valves and the large holes in each valve socket, and with

gentle but firm pressure insert each valve into its socket.

Next, examine the remaining 5U4GB rectifier valve. You will see that there is a rib on

the central pin of the valve base, which ensures that it can only be inserted into the

valve socket correctly. Locate this rib and align with the corresponding aperture in

the centre of the valve socket, located on the right hand circuit board of the amplifier,

in front of the mains inlet transformer (refer to drawing on previous page). With gentle

but firm pressure, insert the valve.

Check one more time that all of the 3 valves are correctly fitted!

VALVE INSTALLATION continued…

Line inputs Being a stereo power amplifier, the P3 Silver is fitted with a single pair

or RCA / Single Ended inputs. Looking from behind the amplifier, they

are located at the lower right hand side of the rear panel. They are

marked „R‟ for the right channel input and „L‟ for the left channel input.

Connect the outputs from your preamplifier to these inputs.

Speakers Each channel is equipped with 3 colour coded binding posts for

connection to your speakers.

Looking from the rear of the amplifier, the 6 binding posts (three per

channel) are located at the centre of the rear panels.

Connect the amplifier‟s black speaker output binding posts marked as

“0” to the black / negative terminal (also marked “ – “) on the

loudspeakers.

Connect the amplifier‟s red speaker output binding posts marked “8

Ohm” to the red / positive terminal (also marked “ + “) on the

loudspeakers. The other red output binding post is marked “4 Ohm”

and may be used with 4 Ohm speakers. If you are uncertain whether

your speaker system is specified as 4 or 8 Ohm, try the following test

once all other connections are made and the amplifier is operational.

Compare the sound quality using a familiar recording with the

speakers connected to the 8 Ohm connections and then the 4 Ohm

connections respectively. The combination that produces the best

frequency balance and maximum dynamics should be used.

Mains The P3 Silver is equipped with an IEC 320 mains inlet socket, located

at the top / left hand side of the rear panel. Use the supplied mains

cable to connect the unit to the local mains supply. The two fuses are

located in the two fuse holders, located on the rear panel to the right

of the main power switch.

Special Note –Make sure that all connections are tight and clean. For

best results use good quality audio interconnects. Although it is

perfectly acceptable to use cables manufactured by other companies,

for best results and performance, we recommend our own Audio Note

(UK) range of interconnects and loudspeaker cables. For further

information, please consult your nearest Audio Note (UK) dealer, or

alternatively please feel free to contact us directly.

CONNECTION

Inhaltsverzeichnis

Andere Audio Note Verstärker Handbücher

Audio Note

Audio Note SORO Line SE Signature Technisches Handbuch

Audio Note

Audio Note SORO Line Technisches Handbuch

Audio Note

Audio Note Quest Silver Signature Bedienungsanleitung

Audio Note

Audio Note M10 Signature Technisches Handbuch

Audio Note

Audio Note SORO Phono SE Signature Technisches Handbuch

Audio Note

Audio Note VINDICATOR Silver Signature Technisches Handbuch

Audio Note

Audio Note M One Bedienungsanleitung

Audio Note

Audio Note P4 Balanced Technisches Handbuch

Audio Note

Audio Note Neiro Technisches Handbuch

Audio Note

Audio Note M2 RIAA Technisches Handbuch

Audio Note

Audio Note Baransu Technisches Handbuch

Audio Note

Audio Note M Zero Technisches Handbuch

Audio Note

Audio Note PALADIN Technisches Handbuch

Audio Note

Audio Note M2 Balanced informatio Technisches Handbuch

Audio Note

Audio Note M1 RIAA Technisches Handbuch

Audio Note

Audio Note Kegon Technisches Handbuch

Audio Note

Audio Note Neiro Technisches Handbuch

Audio Note

Audio Note TOMEI Technisches Handbuch

Audio Note

Audio Note P3 Tonmeister Silver Signature Technisches Handbuch

Audio Note

Audio Note CONQUEROR Silver Signature Low Gain Technisches Handbuch

Audio Note

Audio Note Conquerer Bedienungsanleitung

Audio Note

Audio Note Interstage Mono Block 300D Bedienungsanleitung

Audio Note

Audio Note M6 Phono Technisches Handbuch

Audio Note

Audio Note M3 Phono Technisches Handbuch

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
