Audio Note VINDICATOR Silver Signature Technisches Handbuch

VINDICATOR

Silver Signature

STEREO POWER AMPLIFIER

OWNER’S INFORMATION

1) IMPORTANT SAFETY INFORMATION

2) CE DECLARATION OF CONFORMITY

DISPOSAL

POWER REQUIREMENTS

3) INTRODUCTION

4) OVERVIEW

UNPACKING AND INSTALLATION

5) VALVE INSTALLATION

6) CONNECTION

7) OPERATION

8) TECHNICAL SPECIFICATIONS

9) WARRANTY INFORMATION

10) CONTACT INFORMATION

CONTENTS

SUCH REPLACEMENT MUST ONLY BE CARRIED OUT BY A

QUALIFIED SERVICE TECHNICIAN.

Do not attempt to replace any fuses without first disconnecting the unit

from the mains electricity supply.

! IMPORTANT SAFETY INFORMATION !

RISK OF SHOCK OR ELECTROCUTION! INTERNAL OPERATING

VOLTAGES ARE LETHAL!

Do not remove top cover, unless specifically instructed to do so in the user

manual.

This unit contains fuses and other safety components in accordance with

BS60065 requirements.

In the event of failure, replacement fuse or safety component must be of

the same part type and value.

This product generates high levels of heat. Adequate ventilation must

be provided. Do not restrict airflow through any ventilation slots or

place the unit on any surface that may restrict airflow.

Valve equipment operates at extremely high temperatures;

KEEP OUT OF THE REACH OF CHILDREN AND ANIMALS.!

Do not store or operate this unit in areas of high humidity or in close

proximity to water / moisture.

Do not expose or immerse the unit in liquid of any kind.

This product must be earthed –ensure that the mains supply cable earth /

ground is correctly connected.

OTHER SAFETY PRECAUTIONS: -

Never touch the power cord with wet hands.

Always remove the power cord by grasping the plug, not the cable.

Never expose the unit to excessive heat or magnetism.

Never let an inexperienced person repair or reassemble the unit.

Never put anything, especially metal objects, inside the unit.

Never place excessive weight on the unit.

POWER REQUIREMENTS

Power requirements for electrical equipment vary depending on your geographical

location. Please ensure that your unit meets the power requirements in your area.

The power requirement for your unit is marked on the serial number plate, located on

the rear panel.

If you are in doubt, please contact your dealer before plugging the unit into the mains

supply.

CE DECLARATION OF CONFORMITY

DISPOSAL

This product must not be disposed of as normal household waste. To

prevent possible harm to the environment please separate the product

from other waste to ensure that it can be recycled in an environmentally

safe manner. Please contact your retailer or the appropriate local

government office for collection facilities.

We declare under our sole responsibility that this product is in conformity

with the following standards or standardized documents:

BS EN 60065 in accordance with the regulations 73/23/EEC, 89/336/EEC

(from 1 January 1997)

CE 94

Peter Qvortrup,

Director

Audio Note (UK) Limited

25 Montefiore Road

Hove

East Sussex

BN3 1RD

United Kingdom

Tel: +44 (0)1273 220 511

Fax: +44 (0)1273 731 498

Thank you for purchasing this Audio Note (UK)product. With the correct care it

should give you many years of pleasure and enjoyment.

Please take the time to read all of the information in this manual before connecting

your new component to an electrical supply or your system, to ensure both your

safety and satisfaction.

Please note that due to our desire to continually improve products, specifications are

subject to change without notice. Therefore it is important to refer to the manual that

is supplied with your product for the most accurate information; manuals downloaded

from our website or obtained from other sources may no longer fully apply to your

product.

If you have any questions regarding the information contained within this document

or your new component, please feel free to contact us: -

Audio Note (UK) Limited

25 Montefiore Road

Hove

East Sussex

BN3 1RD

United Kingdom

Tel: +44 (0)1273 220 511

Fax: +44 (0)1273 731 498

e-mail: [email protected]o.uk

INTRODUCTION

Congratulations on your purchase of the Audio Note (UK) VINDICATOR Silver

Signature stereo power amplifier.

It is a Pure Class A Singled Ended valve amplifier that uses the highly regarded 2A3

triode valve, producing a level of performance that is radically superior to the vast

majority of current designs.

It has been specifically engineered for sonic performance rather than technical

specification, and fulfills all Audio Note (UK) Level 3 criteria: -

Pure Class A operation

Zero Negative Feedback

Single Ended Output Stage

Valve Rectification

Directly Heated Triode operation

The Silver Signature version builds upon the already superb performance of the

standard VINDICATOR, and features the following additions: -

Audio Note (UK) Copper Foil signal capacitors

Cerafine capacitors in critical areas

Audio Note (UK) 2 Watt Tantalum film resistors

Audio Note (UK) SHiB Double C-core output transformers

Please take care when unpacking your VINDICATOR Silver Signature stereo power

amplifier. Choose a clean, clear location to unpack your unit. Be aware that the

amplifier is very heavy; before attempting to unpack or lift the unit, check the weight

and if necessary use more than one person so that it can be moved safely and

easily.

We recommend that you retain and carefully store all of the original packing

materials, in case transportation / shipping is required at a later date.

Select a suitable location for the unit. This should be a dry, dust free and level area,

preferably shielded from direct sunlight and free from vibration. Also ensure that the

location is stable and capable of carrying the weight of the unit.

A suitable mains power outlet must be close to the location; power cords must not be

pulled or stretched tightly in an attempt to reach a wall socket. If the power cord will

not easily reach the socket, choose a closer location!

Please ensure that adequate ventilation for the unit is provided, and that airflow

through any ventilation slots in the unit is not restricted. We recommend a distance of

at least 20cm free space is maintained above the unit, and preferably it should be

sited in free space or on the top shelf of your equipment rack or table. Please also

remember that valve equipment operates at extremely high temperatures, so a

position that is inaccessible to any children or animals is essential.

VINDICATOR SILVER SIGNATURE POWER AMPLIFIER

UNPACKING AND INSTALLATION

The amplifier is shipped without its valve compliment installed. It is necessary to

install the valves before operation.

It is essential that the valves are installed correctly or serious damage that is not

covered by the warranty will result. We recommend that your dealer perform

this procedure for you if you are in any way unsure.

FIRSTLY, ENSURE THAT THE AMPLIFIER IS NOT CONNECTED TO A MAINS

ELECTRICAL SUPPLY, AND THAT THE POWER CORD IS NOT CONNECTED TO

THE AMPLIFIER.

Now remove the valves that are packed inside the amplifier and carefully unwrap

them. Also inspect the amplifier to check that nothing has become damaged or

dislodged during transit.

2 x 2A3 output valves

1 x 6SL7GT input stage valve

1 x 5R4GY rectifier valve

Once again, please understand that it is absolutely vital these valves are fitted

correctly.

Looking from the front of the amplifier install the 2A3 valves first. Inspect a 2A3 valve

base and you will notice that two of the pins are larger than the other two; this is to

help ensure that the valve can only be inserted one way.

Now examine the two large apertures located in the top plate of the amplifier,

between the single front valve base aperture and the large, black, square transformer

cover; you will notice that two of the four holes in each aperture are larger than the

others. Line up the large pins on the base of the 2A3 valves and the large holes in

each valve base, and with gentle but firm pressure insert the valve into its socket.

Next, examine the single 6SL7GT input stage valve. You will see that there is a rib on

the central pin of the valve, which ensures that it can only be inserted into the valve

base correctly. Locate this rib and align with the corresponding aperture in the centre

of the valve base, located in the top plate at the front / centre of the amplifier. With

gentle but firm pressure,insert the valve.

Next, examine the remaining 5R4GY rectifier valve. You will see that there is a rib on

the central pin of the valve, which ensures that it can only be inserted into the valve

base correctly. Locate this rib and align with the corresponding aperture in the centre

of the valve base, located in the top plate towards the rear of the amplifier, between

the two large, black, square transformer covers. With gentle but firm pressure,insert

the valve.

Check one more time that all of the 4 valves are correctly fitted!

VALVE INSTALLATION

Line inputs Being a stereo power amplifier, the VINDICATOR Silver Signature is

fitted with one pair of single ended / RCA inputs. Looking from behind

the amplifier, they are located at the right hand side of the rear panel.

The Black socket (top) is for the Left channel, the Red socket (bottom)

is for the Right channel. Connect the output from your preamplifier to

these inputs.

Speakers Each channel is equipped with 3 colour coded binding posts for

connection to your speakers, located on the rear panel.

Looking from the rear of the amplifier, the 3 binding posts at the top

are for the left channel and the 3 binding posts at the bottom are for

the right channel.

Connect the amplifiers black speaker output binding post marked as

“0” to the black / negative terminal (also marked “ –“) on the speaker.

Connect the amplifiers red speaker output binding post marked “8

Ohm” to the red / positive terminal (also marked “ + “) on the speaker.

The other red speaker output binding post is marked “4 Ohm” and

may be used with 4 Ohm speakers. If you are uncertain whether your

speaker system is specified as 4 or 8 Ohm, try the following test once

all other connections are made and the amplifier is operational.

Compare the sound quality using a familiar recording with the

speakers connected to the 8 ohm connections and then the 4 Ohm

connections respectively. The selection that produces the best

frequency balance and maximum dynamics should be used.

Mains The VINDICATOR Silver Signature uses an IEC 320 mains inlet

socket. Use the supplied mains cable to connect the unit to the local

mains supply. The mains fuse and a spare are located in the inlet

socket fuse drawer.

Special Note –Make sure that all connectionsare tight and clean. For

best results use good quality audio interconnects. Although it is

perfectly acceptable to use cables manufactured by other companies,

for best results and performance, we recommend our own Audio Note

(UK) range of interconnects and loudspeaker cables. For further

information, please consult your nearest Audio Note (UK) dealer, or

alternatively please feel free to contact us directly.

CONNECTION

Once all the connections are completed and checked, ensure that the volume control

of your preamplifier / source is at the minimum setting.

Turn on all components in the signal chain BEFORE the VINDICATOR Silver

Signature; it should always be the LAST component to be switched ON, and the

FIRST to be switched OFF.

Turn on the amplifier by using the rocker switch located on the rear top right of the

back panel, just above mains inlet socket.

Bedding in The new amplifier requires about 200 hours of initial use (called

“bedding in”) before the circuitry becomes stable and optimum

performance is realized.

As the amplifier “beds in” the sound will become increasingly

smoother, detailed and open.

Once the amplifier has “bedded in” a warm up time of

approximately 30 to 45 minutes is required each time the

amplifier is switched on before optimum sonic performance is

reached.

Cleaning No special maintenance is required for the amplifier. Use a

soft, clean lint free cloth to remove any surface marks from the

casework. For finger marks / grease, use a soft, clean lint free

cloth, lightly moistened with a solution of warm water and mild

detergent. Do not use any alcohol or solvent based cleaning

products, as they may damage the finish of the amplifier.

ENSURE THAT THE AMPLIFIER IS SWITCHED OFF AND

DISCONNECTED FROM THE MAINS ELECTRICITY

SUPPLY BEFORE UNDERTAKING ANY CLEANING.

Valve Life The valves supplied with your amplifier should provide

approximately 6000 hours of operation. They are specially

selected by us, and should only be replaced with matched

pairs. Please consult your Audio Note (UK) dealer should your

valves need replacing.

OPERATION

TECHNICAL SPECIFICATIONS

INPUT IMPEDANCE

INPUT SENSITIVITY

MAXIMUM OUTPUT

CHANNEL BALANCE

VALVE COMPLIMENT

UNIT WEIGHT

SHIPPING WEIGHT

(ORIGINAL PACKAGING)

UNIT DIMENSIONS

SHIPPING DIMENSIONS

(ORIGINAL PACKAGING)

MAINS INPUT

MAINS FUSE

MAX. POWER

CONSUMPTION

NOTE

100k ohm, line level

250mV for full output

3.5 watts RMS per channel into 4 or 8

Ohm loads

+/-0.3dB

1 x 6SL7GT

2 x 2A3

1 x 5R4GY

20KG

30KG

195mm (h) x 205mm (w) x 500mm (d)

295mm (h) x 320mm (w) x 610mm (d)

AC 100-120V/220-240V 50/60 Hz

2A Anti Surge (110/120V Supply)

1.2A Anti Surge (200/240V Supply)

400mA (Internal HT)

270 VA

Due to Audio Note (UK)’s ongoing

research and development program,

specifications are subject to change

without notice.

Andere Audio Note Verstärker Handbücher

Audio Note

Audio Note I Zero Betriebsanleitung

Audio Note

Audio Note TOMEI Kensei Technisches Handbuch

Audio Note

Audio Note Shinri Bedienungsanleitung

Audio Note

Audio Note SORO Phono SE Technisches Handbuch

Audio Note

Audio Note M6 RIAA Technisches Handbuch

Audio Note

Audio Note L2 Line Preamplifier Bedienungsanleitung

Audio Note

Audio Note M3 Phono Technisches Handbuch

Audio Note

Audio Note SORO Phono Technisches Handbuch

Audio Note

Audio Note SORO Line SE Signature Technisches Handbuch

Audio Note

Audio Note M8 Line Signature Technisches Handbuch

Audio Note

Audio Note P3 Silver Technisches Handbuch

Audio Note

Audio Note M One Bedienungsanleitung

Audio Note

Audio Note M2 RIAA Technisches Handbuch

Audio Note

Audio Note JINRO Shochu Technisches Handbuch

Audio Note

Audio Note M2 RIAA Technisches Handbuch

Audio Note

Audio Note P-ZERO Bedienungsanleitung

Audio Note

Audio Note CONQUEST Low Gain Technisches Handbuch

Audio Note

Audio Note VINDICATOR Technisches Handbuch

Audio Note

Audio Note CONQUEROR Silver Signature Technisches Handbuch

Audio Note

Audio Note Conquest Technisches Handbuch

Audio Note

Audio Note M2 RIAA Technisches Handbuch

Audio Note

Audio Note JINRO Technisches Handbuch

Audio Note

Audio Note M2 Phono Balanced Technisches Handbuch

Audio Note

Audio Note PALADIN Silver Signature Technisches Handbuch

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
