Description

The ACM250P is a 250 watt power amplifier with outputs for 4 ohms, 70 and 100 v olt line. It may be desk or rack

mounted but is packaged as self standing with rubber feet. The ACM250P features a flat screwdriver accessible

gain control on the rear panel.

Inputs

The ACM 250P feat ures two signal inputs. The unit has industry standard 3 pin XLR microphone sockets. Two line lev el

sockets are provided for bridged in/out connection.

Outputs

The ACM250P features 100 volt , 70 v olt and 4 ohm isolated t ransformer out puts.

Protection

Internal current limit ing protects the amplifier from both ov erload and overdrive conditions. The ACM 250P also

features protection in the form of excess temperature auto cut out. An in built auto temperature sensing fan will

turn on at a factory default level but in most situations, will nev er be required.

Manufacture

The ACM 250P is proudly designed and manufactured in Australia.

ACM250P

250w PowerAmplifier

Architectural and Engineering Specifications

The 250 watt power amplifier shall be designed to run 100 v olt line audio syst ems. The unit shall also features a four

ohm output. The amplifier may be desk mounted as standard or rack mounted with the addition of an optional

rack mount kit.

The unit shall feature high temperature prot ection wit h front panel indication. An in built auto temperature sensing

fan shall cool the unit when required and automatically turn off again once the amplifier is running at the correct

temperature. The amplifier must be capable of deliv ering 250 watts into a fourty ohm inductiv e load with less than

0.5% dist ortion measured at 1kHz and with system hum and noise less than 74dB.

The amplifier shall be an Audio Telex model ACM 250P, manufactured in Australia.

Power Output

250 watt s RMS

Max imum Load

40 Ohms @ 100 Volts

Power Bandwidth

60Hz-15kHz< O.5% THD

Frequency Response

60Hz-15kHz (+/- 3dB)

Total Harmonic Distortion

0.5% @ 1 KHz rated power

Signal To Nois e Ratio

-80dB

Input Sensitivity

700mv

Outputs

100v

70v

4 ohm

ACM250P Specifications

Controls

One gain control on rear of the unit v ia flat head

screwdriver control.

Indicators

Power "on" and Protect LED

Power Source

AC 240v-60Hz, 110v-50Hz (special) 3 pin IEC connector

Power consumption

400 watt s.

Protection

Current Limiter protection, plus AC and DC fuses

Dimensions / Weight

88mm H x 480mm W x 330mm D (Chassis Dimensions

only), 15kg

Rack Mounting

Optional ACMRK Rack mount kit

Audio Telex Communicati ons Pty Ltd

www.audi otel ex.com.au

Sydney

(

)

9647 1411, Melbourne

(

)

9890 7477, Brisbane

(

)

3852 1312, Perth

(

)

9228 4222

Auckland

(

)

415 9426, Adelaide

(

)

8352 4444, Hobart

(

)

6228 6373

A.C.N:001 345 482
