1. Before Installing

Ensure that you have received the following items:

9AudioCodes’ MP-252 Multimedia Home Gateway

91 x RJ-11 telephone cable

91 x RJ-45 Ethernet cable

912V AC/DC power adaptor (use only supplied)

You’ll also need (not supplied by AudioCodes) the following:

9A broadband Internet connection

9ADSL cable (if required)

9Analog telephones

9An additional RJ-11 telephone cable (if required)

9Additional RJ-45 Ethernet cables (if required)

2. Cabling

1. Connect MP-252-BW to the Internet by cabling the ADSL port to

the telephone socket, using an RJ-11 telephone cable.

Wi-Fi

Power

110/220 VAC

LAN

Computers

POTS Phone

LAN

ADSL

2. Connect the MP-252-BW 10/100Base-T Ethernet ports labeled LAN

(1to 4) to your LAN computers, using CAT 5 Ethernet cables.

3. Connect the MP-252-BW FXS telephone ports labeled Phone (1to

2) to analog telephones, using RJ-11 telephone cables.

4. Connect MP-252-BW to a standard 110/220 VAC electrical wall

outlet using the supplied AC/DC power adapter; the MP-252-BW

Status LED turns on and when initialization completes (~ 2 min.),

the Status LED changes from red to green. If MP-252-BW is off,

press the Power button located on the rear panel to switch it on.

Before connecting MP-252-BW to power, ensure that the VAC

ratings match, and that you have read the Compliance and

Regulatory Information at www.audiocodes.com/library.

For wall mounting MP-252, refer to the supplied documentation.

3. Configuring Network Parameters

To initially authenticate your MP-252-BW Wi-Fi network, open a

Web browser and then log in with the case-sensitive, default

username (“admin”) and password (“admin”).

1. Verify that your PC’s LAN status displays “Connected” in the ‘Local

Area Connection Status’ window (Start menu > Settings > Network

Connections > Local Area Connection).

2. If the LAN status displays “Disconnected”, click Properties, select

‘Internet Protocol (TCP/IP)’, and then click Properties. Ensure that

the option ‘Obtain an IP address automatically’ is selected.

3. Open your Web browser, and then enter the following URL address:

http://mp252.home.

The MP-252-BW embedded Web server’s ‘Welcome’ screen is

displayed. Click OK, and then define a new login password.

4. In the ‘Quick Setup’ page, choose the Internet connection method.

Consult with your ISP for the required connection type, and then

click OK. The Network map displays devices connected to MP-252-

BW. Your PC is now connected to the Internet and you can now

configure VoIP parameters.

If there is no Internet connection, MP-252-BW Web server’s Map

View page (Home) displays a red icon after the globe icon.

Consult your ISP for valid connection parameters.

4. Configuring VoIP Parameters

Before you can make VoIP calls, you need to register with an ISP

and obtain account and SIP Proxy server information.

1. From the menu bar in the left pane, click Voice Over IP; the ‘Voice

Over IP’ page appears in the right pane.

2. Click the Line Settings tab, select check boxes only of lines that are

connected to telephones (clear those not connected), and click Apply.

3. Click the Edit icon corresponding to your FXS telephone lines, and

then in the ‘Line Settings’ page, configure the parameters with values

provided by your ISP.

4. Click the Signaling Protocol tab, and then select the check box ‘Use

SIP Proxy’. In the field ‘Proxy IP Address or Host Name’, enter the

ISP’s Proxy server’s IP address or host name, as provided by your

ISP. Click OK to complete the VoIP configuration.

To verify successful registration to the Proxy server, ensure that

the Phone LED is lit green, or in the Voice over IP tab (System

Monitoring menu), the entry ‘SIP Registration’ displays

“Registered” for the configured FXS lines.

5. Pick up the phone receiver and listen for a dial tone; you’re now ready

to make an outgoing VoIP call.

Notice

This guide describes the installation of AudioCodes’ MediaPack™ 252

(MP-252) Multimedia Home Gateway.

Information contained in this document is believed to be accurate and reliable at the

time of printing. However, due to ongoing product improvements and revisions,

AudioCodes cannot guarantee accuracy of printed material after the Date Published

nor can it accept responsibility for errors or omissions. This document is subject to

change without notice. Refer to the current Release Notes that may be included with

your documentation or hardware delivery. Updates to this document as well as

software files can be viewed by registered customers at

www.audiocodes.com/downloads.

Date Published: January-13-2011

www.audiocodes.com

AudioCodes CPE & Access Gateway Products

MP-252 Multimedia Home Gateway

Quick Guide

MP-252 Multimedia Home Gateway

LTRT-18603
