Auriol Z30237B Bedienungsanleitung

RADIO-CONTROLLED LCD CLOCK

Operation and Safety Notes

RADIOSTYRD LCD-KLOCKA

Bruksanvisning och säkerhetsanvisningar

RADIO-OHJATTU LCD-KELLO

Käyttö- ja turvallisuusohjeet

LCD-RADIOUR

Betjenings- og sikkerhetshenvisninger

LCD-FUNKUHR

Bedienungs- und Sicherheitshinweise

Z30237B

Z30237C

GB/IE Operation and Safety Notes Page 5

FI Käyttö- ja turvaohjeet Sivu 12

SE Bruksanvisning och säkerhetsanvisningar Sidan 19

DK Brugs- og sikkerhedsanvisninger Side 26

DE/AT / CH Bedienungs- und Sicherheitshinweise Seite 33

1 3

91011

Z30237B

202122232425

Z30237C

1 3

1011

202122232425

5GB/IE

Table of Contents

Introduction

Proper Use........................................................................................................................................Page 6

Description of Parts ..........................................................................................................................Page 6

Technical data..................................................................................................................................Page 6

Safety

General Safety Information.............................................................................................................Page 6

Safety Instructions for Batteries .......................................................................................................Page 7

Before Initial Use

Setting up Devices............................................................................................................................Page 7

Installing the LCD radio-controlled clock........................................................................................Page 8

Inserting or replacing batteries........................................................................................................Page 8

Operation

Reception of DCF radio signal........................................................................................................Page 8

Setting the year/month/date/time/day of the week................................................................Page 9

Setting the day of the week display................................................................................................Page 9

Using the 12/24-hour display.......................................................................................................Page 9

Setting the alarm..............................................................................................................................Page 9

Activating/deactivating the alarm .................................................................................................Page 9

Switching off the alarm signal.........................................................................................................Page 10

Displaying the temperature in °C/°F............................................................................................Page 10

Moon phase (Model B only) ..........................................................................................................Page 10

Displaying summertime....................................................................................................................Page 10

Setting the time zone .......................................................................................................................Page 10

Troubleshooting .....................................................................................................................Page 10

Cleaning and Maintenance...........................................................................................Page 10

Service............................................................................................................................................Page 11

Disposal.........................................................................................................................................Page 11

Declaration of Conformity.............................................................................................Page 11

6 GB/IE

Introduction/Safety

Radio-Controlled LCD Clock

Introduction

Use the product only as described and

for the indicated purpose.

Proper Use

The clock is only suitable for operation in enclosed

spaces at normal room temperature. The device is

not intended for commercial use.

Description of Parts

1Time display

2Radio symbol

3Battery symbol

4Summer time symbol

5Time zone symbol

6Calender week (Model B only)

7Indoor air temperature

8Moon phase (Model B only)

9Year display (Model B only)

10 Month display

11 Date display

12 Day of the week display

13 PM symbol (afternoon)

14 AM symbol (morning)

15 Alarm 1 symbol

16 Alarm 2 symbol

17 Hanger

18 Battery compartment cover

19 Battery compartment

20 SNOOZE button

21 WAVE button

22 DOWN button

23 UP button

24 ALARM button

25 SET button

26 Folding stand

Technical data

Battery type: 2x 1.5 V , AAA (supplied)

Safety

WARNING! Please read all safety information

and instructions. Failure to comply with the safety

information and instructions may result in, ﬁre and/or

severe injuries.

KEEP ALL THE SAFETY ADVICE AND INSTRUC-

TIONS IN A SAFE PLACE FOR FUTURE REFERENCE!

General Safety

Information

WARNING! DANGER TO

LIFE AND ACCIDENT HAZARD

FOR TODDLERS AND

SMALL

CHILDREN! Never allow children

to play un-

supervised with the packaging material. There

is a danger of suﬀocation from the packaging

material. Children frequently underestimate the

dangers. Children should be kept away from

the product at all times. This is not a toy.

Children or persons who lack the knowledge

or experience to use the device or whose

physical, sensory or intellectual capacities are

limited must never be allowed to use the device

without supervision or instruction by a person

responsible for their safety. Children must never

be allowed to play with the device.

Do not use the device if it is damaged. Damaged

devices represent a danger of death!

WARNING! Do not use the device in hospitals

or medical facilities, as otherwise this may result

in malfunctions of life-support systems.

Please prevent the housing of the device from

rubbing to strongly against textiles. This may

result in static charges and aﬀect the results of

the measurements.

Please note that the guarantee does not cover

damage caused by incorrect handling, non-com-

7GB/IE

pliance with the operating instructions or interfer-

ence with the device by unauthorised individuals.

Under no circumstances should you take the

device apart. Improper repairs may place the

user in considerable danger. Repairs should

only be carried out by specialist personnel.

Safety Instructions

for Batteries

WARNING! DANGER TO LIFE! Batteries

can be swallowed, which may represent a

danger to life. If a battery has been swallowed,

medical help is required immediately.

Remove the batteries from the device if they

have not been used for a long period.



CAUTION! DANGER OF EXPLO-

SION! The batteries must never be

recharged!

CAUTION! RISK OF EXPLO-

SION! Use batteries of the indicated

type only. Otherwise there is a risk

of an explosion.

When inserting the batteries, ensure the correct

polarity!

If necessary clean the contacts on the batteries

and on the device itself before inserting them.

Remove exhausted batteries from the device

immediately. Otherwise the batteries are more

likely to leak.

If you disregard the above instructions and

advice, your batteries may discharge beyond

their minimum voltage, thus increasing the

chance of leakage. If the batteries in your

device leak, remove them immediately to

prevent the device from being damaged.

Keep batteries away from children; do not

throw batteries in the ﬁre, short-circuit batteries

or take them apart.

Avoid contact with the skin, eyes and mucous

membranes. Any parts of the body coming into

contact with battery acid should be rinsed oﬀ

with copious amounts of water and/or a doctor

contacted if necessary!

Dispose of batteries in accordance with the

disposal instructions.

Before Initial Use

Unscrew the transport securing device on the

back of the box in order to remove the device.

Remove the protective foil before ﬁrst use.

Setting up Devices

CAUTION! When selecting a location to set

up the device, please ensure that it is not exposed

to any direct sunlight, vibrations, dust, heat, cold or

moisture. Do not place the device close to sources of

heat, e.g. radiators. Otherwise it may be damaged.

Make sure that the device is standing safely on

a stable surface.

Make sure that the device is mounted properly

if installed on a wall. A falling clock could injure

people

or cause damage to the device itself or

to other objects.

Stand the radio-controlled clock on its base 26

or mount it on the wall.

Place the clock on a level, horizontal surface.

Do not stand the device on valuable or sensitive

surfaces without suitable protection. The surface

may otherwise be damaged.

Do not place the device anywhere near to sources

of interference such as televisions, computers,

thick walls, etc. These may hinder reception of

the radio signal.

Do not use the clock in reinforced concrete

buildings, e. g. airports, high-rises, factories or

basements. This can seriously disrupt reception

of the radio signal.

Do not start radio reception in a moving vehicle,

e. g. car or train. Reception of the radio signal

by the device can disrupt the vehicle electronics.

Do not expose the clock to temperatures below

--10°C for any length of time. This can seriously

aﬀect the reception range of the device.

Safety/Before Initial Use

8 GB/IE

Installing the LCD

radio-controlled clock

Note: You will need a drill, suitable assembly

material and a screwdriver for installation.

CAUTION! DANGER TO LIFE AND RISK

OF INJURY; RISK OF DAMAGE TO PROP-

ERTY! Please read the operating and safety instruc-

tions for your drill carefully.

WARNING! DANGER TO LIFE! Please

ensure that you do not drill into any electrical wiring,

gas or water pipes in the wall. If necessary, carry out

checks with a wire, pipe and stud detector before

you drill into a wall.

Find a suitable place to install the radio-controlled

clock.

Mark the drill hole on the wall.

CAUTION! DANGER OF INJURY! Refer to

the operating instructions for your electric drill.

Drill the hole with a drill.



Insert a suitable dowel into the drill hole.

Use a screwdriver to insert a suitable screw.

Hang the radio-controlled clock on the screw

using the mount 17 .

Inserting or replacing batteries

The battery symbol

appears in the LC dis-

play if the batteries are too weak. Make sure you

replace the batteries at the earliest opportunity.

The radio-controlled LCD wall clock starts to receive

the radio time signal as soon as the batteries are

inserted.

Note: Do not alter the position of the radio-controlled

clock during reception of the signal. This may disrupt

reception.

Radio time signal (DCF):

The DCF signal (time signal transmission) consists

of time pulses broadcast from one of the most accu-

rate clocks in the world. It is situated near Frankfurt/

Main, Germany.

Your radio-controlled clock receives these signals

under ideal conditions up to a distance of approx.

1,500 km around Frankfurt/Main. Reception of the

radio signal generally takes approx. 3–10 minutes.

If it does not work properly, restart the radio-

controlled clock. To do this, keep the WAVE

button 21 pressed for approx. 3 seconds.

Reception can be considerably impaired by obstacles

(e.g. concrete walls) or sources of interference (e.g.

other electrical devices). If necessary, change the

location of the radio clock (e.g. by putting it near a

window) if you have problems with reception.

Operation

Reception of DCF radio signal

The radio-controlled clock automatically starts to

search for the DCF radio signal. The radio icon 2

on the LCD indicates that the clock is searching for the

radio signal.

Note: Reception of the radio signal may be seriously

disrupted in reinforced concrete buildings (see “Set-

ting up Devices”).

It is also possible to start reception of the DCF radio

signal manually on the clock.

Press and keep pressed the WAVE button 21

for longer than 3 seconds. The LCD radio-con-

trolled wall clock attempts to receive the DCF

radio time signal. This process takes several

minutes and is indicated in the LC display by a

ﬂashing radio symbol 2.

Note: If the radio-controlled clock cannot pick up

the DCF radio signal on account of an error or the

distance from the transmitter, etc., it is also possible

to set the time manually. As soon as reception of

the DCF signal is successful, the manual settings

are overwritten.

Before Initial Use/Operation

9GB/IE

Setting the year/month/

date/time/day of the week

1. Press and keep pressed the WAVE button 21 for

approx. 3 seconds. The radio symbol 2

ﬂashes.

2. Press and keep pressed the WAVE button 21

again for approx. 3seconds to stop the recep-

tion of the radio time signal.

3. Press and keep pressed the SET button 25 for

approx. 2 seconds. The year display ﬂashes.

Set the desired value by pressing the UP 23 or

DOWN button 22 .

Tip: By keeping the UP 23 or DOWN button 22

pressed you can accelerate the setting process

and reach the desired value more quickly. This

quicker method can also be used for making

the other settings. If during a period of 15sec-

onds no buttons are pressed, the LC display

returns automatically to the default display.

4. Conﬁrm your settings by pressing the SET but-

ton 25 . The month display ﬂashes.

5. Repeat steps 3 and 4 to set the values for day,

hour, minute and day of the week.

Setting the day of the week

display

The day of the week 12 can be displayed in various

languages.

Press the DOWN button 22 and keep it pressed.

In the day of the week display 12 , the abbrevi-

ation for the current language appears. Release

the DOWN button 22 when the abbreviation

for your chosen language appears.

The following languages are available:

GER = German

FRE = French

SPA = Spanish

ITA = Italian

DAN = Danish

DUT = Dutch

ENG = English

Using the 12/24-hour display

While time display 1is indicated press the

UP button 23 to switch between 12- hour and

24-hour format.

Note: The AM icon 14 on the LCD stands for

mornings in 12-hour format. The PM icon 13

on the LCD stands for afternoons in 12-hour

format.

Setting the alarm

Press the SET button 25 once or twice to select

alarm 1 15 or alarm 2 16 .

Press and keep pressed the SET button 25 for

about 2seconds. The hour display ﬂashes.

Press the UP 23 or DOWN button 22 to set

the desired value.

Press the SET button 25 to conﬁrm your setting.

The minute display ﬂashes.

Press the UP 23 or DOWN button 22 to set

the desired minute value.

Press the SET button 25 to conﬁrm your setting.

Press the SNOOZE button 20 as soon as the

alarm signal sounds. The alarm signal stops

sounding. The alarm will sound again 5minutes

after the set waking time or alarm time.

Press any button except the SNOOZE button 20

to stop the alarm signal sounding.

Activating/deactivating the

alarm

Press the ALARM button 24 brieﬂy. The appro-

priate alarm symbol 15 or 16 is dis-

played to indicate that the alarm is activated.

Pressing the ALARM button 24 again causes

the appropriate alarm symbol 15 or 16

to cease to be displayed. The alarm is deacti-

vated.

Operation

10 GB/IE

Switching oﬀ the alarm signal

Press any button except the SNOOZE button 20

to stop the alarm signal sounding. You do not

have to reactivate the alarm. It reactivates itself

automatically according to the weekly rhythm.

Note: The alarm signal switches itself oﬀ after

2minutes.

Displaying the temperature

in °C/°F

The current inside temperature 7is indicated on

the LCD.

Press the DOWN button 22 to switch between

the Celsius and Fahrenheit temperature scales 7.

Moon phase (Model B only)

The LCD radio-controlled wall clock shows the current

moon phase 8in the LC display (Model B only).

It uses the following symbols:

Full moon Waning

gibbous

Last quarter Waning

crescent

New moon Waxing

crescent

First quarter Waxing

gibbous

Displaying summertime

Summertime is automatically indicated on the LCD

by the summertime icon 4. The clock receives

the information as to whether it is summertime or not

from the DCF radio signal.

Note: Reception of the radio signal may be seriously

disrupted in reinforced concrete buildings.

Setting the time zone

Press and keep pressed the DOWN button 22 for

about 2seconds. The time zone symbol 5

is displayed.

Press and keep pressed the SET button 25 for

about 3seconds. The hour display ﬂashes.

Press the UP 23 or DOWN button 22 to set

the desired hour value.

Press the SET button 25 to conﬁrm your setting.

Note: Press and keep pressed the DOWN button 22

for about 2seconds to deactivate the time zone

function.

Troubleshooting

This appliance has delicate electronic compo-

nents. This means that if it is placed near an

object that transmits radio signals, it could cause

interference. This could be, for example, mobile

telephones, walkie talkies, CB radios, remote

controls and microwaves. If the display indicates

a problem, move such objects away from it.

Electrostatic discharges may cause malfunctions.

In the event of such malfunctions, remove the

batteries brieﬂy and reinsert them.

Cleaning and Maintenance

Under no circumstances should you use liquids

or detergents, as these will damage the device.

The device should only be cleaned on the out-

side with a soft dry cloth.

Operation/Troubleshooting/Cleaning and Maintenance

Andere Handbücher für Z30237B

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Auriol Uhr Handbücher

Auriol

Auriol Z29955A Bedienungsanleitung

Auriol

Auriol 4-LD4828 Stücklistenhandbuch

Auriol

Auriol 4-LD4467 Stücklistenhandbuch

Auriol

Auriol 337035 2001 Bedienungsanleitung

Auriol

Auriol 4-LD6283-1-2 Stücklistenhandbuch

Auriol

Auriol Z31957A Bedienungsanleitung

Auriol

Auriol 283736 Bedienungsanleitung

Auriol

Auriol 4-LD4727 Stücklistenhandbuch

Auriol

Auriol 303355 Bedienungsanleitung

Auriol

Auriol Z30237B Bedienungsanleitung

Auriol

Auriol z31163 Bedienungsanleitung

Auriol

Auriol 104007-14-01 Bedienungsanleitung

Auriol

Auriol Z30300A Bedienungsanleitung

Auriol

Auriol 405669 2201 Bedienungsanleitung

Auriol

Auriol 366317 2101 Bedienungsanleitung

Auriol

Auriol z31163 Bedienungsanleitung

Auriol

Auriol HG00161A Bedienungsanleitung

Auriol

Auriol Z29955A Bedienungsanleitung

Auriol

Auriol 4-LD4246 Stücklistenhandbuch

Auriol

Auriol Z30312A Bedienungsanleitung

Auriol

Auriol 93858 Stücklistenhandbuch

Auriol

Auriol HG09063 Bedienungsanleitung

Auriol

Auriol HG06169A Bedienungsanleitung

Auriol

Auriol Z29955A Bedienungsanleitung

Beliebte Uhr Handbücher anderer Marken

Silicon Laboratories

Silicon Laboratories SI5324 Bedienungsanleitung

Heathkit

Heathkit GC-1005 Bedienungsanleitung

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Bedienungsanleitung

Andrew O'Malley

Andrew O'Malley DOTKLOK Bedienungsanleitung

ALGE-Timing

ALGE-Timing ASC3 Bedienungsanleitung

Bodet

Bodet Profil 960 Bedienungsanleitung

Nixie Clock

Nixie Clock Divergence Meter Bedienungsanleitung

La Crosse Technology

La Crosse Technology WS-8256-AL Bedienungsanleitung

Mini Gadgets

Mini Gadgets MCPro Bedienungsanleitung

Casio

Casio TMR-200 Bedienungsanleitung

Progetti

Progetti ILTEMPOSTRINGE Handbuch

BVItech

BVItech BV-101 Bedienungsanleitung

Progetti

Progetti KALIMERO Handbuch

La Crosse Technology

La Crosse Technology WT-3141b Handbuch

La Crosse Technology

La Crosse Technology W86531 Bedienungsanleitung

Sharp

Sharp SPC900 Bedienungsanleitung

La Crosse Technology

La Crosse Technology 404-50447 Bedienungsanleitung

Datexx

Datexx DF0063 Bedienungsanleitung
