Autodesk AUTOCAD MECHANICAL Bedienungsanleitung

Power tools for mechanical design.

AutoCAD®

Mechanical

Facing these issues?

• Productivityislimitedbysoftwarethat

is not built speciﬁcally for mechanical

design.

• Frequentdesignchangesarecreating

hours of manual rework.

• Designerrorsandincorrectbillsof

materials (BOMs) and parts lists are

keeping products from shipping on time.

• Updatingexistingdrawingsiscostingyour

company valuable time.

• Inconsistentuseofdraftingstandardsis

slowing down shop-ﬂoor production.

• Inabilitytondandreusedesignsis

forcing your teams to create too many

drawings from scratch.

Discover why so many designers

and drafters are switching to

AutoCAD Mechanical.

The AutoCAD Mechanical Advantage

The Standard in 2D Mechanical Design

With comprehensive libraries of standards-based

parts, and tools for automating common design

tasks, AutoCAD®Mechanical software acceler-

ates the mechanical design process. AutoCAD

Mechanical provides innovative design and drafting

tools that are wholly focused on ease of use for the

AutoCAD user. Keeping the AutoCAD user experi-

ence intact enables designers to maintain their

existing workﬂows while adopting the enhanced

functionality of AutoCAD Mechanical at their own

pace. Designers gain a competitive edge by saving

countless hours of design and rework, so they can

spend time innovating rather than managing work-

ﬂow issues.

To compete and win in today’s design marketplace, engineers

need to create and revise mechanical drawings faster than

ever before. AutoCAD®Mechanical is AutoCAD®software for

manufacturing, oering signiﬁcant productivity gains over

standard AutoCAD®by simplifying complex mechanical design

work.

Maximize Your Productivity

Creating mechanical designs often requires spend-

ing valuable time on manual workarounds to get the

job done. Since AutoCAD Mechanical provides a

simpliﬁed drafting environment for manufacturing

and automates many manual tasks, it improves the

design experience and oers immediate eciency

gains. AutoCAD Mechanical delivers high-impact

productivity tools to AutoCAD users who are

performing updates and iterative design changes,

reducing the amount of rework associated with

these tasks. In addition, powerful dimensioning

tools make adding, deleting, and editing dimen-

sions fast and easy. Built to save you time, AutoCAD

Mechanical has a speciﬁc tool for almost every

aspect of the mechanical drafting process.

Image courtesy of Thysen-Krupp Corporation

Reduce Errors and Inconsistencies

When creating mechanical drawings, designers

can sometimes inadvertently introduce errors

and design inconsistencies, wasting time and

money. AutoCAD Mechanical includes libraries of

more than 700,000 standard parts and supports

international drafting standards, enabling users to

consistently meet design requirements in the global

marketplace. AutoCAD Mechanical also enables

detailers to document native Autodesk®Inventor®

models in the familiar AutoCAD drafting environ-

ment. This associative workﬂow automatically

synchronizes drawings with the D model, which

reduces errors and inconsistencies and saves hours

of rework. Clear and consistent communication in

the design and documentation process helps team

members avoid delays and errors on the shop ﬂoor,

so your company can stay ahead of the competition.

Manage Design Data More Eectively

Once a design is complete, it is important to share

accurate design and part information with the teams

responsible for ordering and manufacturing the

product. Using software that is not purpose-built for

these tasks often means creating crucial parts lists

and BOMs by hand. With manual methods, even the

smallest design change can introduce errors, result-

ing in delivery delays to the customer.

To help your company prevent errors and costly de-

lays, AutoCAD Mechanical is tightly integrated with

Autodesk Data Management applications, enabling

the ecient and secure exchange of design data and

promoting earlier collaboration between design and

manufacturing workgroups. Dierent workgroups

can manage and track all components of a digital

prototype with free* Autodesk®Design Review

software—the all-digital way to review, measure,

mark up, and track changes to designs—allowing

for better reuse of crucial design data, management

of BOMs, and collaboration with other teams and

partners.

Now Is the Time

Want to get unparalleled productivity from your D

mechanical design process? Now is the time to make

the move to AutoCAD Mechanical.

Image courtesy of

Parker Hanniﬁn Corporation

Top 10 Reasons

to Move from AutoCAD

to AutoCAD Mechanical

1. , Standard Parts

and Features

2. Extended Draw Toolbar

for Manufacturing

3. Powerful and Smart

Dimensions

. Reusable Detailing Tools

. Support for International

Drafting Standards

. Associative Balloons and

BOMs

. Layer Management

. Hidden Lines

. Machinery Generators and

Calculators

. Data Exchange Between

CAD Systems

Visit www.autodesk.com/

autocadmechanical-productivity

for more details.

Digital Prototyping for the Manufacturing Market

Autodesk is a world-leading supplier of engineering software,

providing companies with tools to help them experience their

ideas before they are real. By putting powerful Digital Prototyping

technology within the reach of mainstream manufacturers,

Autodesk is changing the way manufacturers think about their

design processes and is helping them create more productive

workﬂows. The Autodesk approach to Digital Prototyping is

unique in that it is scalable, attainable, and cost-eective, which

allows a broader group of manufacturers to realize the beneﬁts

with minimal disruption to existing workﬂows, and provides the

most straightforward path to creating and maintaining a single

digital model in a multidisciplinary engineering environment.

Learn More or Purchase

Access specialists worldwide who can provide product expertise, a deep

understanding of your industry, and value that extends beyond your software

purchase. To purchase AutoCAD Mechanical, contact an Autodesk Premier

Solutions Provider or Autodesk Authorized Reseller. Locate a reseller near you

at visit www.autodesk.com/reseller.

Autodesk Learning and Education

From instructor-led or self-paced classes to online training or education

resources, Autodesk oers learning solutions to ﬁt your needs. Get expert

guidance at an Autodesk Authorized Training Center (ATC®) site, access learning

tools online or at your local bookstore, and validate your experience with

Autodesk certiﬁcations. Learn more at www.autodesk.com/learning.

Autodesk Services and Support

Accelerate return on investment and optimize productivity with innovative

purchase methods, companion products, consulting services, and support from

Autodesk and Autodesk authorized partners. Designed to get you up to speed

and keep you ahead of the competition, these tools help you make the most

of your software purchase—no matter what industry you are in. Learn more at

www.autodesk.com/servicesandsupport.

Autodesk Subscription

Get the beneﬁts of increased productivity, predictable budgeting, and simpliﬁed

license management with Autodesk®Subscription. You get any new upgrades

of your Autodesk software and any incremental product enhancements, if

these are released during your Subscription term. In addition, you get exclusive

license terms available only to Subscription members. A range of community

resources, including web support direct from Autodesk technical experts,

self-paced training, and e-Learning, help extend your skills and make Autodesk

Subscription the best way to optimize your investment. Learn more at www.

autodesk.com/subscription.

*Free products are subject to the terms and conditions of the end-user license agreement that accompanies

download of this software.

Cover image courtesy of Prensa Jundiai, Brasil

Autodesk, AutoCAD, Autodesk Inventor, and Inventor are registered trademarks or trademarks of Autodesk,

Inc., and/or its subsidiaries and/or aliates in the USA and/or other countries. All other brand names, product

names, or trademarks belong to their respective holders. Autodesk reserves the right to alter product oerings

and speciﬁcations at any time without notice, and is not responsible for typographical or graphical errors that

may appear in this document.
