AutoCAD 2010

Stand-Alone Installation

Guide

January 2009

reproduced in any form, by any method, for any purpose.

Certain materials included in this publication are reprinted with the permission of the copyright holder.

Trademarks

The following are registered trademarks or trademarks of Autodesk, Inc., in the USA and other countries: 3DEC (design/logo), 3December,

3December.com, 3ds Max, ADI, Alias, Alias (swirl design/logo), AliasStudio, Alias|Wavefront (design/logo), ATC, AUGI, AutoCAD, AutoCAD

Learning Assistance, AutoCAD LT, AutoCAD Simulator, AutoCAD SQL Extension, AutoCAD SQL Interface, Autodesk, Autodesk Envision, Autodesk

Insight, Autodesk Intent, Autodesk Inventor, Autodesk Map, Autodesk MapGuide, Autodesk Streamline, AutoLISP, AutoSnap, AutoSketch,

AutoTrack, Backdraft, Built with ObjectARX (logo), Burn, Buzzsaw, CAiCE, Can You Imagine, Character Studio, Cinestream, Civil 3D, Cleaner,

Cleaner Central, ClearScale, Colour Warper, Combustion, Communication Specification, Constructware, Content Explorer, Create>what's>Next>

(design/logo), Dancing Baby (image), DesignCenter, Design Doctor, Designer's Toolkit, DesignKids, DesignProf, DesignServer, DesignStudio,

Design|Studio (design/logo), Design Web Format, Discreet, DWF, DWG, DWG (logo), DWG Extreme, DWG TrueConvert, DWG TrueView, DXF,

Ecotect, Exposure, Extending the Design Team, Face Robot, FBX, Filmbox, Fire, Flame, Flint, FMDesktop, Freewheel, Frost, GDX Driver, Gmax,

Green Building Studio, Heads-up Design, Heidi, HumanIK, IDEA Server, i-drop, ImageModeler, iMOUT, Incinerator, Inferno, Inventor, Inventor

LT, Kaydara, Kaydara (design/logo), Kynapse, Kynogon, LandXplorer, LocationLogic, Lustre, Matchmover, Maya, Mechanical Desktop, Moonbox,

MotionBuilder, Movimento, Mudbox, NavisWorks, ObjectARX, ObjectDBX, Open Reality, Opticore, Opticore Opus, PolarSnap, PortfolioWall,

Powered with Autodesk Technology, Productstream, ProjectPoint, ProMaterials, RasterDWG, Reactor, RealDWG, Real-time Roto, REALVIZ,

Recognize, Render Queue, Retimer,Reveal, Revit, Showcase, ShowMotion, SketchBook, Smoke, Softimage, Softimage|XSI (design/logo),

SteeringWheels, Stitcher, Stone, StudioTools, Topobase, Toxik, TrustedDWG, ViewCube, Visual, Visual Construction, Visual Drainage, Visual

Landscape, Visual Survey, Visual Toolbox, Visual LISP, Voice Reality, Volo, Vtour, Wire, Wiretap, WiretapCentral, XSI, and XSI (design/logo).

The following are registered trademarks or trademarks of Autodesk Canada Co. in the USA and/or Canada and other countries:

Backburner,Multi-Master Editing, River, and Sparks.

The following are registered trademarks or trademarks of MoldflowCorp. in the USA and/or other countries: Moldflow, MPA, MPA

(design/logo),Moldflow Plastics Advisers, MPI, MPI (design/logo), Moldflow Plastics Insight,MPX, MPX (design/logo), Moldflow Plastics Xpert.

All other brand names, product names or trademarks belong to their respective holders.

Disclaimer

THIS PUBLICATION AND THE INFORMATION CONTAINED HEREIN IS MADE AVAILABLE BY AUTODESK, INC. "AS IS." AUTODESK, INC. DISCLAIMS

ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE REGARDING THESE MATERIALS.

Published by:

Autodesk, Inc.

111 Mclnnis Parkway

San Rafael, CA 94903, USA

Contents

Chapter 1 Quick Start to Stand-Alone Installation . . . . . . . . . . . . . . 1

Preparing for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 2

Understanding Administrative Permission Requirements . . . . . . 5

Locating Your Serial Number and Product Key . . . . . . . . . . . 6

Avoiding Data Loss During Installation . . . . . . . . . . . . . . . 7

Choosing a Language . . . . . . . . . . . . . . . . . . . . . . . . . 7

Configure Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Migrating Custom Settings . . . . . . . . . . . . . . . . . . . . . . 9

Installing Multiple or Bundled Products . . . . . . . . . . . . . . . 9

Installing and Running the Product . . . . . . . . . . . . . . . . . . . . 9

Installing AutoCAD . . . . . . . . . . . . . . . . . . . . . . . . . 10

Launch AutoCAD . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Add or Remove Features . . . . . . . . . . . . . . . . . . . . . . . 19

Reinstall or Repair AutoCAD . . . . . . . . . . . . . . . . . . . . 21

Uninstall AutoCAD . . . . . . . . . . . . . . . . . . . . . . . . . 22

Installing Design Review . . . . . . . . . . . . . . . . . . . . . . 22

Chapter 2 Migrating and Customizing . . . . . . . . . . . . . . . . . . . . 25

Migrate Custom Settings and Files from Previous Releases . . . . . . . . 25

Migrate Custom Settings . . . . . . . . . . . . . . . . . . . . . . 26

View the Migration Log File . . . . . . . . . . . . . . . . . 30

iii

Restore Profiles After Migrating Files from an Earlier

Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Use Migration Tools . . . . . . . . . . . . . . . . . . . . . . . . . 31

Customize AutoCAD with Initial Setup . . . . . . . . . . . . . . . . . . 32

Export and Import Custom Settings from the Same Release . . . . . . . 35

Export Custom Settings . . . . . . . . . . . . . . . . . . . . . . . 38

Import Custom Settings . . . . . . . . . . . . . . . . . . . . . . . 39

Migrating and Customizing Issues . . . . . . . . . . . . . . . . . . . . 40

What are the benefits of identifying my industry? . . . . . . . . . 41

How is this information being used? . . . . . . . . . . . . . . . . 41

What happens if I skip or cancel Initial Setup? . . . . . . . . . . . 41

What are the benefits of selecting task-based tools? . . . . . . . . 42

What is a workspace? . . . . . . . . . . . . . . . . . . . . . . . . 42

How do I make changes to a workspace at a later time? . . . . . . 42

What is a drawing template file? . . . . . . . . . . . . . . . . . . 43

How do I modify drawing templates at a later time? . . . . . . . . 43

What are the benefits of customizing AutoCAD? . . . . . . . . . 43

How do I return to this later? . . . . . . . . . . . . . . . . . . . . 44

Chapter 3 Installation Troubleshooting . . . . . . . . . . . . . . . . . . . 45

General Installation Issues . . . . . . . . . . . . . . . . . . . . . . . . 45

How can I check my graphics card driver to see if it needs to be

updated? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

What is a text editor used for? . . . . . . . . . . . . . . . . . . . 46

When performing a Typical installation, what gets

installed? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Why should I install the Material Library? . . . . . . . . . . . . . 47

Where are my product manuals? . . . . . . . . . . . . . . . . . . 47

Licensing Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

What is the difference between a stand-alone license and a

network license? . . . . . . . . . . . . . . . . . . . . . . . . . . 48

What is the benefit of using a network licensed version of the

software? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

What is Internet Explorer used for? . . . . . . . . . . . . . . . . . 49

Uninstall and Maintenance Issues . . . . . . . . . . . . . . . . . . . . 49

When adding or removing features, how can I tell what features

get installed by default? . . . . . . . . . . . . . . . . . . . . . . 49

Is it possible to change the installation folder when adding or

removing features? . . . . . . . . . . . . . . . . . . . . . . . . 51

When should I reinstall the product instead of a repair? . . . . . . 51

Do I need my original disc to reinstall my software? . . . . . . . . 51

After repairing my installation, is it possible to recover my

settings? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

When I uninstall my software, what files are left on my

system? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

iv | Contents

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Contents | v

Quick Start to Stand-Alone

Installation

The Stand-Alone Installation Guide provides instructions about how to prepare, and then install

AutoCAD 2010. If you have never installed the product before, you should familiarize yourself

with the entire installation process and options before beginning.

If you have a previous release installed, you should review the Migrate Custom Settings and

Files from Previous Releases on page 25 section, so you can take full advantage of your custom

settings.

For information about installing network-licensed versions of the program, see the following

related topics:

■Choose an Installation Type (Network Administrator’s Guide)

■Select a License Type (optional) (Network Administrator’s Guide)

■What is the difference between a stand-alone license and a network license?

■What is the benefit of using a network licensed version of the software?

Preparing for Installation

To prepare for installation, you should review the system requirements,

understand administrative permission requirements, locate your AutoCAD serial

number and product key, and close all running applications. Complete these

tasks, and you are ready to begin installing AutoCAD.

System Requirements

The first task you need to complete is to make sure that your computer meets

the minimum system requirements. If your system does not meet these

requirements, problems can occur, both within AutoCAD and at the operating

system level.

Whether your Windows operating system is the 32-bit or the 64-bit version,

the version is automatically detected during installation. The appropriate

version of AutoCAD is installed. A 64-bit version of AutoCAD cannot be

installed on a 32-bit system and vice-versa.

See the following table for hardware and software requirements.

32-bit Hardware and Software Requirements

For more information on Windows

Vista versions see http://www.mi-

crosoft.com/windowsvista/versions/

Windows®XP Home and Professional

Edition SP2 or later

Microsoft®Windows Vista®SP1 or later

including:

Operating systems

■Windows Vista Enterprise

■Windows Vista Business

■Windows Vista Ultimate

■Windows Vista Home Premium

Internet Explorer®7.0 or later

Browser

Windows XP - Intel®Pentium®4 or AMD

Athlon™Dual Core processor, 1.6 GHz

or higher with SSE2 technology

CPU type

Windows Vista - Intel Pentium 4 or AMD

Athlon Dual Core processor, 3.0 GHz or

higher with SSE2 technology

Windows XP - 2 GB RAMMemory

Windows Vista - 2 GB RAM

1024 x 768 with True ColorDisplay resolution

A 32-bit AutoCAD cannot be installed

on a 64-bit Windows operating sys-

tem and vice-versa.

Installation 1 GBHard disk

2| Chapter 1 Quick Start to Stand-Alone Installation

32-bit Hardware and Software Requirements

MS-Mouse compliantPointing device

3D Modeling Addi-

tional Requirements

■Intel Pentium 4 or AMD Athlon

processor, 3.0 GHz or higher; or In-

tel or AMD Dual Core processor, 2.0

GHz or higher

■2 GB RAM or greater

■2 GB free hard disk space available

not including installation

■1280 x 1024 32-bit color video dis-

play adapter (True Color) 128 MB

or greater, Direct3D®capable

workstation class graphics card

64-bit Hardware and Software Requirements

For more information on Windows

Vista versions see http://www.mi-

crosoft.com/windowsvista/versions/

Windows®XP Professional x64 Edition SP2

or later

Microsoft®Windows Vista®SP1 or later

including:

Operating systems

■Windows Vista Enterprise

■Windows Vista Business

■Windows Vista Ultimate

■Windows Vista Home Premium

Internet Explorer 7.0 or laterBrowser

AMD Athlon 64 with SSE2 technologyCPU type

AMD Opteron™with SSE2 technology

Intel Xeon with Intel EM64T support and

SSE2 technology

Intel Pentium 4 with Intel EM64T support

and SSE2 technology

Windows XP - 2 GB RAMMemory

Windows Vista - 2 GB RAM

System Requirements | 3

64-bit Hardware and Software Requirements

1024 x 768 with True ColorDisplay resolution

A 64-bit AutoCAD cannot be in-

stalled on a 32-bit Windows operat-

ing system and vice-versa.

Installation 1.5 GBHard disk

MS-Mouse compliantPointing device

3D Modeling Addi-

tional Require-

ments

■Intel Pentium 4 or AMD Athlon pro-

cessor, 3.0 GHz or higher; or Intel or

AMD Dual Core processor, 2.0 GHz or

higher

■2 GB RAM or greater

■2 GB free hard disk space available not

including installation

■1280 x 1024 32-bit color video display

adapter (True Color) 128 MB or

greater, Direct3D®capable worksta-

tion class graphics card

Additional Hardware and Software Recommendations - 3D use

32-BitOperating system ■It is recommended that non-

English language versions of

Windows XP Home and Professional SP2

or later AutoCAD be installed on an oper-

Windows Vista Enterprise ating system with a user interface

Windows Vista Business language that matches the code

Windows Vista Ultimate page of AutoCAD language. A

Windows Vista Home Premium code page provides support for

64-Bit character sets used in different

languages.

Windows XP Professional x64 Edition

SP2 or later ■Whether the Windows operating

system is 32-bit or 64-bit, the

Windows Vista Enterprise 64-bit

Windows Vista Business 64-bit version is automatically detected

Windows Vista Ultimate 64-bit when you install AutoCAD. The

Windows Vista Home Premium 64-bit appropriate version of AutoCAD

is installed. The 32-bit version of

AutoCAD cannot be installed on

4| Chapter 1 Quick Start to Stand-Alone Installation

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Autodesk Software Handbücher

Autodesk

Autodesk AUTOCAD 2006 Betriebsanleitung

Autodesk

Autodesk 00128-051462-9340 - AutoCAD 2008 - PC Bedienungsanleitung

Autodesk

Autodesk AUTOCAD P AND ID 2010 Bedienungsanleitung

Autodesk

Autodesk 22906-010000-9325 - UPG FROM AUTOCAD 2000I-NET... Montage- und Wartungsanleitung

Autodesk

Autodesk MUDBOX 2011 - SYSTEM REQUIREMENTS Bedienungsanleitung

Autodesk

Autodesk AUTOCAD RASTER DESIGN Bedienungsanleitung

Autodesk

Autodesk AUTOCAD 2010 - Bedienungsanleitung

Autodesk

Autodesk 12909-091452-9750 - Map 3D 2006 Student... Bedienungsanleitung

Autodesk

Autodesk LANDXPLORER SERVER Bedienungsanleitung

Autodesk

Autodesk ALIAS DESIGN Bedienungsanleitung

Autodesk

Autodesk AUTOCAD 2010 - Bedienungsanleitung

Autodesk

Autodesk 551A1-05B111-1001 - Stitcher Unlimited 2009 Bedienungsanleitung

Autodesk

Autodesk GREEN BUILDING STUDIO - QUESTIONS AND... Bedienungsanleitung

Autodesk

Autodesk 18507-051452-9325 - UPG ARCH DESKTOP 2007 Bedienungsanleitung

Autodesk

Autodesk CAICE VISUAL SURVEY 10 - QUESTIONS AND... Bedienungsanleitung

Autodesk

Autodesk AUTOCAD ELECTRICAL 2010 Bedienungsanleitung

Autodesk

Autodesk 466B1-05A761-1304 - AutoCAD Inventor Simulation Suite... Bedienungsanleitung

Autodesk

Autodesk AUTOCAD MAP 3D - BROCHURE 2 Bedienungsanleitung

Autodesk

Autodesk 3ds Max Bedienungsanleitung

Autodesk

Autodesk CAICE VISUAL ROADS 10 Bedienungsanleitung

Autodesk

Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite... Bedienungsanleitung

Autodesk

Autodesk 64006-051108-9001 - Discreet Cleaner - Mac Bedienungsanleitung

Autodesk

Autodesk Design Suite 3D - Planix Home Design Suite... Bedienungsanleitung

Autodesk

Autodesk AUTODESK ROBOT STRUCTURAL ANALYSIS... Bedienungsanleitung

Beliebte Software Handbücher anderer Marken

COMPRO

COMPRO COMPROFM Bedienungsanleitung

Muratec

Muratec OFFICEBRIDGE ONLINE Bedienungsanleitung

Oracle

Oracle Contact Center Anywhere 8.1 Bedienungsanleitung

Adobe

Adobe 65007312 - Photoshop Lightroom Handbuch

Avaya

Avaya NULL One-X for RIM Blackberry Bedienungsanleitung

HP ProLiant BL420c Bedienungsanleitung

PS Audio

PS Audio PowerPlay Betriebsanleitung

Brady

Brady LOCKOUT PRO 3.0 Service-Handbuch

Avaya

Avaya Interaction Center Bedienungsanleitung

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Handbuch

Novell

Novell GROUPWISE 8 - INTERNET AGENT Bedienungsanleitung

Oracle

Oracle Application 9i Bedienungsanleitung

Acer

Acer RDM Bedienungsanleitung

Canon

Canon Vixia HF21 Bedienungsanleitung

Canon

Canon ZR950 Bedienungsanleitung

Samsung

Samsung Auto Backup Bedienungsanleitung

Polycom

Polycom Vortex EF2201 Montage- und Bedienungsanleitung

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Bedienungsanleitung
