AV Access U2EX60 Bedienungsanleitung

60m USB 2.0 Extender

User Manual

U2EX60

www.avaccess.com

info@avaccess.com

Table of Contents

Introduction ......................................................................................... 2

Overview..................................................................................................................2

Features ...................................................................................................................2

Package Contents.................................................................................................2

Panel..........................................................................................................................3

Transmitter......................................................................................................3

Receiver............................................................................................................3

Installation and Application ............................................................... 4

Bracket Installation ..............................................................................................4

Application .............................................................................................................4

Specification......................................................................................... 6

Warranty............................................................................................... 7

Introduction

www.avaccess.com

info@avaccess.com

Introduction

Overview

This product is a transmitter (TX) and receiver (RX) set that can extend

USB-HID and USB 2.0 signal up to 80m/263ft and 60m/197ft via a Cat

5e/6/6a/7 cable. It is designed with compact structure for easy

installation and PoC capability for RX to be installed in narrow spaces or

places without access to power supply, like under the roof for supplying

power to the surveillance camera.

Features

Slim profile, easy to install anywhere.

PoC capable -- RX receives power from TX without any additional

power adapter required.

Transmits USB 2.0 signal up to 60m with a maximum speed of

480Mbps.

Allows connections of up to 4 x USB 2.0 devices and provides a

maximum power output of 3A.

Plug-and-play.

Supports all major operating systems, including Windows, Mac OS,

Linux, etc.

Package Contents

Before you start the installation of the product, please check the

package contents:

U2EX60 (Transmitter) x 1

U2EX60 (Receiver) x 1

DC 18V Power Adapter x 1

USB-A to USB-B Cable (L=1.5m) x 1

Mounting Brackets (with Screws) x 4

User Manual x 1

Introduction

www.avaccess.com

info@avaccess.com

Panel

Transmitter

1432

No.

Name

Description

1 PC Connect to a PC using the USB-A to USB-B cable

provided.

2 18V

Connect to the power adapter provided.

Note: The power-on transmitter

can power receiver

through PoC, no power adapter required at receiver.

3 Power LED 

On: The device is powered on.

Off: The device is powered off.

UTP Out

Connect transmitter to receiver using a Cat X cable.

Receiver

1 32

Installation and Application

www.avaccess.com

info@avaccess.com

No.

Name

Description

1 USB Device

4 x USB-A ports. Connect to USB devices such as

keyboard, mouse, MIC, camera, etc.

Note: The four ports share 3A current.

2 Power LED 

On: The device is powered on.

Off: The device is powered off.

UTP In

Connect receiver to transmitter using a Cat X cable.

Installation and Application

Note: Disconnect all devices from power before installation.

Bracket Installation

Steps to install the device in a suitable location:

1. Attach the bracket to the enclosure using the

screws provided. The bracket is attached to

the enclosure as shown. Repeat this step for

the other side of the device.

2. Mount the device on a flat and solid surface

with screws (screws are not included in the

package).

Application

Application 1 – Video conference system

Bracket Installation

Installation and Application

www.avaccess.com

info@avaccess.com

Application 2 – Personal entertainment system

Application 3 – Surveillance system

Specification

www.avaccess.com

info@avaccess.com

Specification

Technical

Input/Output Port

TX: 1 x DC 18V, 1 x USB Type-B, 1 x UTP Out

RX: 4 x USB Type-A, 1 x UTP In

General

Operating Temperature

0°C to 45°C (32°F to 113°F)

Storage Temperature

-20°C to 70°C (-4°F to 158°F)

Humidity

10% to 90%, non-condensing

ESD Protection

Human-body Model:

±8kV (Air-gap discharge)/±4kV (Contact discharge)

Power Supply

DC 18V 1A (Transmitter powers receiver through PoC)

Power Consumption

(Max)

6.4W (Pair)

Device Dimensions

(W x H x D)

TX: 90mm x 20mm x 55mm /3.54” x 0.79” x 2.17”

RX: 90mm x 20mm x 71mm /3.54” x 0.79” x 2.8”

Net Weight

TX: 0.11kg/0.242lb

RX: 0.14kg/0.308lb

Cable Specification:

Cable Type

Range

Supported USB Devices

Cat 5e/6/6a/7

Up to 263ft (80m)

USB-HID device

Up to 197ft (60m)

USB 2.0 storage device

Warranty

www.avaccess.com

info@avaccess.com

Warranty

Products are backed by a limited 1-year parts and labor warranty. For the

following cases AV Access Technology Limited shall charge for the service(s)

claimed for the product if the product is still remediable and the warranty card

becomes unenforceable or inapplicable.

1. The original serial number (specified by AV Access Technology Limited)

labeled on the product has been removed, erased, replaced, defaced or is

illegible.

2. The warranty has expired.

3. The defects are caused by the fact that the product is repaired, dismantled

or altered by anyone that is not from an AV Access Technology Limited

authorized service partner. The defects are caused by the fact that the

product is used or handled improperly, roughly or not as instructed in the

applicable User Guide.

4. The defects are caused by any force majeure including but not limited to

accidents, fire, earthquake, lightning, tsunami and war.

5. The service, configuration and gifts promised by salesman only but not

covered by normal contract.

6. AV Access Technology Limited preserves the right for interpretation of

these cases above and to make changes to them at any time without

notice.

Thank you for choosing products from AV Access.

If you have any question, please contact us via the following emails:

General Enquiry: info@avaccess.com

Customer/Technical Support: support@avaccess.com
