EVO-zero
Belt Drive System
Compact Equatorial Mount
INSTRUCTION MANUAL
Version 1.0.2 May 2022
All the pictures and contents here included are property of Avalon Instruments. The contents cannot be
reproduced, published, copied or transmitted in any way, including the internet, without the written
permission of Avalon Instruments.
SAFETY STANDARDS AND WARNINGS
Read the manual carefully before installing and using the mount
To make the document easier to read in the field, we recommend that you to copy
all documentation files from the supplied USB flash drive to a smartphone or, even
better, to a computer or tablet
Use the power cable supplied with the mount or else a 12V- 3A stabilized power
supply as suggested in the manual
Make sure that the power cable is connected correctly and securely to the power
socket
Do not bend, pull or press the cable as this may damage it
For any assistance or repairs, please contact only the manufacturer
Be sure to remove the power supply at the end of an observing or imaging session
or before performing cleaning or maintenance When removing from a power
outlet, pull on the plug, not the cable
This mount is intended for use exclusively by adults Do not allow it to be used by
children under 12 or by people with impaired mental faculties
Operate the mount only as indicated in the manual
Modifying or altering the characteristics of the mount in any way will void the
manufacturer’s limited warranty
Never modify the tension of the belts (governed by a dedicated screw) These are set
in the factory and any unauthorized change will void the manufacturer’s limited
warranty
After using the mount, avoid storing it in areas exposed to sunlight or in wet places
IMPORTANT NOTE: DO NOT USE ANY KIND OF LUBRICANT, SPRY, LIQUID OR
OIL ON THE BELT DRIVE SYSTEM !!!
Any use of lubricants will void the manufacturer’s limited warranty
© All Rights reserved 2
IMPORTANT NOTE: THE EVO-ZERO IS A CLUTCHLESS MOUNT WITH A
SAFETY BRAKE SYSTEM THAT MUST BE DISABLED IN ORDER TO ALLOW
THE MOUNT START WORKING
© All Rights reserved 3
Summary
SAFETY STANDARDS AND WARNINGS.............................................................................................2
Technical Specifications..............................................................................................................................5
Foreword......................................................................................................................................................
1. Packing Content.......................................................................................................................................7
2 Mount Description....................................................................................................................................8
3. Initial EVO-zero Setting........................................................................................................................11
1.1 T-pod Mounting...............................................................................................................................11
3.2 Installing the Mount on the Tripod..................................................................................................13
3.4 Latitude range settings.....................................................................................................................13
3.3 StarGo and EVO-zero cabling connections.....................................................................................18
4 Telescope Balancing Operations............................................................................................................22
5. EVO-zero Alignment in Equatorial Mode.............................................................................................22
5.2 Azimuth adjustment.........................................................................................................................23
5.3 EVO-zero Polar Alignment.............................................................................................................24
5.3.1 Polar Kit (optional) Installation................................................................................................24
5.3.2. Polar alignment with a Polarscope..........................................................................................24
5.3.4 External Programs for Finding Polar Position..........................................................................27
5.3.4 More modern and precise approaches to Polar Alignment.......................................................28
© All Rights reserved 4
Technical Specifications
Type Equatorial/Alt Az mount
Weight 4, Kg
Load Capacity Also without counterweights or with a small counterweight on
depending on the setup specs
Transmission Belt Drive System composed by four stage reducer with pulleys
and timing belts.
Construction
material
Anodized aluminum, machined from single blocks with high
precision CNC machines
Goto system Avalon StarGO GOTO System - Wi-Fi
Counterweight bar W = 1 mm / L = 235 mm
Counterweight 3 kg
Mounting Saddle Vixen style
Warranty 2 years from the purchase date, extended to 5 years for the
transmission system
© All Rights reserved 5
Foreword
This manual describes the mounting, operation and correct setup of the EVO-zero single arm
mount, including the proper installation of a suitable optical tube.
Please read this manual carefully to guarantee that you can use the EVO-zero mount in
complete safety and with the maximum satisfaction.
The instructions related to the StarGO control system and related software are described in
separate Instruction Manuals:
Avalon Instruments - StarGO Control System
Both the above manuals are included in the flash drive supplied with the mount.
The design and the configuration of the mount can be subject to modifications without prior
notice, based on design decisions leading to continuous improvements and on the suggestions
of mount owners.
© All Rights reserved 6
1 Packing Content
Open the box and take out all the contents. Remove all the components from the small
cardboard box and from the mount bag side pocket, and place them on a clean, flat surface.
Component List
•Mount Head
•StarGo Controller
•StarGO Keypad
•3 kg Counterweight
•Counterweight rod
•Mount transport bag
•RA/DEC Motor’s connecting cable
•Brake Safety System connecting cable
•Power supply
•Allen wrench
•USB cable
•Azimuth adjustment pin
•3/8” Mount fixing knob
•USB flash drive with manuals and software
Package picture
© All Rights reserved 7
2 Mount Description
The EVO-zero is a compact mount for travelling astronomy and light setup with a payload up to
13 kg, also without counterweights or with a small counterweight on depending on the setup
specs
The following drawing show the EVO-zero mount dimensional characteristics.
© All Rights reserved 8
The EVO-zero was developed on the basis of:
•Belt Drive System improved (more rigidity)
•Computer aided design (CAD)
•High quality manufacturing with digital control 5 axes CNC machines (CNC + CAM)
•Absolute quality materials: Anodized aluminium from milled mono-bloc, stainless steel
components and screws, brass components, techno-polymers
The EVO-zero is mainly designed for astro-imaging with medium-short length tubes (such as
SC-Maksutov, RC up to -8″ aperture and 13 kg weight, according to the tube length).
It is possible to use the EVO-zero even with refractors (400-500 mm), with a piggyback.
Thanks to the Belt Drive System improved with more rigidity and double belt tensioner per
axis, with telescopes within the mount payload capability, it is only required to fix the telescope
on the top vixen clamp without perform a fine balancing adjustment.
The use of pulleys and timing belts has allowed to obtain several advantages: a really steady
motion without play (no backlash) and sudden peaks, factors of paramount relevance for long
guided exposures and during high magnification visual observations. These features are of
particular relevance especially for the declination axis motor that can now quickly reverse the
motion without breaks to recover the plays. The timing belts used in the EVO-zero have the
structure made of special material with steel strands to avoid any deformation.
It is important to underline that in the gear-worm systems the motion transmission has only one
tangent point of contact, any errors on each of the two components will, sooner or later, result
into a tracking errors. On the contrary, in the pulley-timing belt system, no direct contact occurs
between the pulley and the motion is transmitted by the belt engaging from 50% to 90% of the
girth surface. Consequently any error, eventually present, is averaged among the cogs,
moreover soft, greatly reducing the tracking error.
No wearing effects since no relevant frictions occur. In fact, all the pulleys and the axes rotate
on roller bearings that allow to reduce the total friction almost to zero.
Another significant advantage of very low frictions is that the risks of motor slipping during
GOTO operation is virtually null. On the contrary, it is well known the difficulty to regulate the
coupling between gear and worm in the conventional mounts. If the coupling is tight the motors
can stuck with consequent loss of the position, if the coupling is too loose the plays increase.
On the other hands, the absence of significant play in the EVO-zero makes the initial calibration
of guiding CCD quick and easy.
Since there are no gears, there is no need of periodical lubrication of the internal components
and therefore the maintenance is extremely reduced and limited to the external cleaning.
© All Rights reserved 9
© All Rights reserved 10
