Avaya Wireless USB Client Bedienungsanleitung
Avaya Wireless USB Client - Getting Started Guide i
Table of Contents
1 About Wireless LAN
Introduction 1-1
Wireless LAN Network Scenarios 1-2
USB Client Features 1-6
About the CD-ROM 1-8
2 Install your USB Client
Quick Overview 2-1
Verify Kit Contents 2-2
Install the Client Manager Software 2-3
Connect your USB Client 2-4
Install Drivers 2-5
Set Windows Network Properties 2-7
Wireless LAN Properties 2-9
Finish the Installation 2-15
ii Avaya Wireless USB Client - Getting Started Guide
3 Using Wireless LAN and Windows
Introduction 3-1
Use your USB Client 3-2
View Other Computers 3-3
Use the Client Manager 3-5
Find More Information 3-9
4 Advanced Configurations
Introduction 4-1
Advanced Parameters Tab 4-2
Admin Parameters Tab 4-4
A Specifications
Physical Specifications A-1
Power Characteristics A-2
Networking Characteristics A-3
Regulatory Information A-4
Avaya Wireless USB Client - Getting Started Guide iii
B Troubleshooting
Introduction B-1
Common Troubleshooting Tips B-2
Windows 98/ME Troubleshooting Tips B-10
Windows 2000 Troubleshooting Tips B-16
Avaya Wireless USB Client - Getting Started Guide
1-1
1
About Wireless LAN
Introduction
Welcome to Avaya Wireless LAN, the easy way to wireless computing.
Building your wireless network has never been easier.
This book introduces you to the Avaya USB Client, and will help you to
connect to your network in a snap. It describes the most common
configurations.
To install and manage wireless products, it is assumed that you have a
working knowledge of installation procedures for network operating systems
under Microsoft Windows.
1-2
Avaya Wireless USB Client - Getting Started Guide
About Wireless LAN - Wireless LAN Network Scenarios
Wireless LAN Network Scenarios
The USB Client Kit enables you to:
■Connect your computer to a Peer-to-Peer workgroup of wireless
computing devices (see Figure 1-1 on page 1-3).
■Connect your computer to a Local Area Network (LAN) Infrastructure
that includes Avaya Wireless LAN access points, or other IEEE 802.11
compliant LAN systems (see Figure 1-2 on page 1-4).
Wireless stations can be equipped with the USB Client, but also with Avaya
Wireless PC Card or PCI Adapter. All Wireless LAN adapters share the
same wireless functionality.
Peer-to-Peer Workgroup
The Peer-to-Peer workgroup configuration enables you to quickly set up a
small wireless workgroup, where the workgroup participants can exchange
files using features like “File and Printer Sharing” as supported by Microsoft
Networking.
Avaya Wireless USB Client - Getting Started Guide
1-3
About Wireless LAN - Wireless LAN Network Scenarios
Figure 1-1 Peer-to-Peer Wireless Workgroup
You can use this option to setup a temporary or ad-hoc network in
environments where no access points are available (for example in Small
Office/Home Office (SOHO) environments).
As long as the stations are within range of one another, this is the easiest
and least expensive way to set up a wireless network.
Enterprise Networking
With the Wireless LAN access point you can connect to a corporate Local
Area Network (LAN) infrastructure to have wireless access to all network
facilities.
1-4
Avaya Wireless USB Client - Getting Started Guide
About Wireless LAN - Wireless LAN Network Scenarios
LAN Infrastructures may either be:
■Stand-alone wireless LANs.
■Wireless network infrastructures connected to an existing Ethernet
networkaspicturedinFigure1-2.
Figure 1-2 LAN Infrastructure
It’s Easy
The USB Client functions like any standard wired Ethernet card, but does not
need any wires!
Avaya Wireless USB Client - Getting Started Guide
1-5
About Wireless LAN - Wireless LAN Network Scenarios
Where an Ethernet card requires a cable connection to a hub and/or patch
panel, the cable physically ties you down to the location of the wired
connection.
Wireless LAN allows you to connect your computer to a Local Area Network
(LAN) system from anywhere within the wireless coverage area. Expanding
or re-designing your network is easy: Add or relocate access points and/or
Residential Gateway-Is, power-up your wireless computers, and you’re done!
Unlike Ethernet, wireless client adapters and access points will enable you to
roam throughout the network while remaining connected to the LAN.
NOTE:
TheUSBClientisaradioproduct.Refertotheflyer“Informationto
the User” for regulatory information that may apply in your country.
1-6
Avaya Wireless USB Client - Getting Started Guide
About Wireless LAN - USB Client Features
USB Client Features
The USB Client is a wireless network device that is connected through the
USB cable to any standard USB connector.
Figure 1-3 USB Client LEDs and Connector
a. Power ON/OFF LED.
b. Radio LED.
■Off - No wireless activity.
■Blinking - Sensing/transmitting wireless data.
■Solid Green - standard operational mode.
c. USB Connector.
