Avenview FO-DVI-DL-1000M Bedienungsanleitung

www.avenview.com

DVI Dual Link Extender over 2 Strand

Multi-Mode Fiber Optic

Model #: FO-DVI-DL-1000M

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or warranties with

respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any

time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in

Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products

including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.

Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly prohibited.

www.avenview.com

Table of Contents

Section 1: Getting Started ...................................................................................................................... 3

1.1 Important Safeguards ............................................................................................................ 3

1.2 Safety Instructions ................................................................................................................. 3

1.3 Regulatory Notices Federal Communications Commission (FCC) ......................................... 4

1.4 Introduction ........................................................................................................................... 4

1.5 Package Contents................................................................................................................... 5

1.6 Before Installation.................................................................................................................. 5

1.7 Panel Description................................................................................................................... 6

1.8 Installation ............................................................................................................................. 7

Section 2: Specifications......................................................................................................................... 8

2.1 Signal Pin Assignment (Single Link) .............................................................................................. 9

2.2 Signal Pin Assignment (Dual Link) .............................................................................................. 10

www.avenview.com

Section 1: Getting Started

1.1 Important Safeguards

Please read all of these instructions carefully before you use the device. Save this manual for future

reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.

Damage, deterioration or malfunction resulting from:

Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized

product modification, or failure to follow instructions supplied with the product.

Repair or attempted repair by anyone not authorized by us.

Any damage of the product due to shipment.

Removal or installation of the product.

Causes external to the product, such as electric power fluctuation or failure.

Use of supplies or parts not meeting our specifications.

Normal wear and tear.

Any other causes which does not relate to a product defect.

Removal, installation, and set-up service charges.

1.2 Safety Instructions

The Avenview FO-DVI-DL-10000M, DVI Dual Link Extender over Fiber Optic, has been tested for conformance

to safety regulations and requirements, and has been certified for international use. However, like all

electronic equipment’s, the FO-DVI-DL-10000M should be used with care. Read the following safety

instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.

Do not dismantle the housing or modify the module.

Dismantling the housing or modifying the module may result in electrical shock or burn.

Refer all servicing to qualified service personnel.

Do not attempt to service this product yourself as opening or removing housing may expose you to

dangerous voltage or other hazards

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid

falls or spills on to the housing, unplug the module immediately.

Have the module checked by a qualified service engineer before using it again.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

www.avenview.com

1.3 Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this

equipment.

1.4 Introduction

Avenview FO-DVI-DL-10000M, Dual Link DVI Extender over two fiber solution lets you extend dual link digital

signal up to 300m (1000 feet).

-High Speed and long distance transmission

-Uses 2 strand multi-mode SC type Multi-Mode fiber optic cable

-TMDS video signal and EDID data is transmitted by optical fiber

-Supports up to Dual Link WQXGA (2560 x 1600) resolution and WUXGA (1920x1200) Single link

-Extend 2560x1600 Dual Link or 1920x1200 Single Link video signal up to 300m ( 1000 feet)

-DVI Specification 1.0 compliant

-Supports HDCP compliant devices with HDCP rev 1.1 specifications

www.avenview.com

1.5 Package Contents

Before you start the installation of the converter, please check the package contents.

-FO-DVI-DL-10000M Transmitter x 1

-FO-DVI-DL-10000M Receiver x 1

-Power Adapter (+5VDC 2A) x 1

-User’s Manual x 1

1.6 Before Installation

Put the product in an even and stable location. If the product falls down or drops, it may cause an

injury or malfunction.

Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high

humidity.

Use the DC power adapter with correct specifications. If inappropriate power supply is used then it

may cause a fire.

Do not twist or pull by force ends of the optical cable. It can cause malfunction.

Fiber Optic Cable is not included in the package

www.avenview.com

1.7 Panel Description

www.avenview.com

1.8 Installation

Avenview FO-DVI-DL-10000M is composed of a transmitter and a receiver. The Transmitter should be

connected to the computer’s DVI Port and the Receiver should be connected the DVI Port of the digital display

device.

Avenview FO-DVI-DL-10000M Transmitter is designed to be used with the LC type standard optical cable.

Transmitter and Receiver have each of 7 Optical port which are marked on the optical port of the fiber cable

connection.

To setup Avenview FO-DVI-DL-10000M follow these steps for connecting to a device:

1. Connect FO-DVI-DL-10000M Transmitter unit to DVI source

2. Connect FO-DVI-DL-10000M Receiver unit to DVI port of display.

3. Connect 2 Strand Fiber Optic LC Type cable to both Transmitter and Receiver.

4. Plug the power to Receiver Unit.

5. Power on DVI Source and DVI Display.

Use the DC adapter (included in the package) for the Receiver. The Transmitter which is connected

to a computer uses power from the computer.

If Transmitter power LED doesn’t light up after PC is turned on, then use optional external power

adapter for Transmitter.

www.avenview.com

Section 2: Specifications

Item

Description

Units

FO-DVI-DL-10000M (Transmitter)

FO-DVI-DL-10000M (Receiver

Unit Description

DVI Dual Link Transmitter

DVI Dual Link Receiver

Input Signal

TMDS Signal (DVI 1.0 Standard)

Output Signal

TMDS Signal (DVI 1.0 Standard)

Video Bandwidth

1.65Gbps / Channel

Supported Resolution &

Distance

Single Link: WUXGA 1920 x 1200 @ 300 meters ( 1000 feet)

Dual Link: WQXGA 2560 x 1600 @ 300 meters (1000 feet)

Optical Converter

850nm, 7 Ch Transmit OSA

911nm, 1 Ch VCSEL

980nm, 1 Ch PIN P/D Dioad

850nm, 7 Ch Receive OSA

980nm, 1Ch VCSEL

911nm, 1 Ch PIN P/D Diode

DVI Connector

24 pin DVI-D Plug

Optical Connector

2 SC Connector

Fiber Type

50/125 µm Multi-mode glass fiber

Dimensions (L x W x H)

2.97” x 1.97” x 0.6”

Power Supply

5V 2A DC

Power Consumption

1.5W (max)

Environmental

Operating Temperature

32˚~ 104˚F (0˚to 40˚C)

Storage Temperature

-4˚~ 140˚F (-20˚~ 60˚C)

Relative Humidity

20~90% RH (no condensation)

www.avenview.com

2.1 Signal Pin Assignment (Single Link)

TRANSMITTER

Signal Assignment

T.M.D.S. Data2-

T.M.D.S. Data1-

T.M.D.S. Data0-

T.M.D.S. Data2+

T.M.D.S. Data1+

T.M.D.S. Data0+

T.M.D.S. Data2 Shield

T.M.D.S. Data1 Shield

T.M.D.S. Data0 Shield

No Connect

DDC Clock (SCL)

+5V Power

T.M.D.S. Clock Shield

DDC Data (SDA)

Ground (for +5V)

T.M.D.S. Clock+

No Connect

Hot Plug Detect

T.M.D.S. Clock-

RECEIVER

Signal Assignment

T.M.D.S. Data2-

T.M.D.S. Data1-

T.M.D.S. Data0-

T.M.D.S. Data2+

T.M.D.S. Data1+

T.M.D.S. Data0+

T.M.D.S. Data2 Shield

T.M.D.S. Data1 Shield

T.M.D.S. Data0 Shield

No Connect

DDC Clock (SCL)

Out +5V Power

T.M.D.S. Clock Shield

DDC Data (SDA)

Ground (for Out +5V)

T.M.D.S. Clock+

No Connect

Hot Plug Detect

T.M.D.S. Clock-

www.avenview.com

2.2 Signal Pin Assignment (Dual Link)

TRANSMITTER

Signal Assignment

T.M.D.S. Data2-

T.M.D.S. Data1-

T.M.D.S. Data0-

T.M.D.S. Data2+

T.M.D.S. Data1+

T.M.D.S. Data0+

T.M.D.S. Data2/4 Shield

T.M.D.S. Data1/3 Shield

T.M.D.S. Data0/5 Shield

T.M.D.S. Data4-

T.M.D.S Data 3-

T.M.D.S. Data5-

T.M.D.S. Data4+

T.M.D.S. Data3+

T.M.D.S. Data5+

DDC Clock (SCL)

+5V Power

T.M.D.S. Clock Shield

DDC Data (SDA)

Ground (for +5V)

T.M.D.S. Clock+

No Connect

Hot Plug Detect

T.M.D.S. Clock-

RECEIVER

Signal Assignment

T.M.D.S. Data2-

T.M.D.S. Data1-

T.M.D.S. Data0-

T.M.D.S. Data2+

T.M.D.S. Data1+

T.M.D.S. Data0+

T.M.D.S. Data2/4 Shield

T.M.D.S. Data1/3 Shield

T.M.D.S. Data0/5 Shield

T.M.D.S. Data4-

T.M.D.S Data 3-

T.M.D.S. Data5-

T.M.D.S. Data4+

T.M.D.S. Data3+

T.M.D.S. Data5+

DDC Clock (SCL)

Out +5V Power

T.M.D.S. Clock Shield

DDC Data (SDA)

Ground (for Out +5V)

T.M.D.S. Clock+

No Connect

T.M.D.S. Clock-
