AVERATEC R15GN Bedienungsanleitung

r’

’s

Table of Contents

CHAPTER 1

GETTING STARTED

Getting Started

Inventory

Safety and Maintenance

Checklists

Features

Where to Look For Information

Quick Start

Adjusting the Volume

Adjusting the Brightness

Turning off Your Computer

Tips for New Owners

CHAPTER 2

GETTING STARTED

Hardware and Software

Front View

Left View

Right View

Bottom View

LCD Status Indicators

Power Indicators

Function Keys

Numeric Keypad

Touchpad

Connecting a USB Floppy Drive

Disk Drives

Connecting the Printer

The PC Card Slot

Memory

The Graphics System

CHAPTER 3

MAKING CONNECTIONS

Making Connections

Left Side Connectors

Right Side Connectors

Front Side Connectors

CHAPTER 4

POWER MANAGEMENT

Power Management

Power Saving Modes

Power Saving Tips

When to Replace the Battery

Heat Considerations

CHAPTER 5

USING THE BIOS SETUP UTILITY

Using the BIOS Setup Utility

Navigating and Entering Information in BIOS

The Main Menu

Standard CMOS Setup

Standard Feature Description

Advanced CMOS Setup

Power Management

Auto-Detect Hard Disk

Change User Password

Change Supervisor Password

Auto Configuration with Optimal Settings

Exiting and Saving

APPENDIX A

FREQUENTLY ASKED QUESTIONS

Frequently Asked Questions

APPENDIX B

STATEMENTS

Statements

European Notice

UL CAUTION

Canadian Department of Communications

Battery Disposal

CAUTION FOR ADAPTER

BATTERY CAUTION

CLASS 1 LASER PRODUCT

Introduction — Getting Started

Getting Started

Congratulations on your purchase of a notebook computer! Your new notebook features the most

innovative advances in portable computing technology. It combines state-of-the-art ergonomics with

sophisticated architecture to provide you with a personal computer that is compact, powerful, and

easy to use. Designed for a wide range of general, business, and personal productivity applications,

the notebook is an ideal choice for use in the office, at home, and on the road.

For maximum expandability without compromising portability, the notebook accommodates a number

of modules, including a combo DVD+CD-RW drive, one PCMCIA card and three USB devices. The

high capacity hard disk drive provides you with plenty of storage space for multimedia files and

applications.

The notebook features an 85/87-key keyboard and a touch pad with scroll buttons. The high-

resolution 12.1-inch LCD panel provides clear and crisp viewing.

This Manual contains all the information you need to set up and use your new notebook. It describes

all the features of the notebook in an easy-to-read yet thorough manner.

Inventory

This computer system is designed for years of productive and pleasurable computing. Use this

section to keep details of your purchase. This information will be required should you need to make

repairs to your notebook during the warranty period. Update this section when you add new options.

DATE OF PURCHASE:

PLACE OF PURCHASE:

DEALER'S ADDRESS:

TELEPHONE:

E-MAIL ADDRESS/WWW:

CONTACT PERSON:

MODEL NUMBER:

SERIAL NUMBER:

Introduction — Safety and Maintenance

The serial number is located on the label (with a bar code) on the bottom side of the computer and

begins with “SY”.

Safety and Maintenance

You can use your computer under a wide range of environmental conditions. However, to ensure

long use and continued high performance, consider the following factors when setting up your

computer:

• Follow all warnings and instructions noted in this documentation and in the Windows Help

program.

• The first time you use your computer, we recommend that you carefully read the Making

Connections section of this manual and initialize the battery to ensure optimum battery

performance.

• Unplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do

not use aerosols, solvents, or strong detergents.

• Do not use the computer near open water or other liquids. Never spill liquid onto the computer.

• Do not place the computer in an unstable location where it might slip or be knocked over.

Serious damage could result from a fall.

• Slots and openings in the system cabinet are for ventilation purposes. Do not block or cover

these openings or the system could overheat. Do not use or store the computer near a source

of heat or dust.

• On the base or rear panel of this notebook, there is a label with information on the power

requirements of this system. These requirements must be followed. If you are unsure of your

local power supply, consult your dealer or local Power Company.

• Do not step on or place anything on the power cord.

• If you use the computer with an extension cord, ensure that the total ampere ratings of all the

devices sharing the extension do not exceed the rating of the extension cord or the rating of

the wall outlet.

• Never push foreign objects into the computer through any of the slots or openings. Dangerous

voltages are present, which could cause electric shock or fire, or damage sensitive

components.

Introduction — Checklists

• For best results, use a power strip with a built-in surge protector. Do not use inferior extension

cords as this may result in damage to your computer.

• Set the computer on a flat, stable surface. To prevent damage to the computer’s hard disk drive,

avoid using the computer where it will be exposed to strong vibration.

Checklists

After opening the package, carefully inspect the contents. If any of the items is missing or appear

damaged, contact your dealer. The shipping carton should contain the following:

STANDARD

• A notebook computer

• An internal battery

• A combo DVD+CD-RW drive

• An AC adapter with power cord

• Recovery Media

• Operating System Guide

OPTIONS

The following items are optional accessories that are available for purchase separately. Visit

www.averatec.com for additional information.

• 256 MB or 512 MB Memory Module

• USB FDD Drive

• Wireless LAN PC Card

• Auto Adapter

• Spare or Additional AC Adapter with Power Cord

• Spare or Additional Battery

Introduction — Features

Caution: When purchasing any of the accessories

listed above, purchase only those accessories

that are approved for use with your computer.

The above accessories may be proprietary items.

Your system vendor can obtain these approved

accessories. If you use items that are not

approved for use with this computer, you may

cause your computer to malfunction, or to emit

or receive electro-magnetic radiation in excess

of local regulations. For non-proprietary

accessories such as PC cards or printers,

ensure that the accessory functions properly in

your computer before making the purchase. Your

system vendor may be able to recommend reliable

brands and models.

Features

High Capacity Hard Disk Drive

The computer has a high capacity hard disk drive, to store your favorite programs and large multimedia

files.

Built-in Modem/LAN Capability

A built-in 56k modem and 10/100 Mbps Ethernet port allows you to access the Internet or a local area

network (LAN).

Built-in Wireless LAN Capability (some models only)

A built-in wireless LAN allows you to access the Internet or a local area network (LAN) without wires.

Large LCD

Your computer has an easy-to-view XGA (1024x768 resolution) LCD panel.

Built-in Stereo Speakers and Microphone

The stereo speakers and internal microphone enable you to run a variety of multimedia applications.

Introduction — Where to Look For Information

Convenient Audio Control

The conveniently located audio control knob enable you to easily adjust the volume to the stereo

speakers.

Scrolling Button

Comfortably scroll through documents with the ergonomically designed scrolling button.

Where to Look For Information

About Your Computer

This User’s Manual describes the key elements of your computer. New users can find a simple step-by-

step orientation in the Quick Start section of this chapter.

Quick Start

Turning on the Computer for the First Time

1. Connect the AC adapter

power cord to the AC

adapter.

2. Connect the AC adapter

to the DC power port on

the left side of your

computer.

3. Connect the AC adapter

power cord to an AC

outlet.

4. Slide the cover latch in
