Night Vision HD Indoor/Outdoor IP

Dome Camera

HD40D

User Manual

HD40D: Night Vision HD Indoor/Outdoor IP Bullet Camera

Operations Manual

Manual Edition 32332AE– October 2015

No part of this document may be reproduced by any means, electronic or mechanical, for any purpose, except as expressed in the Software License Agreement.

AVERTX shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.

The information in this publication is provided “as is” without warranty of any kind. The entire risk arising out of the use of this information remains with recipient. In

no event shall AVERTX be liable for any direct, consequential, incidental, special, punitive, or other damages whatsoever (including without limitation, damages for

loss of business profits, business interruption or loss of business information), even if AVERTX has been advised of the possibility of such damages or whether in

an action, contract or tort, including negligence.

This software and documentation are copyrighted. All other rights, including ownership of the software, are reserved to AvertX. AVERTX, and AvertX, are

registered trademarks of AVERTX in the United States and elsewhere; Windows is a registered trademarks of Microsoft Corporation. All other brand and product

names are trademarks or registered trademarks of the respective owners.

The following words and symbols mark special messages throughout this guide:

WARNING: Text set off in this manner indicates that failure to follow directions could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information.

AVERTX

1. Read Instructions

Read all of the safety and operating instructions before using the

product.

2. Retain Instructions

Save these instructions for future reference.

3. Attachments / Accessories

Do not use attachments or accessories unless recommended by

the appliance manufacturer as they may cause hazards, damage

product and void warranty.

4. Installation

Do not place or mount this product in or on an unstable or

improperly supported location. Improperly installed product may fall,

causing serious injury to a child or adult, and damage to the

product. Use only with a mounting device recommended by the

manufacturer, or sold with the product. To insure proper mounting,

follow the manufacturer's instructions and use only mounting

accessories recommended by manufacturer.

5. Power source

This product should be operated only from the type of power source

indicated on the marking label.

Operating

 Before using, make sure power supply and others are properly

connected.

 While operating, if any abnormal condition or malfunction is

observed, stop using the camera immediately and then contact

your local dealer.

Handling

 Do not disassemble or tamper with parts inside the camera.

 Do not drop or subject the camera to shock and vibration as this

can damage camera.

 Do not block the cooling holes on the bracket. This camera has a

cooling fan inside the housing. Blocking the cooling holes will cause

heat to build up and cause malfunction.

 Care must be taken when you clean the clear dome cover.

Scratches and dust will ruin the image quality of your camera. Do

not use strong or abrasive detergents when cleaning the camera

body. Use a dry cloth to clean the camera when it is dirty. In case

the dirt is hard to remove, use a mild detergent and wipe the

camera gently.

Installation and Storage

 Do not install the camera in areas of extreme temperatures in

excess of the allowable range. (14°F~ 122°F / -10°C ~ 50°C)

 Avoid installing in humid or dusty places. The relative humidity must

be below 90%.

 Avoid installing in places where radiation is present.

 Avoid installing in places where there are strong magnetic fields

and electric signals.

 Avoid installing in places where the camera would be subject to

strong vibrations.

 Never face the camera toward the sun. Do not aim at bright objects.

Whether the camera is in use or not, never aim it at the sun or other

extremely bright objects. Otherwise the camera may be smeared

and damaged.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This symbol on the product or on its packaging indicates that this

product shall not be treated as household waste in accordance with

Directive 2002/96/EC. Instead it shall be handed over to the applicable

collection point for the recycling of electrical and electronic equipment.

By proper waste handling of this product you ensure that it has no

negative consequences for the environment and human health, which

could otherwise be caused if this product is thrown into the garbage bin.

The recycling of materials will help to conserve natural resources.

For more details information about recycling of this product, please

contact your local city office, your household waste disposal service or

the shop where you purchased the product.

Compliance is evidenced by written declaration from our suppliers,

assuring that any potential trace contamination levels of restricted

substances are below the maximum level set by EU Directive

2002/95/EC, or are exempted due to their application.

DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE

ENCLOSURE.

REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

TABLE OF CONTENTS ................................................................................................................................................................................................................... 5

INTRODUCTION .............................................................................................................................................................................................................................. 8

Overview .................................................................................................................................................................................................................. 8

Camera Default Settings ................................................................................................................................................................................... 8

Product Features ............................................................................................................................................................................................... 8

ONE: GETTING STARTED ............................................................................................................................................................................................................. 9

Box Contents .......................................................................................................................................................................................................... 10

Camera Overview ................................................................................................................................................................................................... 10

Dimensions ...................................................................................................................................................................................................... 10

Side .......................................................................................................................................................................................................... 10

Front ......................................................................................................................................................................................................... 10

Connections .................................................................................................................................................................................................... 11

Weather Resistant Cable Connector ........................................................................................................................................................ 11

TWO: CAMERA FINDER ............................................................................................................................................................................................................... 12

Bench test............................................................................................................................................................................................................... 13

AvertX Camera Finder ..................................................................................................................................................................................... 13

Finding IP Cameras.................................................................................................................................................................................. 13

Accessing the Camera ............................................................................................................................................................................. 13

Changing the IP Address ......................................................................................................................................................................... 13

THREE: SETUP AND CONFIGURATION ..................................................................................................................................................................................... 14

Installing the Camera .............................................................................................................................................................................................. 15

Ceiling and Wall Installation ............................................................................................................................................................................ 15

Removing the Lens Cover ............................................................................................................................................................................... 16

Installing the Desiccant.................................................................................................................................................................................... 16

Resetting the Camera ..................................................................................................................................................................................... 16

MicroSD Card .................................................................................................................................................................................................. 16

Connecting to the Camera ...................................................................................................................................................................................... 18

Connecting In a Web Browser ......................................................................................................................................................................... 18

Administrator/User Privileges .......................................................................................................................................................................... 18

Default Username and Password ............................................................................................................................................................. 18

Connecting a Stream ....................................................................................................................................................................................... 18

Camera Settings ..................................................................................................................................................................................................... 19

Viewer Tabs .................................................................................................................................................................................................... 19

Home ............................................................................................................................................................................................................... 19

Changing the Language ........................................................................................................................................................................... 19

Using Digital Zoom Control ...................................................................................................................................................................... 20

Setup ............................................................................................................................................................................................................... 20

System ..................................................................................................................................................................................................... 20

Streaming ................................................................................................................................................................................................. 21

Camera .................................................................................................................................................................................................... 22

Motion Detection ...................................................................................................................................................................................... 23

Software Upgrade .................................................................................................................................................................................... 24

Logout ............................................................................................................................................................................................................. 25

Logging In as a Different User .................................................................................................................................................................. 25

Connecting to the Camera as Admin ...................................................................................................................................................................... 25

Connecting in a Web Browser ......................................................................................................................................................................... 25

Admin Camera Controls ........................................................................................................................................................................... 26

Security .................................................................................................................................................................................................... 27

Network .................................................................................................................................................................................................... 28

DDNS ....................................................................................................................................................................................................... 29

Mail........................................................................................................................................................................................................... 29

FTP .......................................................................................................................................................................................................... 29

HTTP ........................................................................................................................................................................................................ 30

Events ...................................................................................................................................................................................................... 30

32332AA 7

Storage Management ............................................................................................................................................................................... 31

Recording ................................................................................................................................................................................................. 32

Schedule .................................................................................................................................................................................................. 32

File Location ............................................................................................................................................................................................. 32

View Information ...................................................................................................................................................................................... 32

Factory Default ......................................................................................................................................................................................... 33

Software Version ...................................................................................................................................................................................... 33

Maintenance ............................................................................................................................................................................................. 33

Video Format ............................................................................................................................................................................................ 33

Camera............................................................................................................................................................................................................ 35

FOUR: SPECIFICATIONS ............................................................................................................................................................................................................. 37

Camera Specifications ............................................................................................................................................................................................ 38

The HD40D Night Vision HD Indoor/Outdoor IP Bullet Cameras are

compact cameras designed for easy setup and use. The 4 megapixel

resolution provides high definition images. The HD40D camera also

offer quad streaming and can be used in a variety of installations

including shops, stores, banks, factories and for building surveillance.

With Power over Ethernet (PoE), the need for separate power lines is

eliminated and cabling and installation costs can be significantly

reduced. The light weight, and small size of the camera make

installation easy in a variety of locations.

The HD40D includes Digital Wide Dynamic Range, 3D Noise Reduction,

and Day/Night ICR, making it useful for challenging lighting conditions

and nighttime installations.

IP Address

192.168.0.250

Username

admin

Password

1234

Management Port

Streaming Port (RTSP)

554

 Progressive Scan CMOS Sensor

 1080p and 4MP Resolution Available

 H.264 Encoding

 Dual Streaming

 Multi-Language Support

 Tampering Alarm

 Digital Wide Dynamic Range

 Motion Detection

 Privacy Masks

 Smart Picture Quality / 3D Noise Reduction

 Network Failure Detection

 Digital Day/Night (ICR)

 IR LED Module (working distance up to 30m)

 MicroSD Support (up to 64GB microSD Card)

 Weatherproof (IP66 Outdoor Rated)

 ONVIF Support

32332AE 9

Box Contents

Camera Overview

Before proceeding, please check that the box contains the items listed

here. If any item is missing or has defects, DO NOT install or operate

the product and contact your dealer for assistance.

HD40D Camera

Desiccant

Self-Tapping Screws

Plastic Screw Anchors

Quick Start Guide

Before installing or connecting the camera, please refer to this section

and complete preparations for setup and all switch settings.

Andere avertX Sicherheitskamera Handbücher

avertX

avertX HD438IR Bedienungsanleitung

avertX

avertX HD6022-APW Bedienungsanleitung

avertX

avertX HD510 Bedienungsanleitung

avertX

avertX HD30 High Definition Network Dome Camera Bedienungsanleitung

avertX

avertX C7012-RW Bedienungsanleitung

avertX

avertX HD90IR Bedienungsanleitung

avertX

avertX HD420 Bedienungsanleitung

avertX

avertX HD320 Bedienungsanleitung

avertX

avertX HD828 Bedienungsanleitung

avertX

avertX AVX-HD848IRM Bedienungsanleitung

avertX

avertX HD354IR Bedienungsanleitung

avertX

avertX HIGH DEFINITION NETWORK DOME CAMERA Bedienungsanleitung

avertX

avertX C6012-RW Bedienungsanleitung

avertX

avertX HD40IR Bedienungsanleitung

avertX

avertX HD300 Bedienungsanleitung

avertX

avertX HD828 Bedienungsanleitung

avertX

avertX DP15IR Bedienungsanleitung

avertX

avertX HD80 Bedienungsanleitung

avertX

avertX C7022-FPW Bedienungsanleitung

avertX

avertX HD810 Bedienungsanleitung

avertX

avertX AVX-HD458IR Bedienungsanleitung

avertX

avertX AVX-HD119IR Bedienungsanleitung

avertX

avertX HD420 Bedienungsanleitung

avertX

avertX HD438 Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung

avertX HD40D Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken
