Monarch®, 9825®, 9855®, and 9860®are trademarks of Paxar Americas, Inc.

Avery Dennison®is a trademark of Avery Dennison Corp.

DataBar is a trademark of GS1.

PROGRAMMER’S ADDENDUM

This addendum describes the software changes available in

♦ version 6.0 of the Monarch®9855®and 9860™printers.

♦ version 3.0 of the Monarch®9825®printer.

This addendum contains information about

♦ defining a GS1 DataBar™(RSS) bar code symbology.

♦ defining the RFID Setup Packet.

♦ using the Unicode UTF-8 symbol set.

♦ viewing the printer's serial number.

Note: Information in this document supercedes information in previous

versions. Check our Web site (www.monarch.com) for the latest

documentation and release information.

Audience

This addendum is for the System Administrator, who designs and prints

Monarch®Printer Control Language II (MPCLII) formats.

Defining a GS1 DataBar™(RSS) Symbology

The GS1 DataBar is a family of linear symbologies. Depending on the bar

code data entered, the bar code may appear as a 2D bar code stacked on

top of the linear bar code. For more information about the GS1 DataBar bar

code, refer to the GS1 General Specification.

Syntax B,field#,# of char,fix/var,row,column,

font,density,height,text,alignment,field rot,

type,sep_height,segment¦

B1. BBar Code Field.

B2. field# Unique number from 1-999 to identify this field.

B3. # of char Maximum number of characters. The actual maximum

number of characters is limited by the size of the label

and bar code density. Range: 0-2710. The default is 30.

B13. Bar Code Type B3. Number of Characters (Max.)

1 - GS1 DataBar 14 13 - no check digit input

2 - GS1 DataBar 14 Truncated 13 - no check digit input

3 - GS1 DataBar 14 Stacked 13 - no check digit input

4 - GS1 DataBar 14 Stacked

Omni directional

13 - no check digit input

5 - GS1 DataBar Limited 13 - no check digit input

6 - GS1 DataBar Expanded *

7 - UPCA 11 - no check digit input

8 - UPCE 10 - no check digit input

9 - EAN13 12 - no check digit input

10 - EAN8 7 - no check digit input

11 - UCC/EAN128 and CC A/B *

12 - UCC/EAN128 and CC C *

* For more information, refer to the GS1 General Specification.

Note: If not enough characters are entered, the bar code pads to the left

with zeros. If too many characters are entered, unpredictable

results may occur.

Left-Justified Fields

Row

B4. fix/var Fixed (F) or variable (V) length field.

B5. row Distance from bottom of the

print area to the pivot point

of the field. The pivot point

varies, depending on how

the field is justified.

To easily identify the

pivot points (marked with

a circle), a linear bar

code is shown:

Printer Unit of Measure Row or

End Row Column or

End Column

9855/

9860 English (1/100 inch)

Metric (1/10 mm)

203 dpi Dots

0-1599

0-4061

0-3246

0-399

0-1013

0-810

9855/

9860 English (1/100 inch)

Metric (1/10 mm)

300 dpi Dots

0-1199

0-3045

0-3597

0-399

0-1013

0-1197

B6. column Distance from the lower left edge of the print area to the

pivot point. Use the previous table for values.

Allow a minimum of 1/10 inch between the scan edge of

bar code and label edges or other data.

B7. font Bar code type. Use 38.

Col

B8. density Bar code density. The range is 2-8. The default is 2.

Select the density from the following table.

Bar Code

Type Density

Selector

203 dpi

Narrow

Element Size

(dots/mils)

300 dpi

Narrow

Element Size

(dots/mils)

Data

Length Char

Set

2 2/9.9 3/9.8

3 3/14.8 4/13.1

4 4/19.7 5/16.4

5 5/24.6 7/23

6 6/29.6 8/26.2

7 7/34.5 10/32.8

GS1

DataBar

8 8/39.4 11/36.1

0-2710 00H to

FFH

B9. height Bar code height of the linear bar code, in 1/100 inches,

1/10 mm, or dots. Minimum values:

English 19

Metric 48

203 Dots 38

300 Dots 57

Note: Only for use with UCC/EAN family types listed

below.

B10. text Appearance of text with bar code. Options:

0Default

8 No text, bar code only

B11. alignment Alignment of bar code data in the field. Use L(left).

B12. field rot Field rotation. Field rotation rotates the whole field.

Rotation is affected by the pivot point, which varies

depending on how text is justified. The lower left corner

of the field is the pivot point. The default is 0. Options:

0Top of field points to top of supply

1 Top of field points to left of supply

2 Top of field points to bottom of supply

3 Top of field points to right of supply

B13. type Select from the bar code family. Options:

1GS1 DataBar 14

2 GS1 DataBar 14 Truncated

3 GS1 DataBar 14 Stacked

4 GS1 DataBar 14 Stacked Omni directional

5 GS1 DataBar Limited

6 GS1 DataBar Expanded

7 UPCA

8 UPCE

9 EAN13

10 EAN8

11 UCC/EAN128 and CC A/B

12 UCC/EAN128 and CC C

B14. sep_height Height of the separator between the linear bar code and

2D bar code. The value is 1or 2. The default is 1.

B15. segment Width of the segment – only for use with GS1 DataBar

family types listed above. The range is even numbers

from 2to 22. The default is 22.

Example B,1,30,V,5,5,38,4,0,0,L,0,1,2,22¦

Defines a bar code field (field #3) with up to 30 characters of variable length

starting at row 5, column 5. The GS1 DataBar uses a density of 4. No text

is shown with the bar code. The bar code is left-aligned with no field

rotation.

{F,1,A,R,E,400,400,""¦

B,1,30,V,5,5,38,4,0,0,L,0,1,2,22¦}

{B,1,N,1¦

1,"123456|Monarch Brand Printers"¦}

{F,1,A,R,E,400,400,""¦

B,1,30,V,5,5,38,4,35,0,L,0,11,2,22¦}

{B,1,N,1¦

1,"10ABC|Monarch"¦}

This GS1 DataBar uses UCC/EAN128 and CC A/B as the bar code type and

specifies the linear bar code height at 0.35 inches.

Defining the RFID Setup Packet for UHF (9855 only)

Use the RFID setup packet (X) to set the protocol, write attempts, read

power, write power, and signal adjust.

Note: Refer to the RFID Setup Guide and Supply Chart for the read and

write power settings and signal adjustment based on your RFID

supplies.

Syntax {I,X,protocol,write_attem,read_power,

write_power,signal_adjust¦}

X1. X RFID Setup Packet

X2. protocol Select the UHF protocol. The default is 0. Options:

0 C1Gen2 (Class 1 Gen 2)

1 C1Gen1 96 (Class 1 Gen 1 96-bit)

2 C1Gen1 EPC64/96 (Class 1 Gen 1 EPC64/96)

3 EM4122

X3. write_attem The number of times the interrogator tries to program the

RFID tag in the RF Field. The range is 1– 5. The

default is 3.

X4. read_power The amount of power to read an RFID tag. The range is

1– 25. For the Japanese frequency, the range is 1– 10.

The default is 18.

X5. write_power The amount of power to write (program) an RFID tag.

The range is 1– 25. For the Japanese frequency, the

range is 1– 10. The default is 18.

X6. signal_adjust The strength of the RF Field emitted by the printer’s

antenna. The higher the value, the greater the power of

the RF Field. The signal adjustment varies depending on

the selected protocol. The range is 2– 10. The default

is 2.

Example {I,X,0,3,10,10,6¦}

Uses the default protocol (Class 1 Gen 2), sets the number of write attempts

to 3, sets the read and write power to 10 and the signal adjustment to 6.

The test label has been updated to show the settings for the RFID Setup

Packet.

RFID Setup Packet

Defining the RFID Setup Packet for HF (9855 only)

Use the RFID setup packet (X) to set the protocol, write attempts and

attenuation.

Note: Refer to the HF Setup Guide and Supply Chart for the protocol and

attenuation settings based on your RFID supplies.

Syntax {I,X,protocol,write_attem,attenuation¦}

X1. X RFID Setup Packet

X2. protocol Select the HF protocol. The default is 0. Options:

0 AUTO-Select

1 TI ISO15693

2 NXP ISO15693

3 I-CODE UID

X3. write_attem The number of times the interrogator tries to program the

RFID tag in the RF Field. The range is 1– 4. The

default is 3.

X4. attenuation The amount of power to read an RFID tag. The range is

1– 4. The default is 2.

Example {I,X,0,3,2¦}

Uses the default protocol (AUTO-Select), sets the number of write attempts

to 3 and the attenuation to 2.

The test label has been updated to show the settings for the RFID Setup

Packet.

Using International Fonts

Version 6.0 or greater (9855/9860) and version 3.0 or greater (9825) have a

new font rasterizer, which allows for an additional symbol set

(110 – Unicode UTF-8). To use this symbol set, you must download an

International TrueType font. An International TrueType font containing

Chinese or Japanese characters requires the high memory option

(purchased separately). The high memory option is only available with the

9855/9860 printers. An International TrueType font containing Arabic

characters may not require the high memory option.

Note: Because the 9825 printer's memory is limited, only Latin fonts

(smaller than 256K) may fit in the printer's flash memory. There is

not enough memory to store an Asian font. For more information

about downloading a font to flash memory, refer to the Packet

Reference Manual available on our Web site.

To use International fonts, consider the following information:

♦ All fonts contain an internal character mapping. The mapping is

organized by one or more standards, such as BIG5. These mapping

standards can provide over 65,000 characters, which are not represented

in this manual. The printers support several mapping standards:

♦ Unicode (UCS-2)

♦ BIG5

♦ GB2312

♦ SJIS

♦ Specify a symbol set based on the characters to print and one that is

compatible with the font's character mapping. For example, to print

Japanese characters, select symbol set 932 (Japanese Shift JIS) and a

font compatible with that symbol set. See "Selecting a Symbol Set" for

more information.

♦ To enter batch data, use the method specified by the font's character

mapping and a compatible symbol set.

Selecting a Symbol Set

Specify a symbol set based on the characters to print and one that is

compatible with the font's character mapping. The symbol set parameter

identifies the character mapping used in the text field or constant text field,

for example, Unicode, BIG5, etc. If no symbol set is selected, the default

symbol set (Internal Symbol Set) is used.

The printer automatically translates some character mappings to others. For

example, if you need a BIG5 font, it is possible to use Unicode text data.

Use Unicode in the symbol set parameter to indicate the text mapping and

select the BIG5 font needed in the font parameter (T8 or C5). The printer

automatically translates the Unicode character values into BIG5 values

before printing the character.

The following table lists the compatible mappings and symbol sets.

Font Character Mapping Symbol Set Parameter (T15, C13, or A6)

Batch

Data*

TrueType Font

Character Mapping

use in text or constant text fields

Unicode BIG5

Unicode SJIS

Unicode KSC5601

Unicode GB2312

Unicode Unicode

102 – Unicode

If you are unsure which character mapping to

select, use this symbol set, because the

printer automatically translates the character

mappings.

BIG5 Unicode 103 - BIG5

GB2312 Unicode 104 - GB2312

SJIS SJIS 105 - SJIS (Code Page 932 - Japanese

Shift-JIS)

GB2312 GB2312 106 - GB2312 (Code Page 936 - Simplified

Chinese)

BIG5 BIG5 107 - BIG5 (Code Page 950 - Traditional

Chinese)

UTF-8 Unicode

BIG5

SJIS

KSC5601

GB2312

110 – Unicode UTF-8

If you are unsure which character mapping to

select, use this symbol set, because the

printer automatically translates the character

mappings.

Note: UTF-8 is very common. We

recommend using it for compatibility

with different host applications and

data streams.

* Characters in batch data must be entered based on their mapping (Unicode,

BIG5, etc.).

In text (T15) and constant text (C13) fields, symbol set 110 (Unicode UTF-8)

is available.

T15. sym set Symbol set. Options:

0 Internal Symbol Set

1 ANSI Symbol Set

100 Macintosh

101 Wingdings

102 Unicode (user input) for particular mapping

103 BIG5 (user input) for Unicode mapping*

104 GB2312 (user input) for Unicode mapping*

105 SJIS (user input) for Unicode mapping*

Code Page 932 (Japanese Shift-JIS)

106 GB2312 (user input) for GB23212 mapping*

Code Page 936 (Simplified Chinese)

107 BIG5 (user input) for BIG5 mapping*

Code Page 950 (Traditional Chinese)

110 Unicode UTF-8

437 DOS Code Page 437 (Domestic)

850 DOS Code Page 850 (International)

852 DOS Code Page 852 (Latin 2)

855 DOS Code Page 855 (Russian)

857 DOS Code Page 857 (IBM Turkish)

860 DOS Code Page 860 (MS-DOS Portuguese)

1250 Code Page 1250 (Latin 2)

1251 Code Page 1251 (Cyrillic)

1252 Code Page 1252 (Latin 1)

1253 Code Page 1253 (Greek)

1254 Code Page 1254 (Turkish)

1255 Code Page 1255 (Hebrew)

1256 Code Page 1256 (Arabic)

1257 Code Page 1257 (Baltic)

1258 Code Page 1258 (Vietnamese)

* Code pages 103 – 107 are only available using the 9855/9860

printers.

Note: Code pages 102 - 107 and 110 may require the high memory

option and a downloaded International TrueType font. TrueType

fonts are designed to be regionally specific; therefore, all code

pages may not be supported in a given font.

When using symbol set 110 (Unicode UTF-8), make sure the MPCLII control

characters (start of header, parameter separator, etc.) are set to decimal

values 0to 128. Otherwise, errors may occur with the Unicode data you

enter. For more information about setting the control characters, refer to the

Packet Reference Manual available on our Web site.

Andere Handbücher für Monarch 9825

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Avery Dennison Drucker Handbücher

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Platinum 9462 Bedienungsanleitung

Avery Dennison

Avery Dennison MONARCH 9416 XL Bedienungsanleitung

Avery Dennison

Avery Dennison Pathfinder 6140 Technisches Dokument

Avery Dennison

Avery Dennison Monarch 9419 Bedienungsanleitung

Avery Dennison

Avery Dennison ALS 204 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch Tabletop Printer 2 Bedienungsanleitung

Avery Dennison

Avery Dennison 686 HT Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch 9493 SNP Gebrauchs- und Pflegehandbuch

Avery Dennison

Avery Dennison AP 2.4 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch ADTP1 Service-Handbuch

Avery Dennison

Avery Dennison Wireless Ethernet Print Server Monarch 7411 Bedienungsanleitung

Avery Dennison

Avery Dennison AP4.4 Bedienungsanleitung

Avery Dennison

Avery Dennison SNAP 600 Bedienungsanleitung

Avery Dennison

Avery Dennison 9688 Bedienungsanleitung

Avery Dennison

Avery Dennison FreshMarx 9417 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch ADTP2 EcoCut Service-Handbuch

Avery Dennison

Avery Dennison SNAP 500 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch 9485 Bedienungsanleitung

Avery Dennison

Avery Dennison Pathfinder 6140 Bedienungsanleitung

Avery Dennison

Avery Dennison Pathfinder 6059 Technisches Dokument

Avery Dennison

Avery Dennison MONARCH 9416 XL Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch TC6039SA Service-Handbuch

Avery Dennison

Avery Dennison Monarch 9419 Service-Handbuch

Avery Dennison

Avery Dennison Monarch 9855 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
