MONARCH®, 9825®, 9855®, and 9860 are trademarks of Paxar Americas, Inc.

Paxar®is a trademark of Paxar Corporation.

Avery Dennison®is a trademark of Avery Dennison Corp.

Oracle, JD Edwards, PeopleSoft, and Siebel are registered trademarks of Oracle Corporation

and/or its affiliates. SAP and NetWeaver are trademarks of SAP AG in Germany and in several

other countries.

TC9855XMLQR Rev. AD 11/07

XML QUICK REFERENCE

This Quick Reference lists the XML-enabled tags that the Monarch®

9825®, 9855®or 9860™printers can interpret.

Your printer has one of the following options:

♦ Oracle® WMS (Warehouse Management) print jobs

♦ SAP NetWeaver® Auto-ID (RFID) Infrastructure (AII-DC-RFID)

The following table lists the software versions that support the

XML options.

XML Options 9825 9855 9860

Oracle® WMS (Warehouse Management) print jobs 2.8 5.0 5.0

SAP NetWeaver® Auto-ID (RFID) 2.8 5.3 5.3

About This Quick Reference

This Quick Reference contains

♦ information that applies to both XML-enabled options, including

“Defining the Format Header,” “Using Option 21 (Define Extended

Field Names),” and “Error Messages.”

♦ specific information for each option. See the following sections as

necessary based on your printer.

♦ a sample label format.

Note: This Quick Reference does not contain information about

installing or setting up the printer for use on a network running

Oracle®software or the SAP NetWeaver®platform.

Information in this document supercedes information in previous versions.

Check our Web site (www.paxar.com) for the latest documentation and

release information.

2 Quick Reference

Defining the Format Header

Use this section with either XML-enabled option. A Format Header

begins a format file.

Syntax {F,format#,action,device,measure,length,

width,"name"¦

F1. F Format Header.

F2. format# Number from 1-999 to identify the format.

F3. action Enter Ato add a new format to the printer.

F4. device Format storage device. Use F(Flash).

F5. measure Unit of measure: E(English), M(Metric), or

G(Graphic Dots).

Printer Unit of Measure Length Width

9855/9860 English (1/100 inch)

Metric (1/10 mm)

203 dpi Dots

75-1600

191-4064

152-3248

32-400

81-1016

62-812

Refer to the optional Packet Reference Manual for

more information.

F6. length Length in selected units. Measure supply from the

leading edge of one label to the leading edge of the

next label. The leading edge is the edge that exits

the printer first.

F7. width Width, from left to right, in selected units.

F8. "name" Format name, 1-256 characters, enclose within

quotation marks. The name can contain special

characters, excluding non-printable control characters

and the quotation mark (").

Example {F,1,A,F,E,300,200,"XML_FORMAT_ONE"¦

Defines the name for format 1 as XML_FORMAT_ONE.

Using Option 21 (Define Extended Field Names)

Use this section with either XML-enabled option. Option 21 defines

names for each field in a format, which can be longer than eight

characters.

Syntax R,21,"field_name"¦

R1. ROption Header.

R2. 21 Option 21.

R3. field_name Specifies the field name. Must be enclosed within

quotations. The name can be up to 256 characters,

excluding non-printable control characters and the

quotation mark ("). This name must match the one

specified in the variable name or Field name attribute.

Example T,2,10,V,250,50,0,1,1,1,B,C,0,0,0¦

R,21,"SALEPRICE_FIELD"¦

Defines the name for text field 2 as “SALEPRICE_FIELD.”

Error Messages

Use this section with either XML-enabled option. You may receive this

error when using XML supported tags.

002 The Format Name must be between 1 to 8 characters inside quotes.

Extended Format Names and Option 21 names can be between 1 and

256 characters excluding non-printable control characters and the

quotation mark (").

About Oracle WMS Print Jobs

The XML-enabled printer contains the following 10 Oracle® Warehouse

Management print jobs (label formats):

♦ LPN Label ♦ LPN Content Label

♦ LPN Summary Label ♦ Material Label

♦ Serial Label ♦ Location Label

♦ Shipping Label ♦ Shipping Content Label

♦ WIP Content Label ♦ Flow Content Label

Refer to your Oracle

Integration Certification Document – Oracle

Warehouse Management Label Printing Integration Kit for information

about the format layout and descriptions of each field on the formats.

4 Quick Reference

When you turn on the printer, you see

WMS XML

Mode Ready

When you print test labels, the model number appears as M9855X, for

example.

Supported Tags – Oracle WMS Print Jobs

There are three supported XML tags for Oracle Warehouse Management

print jobs. The printer ignores any other XML tags/attributes not defined

in this document and no error is reported.

Syntax <labels attributes="values">

</label>

</labels>

labels This tag contains one or more labels, which may

include one or more of the following attributes:

_FORMAT The default name of the format.

This name must match the one

specified in the Format Header.

_QUANTITY Quantity to print. 1 is the default.

label This tag contains a single label, which may include

one or more of the following attributes:

_FORMAT The default name of the format.

This name must match the one

specified in the Format Header. If

no format name is given, then the

default format name from the

labels tag _FORMAT attribute is

used.

_QUANTITY Quantity to print. If no quantity is

specified, then the default quantity

from the labels tag _QUANTITY

attribute is used.

variable This tag specifies the field name and the variable

field data. It must contain the following attribute:

name The name of the field that matches

the ones specified using Option

21. It must contain the variable

data (batch data) associated with

the format.

Sample MPCL Format

{F,1,A,F,E,400,400,"XML_FORMAT_ONE" ¦

T,1,25,V,20,20,0,1,1,1,B,L,0,0¦

R,21,"TEXT_FIELD_XML"¦

B,2,30,V,100,20,8,8,75,0,L,0¦

R,21,"CODE_128_BARCODE_FIELD_XML"¦}

This MPCL format uses:

♦ format – XML_FORMAT_ONE

♦ text field – TEXT_FIELD_XML

♦ bar code field – CODE_128_BARCODE_FIELD_XML.

Sample XML Print Job

<?xml version="1.0" encoding="UTF-8"

standalone="no"?>

<!DOCTYPE labels SYSTEM "label.dtd">

<label>

<variable name= "TEXT_FIELD_XML">XML Test

Label</variable>

<variable name=

"CODE_128_BARCODE_FIELD_XML">Code128data</variable>

</label>

</labels>

This XML print job uses:

♦ format –XML_FORMAT_ONE

♦ text field – TEXT_FIELD_XML with data – XML Test Label

♦ bar code field –CODE_128_BARCODE_FIELD_XML with data –

Code128data.

6 Quick Reference

About the SAP NetWeaver® Auto-ID Infrastructure

The XML-enabled printer is designed for use with the SAP NetWeaver®

platform and the Auto-ID Infrastructure component (AII-DC-RFID).

When you turn on the printer, you see

SAP XML

Mode Ready

When you print test labels, the model number appears as M9855X, for

example.

Supported Tags – SAP Auto-ID Infrastructure

There are five supported XML tags for the SAP NetWeaver Auto-ID

Infrastructure. The printer ignores any other XML tags/attributes not

defined in this document and no error is reported.

Syntax <Command>

<Item>

</Field>

</FieldList>

</Item>

</WriteTagData>

</Command>

Command This tag contains one or more WriteTagData tags.

There are no attributes required. The xmlns:xis

attribute is ignored.

WriteTagData This tag contains one or more Item tags. There are

no attributes required. The readerID attribute is

ignored.

Item This tag contains one FieldList tag or multiple TagID

tags. There are no attributes required. The TagID

tag is ignored.

FieldList This tag contains one or more Field tags, which may

include one or more of the following attributes:

format The default name of the format. This

name must match the one specified in

the Format Header.

This attribute is required.

jobname This attribute is ignored.

quantity Quantity to print. 1 is the default.

This attribute is optional.

Field This tag specifies the field name and the variable

field data. It must contain the following attribute:

name The name of the field that matches the

ones specified using Option 21. It must

contain the variable data (batch data)

associated with the format.

Note: The SAP software sends RFID

data in a field named “EPC”.

Apply Option 21 to the RFID Data

Field and name that field “EPC”.

8 Quick Reference

Sample MPCL Format

{F,1,A,F,E,600,400,"EPC_FORMAT_3"¦

C,560,10,0,1,1,1,O,L,0,0,"DOCUMENT_NO:"¦

T,1,40,V,560,140,0,1,1,1,O,L,0,0¦

R,21,"DOCUMENT_NO"¦

C,520,10,0,1,1,1,O,L,0,0,"DOCUMENT_TYPE:" ¦

T,2,40,V,520,150,0,1,1,1,O,L,0,0¦

R,21,"DOCUMENT_TYPE"¦

C,480,10,0,1,1,1,O,L,0,0,"EPC_TYPE:" ¦

T,3,40,V,480,110,0,1,1,1,O,L,0,0¦

R,21,"EPC_TYPE"¦

C,440,10,0,1,1,1,O,L,0,0,"EPC_URN:"¦

T,4,60,V,420,20,0,1,1,1,O,L,0,0¦

R,21,"EPC_URN"¦

C,380,10,0,1,1,1,O,L,0,0,"EPC_URN_NO_HEADER:"¦

T,5,40,V,380,180,0,1,1,1,O,L,0,0¦

R,21,"EPC_URN_NO_HEADER"¦

C,340,10,0,1,1,1,O,L,0,0,"GTIN:"¦

T,6,40,V,340,80,0,1,1,1,O,L,0,0¦

R,21,"GTIN"¦

C,300,10,0,1,1,1,O,L,0,0,"PRODUCT:"¦

T,7,40,V,300,100,0,1,1,1,O,L,0,0¦

R,21,"PRODUCT"¦

C,260,10,0,1,1,1,O,L,0,0,"PRODUCT_DESCRIP:"¦

T,8,40,V,260,160,0,1,1,1,O,L,0,0¦

R,21,"PRODUCT_DESCRIPTION"¦

X,99,24¦

R,21,"EPC"¦}

This MPCL format uses:

♦ format – EPC_FORMAT_3

♦ text field – DOCUMENT_NO

♦ text field – DOCUMENT_TYPE

♦ text field – EPC_TYPE

♦ text field – EPC_URN

♦ text field – EPC_URN_NO_HEADER

♦ text field – GTIN

♦ text field – PRODUCT

♦ text field – PRODUCT_DESCRIPTION

♦ RFID data field – EPC (line beginning with X).

Sample XML Print Job

<?xml version="1.0" encoding="UTF-8" ?>

<Command xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance" xsi:noNamespaceSchemaLocation="Command.xsd">

<Item>

<FieldList format="EPC_FORMAT_3"

jobName="WRITE20051215190125" quantity="1">

<Field name="EPC_TYPE">SGTIN-96</Field>

<Field name="EPC_URN">urn:epc:tag:sgtin-

96:3.0037000.065733.28</Field>

<Field name="PRODUCT_DESCRIPTION">RFID Material 1</Field>

</FieldList>

</Item>

</WriteTagData>

</Command>

This XML print job uses:

♦ format – EPC_FORMAT_3

♦ text field – DOCUMENT_NO with data – Nov_29_02

♦ text field – DOCUMENT_TYPE with data – 51

♦ RFID Data Field – EPC with data – 30740242204031400000001C

♦ text field – EPC_TYPE with data – SGTIN-96

♦ text field – EPC_URN with data – urn:epc:tag:sgtin-

96:3.0037000.065733.28

♦ text field – EPC_URN_NO_HEADER with data – 3.0037000.065733.28

♦ text field – GTIN with data –00037000657330

♦ text field – PRODUCT with data – RFID_MAT1

♦ text field – PRODUCT_DESCRIPTION with data – RFID Material 1.

10 Quick Reference

Sample Label

Andere Handbücher für Monarch 9825

Dieses Handbuch passt für folgende Modelle

Andere Avery Dennison Drucker Handbücher

Avery Dennison

Avery Dennison SNAP 700 Bedienungsanleitung

Avery Dennison

Avery Dennison Pathfinder 6059 Technisches Dokument

Avery Dennison

Avery Dennison Monarch 9419 Bedienungsanleitung

Avery Dennison

Avery Dennison MONARCH 9416 XL Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Platinum 9462 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch 9419 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch ADTP2 EcoCut Service-Handbuch

Avery Dennison

Avery Dennison SNAP 500 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch 9460 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Platinum 6039 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch 9825 Montage- und Bedienungsanleitung

Avery Dennison

Avery Dennison AP4.4 Bedienungsanleitung

Avery Dennison

Avery Dennison 9688 Bedienungsanleitung

Avery Dennison

Avery Dennison SNAP 600 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch Service-Handbuch

Avery Dennison

Avery Dennison Monarch Pathfinder Ultra Silver 6032 Service-Handbuch

Avery Dennison

Avery Dennison ALX 92x Betriebsanleitung

Avery Dennison

Avery Dennison Monarch SIERRA SPORT4 9493 Bedienungsanleitung

Avery Dennison

Avery Dennison 9486 Bedienungsanleitung

Avery Dennison

Avery Dennison FRESHMARX 9416 Technisches Dokument

Avery Dennison

Avery Dennison Monarch 9419 Service-Handbuch

Avery Dennison

Avery Dennison LOKPRINT 676 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch Tabletop Printer 2 Bedienungsanleitung

Avery Dennison

Avery Dennison Monarch 9460 Service-Handbuch

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
