AVPro Edge AC-MX-44HDBT Bedienungsanleitung

User Manual

18Gbps True 4K60 4:4:4, 4x4 Matrix with four

HDMI inputs as well as four mirrored HDBaseT

outputs blocks.

AC-MX-44HDBT

INTRODUCTION ��4

FEATURES ��4

WHATS IN THE BOX ��4

SPECIFICATIONS ��5

COMPATIBLE HDBASET RECEIVERS ��6

FRONT AND REAR PANEL OVERVIEW ��7

INITIAL SETUP: WEBUI ��8

ADVANCED SETUP: WEBUI INPUT SETTINGS �� 12

ADVANCED SETUP: WEBUI OUTPUT SETTINGS �� 13

ADVANCED SETUP: WEBUI EXTRACTED AUDIO OUTPUT SETTINGS �� 14

WEBUI: VIDEO MATRIX �� 16

WEBUI: AUDIO MATRIX �� 17

WEBUI: I/O CONFIG - INPUT SETTINGS �� 18

WEBUI: I/O CONFIG - INPUT SETTINGS CONT� �� 19

WEBUI: I/O CONFIG - OUTPUT SETTINGS �� 19

WEBUI: I/O CONFIG - OUTPUT SETTINGS CONT� �� 20

WEBUI: I/O CONFIG - OUTPUT SETTINGS CONT� �� 21

WEBUI: I/O CONFIG - OUTPUT SETTINGS CONT� �� 22

WEBUI: SYSTEM - IP SETTINGS �� 23

WEBUI: SYSTEM - RS232 SETTINGS �� 23

WEBUI: SYSTEM - TELNET SETTINGS �� 24

WEBUI: SYSTEM - ADMIN WEB INTERFACE �� 24

WEBUI: SYSTEM - USER WEB INTERFACE �� 25

WEBUI: SYSTEM - CLOUD SERVICES �� 26

WEBUI: SYSTEM - FIRMWARE UPDATE CONT� �� 27

WEBUI: SYSTEM - HARDWARE �� 27

WEBUI: DIAGNOSTICS - HDMI IN �� 28

WEBUI: DIAGNOSTICS - HDMI IN CONT� �� 29

WEBUI: DIAGNOSTICS - HDMI OUT �� 30

WEBUI: DIAGNOSTICS - HDBT OUT �� 31

WEBUI: DIAGNOSTICS - HDBT OUT CONT� �� 32

WEBUI: CONSOLE �� 33

FRONT PANEL CONTROL - SWITCHING �� 34

FRONT PANEL CONTROL - EDID �� 35

FRONT PANEL CONTROL - AUDIO �� 36

FRONT PANEL CONTROL - NETWORK �� 36

FRONT PANEL CONTROL - IR REMOTE: �� 37

IR REMOTE CONTROL: �� 37

IR CONTROL: �� 38

IR CONTINUED: �� 40

RS-232 AND TCP/IP CONTROL: �� 41

COMMAND LIST: �� 42

COMMAND LIST CONTINUED: �� 43

COMMAND LIST CONTINUED: �� 44

EXTRACTED AUDIO: �� 45

AUDIO OUTPUT LOGIC AND CABLE PREP: �� 46

TROUBLESHOOTING �� 47

BANDWIDTH CHART �� 47

MAINTENANCE �� 48

DAMAGE REQUIRING SERVICE �� 48

SUPPORT �� 49

WARRANTY �� 49

The AC-MX-44HDBT is a true 4x4 HDMI/HDBaseT matrix switch. This unit includes 4 HDMI inputs and 4

HDMI/HDBaseT output blocks. These output blocks include an HDBaseT and HDMI port, these ports are

mirrored, and both are active. This Matrix supports HDMI 2.0(a/b), HDCP 2.2, up to 4K video resolution,

and up to 18 Gbps bandwidth. We can pass 18Gbps through category cable by using the new HDBaseT

technology we have developed called “ICT”, learn more about ICT below. This switch allows any source

(Blu-ray, UHD Blu-ray, satellite receiver, game consoles, PCs, etc...) to be shown on any of the connect-

ed displays. This matrix equalizes and amplies the output to ensure the HDMI signal can be transmitted

through long HDMI cables without loss of quality.

Audio Delay is “On-Board” so you can manage lip-sync issue before it is a problem. Also, with built-in Scal-

ers you don’t have to forfeit that 4K signal just because you have a couple of older displays. All that with

Full EDID management allows maximum exibility with today’s wide mixture of sources and displays.

Features

·HDMI 2.0(a/b)

·18Gbps Uncompressed Bandwidth Support on HDMI

·18 Gbps with ICT on HDBaseT outputs

·4K60 4:4:4 Support

·Full HDR Support (HDR 10 & 12 Bit)

·Dolby Vision, HDR10+ and HLG Support

·HDCP 2.2 (and all earlier versions supported)

·1080p > 4K Up Scaling on HDMI outputs

·4K > 1080p Down Scaling on HDBaseT outputs

·Advanced EDID Management

·IR, RS-232 and LAN Control Options

·Digital Toslink Out (7CH PCM, DD, DD+, DTS, DTS-MA)

·Balanced Analog Out (2CH PCM)

·Audio Delay for Digital & Analog Out

·HDBaseT Compatibility mode for mixed systems! (More

below)

·Driver Support for Crestron, C4, RTI, ELAN and more!!!

·Extracted Audio Supports DD+, DTS Master Audio on

Toslink

·Extracted Audio has 3 Operating Modes. Bound to

Input, Bound to Output, or Independent Matrix

·Built in Test Pattern on Each Output to Verify Infrastruc-

ture

Whats in the box

·AC-MX-44HDBT Matrix

·IR Remote Control (*No Battery Included)

·IR Extension Cable

·48v Power Supply

·RS-232 terminal blocks

·Rack ears

·Grounding Strap

·x4 AC-CABLE-5PIN-2CH audio adapters

Introduction

*3V CR2025 Battery Required For IR Remote Control

Not Included

Specications

Compatible HDBaseT Receivers

AC-EX70-444-RNE (Receiver /No Ethernet)

·70M 4k 60 4:4:4 & HDR

·100M 1080P

AC-EX70-SC2-R (Scaling Receiver)

·70M 4k 60 4:4:4 & HDR

·100M 1080P

AC-CX100-RAMP

·70M 4k 60 4:2:0 & HDR

·70M 1080P

AC-EX70-UHD-R

·40M 4k 30 4:4:4/4k 60 4:2:0

·70M 1080P

Non AVPro HDBaseT Receivers may work but ICT (our Invisible Compression Technology) will not. This

means higher bandwidth signals (greater than 10.2Gbps) will not pass as this requires ICT.

Front and Rear Panel Overview

Initial Setup: WebUI

1. With the AC-MX-44HDBT placed into its new home (AV Rack, cabinet, table top) take a Phil-

lips head screwdriver and attach the included yellow ground strap to the back of the chassis

using the pre-installed screw, then attach the other end to a suitable grounded object.

2. Connect the HDMI Input sources to the HDMI Inputs on the back of the matrix.

3. Connect the HDMI/HDBaseT devices to the HDMI/HDBaseT Outputs.

4. Connect the network LAN cable to the RJ45 port labeled LAN (between the Micro USB and 3pin RS232

port).

5. Power on the sources (Inputs).

6. Power on the Output devices/displays.

7. Connect the 48V power supply to power on the matrix and then to a suitable power source.

8. In order to see the current IP settings, press and hold (for 3 seconds) INPUT 3 and INPUT 4 buttons

simultaneously. This screen will change every 3 seconds showing

additional settings (host, net mask, router IP).

NOTE: This screen starts with the current IP address of the matrix.

9. To Enable/Disable DHCP, press and hold INPUT 1 and INPUT 4 at the same time for 3 seconds. With

the matrix connected to the local network, using a computer on the same network open up a web

browser and type the HIP (Host IP Address) into the address bar to navigate to the WebUI.

10.With the WebUI open, navigate to System. Click on the Privacy Policy and Terms of Use, this will open

these documents in a new tab for review. Once read click on the boxes next to each to agree. When

both are checked the switch for Enable Cloud Services will be selectable (will be red or disabled by

default). Click to enable (the switch will turn green).

The AC-MX-44HDBT can be controlled using the Micro USB port, 3pin RS232, or over TCP/IP using the LAN

connection. For initial setup it is recommended to connect the matrix to a local area network (LAN) and use

a computer on the same network in conjunction with the built in WebUI. After making all the physical con-

nections, the rst step will be to check for any Firmware Updates. The below steps are an example of this

setup, other control options are covered in separate sections of this user manual.

11. With the AVProEdge WebUI open, navigate to System. Click on the Privacy Policy and Terms of Use,

this will open these documents in a new tab for review. Once read click on the boxes next to each to

agree. When both are checked the switch for Enable Cloud Services will be selectable (will be red or dis-

abled by default). Click to enable (the switch will turn green).

12. With the Cloud Services enabled under the Hardware section click the Update Firmware button to

check for new Firmware OTA (over the air). This will compare the rmware versions currently loaded on

the AC-MX-44HDBT and compare to the latest available. If it is up to date, you will see a prompt stating

“No update available!”

13. If an update is available, the following prompt will show. Simply click UPDATE.

14. If a new update is available a le will automatically be selected, simply click the UPLOAD button to

load the rmware les to the Matrix. Uploading does not install the Firmware, that is the next step.

15. Once the rmware le has been uploaded, it will display all containing rmware les. Here you can

select individual rmware les to load or simply leave all les/options selected. If the version currently in-

stalled is not newer (does not need to be updated), then that update will be skipped automatically. Click

the UPGRADE button to start.

16.Once the progress bar hits 100% click the CLOSE button, the rmware upgrade process is complete.

17. With the Firmware up to date it’s time to start setting up the matrix. With the AVPro Edge WebUI open,

navigate to the I/O Conifg section. Label the applicable Inputs (Apple TV, Cable Box, Roku, etc) under

the Input Settings - Label.

18.Label the Outputs (Living Room, Bedroom, Den, etc) under the Video Output Settings - Label.
