Axicon 12600 Bedienerhandbuch
1
AXICON
BARCODE VERIFIER
Model 12600
Model 12700
(with “Trucheck” software)
DOCUMENTATION BOOKLET
www.axicon.com
© Copyright
2014 Axicon Auto ID Ltd
2
Axicon 12700 Start-Up Guide
CONTENTS
Page
START UP GUIDE
Important information 6
Minimum System Requirements 7
What’s in the transit case 8
Software Installation 9
Hardware installation 11
Software Configuration 12
User Calibration 15
How to use the verifier 18
The Verification Report 20
Explanation of the 2D ISO parameters 22
AXICON SOFTWARE LICENCE AGREEMENT AND TERMS 24
(INCL DISCLAIMER ETC)
AXICON WARRANTY AND SERVICE CONTRACT
Warranty on all Products 27
Service Contract 28
VERIFIER SERVICING & FACTORY RECALIBRATION (VCAS)
Axicon Factory Recalibration Service (VCAS) 29
Other faults or damage 30
Equipment Rental Scheme 30
CONTACT US 31
SERVICE RECORD 32
- 4 -
Axicon 12700 Start-Up Guide
5
Thank you for purchasing an Axicon Model 12700 2D Verifier. This
short guide will enable you to get started with your Axicon 2D
Verifier quickly and easily.
This Axicon Verifier is a precision piece of quality control
equipment.
It has been manufactured to the highest standards through our ISO
9001 Quality Management System and has been thoroughly and
extensively tested immediately prior to shipment.
When used in accordance with the manufacturer’s instructions this
equipment will provide accurate quality analysis for a minimum of
12 (twelve) months from the date of testing shown on the
Certificate of Conformance.
Different operating conditions will affect the frequency with which
this equipment will need to be serviced.
We recommend that this equipment is regularly checked and re-
certified. This can be done either by returning the verifier to
Axicon for a VCAS (Verifier clean and service) program or else by
purchasing the optional “Performance Qualification Test Kit” that
comprises a test program and a set of traceable Reference Test
Cards which, by following the instructions, will enable the user to
re-certify the equipment after satisfactory on-site testing or else
know for certain that the equipment needs returning to the
manufacturer for servicing.
Axicon 12700 Start-Up Guide
6
IMPORTANT INFORMATION
1. Your Axicon verifier is a piece of high precision quality control
equipment and should be handled with due care.
2. Please retain the plastic transit case. It will protect the
equipment in transit.
3. Only use power and data cables supplied by Axicon. Use of non-
approved accessories will invalidate the warranty.
4. If the verifier is dropped (or subjected to similar misuse) the
accuracy of the results may be affected. The unit should be
returned to Axicon immediately for servicing.
5. Axicon recommends that the verifier is factory recalibrated
annually. The unit should be returned to Axicon or to your
approved Axicon reseller for this check to be performed.
Axicon 12700 Start-Up Guide
7
MINIMUM SYSTEM REQUIREMENTS
System required :
- A Microsoft-supported version of Windows (32 or 64 bit)
- 512 MB of RAM (Minimum)
- A USB 2.0 port
- Microsoft .NET Framework Version 3.5 SP1 or later
The following table shows the various models in the Axicon 12000
series which can be used in conjunction with this software – and
their typical applications:
Model Field of
View Applications
Axicon
12000 24 x 18 mm High resolution 2D codes
Axicon
12500 40 x 24 mm High to medium resolution 2D codes
Axicon
12600 51 x 38 mm EAN/UPC and 2D codes
Axicon
12700 70 x 51 mm EAN/UPC and large 2D Codes
Axicon 12700 Start-Up Guide
8
WHAT’S IN THE TRANSIT CASE?
Please ensure that the following items are present upon receipt.
• Axicon 12000 series 2D verifier
• Power supply and fly lead
• Mains lead
• Software CD
• Wallet containing Documentation Booklet (includes Start Up
Guide), Conformance Certificate and Calibration Sheet
OPTIONAL EXTRAS
Axicon also offer the following optional extras to be used in
conjunction with the system:-
-IQ/OQ Procedural Documentation
-Performance Qualification Test Kit – Comprising a set of
test cards traceable to international standards and full
procedural instructions. (Use of this kit enables users to
run sufficient tests to empower them to re-certify the
verifier on-site.)
-Set of Reference Test Cards – traceable to international
standards (ideal for optimising the location, angle,
distance etc of on-line scanning equipment)
Axicon 12700 Start-Up Guide
9
SOFTWARE INSTALLATION
Note:- Please do NOT connect the verifier to the PC at this stage –
the software MUST be installed first and only once this has
been completed should the verifier be connected.
• The “Trucheck” application software supplied with this product
requires the .NET Framework version 3.5 to be installed.
The software installation process will automatically check
whether the .NET framework is present. If it is not present then
the installation process will install it for the user.
• Insert the CD into an
appropriate drive and the
Install program should start
automatically. If not run
“Setup.exe”
Set the location where you
would like the software
installed (the default is
shown).
Also at this stage specify
whether the installation
should be for a single user
or all users.
Axicon 12700 Start-Up Guide
10
The user will be asked to confirm the installation before it
proceeds which will then be confirmed:-
At this point the user will be asked to confirm that they want
to install the (essential) USB drivers.
Please press “Install” to install the drivers
After the software installation has been completed, please
connect the verifier to install the USB drivers prior to
running the software.
