©2020 Babcock-Davis
Rev 8/2020
Installation, Operation & Maintenance
Fore Blanket Cabinet
Model(s): BBC-6601/BBC-6603/BBC-6605/BBC-6606/BBC-6607/BC-6609
4. Secure cabinet into the wall studs by installing #12 by 2” self-drilling mounting screws.
Fire Rated Cabinets
Fire Rated Extinguisher Cabinets can be installed in either metal or wood stud walls. All framing dimensions
must correspond with the dimensions indicated on our submittals.
1. Framing must be on all four (4) sides of the cabinet. Where load bearing studs are cut, a load bearing
header or frame out must be installed above the cabinet to maintain the load bearing integrity of the
wall.
2. Position the cabinet in the wall, verifying that the backside of the cabinet frame is flush against the wall
surface.
3. Drill pilot holes at least every 12” on each side of the cabinet through the double tub construction and
continue drilling through the studs.
4. Secure cabinet into the wall studs by installing #12 by 2” self-drilling mounting screws.
OPERATION
Fire Cabinets are designed and built for years of dependable wall access.
MAINTENANCE
oFire Cabinet doors should be manually operated once a year to check performance.
oLubricate moving parts such as hinges and latches with a silicone spray lube as required to
maintain a smooth opening and closing of the door. Do not overlubricate. Do not use
regular lubricating oil that can attract dust and grit.
oNon-moving parts can be cleaned with a mild soap or dishwashing detergent and water
solution.
oGaskets can be cleaned with a clean, damp, lint-free cloth. Do not apply mineral oils, vinyl
dressings, or other lubricants to the gasket as they can cause the gasket to break down over
time.
QUESTIONS?
For more information on installation, repair or replacement, please visit
www.Babcockdavis.com or call (888)-4123726
