Baby Lock Audrey BL67 Bedienungsanleitung

Model BL67

Getting to Know:

A-LINE SERIES

Baby Lock Consumer Helpline: 800-313-4110

www.babylock.com

A-LINE SERIES

Model BL67

No matter where you love to sew, Audrey is the free-spirited friend you’ll want by your side. At

just 12.8 lbs., this lightweight machine can easily travel or attend classes with you. Don’t worry,

Audrey has packed plenty of features for the road, like 66 built-in stitches, push button features,

a drop-in bobbin and plenty of accessories.

This Getting to Know Guide will take you through a simple, step-by-step process on how to

wind your bobbin, thread the machine, set stitches and more. Once you’re familiar with your

machine, refer to the instructions and reference guide (packaged with your machine) for

additional directions.

Like all machines in theA-Line Series, Audrey has the features and the durability to handle all

of your projects – you can always count on her to be there for you. Be sure to ask your Baby

Lock Retailer aboutAudrey’s friends in theA-Line, like Lauren, Natalie, Maria and Grace. From

classic tailored looks to modern-day fashions, the machines in the A-Line Series will help you

sew and serge with success – all with the quality you’ve come to expect from Baby Lock.

Winding the Bobbin

REMOVING THE BOBBIN

1 Remove the bobbin cover by sliding the release lever to the right and push down the left corner of

bobbin cover at the same time.

2. Remove the bobbin from the machine.

1. Raise the presser foot lever. Pivot spool pin into highest position. Place a spool of thread on the spool

pin. Secure it with the spool cap to ensure smooth flow of thread. Use a spool cap closest in size to

the spool of thread being used.

2. Pass thread from the spool through the thread guides as shown.

3. Pull the end of thread through hole in bobbin as shown.

4. Move bobbin winder shaft to the left. Place bobbin onto shaft until it clicks into position with the end

of thread coming from top of bobbin. Push bobbin winder shaft to the right until it clicks. Hold onto the

end of thread.

5. Start machine to wind the bobbin. Stop machine after a few turns to trim the thread tail with scissors.

Bobbin will stop turning when completely filled. Cut the thread and push shaft to the left to remove

bobbin.

WINDING THE BOBBIN

Inserting the Bobbin

1. Place the bobbin into the bobbin holder with the thread unwinding counterclockwise.

2. Draw the thread into notch (A).

3. Pull the thread toward the left and along the inside of spring (B) until it slips into notch (C) being sure

that thread does not slip out of notch (A).

4. Pull thread out about 10 inches and replace the bobbin cover by inserting the left side and lowering the

right side until it snaps into position.

CBA

Threading the Machine

THREADING THE UPPER THREAD

1. Raise the presser foot lever.

2. Press the needle up / down button or rotate the handwheel toward you to raise the needle in the up position.

3. Place a spool of thread onto the spool pin and secure with the proper size spool cap.

4. Pass the thread into the thread guide for upper threading and snap forward between the thread guide

and guide plate.

5. Bring thread forward down the right channel, then to the left and up the left channel.

6. Pull the thread through and into the take-up lever from left to right.

7. Pass the thread down the left channel and into the thread guide at the base of the face cover.

8. Pass the thread from right to left into the thread guide on the needle clamp.

9. Thread the needle from front to back or follow directions for needle threader on next page.

Using the Needle Threader

1. Lower the presser foot.

2. Set needle in up position.

3. Lower the threader slowly and draw thread through thread guide (A) and pull toward the right.

4. Lower the lever as far as it will go. The threader will turn and the hook pin will go through the needle eye.

5. Position thread below the needle eye and under the hook pin.

6. Hold thread loosely and slowly return lever to original position. Hook will turn and pass thread through

needle eye while making a loop of thread.

7. Raise presser foot and pull thread out about 10 inches from needle eye.

Note: The needle threader can only be used for needle sizes 11, 14 and 16.

Raising the Lower Thread

DRAWING UP THE BOBBIN THREAD

1. Raise the presser foot.

2. Hold the upper thread loosely and press needle up/down button, which is the first button on the right.

The handwheel will turn one complete turn once you push this button.

3. Pull upper thread lightly. Bobbin thread will come up in a loop.

4. Pull both upper and bobbin threads about 10 inches toward the back and under the presser foot.

Selecting the Stitch

SETTING THE STITCH WIDTH AND STITCH LENGTH

Preset stitch length and stitch width are indicated by the number of LED lights. The longer or wider the stitch

length/stitch width is, more of the LED lights are on. Some stitches have a blinking light which indicates the setting

between two LED lights.

01. STRAIGHT STITCH

02. LEFT POSITION, STRAIGHT STITCH

03. QUILT STITCH, LIKE HAND SEWN

04. TRIPLE STRAIGHT STITCH

05. STEM STITCH FOR STRETCH FABRICS

06. ZIG ZAG STITCHING

07-14. BUTTONHOLES

15. 3-STEP ZIG ZAG

16. SATIN STITCH

17. RICK-RACK

18. OVERLOCK

19. DOUBLE OVERLOOK

20. SHELL

21. BLIND HEM

22. STRETCH BLIND HEM

23. DOUBLE ACTION

24. BRIDGING

25. FEATHER

26. FEATHER

27-66. DECORATIVE AND FUNCTIONAL STITCHES

may

has

button,

button.

Adjust thestitch widthby pressing For

widerstitch width,pressbuttontogetmore LED lights

displayed. Fornarrower stitch width, pressbutton

past ve LEDlights tilloneis litandthen continue.

For longer stitch length, press the button(A)

toget more LED lights. For shorter stitch

length, press the buttontoget allve LED

lightsdisplayed, then pressthe buttonagain

tillone LED is displayed and so on.

Patternbutton toselect the pattern

desired.

Pressyou get higher number

ofthepattern.

Press you get the lower

number of thepattern.

ExampleLED indicating 15

Pressyou getNo.16,17and so on.

Pressyouget No.14,13and so on.

Toselect pattern

VARIOUS NEEDLE POSITIONS

When straight stitch patternbeen

selected,stitchwidthbutton be

used toadjust the needle position.

21 22

20191817161514

615958 60 6362 64

2625 27

3029 31

65 66

54 55

43 44

32 33

10060403 05 0807 09 11

Starting to Sew

The machine will be set at 01 automatically to sew straight stitches when the power switch is turned on.

1. Raise the presser foot.

2. Place the fabric under the presser foot.

3. Lower the presser foot.

4. Hold both threads to the back when starting to sew. Let the threads go after sewing a few stitches.

5. While sewing, regulate the speed with the sliding speed control lever or foot control.

6. Stop the machine when you reach the end of the seam.

7. Raise the presser foot lever.

8. When you have reached the end of a seam, stop sewing and turn the handwheel toward you to bring the

needle to highest position. Raise the presser foot and pull the fabric out from under the foot to the back of

the machine. Cut the threads in the thread cutter on the left side of the machine.

Starting to Sew

REVERSE STITCHING

Reverse stitching is used for reinforcing the ends of the seams.

1. Place the fabric in position where back stitching is to be made and lower the presser foot.

2. Press reverse stitch button and sew 4-5 stitches. (If using the foot control, press pedal while pressing

reverse stitch button.)

3. Press start button and resume sewing. (If using the foot control, release reverse stitch button and press

the foot control to sew forward.)

4. When you reach the end of the seam, press the reverse stitch button and sew 4-5 reverse stitches.

SEAMING GUIDE ON THE STITCH PLATE

The figure on each guide line on the stitch plate indicates the distance between this guide line and the center

needle position. Guide the fabric along the specific guide line in order to get the desired seam allowance

between the stitching and the edge of the fabric.

1/2

7/8

201510

5/83/4
