Thank you for choosing our Baby Lock product.

For additional Baby Lock product information and updates, visit our website

at www.babylock.com.

Information found in this guide is current at the time of printing.

Please be aware that some contents of this manual and product

specifications are subject to change without notice.

The examples used throughout this guide are screens shots taken from

Windows 7.

Read this guide before installing.

Nous vous remercions d’avoir choisi notre produit Baby Lock.

Pour plus d’informations sur les produits Baby Lock et les mises à jour,

visitez notre site Web à l’adresse www.babylock.com.

Les informations contenues dans ce guide sont à jour au moment de

l’impression.

Le contenu de ce guide et les spécifications de ce produit peuvent être

modifiés sans avis préalable.

Les exemples utilisés dans ce guide sont des copies d’écran de Windows 7.

Lisez ce guide avant de procéder à l’installation.

Gracias por elegir nuestro producto Baby Lock.

Si desea obtener actualizaciones o información adicional acerca de los

productos Baby Lock, visite nuestro sitio web www.babylock.com.

La información que se encuentra en esta guía está actualizada al momento

de la impresión.

Tenga en cuenta que parte del contenido de este manual y las

especificaciones del producto están sujetas a cambios sin previo aviso.

Los ejemplos utilizados en esta guía son capturas de pantalla de Windows 7.

Lea esta guía antes de la instalación.

ENGLISH

CONTENTS

Accessories ................................................................................ 2

Contents of CD-ROM ................................................................. 2

Installation Overview ................................................................. 2

Computer Requirements............................................................. 3

Installation Procedure................................................................. 3

Accessories

The following items are included with your purchase.

Please verify all contents and if anything is missing or

damaged, contact your authorized Baby Lock retailer.

• CD-ROM (For details regarding contents, refer to

the following.)

• Installation Guide (this guide)

In addition, this kit contains sheets of embroidery

positioning stickers. These are necessary for using the

pattern connecting function. Refer to the Instruction

and Reference Guide for use.

• Embroidery positioning sticker sheets

Contents of CD-ROM

• Certification Key Issuing Wizard

• Enterprise™ Embroidery Upgrade IInstruction

and Reference Guide (PDF)

* Adobe Reader is required for viewing and printing the

Instruction and Reference Guide.

• Upgrade application for KIT I

Installation Overview

First, use the Certification Key Issuing Wizard on the

enclosed CD-ROM to obtain a Certification Key. Then,

use the Certification key within the Settings screen,

page 6, to activate the upgrade application for KIT Ion

the embroidery machine.

In the procedures section, indicates operations

performed with the embroidery machine and

indicates operations performed with the computer.

[Step 1] Make a note of the internal

machine identification number (No.).

[Step 2] Insert the CD-ROM into the

computer’s CD-ROM drive, and then

start the Certification Key Issuing

Wizard.

[Step 3] Follow the wizard instructions

for obtaining the Certification Key.

[Step 4] Install the upgrade application

for KIT Ion the embroidery machine.

[Step 5] Remove the USB media, and

turn the machine off and then on again.

[Step 6] After the upgrade has been

successfully installed, certify the “KIT I”

in the Settings screen of the embroidery

machine.

Note

• For details on proper use of the included

accessories see the Instruction and Reference

Guide viewable from the disc by clicking on the

“manual” folder and selecting your preferred

language.

You may also view the Instruction and Reference

Guide by clicking on the “manual_index.pdf” icon

contained within the disc and selecting your

preferred language.

Note

• Upgrade application data is contained in the

“BNT10_BNT10L” folder.

ENGLISH

Computer Requirements

Before starting the Certification Key Issuing Wizard,

check that the computer to be connected meets the

following operating conditions.

* “IBM” is a registered trademark of IBM Corporation in the United

States and other countries.

* “Windows XP”, “Windows Vista”, and “Windows 7”, are registered

trademarks of Microsoft Corporation in the United States and other

countries.

* Each company whose software title is mentioned in this guide has a

Software License Agreement specific to its proprietary programs.

All other brands and product names mentioned in this guide are

registered trademarks of their respective companies. However, the

explanations for markings such as ®and ™ are not exhibited

clearly within the text.

Installation Procedure

The following procedure describes how to upgrade

your embroidery machine to KIT I.

aMake a note of the 10-digit number (internal

machine identification number) displayed

beside “No.” on page 5 or 6 of the Settings

screen.

* The number of pages in the Settings screen may differ depending

on the version.

bInsert the CD-ROM into the computer’s CD-

ROM drive.

Computer IBM-PC or compatible computer

Operating System Windows XP, Windows Vista

and Windows 7

CD-ROM drive Required for installation

Others Internet connection available

and one available USB port

(required to upgrade the

embroidery machine) when

using computer

Note

• If the procedure described below is not fully

completed, your embroidery machine cannot be

upgraded to KIT I.

• Access to the Internet is required in order to obtain a

Certification Key.

Memo

• Make sure the internal machine identification

number (No.) is recorded accurately as these

numbers need to be entered within the Certification

Key Issuing Wizard in order to obtain the

Certification Key.

Internal

machine

identification

number (No.)

Version

number

Note

• The internal machine identification number that

appears beside “No.” is different from the machine

serial number (SER. NO.) located on the label

attached to the back of the embroidery machine.

Memo

• In Windows 7 or Windows Vista, when the AutoPlay

dialog box appears, click Open folder to view files.

cOpen the designated drive for your CD-ROM

(usually the “D” drive) on the computer (My

Computer), double-click to start the

Certification Key Issuing Wizard.

→The Select Language dialog box automatically

appears.

dSelect the desired language, and then click

OK.

→KIT ICertification Key Issuing Wizard appears.

eCarefully read the information that appears,

and then click Next.

fThe Wizard checks for the latest program on

the web.

If the file on the CD-ROM is the latest upgrade

file the following window appears. Click Next.

If the latest upgrade file is on the web select

your model and click Download, then save the

upgrade program (************.upf) on your

computer. Click Next.

Memo

• The following procedure can be used to start the

Certification Key Issuing Wizard.

1. Click Start.

2. Click Run or in the search box, type run, and

then, in the list of results, click Run.

→The Run dialog box appears.

3. Type the path to the application file

(D:\KeyWizard_Kit1.exe), and then click OK.

Note

• If the displayed version has already been installed in

the machine, click Next to continue with the

procedure without downloading the latest file.

ENGLISH

gType in the 15-digit CD key found on the label

attached to the CD-ROM envelope of the

upgrade kit, and then click Next.

If the following error message appears

Check below list for possible entry error(s).

To close the message, click OK.

• Are symbols or characters other than letters and

numbers entered?

• Has the uppercase letter “I” been entered in place of

the number “1”?

• Has the uppercase letter “O” been entered in place

of the number “0”?

hType in the internal machine identification

number (No.) written down in step a, and

then click Next.

If the following error message appears

Check that symbols or characters other than

numbers have not been entered. To close the

message, click OK.

iCarefully verify that the information has been

entered correctly and then click Certify.

• To change the entered information, click Back.

→Connect to the certifying server, and then obtain the

upgrade Certification Key.

Memo

• To help eliminate any confusion between the

number “0” and the uppercase letter “O” or “1” and

the uppercase letter “I”, the uppercase letter “O” and

“I” are not used in the CD Key. Also, no symbols are

used in the CD key.

Note

• In order to obtain the Certification Key, a connection

to the Internet must be established.

If the following error message appears

• Verify that the CD key and internal machine

identification number (No.) have been entered

correctly, and then repeat the procedure from step

c. To close the message, click OK.

• The CD Key is valid for use with only one

designated internal machine identification number

(No.).

Check that the CD key has been entered correctly,

and then repeat the procedure from step c. To

close the message, click OK.

• Check the Internet connection, and then click

Certify again. To close the message, click OK.

jWrite down the 8-digit Certification Key that

appears.

kClick Finish.

If the latest program has already been

installed in the machine

Skip the steps lto q, and then start the

procedure from step r.

lWhile pressing the “Automatic Threading”

button, turn the embroidery machine on.

Use USB media or a computer to install the upgrade

application for KIT Ion the embroidery machine.

If USB media is to be used, refer to the instructions that

follow.

If a computer is to be used, refer to page 8.

When using USB media to perform the installation

mCopy Upgrade application for KIT I

(************.upf) from the CD-ROM to the

USB media.

If you downloaded the latest program in step

f, copy the file (************.upf) from your

computer.

Note

• After upgrading the embroidery machine to KIT I,

the Certification Key must be entered in the

embroidery machine Settings screen.

Note

• Upgrade application data is contained in the

“BNT10_BNT10L” folder.

• Copy only the Upgrade application for KIT I to the

USB media; no other files should be on the media.

ENGLISH

nPress .

oInsert the USB media into the primary (top)

USB port connector on the right side of the

machine.

pPress .

qRemove the USB media.

Continue with step ron page 9.

Note

When the message “Upgrade complete.” appears,

installation of the upgrade application has been

completed.

(If an error occurs, a message will appear in red.)

When using a computer to perform the installation

mPress .

nPlug the USB cable connectors into the

corresponding USB port connectors for the

computer and for the machine.

→Removable Disk appears in Computer (My

Computer).

oCopy Upgrade application for KIT Ifrom the

CD-ROM to Removable Disk.

If you downloaded the latest program in step

f, copy the file (************.upf) from your

computer.

pPress .

Note

• Upgrade application data is contained in the

“BNT10_BNT10L” folder.

• The “Connected to PC. Do not disconnect the

USB cable.” message appears on the embroidery

machine LCD screen.

Inhaltsverzeichnis

Sprachen:

Andere Baby Lock Nähmaschine Handbücher

Baby Lock

Baby Lock Ellageo PLUS BLL2 Technisches Handbuch

Baby Lock

Baby Lock Soprano BLMSP Technisches Handbuch

Baby Lock

Baby Lock Quest PLUS BLQ2-PL Technisches Handbuch

Baby Lock

Baby Lock ellegante 2 BLG2 Bedienungsanleitung

Baby Lock

Baby Lock Euphoria BLC4 Technisches Handbuch

Baby Lock

Baby Lock Diana BL480A Technisches Handbuch

Baby Lock

Baby Lock Enterprise BNT10L Bedienungsanleitung

Baby Lock

Baby Lock Kinetic Frame Bedienungsanleitung

Baby Lock

Baby Lock Decorator's Choice BLDC2 Technisches Handbuch

Baby Lock

Baby Lock Enlighten BLE3ATW-2 Technisches Handbuch

Baby Lock

Baby Lock imagine wave BLE3ATW Bedienungsanleitung

Baby Lock

Baby Lock Quest BLQ2 Bedienungsanleitung

Baby Lock

Baby Lock Quilter's Choice BLQC2 Bedienungsanleitung

Baby Lock

Baby Lock Triumph BLETS8 Technisches Handbuch

Baby Lock

Baby Lock A-LINES Sofia BL137A Bedienungsanleitung

Baby Lock

Baby Lock Serenade BLSN Technisches Handbuch

Baby Lock

Baby Lock BL-6800 Bedienungsanleitung

Baby Lock

Baby Lock A-LINE Natalie BL18A Technisches Handbuch

Baby Lock

Baby Lock Symphony BLSY Bedienungsanleitung

Baby Lock

Baby Lock BLSOG Bedienungsanleitung

Baby Lock

Baby Lock Gallant Referenzhandbuch

Baby Lock

Baby Lock Pro-Line 097 Bedienungsanleitung

Baby Lock

Baby Lock Tiara II BLTR16-2 Technisches Handbuch

Baby Lock

Baby Lock Amelia BL100A Technisches Handbuch

Beliebte Nähmaschine Handbücher anderer Marken

Riccar

Riccar RL634DE Bedienungsanleitung

Singer

Singer 2517 Bedienungsanleitung

Pfaff

Pfaff 3307-1 SERIES Bedienungsanleitung

Janome

Janome Quilt Maker Pro 18 VERSA Bedienungsanleitung

Siruba

Siruba C007JP Bedienungsanleitung

Husqvarna Viking

Husqvarna Viking Designer SE Bedienungsanleitung

Singer

Singer 148-5 Bedienungsanleitung

IKEA

IKEA SY Bedienungsanleitung

Pfaff

Pfaff 571 Bedienungsanleitung

Singer

Singer 15-91 Bedienungsanleitung

Brother

Brother BB370 Bedienungsanleitung

Pegasus

Pegasus WT100 Series Bedienungsanleitung

Reliable

Reliable 7100DB Bedienungsanleitung

Pfaff

Pfaff 937 Bedienungsanleitung

Singer

Singer 6038 Bedienungsanleitung

Singer

Singer 413K Bedienungsanleitung

Pfaff

Pfaff 1471 E1 Bedienungsanleitung

Kenmore

Kenmore 16677 - Serger Sewing Machine Bedienungsanleitung
