PW-100 V5 PW-100 V5
6 7
SETTING UP FUNCTIONS
Setting up HORN tone
The default tone is Standard HORN, although the equipment allows to choose between
Standard HORN and B&G HORN, as explained below.
1.Press and hold HORN. 2.While HORN is held, press and hold
SIREN (3 s) until the tone changes.
3.To change tone again, repeat steps
1 & 2.
Setting up SIREN
SIREN function allows to choose among 4 different tones: WAIL, Hi-Lo, PHASER & YELP.
1.Press and hold SIREN (5 s) until the
siren sound briey pauses.
2.Press HORN to choose among tones. 3.Press SIREN to nish setup.
Setting up AUX
AUX allows to either play an auxiliary siren tone, or change the activation state of an
auxiliary load up to 15 Amp (useful to manage a light set or other devices).
1.Press and hold AUX (5 s).
If it beeps once, it’s set to AUX LOAD.
If siren stops & restarts, it’s set to
AUX SIREN.
2.Press SIREN to switch among AUX
LOAD and AUX SIREN.
If it beeps once, it’s set to AUX LOAD.
If siren stops & restarts, it’s set to
AUX SIREN.
3.Press AUX to nish setup.
Upon nishing beeps twice.
Setting up AUX SIREN tone
With AUX set to AUX SIREN, it is possible to select the AUX SIREN tone to one of the
available tones (WAIL, Hi-Lo, PHASER or YELP).
It is not possible to set the same tone for both SIREN and AUX SIREN, meaning that while
setting AUX SIREN, the SIREN tone in use will be unavailable; also, if the AUX SIREN tone
is selected for SIREN, AUX SIREN’s tone will automatically change.
1.Press and hold AUX (5 s) until the
siren sound briey pauses.
2.Press HORN to switch among the
available tones.
3.Press AUX to nish setup.
Setting up AUX LOAD
With AUX set to AUX LOAD, it is possible to set AUX LOAD in a way that it gets activated
together with SIREN (for instance, that when SIREN sounds, a light set associated to AUX
LOAD turns on)*, in addition to the activation by pressing AUX.
1.Press and hold AUX (5 s) until you
hear 1 beep.
2.Press HORN to switch AUX LOAD mode.
If it beeps once, it’s set to independent.
It it beeps twice, it turns on with SIREN.
3.Press AUX to nish setup.
Setting the volume of the internal speaker, “internal volume”
1.While INTER is on, press and hold
INTER.
2.While INTER is held, press WAIL to
increase volume.
3.While INTER is held, press HORN to
decrease volume.
Setting the volume of the external loudspeaker, “external volume”
1.Press and hold PTT. 2.While PTT is held, press WAIL to
increase volume.
3.While PTT is held, press HORN to
decrease volume.
External Volume Auto-Adjustment (VAA)
In addition to the manual adjustment, the equipment is capable of detecting the vehicle’s
level of acoustic isolation and adjust the maximum external volume accordingly.
To perform this procedure, close all of the vehicle’s doors and windows, and follow the
steps explained below.
To cancel the procedure, press PTT.
1.Press and hold PPT.
Remain silent during the procedure.
2.While PTT is held, press INTER.
Release both upon hearing a beep.
3.Wait up to 30 s, the equipment will
beep 2 times when VAA has nalized.
Enabling Hidden Siren Function
The equipment allows to silence the siren sounds, meaning that when this function has
been enabled and activated, the pressing of any of the siren buttons (SIREN, WAIL, HORN,
AUX SIREN) will not yield a response.
1.To switch between both states, press simultaneously
WAIL, HORN, AUX, SIREN, and hold for 5 s.
2.If it beeps 1 time, Hidden Siren is enabled.
If it beeps 2 times, Hidden Siren is disabled.
Activating / Deactivating Hidden Siren
Once Hidden Siren has been enabled, it is possible to activate it to effectively silent all
sirens, and deactivate to return all sirens to normal function.
1.To activate Hidden Siren, press and
hold INTER.
2.While INTER is held, press and hold
PTT until keyboard’s backlights blink.
3.Sirens will now be silenced.
1.To deactivate Hidden Siren, simultaneously press and hold
WAIL and HORN until keyboard’s backlights blink.
2.Sirens will now sound.
