BGL09RF-WIFI Wireless Thermostat User Manual
Technical Data
☆Power: Receiver:230Vac 50/60HZ ☆Range of temperature display: 0~40°C
Transmitter: USB power supply/4*AAA Batteries
! Pls remove batteries when USB power is working.
☆Display accuracy: 0.5°C ☆Insulating condition: Normal environment
☆Probe sensor: NTC(10k)1% ☆Running program: Set per 1 week as a cycle
☆Contact capacity: 5A/250V(WW);16A/250V(WE) ☆Output: Switch relay
☆Working environment temperature: 0~70°C ☆Installation: Wall mounted or on battery seat
☆Range of temperature adjustment: 5~35°C ☆Size(mm)：130*90*25
Home Screen
1 Short press to switch automatic mode and manual mode
2 Power on state, long press for 3-5 seconds to do programmable setting
3 Power off state, long press for 3-5 seconds to do advanced setting
1 Confirm key
2 Short press it to set time
3 Holiday mode setting.
1 Decrease key
2 Long press to lock /unlock
1 Increase key
2 Auto mode state, press , to enter into temporary manual mode
3 Long press to check external sensor temperature
(only used for the receiver with external sensor)
Time Setting
Power on state, press to set minute. Second press to set hour. Third press to set week.
Press , to change value. Press again to confirm.
Holiday Mode Setting
Power on state, long press for 3-5 seconds to do holiday mode setting. Press or to change
“OFF” to “ON”. Then press to switch days and temperature, press , to change value. Press
again to confirm. If you want to close holiday mode, press
Programmable Mode Setting
6 times period setting: 5+2 days(factory default),6+1 days, 7 days
Long press “ ” 3-5 seconds to do Programmable Mode Setting . Short press “ ” to switch and
confirm. Press “ ” and “ ” to adjust value.
Power on state, long press “ ” 3-5 seconds to enter into first time period then set hour. press “ ” and
“ ” to adjust hour, short press “ ” to confirm then set minutes, press “ ” and “ ” to adjust minutes,
press “ ” to confirm then enter into temperature setting, press “ ” and “ ” to adjust value. Pls
follow the steps of first time period to set second time period, thirdly time period ......
After finish setting , stand for about 10 seconds ,it will save setting then exit .
Download “Smart Life” app from Google
play and app store.
● When power on state, long press receiver
button“push” to match wifi. Normally on is EZ mode.
Blinking is AP mode. Successive blinking is matching.
● The App advanced password is 123456
!Considering battery usage, RF data updates
every 20 minutes. If shorten interval, pls use USB
power and remove batteries. Follow B05, B06
operation.
