MammoTomosynthesis5MP(MDMG5221)
5 MegaPixel display system for digital breast imaging, including breast tomosynthesis
Optimizedfordigitalbreasttomosynthesis
Barco'sMammoTomosynthesis5MPhasbeendevelopedtooptimizereading
andinterpretationofdigitalbreasttomosynthesis,agroundbreakingimaging
modalitythat significantly improvesaccuracy ofbreast cancer detection. Its
uniquetechnologiesfortomosynthesisvisualizationincreaseconspicuityofthe
smallest details, providing radiologists with a new degree of diagnostic
confidence.
The Mammo Tomosynthesis 5MP is the first display system availablefor
breast tomosynthesis. It iscleared by the US Food and Drug Administration
(FDA) foruse in standard and multiframe digitalmammographyas well
asbreasttomosynthesis.
Quickreadings,exceptionalresults
TheMammoTomosynthesis5MPensuresinstantdeliveryofimageswithout
motionblur,increasingcorrectdiagnosisandswiftworkflow.
Brightimages,moredetails
Featuringtwice the brightness ofconventional systems and lastingtwice as
long,theMammo Tomosynthesis 5MP offers unrivalledimage precision and
visibilityofthemostsubtledetails.
MammoTomosynthesis5MP(MDMG5221)
5 MegaPixel display system for digital breast imaging, including breast tomosynthesis
Lessnoise,improvedaccuracy
Screennoiseoftenhidessubtledetails.That'swhytheMammoTomosynthesis
5MP ensures pixelperfect images without disturbing screen noise, offering
clearervisibilityofdifferencesintissuedensity.
Guaranteedcompliance,diagnosticconfidence
Automatedchecksofcontrastandluminance,incombinationwithanonline
calibrationservice,resultin anoptimalworking environmentandworryfree
readings.
Technicalspecifications MammoTomosynthesis5MP(MDMG5221)
Screentechnology TFTAMLCDDualDomainIPSWideView
Activescreensize(diagonal) 541mm(21.3")
Activescreensize(HxV) 337.9x422.4mm(13.3x16.6")
Aspectratio(H:V) 4:5
Resolution 5MP(2048x2560)
Pixelpitch 0.165x0.165mm
Colorimaging No
Grayimaging Yes
Numberofgrayscales(LUTin/LUTout) 1024graylevels(10/12)
Viewingangle(H,V) 176°
PerPixelUniformity(PPU) Yes
RapidFrametechnology Yes
ILuminatebutton Yes
AmbientLightCompensation(ALC) Yes
IGuard Yes
Maximumluminance 2100cd/m²
DICOMcalibratedluminance(ULToff) 1000cd/m²
Contrastratio(darkreadingroom,typical) 950:1
Responsetime(Tr+Tf) 15ms(typical)
Scanningfrequency(H;V) 30150kHz;1580Hz
Housingcolor Gray
Videoinputsignals DP,DVI
Videoinoutterminals NA
USBports 1upstream+1endpoint,2downstream
USBstandard 2.0
Powerrequirements(nominal) 100240V
Powerconsumption(nominal) 125W
Powersavemode Yes
Powermanagement DVIDMPM
Dotclock 280Mhz
OSDlanguages English,French,German,Italian,Spanish
Dimensionswithstand(WxHxD) 392x558x250mm
Dimensionsw/ostand(WxHxD) 392x484x123mm
Dimensionspackaged(WxHxD) 780x550x261mm
Netweightwithstand 15.4kg
Netweightw/ostand 10.9kg
Netweightpackagedw/ostand 17.3kg
Heightadjustmentrange 100mm
Tilt 5°/+24°
Swivel 45°/+45°
Pivot 90°
Mountingstandard VESA(100mm)
Screenprotection Protective,nonreflectiveglasscover
Recommendedmodalities breasttomosynthesis,mammography,CT,MR,US,DR,CR,NM,Film
Technicalspecifications MammoTomosynthesis5MP(MDMG5221)
Certifications UL6060112NDEDITION,CAN/CSAC22.2NO.601.1M90:2005,IEC6060112ND
ED:1988+A1:1991+A2:1995,IEC609501:20052NDEDITION,CE2004/108/EC,
CE93/42/EC,A1:2007/47/ECCLASSIIB,DEMKOEN606011,CCC
GB92542008+GB49432001+GB17625.12003,BSMICNS13438(95)+
CNS14336(94),KC,VCCI,FCCclassB;FDA510(k),RoHs
Suppliedaccessories Usermanual,Videocable(DisplayPort),Maincables(UK,European(CEBEC/KEMA),
USA(UL/CSA;adaptorplugNEMA515P),Chinese(CCC)),USBcable,external
powersupply,filmclip,keyboardlight
Optionalaccessories NA
QAsoftware MediCalQAWeb
Unitsperpallet NA
Palletdimensions(WxH) NA
Warranty 5years
Colorsupport NA
UniformLuminanceTechnology(ULT) Yes
Generatedon:19Dec2013
Technicalspecificationsaresubjecttochangewithoutpriornotice.
Pleasecheckwww.barco.comforthelatestinformation.
