OverViewOL521
Fully redundant 50" full HD 16:9 LED video wall
Barco's OverViewOL series LEDlit video
walls are the first choice for 16:9
missioncritical control rooms that require a
guaranteeduptime.Themodules’highlevel
of redundancy, not only of the individual
LEDs, but also of the LEDs' power supplies
and even inputs,ensures nothing can go
wrong,givingusersthepeaceofmindthey
need. Featuring a structure that can be
tailoredtotherequirementsofthecustomer,
the OverView OL series knows virtually no
limitsinsize.
Ultimatepeaceofmind
TheOverViewOL521videowallmoduleshavebeendesignedforanentirely
maintenancefree operation over several years, without any need for
consumables. Barco's unique liquid cooling system ensures lower LED
temperature, resulting in longer LED lifetime (>80,000 hours in eco mode).
Displaying the sharpest and most saturated colors in full HD resolution
(1920x1080),theOverViewOL521offersanergonomicallyexcellentviewing
experience. The availability of alternative screen types makes sure you can
adjust the video wall to your specific needs in terms of viewing angle and
brightness.
Alwaysthemostoptimalpicture
OverView OL series video walls come with Sense6, Barco's unique sensor
technology that provides brightness and color stability over time and across
the entire display. Sense6 continuously measures brightness and color by
meansofahighqualityspectrometer,andadjuststhecolorspacetoprovide
an image that is most convenient for the human eye. This means that no
maintenance or manual adjustments are needed. The colors can also be
adjustedtotheveryspecificneedsofTVcameras,makingtheOverViewOL
seriessuitableforbackdropapplications.
OverViewOL521
Fully redundant 50" full HD 16:9 LED video wall
Awardwinningdesign
The OverView OL series’ design, combining usability with style, has been
laudedwiththeprestigiousRedDotDesignAwardandwasnominatedforthe
GermanDesignAward.Theindividualmoduleshavethesmallestdepthonthe
market today, allowing to build the most shallow video walls possible. This
makestheOverViewOLseriestheproductofchoiceforinstallationinconfined
spaces.
Technicalspecifications OverViewOL521
Resolution FullHD(1920x1080px)
Brightness onscreen:460Cd/m²
Onscreencontrast 560,000:1
Color Upto165%EBU(atmaximumcolormode)
Displaytechnology RearprojectionDLP
Whitepoint 2,300K|6,500K|9,300K|arbitrary
Brightnessuniformity 95%ANSI9
Screen FXS,withH/V34°/33°(+/3°)halfgainangle
Screengap Hor:0.8mm|0.03”,Vert.0.5mm|0.02”(@25°C)
Hor:<0.4mm|0.015”,Vert.<0.3mm|0.012”(@30°C)
Colorstability SelfcalibrationwithspectrometerbasedSense6
Dimensions •Diagonal:50"
•Width:1,088mm|42.8"
•Height:612mm|24.1"
•Depth:454mm|17.9"
•Weight:ProjectionModule:<44kg|97lbs
•Weight:Pedestal:<28kg|62lbs
Lightsource 6xredundancyforeachof3LED’s
Lightsourcelifetime >60,000h(at6500k)
>80,000hinecomode
MTBFLED>500,000h
Recommendedmaintenanceinterval >5years
Lifetimewarrantyagainstburninorimageretention
Conditionsforoperation 10°C40°C,50°F104°F,80%humidity(nc)
ACinputvoltage 90–240V,5060Hz
Power 170W(eco)
230W(typ.)
350W(max)
Heatdissipation 580BTU/h(eco)
785BTU/h(typ.)
1,194BTU/h(max)
Signal 2xDuallinkDVIin/2xDuallinkDVIout
Pixelclock 330MHz
Inputfrequency 24–62Hz
Genlock 49–61Hz
Minimumframedelay 1frame
Signalprocessing Loopthrough
Freecropping,freescaling(optional)
Directethernetaccess Builtinwebserver
Graphicaluserinterface Allsettingsandoperationalparameters
Integrationtothirdpartyequipment WEBserviceAPI(optional)
Warranty 2years
Generatedon:19Dec2013
Technicalspecificationsaresubjecttochangewithoutpriornotice.
Pleasecheckwww.barco.comforthelatestinformation.
