Barco D-Cine Premiere DP90P Bedienungsanleitung

Key benefits include:

• Increased detail in low light images thanks to:

Contrast ratio of 2500:1

• Improved brightness uniformity through: A guaranteed brightness uniformity of 80%

•Greater freedom for colorist & director through: Wide color gamut exceeding current DCI and SMPTE

recommendations

•Ability to create 2D & manage custom-built

3D look-up tables with: D-Cine Communicator (post production edition)

The Barco DP90P is the only digital cinema projector on the market today, specifically designed

and built to meet the enhanced performance needs of the post production market.

Based on 2k DLP Cinema™ technology from Texas Instruments, the DP90P projector is the first

dedicated post production projector to enable an enhanced color gamut, significantly exceeding

the current DCI recommended color space. When combined with a Post Production edition of

the D-Cine Communicator software, this increased color space provides the production

professional with the tools to perform at the highest level.

The DP90P comes fitted with a motorized lens holder and CLO software which ensures constant

light output of the projector over time.

D-Cine Premiere DP90P

Dedicated Post Production projector

DS DP90P may06 20-06-2006 09:32 Pagina 1

D-Cine Premiere DP90P specifications

www.barco.com/digitalcinema

Barco Digital Cinema - WW Headquarters

Noordlaan 5, 8520 Kuurne - Belgium

Tel: +32-56-36 80 47 - Fax: +32-56-36 83 86

e-mail: sales.digitalcinema@barco.com

Ref.no. R599115 - May 2006

Barco Projection Systems is an ISO 9001 registered company.

The information and data given are typical for the equipment described.

However any individual item is subject to change without any notice.

The latest version of this product sheet can be found on www.barco.com.

Digital Light Processing, DLP,

Digital Micromirror Device, DMD

and DLP Cinema are trademarks

of Texas Instruments Incorporated.

ITEA

Digital Micro Mirror Device™ 3 x 1.2” dark metal type

Advanced DLP Cinema™ signal processing with built-in 3D look-up table

Native resolution 2048 x 1080

Dust protection Hermetically sealed optical engine (DMD™ + prism)

DMD temperature management Liquid Cooling

Peltier heat extraction

Mounting Standing or ceiling mounted

Up to 7 degrees tilt via projection head

Lamp 1.5k to 4.0k Xenon arc lamp sizes

Compatible with standard and high performance lamp types

Brightness (at 14ftL and gain = 1.5) Meets or exceeds SMPTE screen brightness standards

(without anamorphic) up to 10m (32.8ft) wide

Uniformity Exceeds the DCI and SMPTE draft recommendations (> 80%)

Contrast ratio 2500:1

Digital Video Inputs 2 x SMPTE 292M inputs and 2 x DVI input, both selectable as single or as dual link

Standard features Motorized lensholder

CLO software

Prime lenses M25 1.25 - 1.45:1 / M25 1.45 - 1.8:1 / M25 1.8 - 2.4:1 / M25 2.2 - 3.0:1 zoom

and M25 3.0 - 4.3:1

Extended color space

Exceeds the current DCI and SMPTE recommended color space

Native color points native red: x = 0.7 y = 0.3

native green: x = 0.2 y = 0.76

native blue: x = 0.145 y = 0.040

Projector diagnostics Via touch screen

Via D-Cine Communicator control software

Post production edition standard with every product

Via SNMP agent

Power requirements 1 x 220V

max. 17,000 BTU/hr (with 4kW lamp)

Dimensions projector:

640(H) x 730(W) x 1170(D) mm /

24.2(H) x 28.7(W) x 46.1(D) inch

powerbox:

295.3(H) x 329.5(W) x 473.7(D) mm /

14.6(H) x 13.0(W) x 18.6(D) inch

Weight projector: approx. 120kg (265lb)

powerbox: approx. 20kg (44lb)

Options • Anamorphic lens fitting for 1.25:1 scope lens

• Acsar 2 Alternative Content Input Processor

• ImagePRO HD

• SNMP agent (v3)

Order information R9004441

DS DP90P may06 20-06-2006 09:32 Pagina 2
