Barco RLM G5 Performer Bedienungsanleitung

www.barco.com

With its compact design and sealed optics, the RLM G5i Performer is an ideal all-round pro-

jector suitable to both the rental as well as staging markets.

Feature-rich and ready to use, the RLM G5i Performer allows everything from seamless

switching to picture-in-picture and enables you to show up to 4 sources simultaneously

on-screen.

With its sealed optics (prism and DMD’s), a dedicated lens range and compatibility with

the existing SLM Projector lenses, the RLM G5i Performer becomes the ideal staging or

corporate rental projector.

RLM G5i Performer

DS RLM G5i jan05.qxd 08-03-2005 10:33 Pagina 2

www.events.barco.com

RLM G5i Performer specifications

Ref.no. R599824 - January 2005

DLP™ technology by Texas Instruments offers crystal clear images with superior quality.

DLP is a trademark of Texas Instruments.

The information and data given are typical for the equipment described.

However any individual item is subject to change without any notice

The latest version of this product sheet can be found on www.events.barco.com.

Barco Events

Noordlaan 5, 8520 Kuurne - Belgium

Tel +32 56 36 8047 - Fax +32 56 36 88 24

email: sales.events@barco.com

705mm (27.8”)

707.8mm (27.9”)

289.7mm (11.4”)

24.5mm

(1.0”)

Light output (1) 4,500 Ansi DIMENSIONS

Resolution 1,024 x 768 (native)

Contrast ratio 1,000:1 (full field)

Lamp 2 x 250 W mercury

Lamp lifetime (maximum) 1,500 Hrs

Lamp lifetime (typical) 1,000 Hrs

Lamp lifetime (minimum) 750 Hrs

Max. ambient temperature 40°C (104°F)

Power consumption 700W

Mains voltage 92 - 240 V

Weight projector 25 kg (56 lbs)

Weight frame 5 kg (11 lbs)

Dimensions (W x L x H) 705 x 707.8 x 316.6 mm (27.8 x 27.9 x 12.5 inch)

FEATURES

Sealed DLP core standard

Scenergix standard horizontal & vertical electronic edge blending

Advanced picture in picture up to 4 sources simultaneous (2 data, 1 video, 1 SDI)

INPUTS

Input source compatibility (2) 1,600 x 1,200 (max. input)

Fixed inputs (standard) 1x configurable 5 cable (BNC) • 1x Composite Video (BNC) • 1x S-video (4-pin DIN)

1x analogue RGB (D15 connector) • 1x SDI (+ loop through) • 1x DVI

ORDER INFORMATION

Projector body (without lens) R9010320

Spare dual lamp R9852940

LENSES throw ratio on RLM G5i throw ratio on RLM G5i

Fixed focal lenses RLD 0.8 0.8 R9832640

TLD HB 0.8 1.0 R9842040

Zoom lenses RLD 1.5 - 1.8 1.5 - 1.8 R9832642 TLD HB 1.6 - 2.0 2.0 - 2.5 R9842060

RLD 1.8 - 2.25 1.8 - 2.25 R9832643 TLD HB 2.0 - 2.8 2.5 - 3.5 R9842080

RLD 2.25 - 3.0 2.25 - 3.0 R9832644 TLD HB 2.8 - 5.0 3.5 - 6.3 R9842100

RLD 3.0 - 4.5 3.0 - 4.5 R9832645 TLD HB 5.0 - 8.0 6.3 - 10.0 R9842120

RLD 4.5 - 7.0 4.5 - 7.0 R9832646

RLD adapter for TLD lenses R9832650

(1) optical spec. measurements with RLD 4.5 - 7.0:1 on axis at 220V

(2) all current video sources in composite, S-VHS, RGB or component or Serial digital format

all current proposed HDTV, extended and improved television standards (1080i, 720p, ...)

computer and workstations with a resolution up to 1,600 x 1,200

most Macintosh computers

direct digital interfacing with current and future digital standards

DS RLM G5i jan05.qxd 08-03-2005 10:33 Pagina 1
