Barco RLM R6+ Performer Bedienungsanleitung

www.barco.com

The RLM R6+ Performer projector is Barco’s latest high brightness mid venue projector with

6,000 Ansi Lumen (6,500 Center Lumen) light output. The RLM R6+ offers all the benefits

of the reliable RLM projector range, with the added benefit of SXGA+ resolution.

Renowned for its extreme low noise levels, the RLM R6+ is the ideal projector for use in

noise sensitive environments with higher brightness requirements.

With its sealed engine and long lifetime lamps, the RLM R6+ offers a reliable, high brightness

projection solution with a low total cost of ownership. Customers that invested in SLM

series can also re-use their TLD HB lenses, which lowers the investment cost of RLM R6+.

Having all digital inputs standard, the RLM R6+ is future proof and stands for high quality

image performance.

RLM R6+ Performer

DS RLM R6+ dec05.qxd 22-12-2005 10:42 Pagina 2

www.barco.com/events

RLM R6+ Performer specifications

Ref.no. R599817 - December 2005

DLP™ technology by Texas Instruments offers crystal clear images with superior quality.

DLP is a trademark of Texas Instruments.

The information and data given are typical for the equipment described.

However any individual item is subject to change without any notice

The latest version of this product sheet can be found on www.barco.com.

Barco Media & Entertainment

Noordlaan 5, 8520 Kuurne - Belgium

Tel +32 56 36 80 47- Fax +32 56 36 83 86

email: sales.events@barco.com

705mm (27.8”)

707.8mm (27.9”)

289.7mm (11.4”)

24.5mm

(1.0”)

Light output (1) 6,000 Ansi / 6,500 Center lumen DIMENSIONS

Resolution 1,400 x 1,050 (native)

Contrast ratio 1600:1 (full field)

Lamp 2 x 250 W mercury

Lamp warranty 1,000 Hrs

Max. ambient temperature 40°C (104°F)

Power consumption 700W

Mains voltage 92 - 240 V

Weight projector 25 kg (56 lbs)

Weight frame 5 kg (11 lbs)

Dimensions (W x L x H) 705 x 707.8 x 316.6 mm (27.8 x 27.9 x 12.5 inch)

FEATURES

Sealed DLP core standard

Scenergix standard horizontal & vertical electronic edge blending

Advanced picture in picture up to 4 sources simultaneous (2 data, 1 video, 1 SDI)

INPUTS

Input source compatibility (2) 1,600 x 1,200 (max. input)

Fixed inputs (standard) 1x configurable 5 cable (BNC) • 1x Composite Video (BNC) • 1x S-video (4-pin DIN)

1x analogue RGB (D15 connector) • 1x SDI/HDSDI (+ loop through) • 1x DVI

ORDER INFORMATION

Projector body (without lens) R9010270

Spare dual lamp R9852940

LENSES throw ratio on RLM R6+

Fixed focal lenses TLD HB 0.8 0.75 R9842040

Zoom lenses TLD HB 1.6 - 2.0 1.45 - 1.85 R9842060

TLD HB 2.0 - 2.8 1.85 - 2.55 R9842080

TLD HB 2.8 - 5.0 2.55 - 4.55 R9842100

TLD HB 5.0 - 8.0 4.55 - 7.3 R9842120

(1) optical specs measured with TLD 1.6 - 2.0:1 on axis at 220V

(2) all current video sources in composite, S-VHS, RGB or component or Serial digital format

all current proposed HDTV, extended and improved television standards (1080i, 720p, ...)

computer and workstations with a resolution up to 1,600 x 1,200

most Macintosh computers

direct digital interfacing with current and future digital standards

DS RLM R6+ dec05.qxd 22-12-2005 10:42 Pagina 1
