Instructions for use

KGI 2900/A

CB 18 M - 16M /1c PRODUCT DESCRIPTION GB

DE FR NL ES PT GRGB IT DK

SE NO FI

A. Refrigerator compartment

1. Crisper drawers

2. Crisper cover

3. Shelves / shelf area

4. Thermostat control knob / light

5. Top shelf

6. Door trays

7. Bottle shelf

8. Removable bottle retainer

9. Rating plate (at side of crisper drawer)

B. Freezer compartment

10. Upper basket (for fast freezing of fresh

food products)

11. Storage area for frozen or deep-frozen

food

12. Ice cube tray (inside basket)

13. Freezer compartment inner door panel

Cool zone

Intermediate temperature

Cold zone

Note: the number of shelves and the design of the accessories may vary depending on the model.

Shelves and door trays are all removable.

Warning: refrigerator accessories are not dishwasher-resistant.

CB 18 M - 16M /1c

4619 997 78992 DE FR NL ES PT GRGB IT DK

SE NO FI

The fridge-freezer is switched on by means of the thermostat knob in the refrigerator compartment. The

thermostat knob also provides temperature adjustment for both the refrigerator and freezer compartments.

Refrigerator / Freezer compartment controls

A. Thermostat knob

B. Light switch

C. Light diffuser

D. Freeze button

E. Thermostat control reference

Thermostat setting z: no refrigeration, no light

Thermostat setting 1:minimum cooling

Thermostat setting 7:maximum cooling

The average recommended thermostat setting is 3.

Pressing the freeze button (D) increases freezing power.

Fresh food will be completely frozen after 24 hours and the freeze function should be switched off.

When room temperature is lower than 16°C, activating the freeze function (D) will improve food

storage properties.

Note: The room air temperature, the number of times the door is opened and the position of the appliance

will affect the temperature of the fridge and freezer compartments. Take these factors into consideration

when you set the thermostat.

Removing the diffuser

1 - Hold the diffuser as shown and squeeze it slightly

2 - Slide it towards the rear of the appliance

GB CONTENTS

BEFORE USING THE APPLIANCE PAGE 13

SAFEGUARDING THE ENVIRONMENT PAGE 13

PRECAUTIONS AND GENERAL

RECOMMENDATIONS PAGE 14

HOW TO USE THE REFRIGERATOR

COMPARTMENT PAGE 15

HOW TO USE THE FREEZER COMPARTMENT PAGE 16

HOW TO DEFROST THE FREEZER

COMPARTMENT PAGE 18

HOW TO CLEAN THE REFRIGERATOR

COMPARTMENT PAGE 18

CARE AND MAINTENANCE PAGE 19

TROUBLESHOOTING GUIDE PAGE 19

AFTER-SALES SERVICE PAGE 20

INSTALLATION PAGE 20

ELECTRICAL CONNECTION PAGE 21

33051-gb.fm5 Page 12 Tuesday, December 22, 1998 3:52 PM

Your new appliance is a combined fridge freezer

exclusively for domestic use.

The freezer compartment can be

used to deep freeze fresh and cooked food,

make ice cubes, and for the storage of frozen

and deep-frozen food; defrosting the freezer is

a manual procedure. The refrigerator

compartment, which has an automatic defrost

feature, is used for the storage of fresh food and

beverages.

To get the most out of your new appliance,

read the user handbook thoroughly. The

handbook contains a description of the

appliance and useful tips for storing food.

Keep this handbook for future consultation.

1. After unpacking the appliance, make sure

that the doors shut properly. Any damage

must be reported to your retailer within 24

hours after delivery of the appliance.

2. Wait at least two hours without moving

the appliance before connecting it to the

power supply.

3. Appliance installation and electrical

connections must be carried out by a

qualified technician in accordance with the

manufacturer’s instructions and local

regulations.

1. Packing

The packaging material is 100% recyclable

(marked with recycling symbol). Adhere to local

regulations when disposing of packaging

material.

The packaging material (plastic bags,

polystyrene parts, etc.) is potentially dangerous

and must be kept out of reach of children.

2. Product

The appliance is made from recyclable materials

and must be scrapped in accordance with local

waste disposal regulations.

Make the appliance unusable by cutting off the

powercord.Theappliance must be consignedto

an authorised collection centre for the recovery

of refrigerant gas.

Information:

This appliance does not contain CFCs (replaced

with R134a) or HFCs (replaced with R600a -

Isobutane). For information, refer to the rating

plate affixed to the appliance.

BEFORE USING THE APPLIANCE

SAFEGUARDING THE ENVIRONMENT

33051-gb.fm5 Page 13 Tuesday, December 22, 1998 3:52 PM

•Use the refrigerator compartment only for

storingfreshfoodandbeveragesandusethe

freezer compartment only for storing frozen

food, freezing fresh food and making ice

cubes.

•Do not cover or close the air vents.

•Do not store liquids in glass containers in the

freezer compartment - danger of bursting.

•Donoteat icecubesoricelolliesimmediately

after taking them out of the freezer

compartment - risk of “cold” burns.

•Do not allow children to play or hide inside

the appliance - risk of becoming entrapped

and suffocating.

•Do not ingest the contents (non-toxic) of the

ice packs.

•Before cleaning or servicing, always unplug

the appliance or switch the power supply off.

Declaration of conformity

•This appliance is intended to come into

contact with foodstuffs and conforms to D.L.

108 of 25.01.1992 (European Directive

89/109/EEC).

Information

Appliances with isobutane (R600a)

Isobutane is a naturally occurring low

environmental impact gas. Caution is required,

however, because Isobutane is inflammable.

Take care not to damage the pipelines of the

refrigerant circuit.

PRECAUTIONS AND GENERAL RECOMMENDATIONS

33051-gb.fm5 Page 14 Tuesday, December 22, 1998 3:52 PM

This appliance is a refrigerator with a 4 star

freezer compartment.

Defrosting of the refrigerator compartment is

performed automatically.

The refrigerator can operate in room

temperatures between +10°C and +38°C.

Optimal performance of the appliance depends

on the climatic class, which is indicated on the

rating plate.

Switching on the appliance

Plug in the appliance.

The thermostat knob in the refrigerator

compartment serves to adjust the temperature in

both the refrigerator and freezer compartment if

your appliance is equipped with a single

compressor.

Refrigerator compartment and freezer

compartment temperature adjustment is

independent in the case of appliances with two

compressors (see product description sheet).

Temperature adjustment

1. To ensure correct operation and the best

possible food storage in both compartments,

set the thermostat in accordance with the

indications on the enclosed product

description sheet.

2. To alter the temperature in the refrigerator

andfreezercompartmentssetthethermostat

knob to:

•lower numbers 1-2 (MIN) if you want to

INCREASE the temperature;

•higher numbers 5-7 (MAX) if you want to

DECREASE the temperature.

Thermostat setting zswitches off all functions of

the appliance including the interior light.

Note:

The room air temperature, the number of times

the door is opened and the position of the

appliance will affect the temperature in the

refrigerator and freezer compartments. Take

thesefactors intoconsiderationwhenyouset the

thermostat. For example if the machine is

operated in a room with high temperature you

may need to set the thermostat to a low number.

Using the refrigerator compartment

Position the food as shown in the figure.

A Cooked food

B Fish, meat

C Fruit and vegetables

D Bottles

E Butter

F Dairy products, cheese

Notes:

•The space between the shelves and the rear

wall of the refrigerator compartment must be

unobstructed to allow air circulation.

•Do not place the food in direct contact with the

rear wall of the refrigerator compartment.

•Do not place hot food in the refrigerator.

•Store liquids in closed containers.

•Storage of vegetables with high water

contents can lead to the formation of

condensation: this will not affect the correct

operation of the appliance.

HOW TO USE THE REFRIGERATOR COMPARTMENT

33051-gb.fm5 Page 15 Tuesday, December 22, 1998 3:52 PM

The appliance has a 4 star freezer

compartment in which food canbe stored for

the time indicated on the packaging. The

freezer can also be used to freeze fresh food

by positioning it on the racks; place frozen

food in the lower basket so that there is no

contact with fresh food that has yet to be

frozen.

The quantity of fresh food that can be frozen

in 24 hours is shown on the rating plate.

Freezing fresh food

If your appliance is equipped with a single

compressor:

•Set the thermostat knob to 2-3.

•If the appliance is equipped with a freeze

button, press it to activate the function (the

yellow indicator light will switch on). Also the

red indicator light (models with control panel)

may switch on. The red indicator light will

switch off when the freezer compartment has

reached the optimum temperature.

Note:

The freeze function makes it possible to freeze

fresh food while maintaining the temperature in

the refrigerator compartment at the optimum

level.

Rapid freezing function

If your appliance is equipped with two

compressors,activate the rapidfreezing function

6 hours before inserting fresh food to obtain the

maximum freezing power as indicated on the

rating plate.

Important:

•Before freezing, wrap and seal fresh food in:

aluminium foil, cling film, air and water-tight

plastic bags, polythene containers with lids

or special freezer containers.

•Arrange the fresh food in the upper area of

the freezer compartment, leaving sufficient

space around each pack for the air to

circulate.

•The food willbe completely frozenin 24 hours.

•Press the rapid freezing button to switch off

the function (yellow indicator light switches

off).

Temperature alarm function

(control panel versions)

When the appliance is running normally or when

food is being frozen, the red led may switch on

(in certain models this will be accompanied also

by an audible signal) informing you that the

temperature in the freezer compartment is too

high.

This may occur in the following situations:

•whenthe applianceisswitched onforthefirst

time;

•when it is switched on following defrosting

and cleaning;

•if you load too much food at room

temperature;

•if the freezer door has been left ajar;

•ifthe“freezerthermostat knob”on the control

panel is advanced towards the “MAX”setting

(intense cold);

To mute the acoustic alarm press the “Fast

freeze”button.

When temperature in the freezer compartment

has fallen to acceptable levels, the red indicator

LED will switch off automatically. At this point

remember to switch off the “Fast freeze”

function.

HOW TO USE THE FREEZER COMPARTMENT

33051-gb.fm5 Page 16 Tuesday, December 22, 1998 3:52 PM

Note:

The temperature in the freezer compartment is

maintained at the ideal level for the storage of

frozen food also during power failures of limited

duration, although it is advisable to avoid

opening the freezer compartment door during

such periods.

Important:

Thetablealongsideshowstherecommended

maximum storage time for frozen fresh

foods.

When purchasing frozen food products:

•ensure that the packaging is not damaged

(frozen food in damaged packaging may

have deteriorated). Avoid packages that are

swollen or show evidence of damp areas

indicating that the food may have thawed

partially during its period of storage.

•When shopping, leave frozen food

purchases till last and transport the products

in a thermally insulated cool bag.

•Place the items in the freezer compartment

as soon as you get home.

•If food has thawed, even partially, do not re-

freeze it. Consume within 24 hours.

•Avoid subjecting foods to temperature

variations. Observe the “best before”date on

the package.

•Always observe the storage information on

the package.

Removing the baskets

•Pull out fully, raise slightly and remove.

Note:

The freezer compartment can be used without

the two upper baskets to increase storage space

for large products. The lower basket must not be

removed.

Place the food products directly on the racks.

After inserting food, ensure that the freezer

compartment door closes properly.

Making ice cubes

•Pour water into the ice tray up to 2/3 full and

place it in the freezer compartment.

•If the ice tray sticks to the shelves, do not use

pointed or sharp objects to detach it.

•Bend the ice tray slightly to remove the

cubes.

HOW TO USE THE FREEZER COMPARTMENT

MONTHS FOOD

33051-gb.fm5 Page 17 Tuesday, December 22, 1998 3:52 PM

Before servicing or cleaning the appliance,

unplug it from the mains or disconnect the

electricity supply.

Defrost the freezer compartment once or

twice a year or when the formation of ice on

the racks is excessive.

It is perfectly normal for ice to form on the

racks.The amount andspeed at which theice

forms depends on room air temperature and

humidity and the frequency with which the

doorisopened.Iceformationis concentrated

on the racks at the top of the freezer

compartment.

If possible, defrost the freezer compartment

when it is nearly empty.

•Remove the food from the freezer

compartment, wrap in a newspaper and

grouptogether in a cool place or in a portable

cooler.

•Leave the freezer door open so that the ice

can thaw.

•Pull out the defrost water drain and place a

tray below it.

•Clean the interior of the freezer compartment

with a sponge and warm water and/or neutral

detergent. Do not use abrasive products.

•Rinse the interior and dry thoroughly.

•Fit the drain back into place.

•Put the food back into the freezer

compartment.

•Close the compartment door.

•Plug in the appliance / reconnect the

electricity supply.

•Switch the appliance on.

The refrigerator compartment must be

cleaned periodically.

Defrosting of the refrigerator compartment is

completely automatic.

Droplets of water on the rear wall of the

refrigerator compartment indicate that the

periodic automatic defrost cycle is in progress.

The defrost water is routed to a drain outlet and

into a container on the compressor from which it

evaporates.

Clean the defrost water drain outlet regularly

using the tool supplied with the appliance. This

precautionensuresthatdefrostwaterisremoved

correctly from the interior of the refrigerator

compartment.

Before cleaning the refrigerator compartment,

unplug the appliance from the mains.

•Useaspongewithwarmwaterand/orneutral

detergent.

•Rinse the interior and dry with a soft cloth.

Do not use abrasive products

HOW TO DEFROST THE FREEZER COMPARTMENT

HOW TO CLEAN THE REFRIGERATOR COMPARTMENT

33051-gb.fm5 Page 18 Tuesday, December 22, 1998 3:52 PM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Bauknecht Kühlschrank Handbücher

Bauknecht

Bauknecht KVIK20041A Bedienungsanleitung

Bauknecht

Bauknecht GKN 1774 2 Bedienungsanleitung

Bauknecht

Bauknecht KRA 175 OPTIMA Bedienungsanleitung

Bauknecht

Bauknecht KGNA 335 Bedienungsanleitung

Bauknecht

Bauknecht KRB 1310 Bedienungsanleitung

Bauknecht

Bauknecht KVE 2530/A Bedienungsanleitung

Bauknecht

Bauknecht GKNA 3200 Optima Bedienungsanleitung

Bauknecht

Bauknecht BNF70 400 Bedienungsanleitung

Bauknecht

Bauknecht WLMG 1015 Bedienungsanleitung

Bauknecht

Bauknecht KSDN 5061/A/1 Bedienungsanleitung

Bauknecht

Bauknecht KGTNF 20CME IN Bedienungsanleitung

Bauknecht

Bauknecht KRIK 2209/A Bedienungsanleitung

Bauknecht

Bauknecht GKA 1713 Optima Bedienungsanleitung

Bauknecht

Bauknecht UVI 1340 Bedienungsanleitung

Bauknecht

Bauknecht KDMC Bedienungsanleitung

Bauknecht

Bauknecht KDA 2800/1 Bedienungsanleitung

Bauknecht

Bauknecht KSI 9VS1 Bedienungsanleitung

Bauknecht

Bauknecht KGA 275 OMPTIMA Bedienungsanleitung

Bauknecht

Bauknecht GKEA 2550 Optima Bedienungsanleitung

Bauknecht

Bauknecht KDA 3710 Bedienungsanleitung

Bauknecht

Bauknecht GKNE 1770 A Bedienungsanleitung

Bauknecht

Bauknecht KGA 325 OPTIMA Bedienungsanleitung

Bauknecht

Bauknecht KVIE 2009/A Bedienungsanleitung

Bauknecht

Bauknecht KSN 7050 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
