Instructions for use

KVE 2530/A

TABLE OF CONTENTSGB

DESCRIPTION OF THE APPLIANCE Page 13

CONTROLS Page 14

BEFORE USING THE APPLIANCE Page 15

PRECAUTIONS AND GENERAL SUGGESTIONS Page 15

HOW TO USE THE REFRIGERATOR COMPARTMENT Page 16

HOW TO USE THE FREEZER COMPARTMENT Page 17

HOW TO DEFROST AND CLEAN THE APPLIANCE Page 18

TROUBLE-SHOOTING GUIDE Page 18

AFTER-SALE SERVICE Page 19

INSTALLATION Page 19

DESCRIPTION OF THE APPLIANCE

i u

A) Refrigerator Compartment

(for storing fresh food)

Shelves (partially adjustable in height)

Fruit and vegetables drawers

Inside of the door with

(if available):

a. Adjustable containers

b. Door box - top

c. Door box - bottom

Pull-out drawer (telescopic)

(if available)

Defrost water run-off

Rating plate

B) Freezer Compartment (if available)

(with the

symbol, for freezing

and/or storing fresh and frozen food, storing

deep-frozen food and making ice cubes).

Freezing section

Icecubetrays

C) Controls

CONTROLS

Thermostat knob

Light switch

Light shield

Pilot light switch (if available)

Setting mark

3 4 1 25

BEFORE USING THE APPLIANCE

Your new appliance is designed exclusively for use

in the home.

For maximum satisfaction from your

appliance carefully read these user

instructions which contain a description of

the appliance along with some useful food

storage tips. Keep this booklet in a safe place

for future consultation.

After unpacking, make sure the appliance is

undamaged and that the doors close correctly. Any

damage must be communicated to your retailer

within 24 hours of delivery.

Wait at least 2 hours before starting the

appliance in order to ensure optimal

performance from the refrigerant circuit.

Make sure the appliance is installed and electrical

connections are made by a qualified technician in

compliance with the manufacturer’s instructions

and current local safety regulations.

PROTECTING THE ENVIRONMENT

Packing

The packing material may be fully recycled as

confirmed by the recycling symbol. Follow local

waste disposal regulations when scrapping. Keep

potentially hazardous packaging (plastic bags,

polystyrene etc.) out of the reach of children.

Appliance

The appliance is built from reusable materials.

Follow local waste disposal regulations when

scrapping. Before scrapping, cut off the power

cable so that the appliance cannot be connected

to the mains. Dispose of the appliance at an

authorised collection centre for refrigerant gases.

Information

This appliance is free of CFC’s (refrigerant circuit

contains R134a) or free of HFC’s (refrigerant circuit

contains R600a – Isobutane). For more details,

please refer to the rating plate on the appliance.

PRECAUTIONS AND GENERAL RECOMMENDATIONS

In the

freezing compartment it is

possible to store frozen food.

In the

freezing compartment it is

possible to store food for several months.

Furthermore, it is possible to freeze foods.

Do not cover or close the air vents.

Do not store liquids in glass containers in the

freezing compartment since they may explode.

Do not eat ice cubes or ice lollies immediately after

taking them out of the freezing compartment since

they may cause cold burns.

Do not allow children to play or hide in the

appliance to prevent the risk of trapping and

suffocation.

Do not drink the liquid contained in the ice-packs.

Before cleaning or servicing the appliance,

always unplug it or switch off the mains

power supply.

The mains power cable may be replaced only by

authorized personnel.

Declaration of conformity

This appliance is designed to store food products

and complies with European Directive 89/109/EEC.

Information

For appliances with Isobutane (R600a)

The refrigerant Isobutane is a natural gas of high

environmental compatibility but which is

inflammable. Therefore, it is essential to ensure

that the ducts of the refrigerant circuit do not get

damaged.

HOW TO USE THE REFRIGERATOR COMPARTMENT

This appliance is either a refrigerator, or a refrigerator

with a

compartment, or a refrigerator with a

compartment.

The appliance has been designed to run at a room

temperature ranging from +10

Cto+38

C. For appliances

with a

compartment without pilot light (4), from

+16

Cto+38

Getting started

After the appliance has been connected to the power supply,

the inside light turns on when the refrigerator door is opened

and the thermostat knob is not on position

. After the

temperature has been set, as described below, the appliance

is ready for use.

To set the temperature:

Thermostat knob (1) on

: no cooling and light off.

Thermostat knob (1) on 1: minimum cooling

Thermostat knob (1) on 3-4: average cooling

Thermostat knob (1) on 7: maximum cooling

Important:

Press the pilot light switch (4) when you freeze food and/or

when room temperature drops below 16

C. The pilot light

(4) turns on.

When room temperature rises above 16

Cturn the pilot light

switch (4) off.

Inside temperatures are affected by the position of the

appliance, room temperature and frequency of door openings.

Thermostat setting (1) may have to be changed depending

on these factors.

How to store food in the refrigerator

compartment

We suggest to arrange food as shown in the figure on the

side:

1. Cooked food

2. Dairy products, tinned products, cheese, butter

3. Fish, meet

4. Sliced food

5. Fruit and vegetables

6. Small tins, eggs

7. Tubes, small tins

8. Sausage

9. Bottles

Notes:

Do not store food in an open container since it would dry up.

Do not store food that is still warm in the refrigerator

compartment.

Make sure that air circulates freely between stored food.

Defrosting of the refrigerator compartment is

completely automatic.

HOW TO USE THE FREEZER COMPARTMENT

Only for appliances with

compartment or

compartment:

In the

freezing compartment it is possible to

store frozen food.

In the

freezing compartment it is possible to

store food for several months. Furthermore, it is

possible to freeze foods. The quantity in kilos of fresh

food that can be frozen within 24 hours is indicated on

the plate (6).

Freezing of foods

Press the pilot light switch (4) 12 hours before introducing

the food. The pilot light turns on.

Set the thermostat (1) 12 hours before introducing the food.

For freezing put the food in the middle of the

compartment (at the back).

Important:

Wrap and seal food in aluminium foil, cling film, air- and

watertight plastic bags, polyethylene containers with lids,

containers suitable for freezers.

When buying frozen food, make sure that:

Wrapper or package is intact as the food may deteriorate. If it

bulges or has spots of moisture on it, it means that it has not

been stored in adequate conditions and that the contents

may have started to thaw.

Always use thermal bags or cold boxes for transport.

Frozen food should always be purchased last.

When at home, immediately store it in the freezing

compartment.

Any food, even if partially thawed, cannot be re-frozen but

mustbeeatenwithin24hours.

Any rise in temperature of frozen food should be avoided or

kept as short as possible. Frozen food should not be kept

beyondthedateindicatedonthepackage.

Always follow the instructions on how to store frozen food

writtenonthepackaging.

Making ice cubes

Fill the ice cube trays (8) 3/4 full of water and place them on

the bottom of the freezer compartment.

Use the handle of a spoon to free the ice cube trays if they

are stuck.

Do not use sharp or pointed tools.

HOW TO DEFROST AND CLEAN THE APPLIANCE

Before carrying out any cleaning or maintenance, always

unplug the appliance.

You should defrost the freezer compartment when frost

build-up reaches 3 mm in thickness.

Remove all food from the

compartment and

turn the thermostat knob to

Periodically clean the inside of the appliance with a sponge

dampened in a solution of warm water and neutral pH

detergent.

Rinse and dry.

Defrosting of the refrigerator compartment is completely

automatic.

Regularly clean the defrost water run-off with the supplied

brush so that the defrost water will flow down unhindered.

After having cleaned the appliance, plug it in.

Do not use abrasives.

Long vacation

Empty the appliance.

Unplug the appliance.

Defrost and clean the inside.

Leave the door open to prevent odour from setting in.

TROUBLE-SHOOTING GUIDE

1. The temperature is not cold enough

Is the food preventing the door from closing

properly?

Is the thermostat on the correct setting?

Is air circulation blocked?

2. The temperature in the refrigerator compartment

is too cold

Is the thermostat on the correct setting?

3. The appliance is excessively noisy

Has the appliance been properly installed?

Do the pipes on the back touch and rattle?

Gurgling noises inside the refrigerating circuit

are normal.

4. The appliance does not work

Is there a power failure?

Is the plug properly inserted in the socket?

Has the fuse blown?

Is the appliance switched on?

5. There is water on the bottom of the refrigerator

compartment

Is the thermostat on the correct setting?

Is the defrost water run-off clogged?

6. The inside light does not work

First check point 4, then:

Unplug the appliance.

1. Press the light shield (3).

2. Remove the light shield (3).

Replace the bulb (220»240 V, 15 W).

AFTER-SALE SERVICE

Before calling for Service:

1. Carefully check the Trouble-Shooting Guide to see if

you can fix the problem yourself.

2. Let the appliance run for a while to see if the problem

has cleared itself.

If the appliance still does not work properly,

please call for Service.

The Service No. of the appliance is indicated on

the rating plate (6) (inside on the bottom left).

INSTALLATION

Do not install the appliance close to any heat source.

Place it in a dry and well ventilated room.

Clean the inside (see chapter “How to defrost and clean the

appliance”).

Assemble the accessories.

Check door gasket tightness, especially in built-in appliances

and after door swing has been changed.

Electrical connection

0

Check that the voltage on the rating plate (6) corresponds to

the voltage in your home.

Appliance earthing is compulsory by law. The Manufacturer

shall not be liable for any damage to person or property

arising from the failure to comply with this requirement.

If the plug and the socket are not of the same type, have the

socket replaced by a qualified technician.

Do not use adapters, multiple sockets or extension cables.

Inhaltsverzeichnis

Andere Bauknecht Kühlschrank Handbücher

Bauknecht

Bauknecht KDMC Bedienungsanleitung

Bauknecht

Bauknecht KVA 2500/1 Bedienungsanleitung

Bauknecht

Bauknecht KVA 1312 Bedienungsanleitung

Bauknecht

Bauknecht KVIE 2009/A Bedienungsanleitung

Bauknecht

Bauknecht GKA 1713 Optima Bedienungsanleitung

Bauknecht

Bauknecht GKEA 2515 OPTIMA Abmessungen

Bauknecht

Bauknecht KGTNF 20CME IN Bedienungsanleitung

Bauknecht

Bauknecht KDA 2800/1 Bedienungsanleitung

Bauknecht

Bauknecht KDNA 4300 Bedienungsanleitung

Bauknecht

Bauknecht Optima+ KVA 172 Bedienungsanleitung

Bauknecht

Bauknecht KGN 7050/0 Bedienungsanleitung

Bauknecht

Bauknecht KSDN 5061/A/1 Bedienungsanleitung

Bauknecht

Bauknecht KGNA 336 OPTIMA Bedienungsanleitung

Bauknecht

Bauknecht KGI 2900/A Bedienungsanleitung

Bauknecht

Bauknecht KSDN 5061/A Bedienungsanleitung

Bauknecht

Bauknecht KSDN 5060 Bedienungsanleitung

Bauknecht

Bauknecht KGA 275 OMPTIMA Bedienungsanleitung

Bauknecht

Bauknecht KGA 325 OPTIMA Bedienungsanleitung

Bauknecht

Bauknecht KRB 1310 Bedienungsanleitung

Bauknecht

Bauknecht KGNA 335 Bedienungsanleitung

Bauknecht

Bauknecht KVIK20041A Bedienungsanleitung

Bauknecht

Bauknecht WLMG 1015 Bedienungsanleitung

Bauknecht

Bauknecht KVI 1300 Bedienungsanleitung

Bauknecht

Bauknecht KR 19G4 A2 + IN Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
