Baumatic BTM17.1SS Bedienerhandbuch

User Instruction Manual for your

BTM17.1SS MICROWAVE

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING

YOUR MICROWAVE OVEN. IF YOU FOLLOW THE INSTRUCTIONS, YOUR

OVEN WILL GIVE YOU MANY YEARS OF GOOD, SAFE SERVICE. PLEASE

KEEP THIS MANUAL SAFELY FOR FUTURE REFERENCE.

* NOTE: This manual is designed to be used either as a whole

or to be used for quick set-up so you can get using your

appliance as soon as possible.

For the

6. Please also

quickly see the IMPORTANT PAGES. They are marked in

bold on the next page.

13/05/05

!>>

UICKFIRE! >>>>>>

Specifications………..…………….……………………………….……3

Safety Information ……..…………….…….…..…4-5

Environmental Note ……………………………………….………..5

Avoiding Exposure to Microwave Energy……….6

Never Use Your Microwave Oven to: ……..…..…7

Your Baumatic Microwave Oven ...…….…………8

Placing your Microwave Oven ………….……….…9

Before you Start Cooking with

your Microwave….…………………………..……10-11

Materials that you CAN use in your Microwave………12

Materials that you CAN’T use

in your Microwave .…………….…………….….13

Setting your Microwave’s Clock …………..………..………14

Notes on Microwaving Food ……………………………...….15

Using your Microwave Oven ……………...…16-20

Child Safe Lock Function……………………..…….21

Cleaning …………………………………………………………………22

Troubleshooting …………………………………23-26

Conditions of Guarantee ……………………………………….27

Contact Details……………….………………………………………28

Your Baumatic BTM17.1SS Microwave has:

8 Functions

5 Power Levels

Pushbutton Control Operation

LED full programmer

Child Safety Lock

Stainless Steel Exterior

Cooking Features:

General Cooking (see pages 16-17)

Quick Start (see page 18)

Defrost by Weight (see page 18)

Defrost by Time (see page 18)

Auto Menu (see page 19)

Relay Start (see page 20)

ecifications

PLEASE READ BEFORE USING!

(To reduce the risk of fire, electric shock, injury or exposure

to Mircowave energy)

ELECTRICAL SAFETY

•1 NOTE - This appliance must be grounded. In the event of a

malfunction or breakdown, grounding will reduce the risk of electric

shock by providing a path of least resistance of electrical current. You

will be able to tell if it is because a non-grounded appliance will give

off an electrical discharge. Your Microwave’s plug must have a

grounding pin and if you use an extension cord, this must have a 3-pin

inlet/outlet as well as carry the same rating or greater than your

microwave. Only connect to a properly grounded outlet.

•2 Manufacturer declines all responsibility for any damage due to non-

grounding of appliance.

•3 DURING THE GUARANTEE PERIOD ONLY BAUMATIC SERVICE ENGINEERS OR

AN AUTHORISED AGENT OF BAUMATIC SHOULD CARRY OUT REPAIRS ON

THIS UNIT. THEREAFTER, IT SHOULD BE SERVICED ONLY BY QUALIFIED

TECHNICIANS.

•4 DO NOT USE IF THE SUPPLY CORD IS DAMAGED OR IF IT HAS BEEN

IMMERSED IN WATER.

•5 DO NOT USE IF THE OVEN HAS BEEN DAMAGED OR DROPPED.

•6 KEEP CORD AWAY FROM HEAT SOURCES.

•7 DON’T LET THE CORD HANG OVER THE EDGE OF TABLE.

•8 DO NOT USE YOUR MICROWAVE OUTDOORS OR NEAR A KITCHEN SINK,

SWIMMING POOL, IN A WET BASEMENT OR ANYWHERE CLOSE TO A SOURCE

OF WATER.

•9 NEVER TRY TO DISASSEMBLE OR REPAIR YOUR MICROWAVE – IT RETAINS A

HIGH POWER VOLTAGE CHARGE EVEN WHEN UNPLUGGED!

Safet

Information

GENERAL SAFETY

•READ AND FOLLOW THE

“PRECAUTIONS TO AVOID

POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE

ENERGY” (Page 6).

•AS WITH MOST COOKING

APPLIANCES, CLOSE

SUPERVISION IS NEEDED TO

REDUCE THE RISK OF FIRE IN

YOUR MICROWAVE OVEN.

•SHOULD A FIRE START:

1) KEEP THE OVEN DOOR CLOSED.

2) TURN THE OVEN OFF & UNPLUG

THE APPLIANCE.

3) DISCONNECT THE POWER AT

THE FUSE OR CIRCUIT

BREAKER PANEL.

•ONLY EVER USE YOUR

MICROWAVE FOR ITS

INTENDED USE (HEATING

FOODS) AND NEVER FOR

INDUSTRIAL OR LABORATORY

PURPOSES.

•COOKING UTENSILS & DISHES

WILL BE HOT WHEN YOU TAKE

THEM OUT AFTER COOKING –

HANDLE WITH CARE!

•NEVER USE CORROSIVE

CHEMICALS OR VAPOURS IN

YOUR MICROWAVE. WHEN

YOU CLEAN THE DOOR AND

OVEN SURFACES, USE ONLY

MILD, NONABRAISIVE SOAPS

OR DETERGENTS APPLIED

WITH A SPONGE OR SOFT

CLOTH.

•DO NOT COVER OR BLOCK ANY

VENTS ON THE OVEN.

•ONLY PLACE YOUR OVEN ON A

FLAT, LEVEL SURFACE.

•DON’T LET CHILDREN PLAY

WITH YOUR MICROWAVE.

•MAKE SURE YOU READ THE

SECTION ON INSTALLING YOUR

MICROWAVE PROPERLY (Page

9).

•MAKE SURE YOU READ THE

SECTION ON COOKING FOODS

IN YOUR OVEN. THERE ARE

SOME ITEMS WHICH SHOULD

NOT BE HEATED IN YOUR

MICROWAVE. (Page 13) AND

THINGS YOU MUST NEVER USE

YOUR MICROWAVE FOR (Page

7).

PLEASE READ THE NOTE ON SUPERHEATED LIQUIDS ON PAGES 10 & 11.

________________________________

CONFORMITY TO W.E.E.E. DIRECTIVE

Safet

Information / Environmental Note

AVOIDING POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY

IMPORTANT NOTES ABOUT MICROWAVE ENERGY – READING THESE PRECAUTIONS

WILL HELP YOU TO AVOID POSSIBLE EXPOSURE TO MICROWAVE ENERGY

oNEVER

ATTEMPT TO

USE YOUR

OVEN WITH

THE DOOR

OPEN. THE

DOOR MUST BE

FULLY CLOSED

EVERY TIME

YOU OPERATE

YOUR OVEN

OTHERWISE

YOU RISK

EXPOSING

YOURSELF AND

OTHERS TO

HARMFUL

MICROWAVE

ENERGY.

oYOUR

MICROWAVE IS

FITTED WITH

SAFETY

INTERLOCKS.

IT IS VERY

IMPORTANT

THAT THESE

ARE NEVER

TAMPERED

WITH!

oDO NOT PLACE

ANY OBJECT

BETWEEN THE

OVEN’S DOOR

AND THE

DOORWAY

(FRONT FACE).

NEVER ALLOW

DIRT, FOOD OR

CLEANER

RESIDUE TO

ACCUMULATE

ON THE

SEALING

SURFACES

BETWEEN THE

INSIDE OF THE

DOOR AND THE

PART OF THE

DOORWAY

WHERE IT

MEETS.

oYOUR

MICROWAVE

HAS SEVERAL

BUILT-IN

SAFETY

SWITCHES TO

ENSURE THE

POWER

REMAINS OFF

WHEN THE

DOOR IS OPEN.

NEVER TAMPER

WITH THESE

SWITCHES.

oNEVER TRY TO

OPERATE A

DAMAGED

MICROWAVE

OVEN. APART

FROM MAKING

SURE THAT

THE OVEN

DOOR CAN

PROPERLY,

YOU NEED TO

ALSO CHECK

THAT THERE IS

NO DAMAGE TO

THE:

1) DOOR (EG.

DENTED)

2) HINGES &

LATCHES

(BROKEN OR

LOOSENED)

3) DOOR SEALS &

SEALING

SURFACES

oREMEMBER THAT

YOUR

MICROWAVE

OVEN SHOULD

NOT BE

ADJUSTED OR

REPAIRED BY

ANYONE BUT A

QUALIFIED

SERVICE

TECHNICIAN.

oNEVER USE THE

INTERIOR OF

YOUR

MICROWAVE

OVEN FOR

STORAGE

PURPOSES.

NEVER STORE

COMBUSTIBLE

ITEMS SUCH AS

BREAD, COOKIES,

PAPER

PRODUCTS, ETC.

INSIDE THE OVEN

TO FACILITATE

COOKING.

ACCIDENTAL

OPERATION CAN

CAUSE THESE

ITEMS TO GO ON

FIRE AND DO

DAMAGE TO YOUR

MICROWAVE,

THEREBY

PUTTING YOU AT

RISK IF YOU USE

IT WHILE IT IS

DAMAGED.

Avoidin

osure to Microwave Ener

A note on the type of energy used

by your Microwave Oven

Microwaves are electromagnetic waves that transmit energy. When cooking,

the microwave energy penetrates food to a depth of 4cm (1½ inches),

causing its molecules to vibrate. The heat produced by this friction

enables food to be heated, cooked or defrosted.

How quickly a microwave oven cooks will depend on the size, quality and

shape of the food being cooked. Microwave cooking is healthy in that,

without the need for large amounts of cooking liquid, it means that food

retains vitamins, nutrients, aromas and flavour.

Microwave Ovens are also more energy efficient than conventional cooking

because they use up to 70% less energy.

______________________

Never use your

Microwave Oven to:

Dry clothes or fabrics

Dry or warm up pets or live animals

Warm or heat any item other than food and the

appropriate utensil

Cook sealed containers

Cook items where you have placed a liquid or

mercury thermometer (eg. Inside roasts or turkeys)

Heat large quantities of cooking oil (fondue or deep

frying) or drinks with high alcohol contents

Never use

our Microwave to…

Your Baumatic Microwave Oven

oONCE YOU ARE SURE THAT YOUR OVEN IS NOT DAMAGED (EG. DENTS

OR A BROKEN DOOR) AND THAT THERE ARE NO PACKING MATERIALS

AND ACCESSORIES INSIDE IT, YOU CAN THEN INSTALL IT ON A FLAT

SURFACE SUCH AS A COUNTERTOP. BE SURE THAT THE SURFACE CAN

HOLD AT LEAST YOUR MICROWAVE’S WEIGHT (12.0 kg).

oBEFORE PLACING ON YOUR COUNTERTOP: REMOVE ANY PROTECTIVE

FILM ON THE CABINET SURFACE.

oBUT DO NOT REMOVE THE LIGHT BROWN MICA COVER THAT IS SCREWED TO

THE OVEN CAVITY TO PROTECT THE MAGNETRON.

oFIND A LEVEL SURFACE THAT PROVIDES ENOUGH OPEN SPACE FOR

THE INTAKE AND OUTLET VENTS.

oYOU NEED TO LEAVE A MINIMUM OF 3.0 INCHES (7.5 CM) BETWEEN

THE OVEN AND ANY ADJACENT WALL. ONE SIDE MUST BE OPEN TO

ALLOW THE DOOR TO OPEN AND CLOSE.

oLEAVE A MINIMUM CLEARANCE OF 12 INCHES (30CM) ABOVE

THE OVEN.

oDO NOT REMOVE THE LEGS FROM THE BOTTOM OF THE OVEN.

oDON’T LET ANYTHING BLOCK EITHER THE INTAKE OR THE

OUTLET OPENINGS AS THIS CAN DAMAGE THE OVEN.

oPLACE YOUR MICROWAVE OVEN AS FAR AWAY AS POSSIBLE FROM

RADIOS AND TELEVISIONS - YOUR OVEN MAY CAUSE SIGNAL

INTERFERENCE.

oDO NOT PUT YOUR OVEN ON TOP OF ANY OTHER HEAT-

PRODUCING APPLIANCE OR A RANGE COOKTOP. DOING SO

COULD DAMAGE YOUR OVEN AND MAKE THE WARRANTY VOID.

Placin

Your Microwave Oven

PLEASE REMEMBER: NOT ALL FOODS AND UTENSILS ARE

SUITABLE for use in MICROWAVE OVENS.

FOODS THAT MUST NEVER BE MICROWAVED:

•Eggs in their shell or

whole hard-boiled

eggs since they may

explode, even after

your Microwave has

stopped heating them.

•Foods that need

deep-frying: your

Microwave cannot

deep-fry and is

liable to present a

fire hazard if you

attempt to deep fry

with it.

•Foods that you intend

to can at home. There

is no way of ensuring

that foods intended for

home canning have

reached the required

boiling temperature.

•Narrow-necked

containers like

syrup bottles – the

neck could explode.

•Never use your

Microwave when it is

empty. This is a fire

hazard.

•Sealed liquids and

food containers –

these will almost

certainly explode –

NEVER PLACE THEM

IN YOUR

MICROWAVE!

_______________________

And please be careful with …

Heating liquids and drinks: when you heat liquid using a

Microwave, part of the liquid can exceed boiling point. Its surface

tension is such that it will be susceptible to upward surges. To avoid

the risk of being scalded, always handle bowls and cups of heated

liquid steadily and carefully. PLEASE SEE NEXT PAGE FOR

FURTHER ADVICE TO AVOID SCALDING!

Before

ou Start Cookin

with Your Microwave

Inhaltsverzeichnis

Andere Baumatic Mikrowellenofen Handbücher

Baumatic

Baumatic BMM174SS Bedienungsanleitung

Baumatic

Baumatic BTM23.1SS Bedienungsanleitung

Baumatic

Baumatic BTM21SL Bedienerhandbuch

Baumatic

Baumatic BMIC4625 Bedienungsanleitung

Baumatic

Baumatic BTM23.1SS Bedienungsanleitung

Baumatic

Baumatic BMM204SS Bedienungsanleitung

Baumatic

Baumatic BTM31SS Bedienungsanleitung

Baumatic

Baumatic GMGI250SS Bedienungsanleitung

Baumatic

Baumatic BMGI250SS Bedienungsanleitung

Baumatic

Baumatic BMC455TS Bedienungsanleitung

Baumatic

Baumatic BAMW2330-P Bedienungsanleitung

Baumatic

Baumatic BTM25.7SS Bedienungsanleitung

Baumatic

Baumatic BTM30SS Bedienungsanleitung

Baumatic

Baumatic BTWM2SS Betriebsanleitung

Baumatic

Baumatic BMC460BGL Bedienungsanleitung

Baumatic

Baumatic BMMI170SS Bedienungsanleitung

Baumatic

Baumatic BSCM45-ANZ Bedienungsanleitung

Baumatic

Baumatic BTM25.3SS Bedienungsanleitung

Baumatic

Baumatic BMC253SS Bedienungsanleitung

Baumatic

Baumatic BMIC4644X Bedienungsanleitung

Baumatic

Baumatic BMG200SS Bedienungsanleitung

Baumatic

Baumatic BTM17.4SS Bedienungsanleitung

Baumatic

Baumatic BMC253SS Bedienungsanleitung

Baumatic

Baumatic BMFS3420 Bedienungsanleitung

Beliebte Mikrowellenofen Handbücher anderer Marken

Daewoo

Daewoo KOG-574R0S Bedienungsanleitung

LG MH7040SS Bedienungsanleitung

Sharp

Sharp R-895(AL)M Bedienungsanleitung

Dometic

Dometic DOTRM13W Bedienungsanleitung

Sanyo

Sanyo EM-X680 Bedienungsanleitung

Sharp

Sharp R-393M Bedienungsanleitung

KitchenAid

KitchenAid KMCX4510 Montageanleitung

Smeg

Smeg S45MCX1 Bedienungsanleitung

Russell Hobbs

Russell Hobbs RHM2044 Bedienungsanleitung

Sunbeam

Sunbeam SMW759 Bedienungsanleitung

Gallet

Gallet FMOE230S Bedienungsanleitung

Bosch

Bosch CEG732X.1B Bedienungsanleitung

Dometic

Dometic Roadmate 230 Bedienungsanleitung

Samsung

Samsung SJ0396W Bedienungsanleitung

Sanyo

Sanyo EM-P494WS Bedienungsanleitung

Sharp

Sharp R-240 Bedienungsanleitung

Electrolux

Electrolux EMS2840 Bedienungsanleitung

Daewoo

Daewoo KOC-984T2S13 Bedienungsanleitung
