Baumatic B602.1 Bedienungsanleitung

B602.1/B604.1/

B609.1 60 cm Gas

fan-assisted oven

User Manual for your Baumatic

B602.1BL/W

B604.1SS

B609.1SS

60 cm Gas fan-assisted oven

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

DD 23/04/07

Contents

Environmentalnote 4

Important safety information 5 – 8

Specifications 9

Productspecifications 9

Standardaccessories 10

Optionalextras 10

Electricaldetails 10

Control panel 11

Beforefirstuse 12

Setting the time of day (B609.1SS only) 12

Switching the gas oven on 13

Switching the gas grill on 14

Operationofthefan 15

Cookingguidelines 15

Warnings 16

Setting a countdown time (B609.1SS only) 17

Using the minute minder (B602.1 & B604.1 only) 18

Theovenlight 18

Cleaning and maintenance 19

Replacing the oven bulb 20

Removing the oven door for cleaning 21

Removing the inner door glass for cleaning 22

Installation 22

Electrical connection 22-23

Positioning 23

Installing the oven into the kitchen cabinet 24

Positioning the appliance 24

Ventilation requirements 25-26

Gasconnection 27

Gas Safety (Installation and Use) Regulations 28

Gasconnection 29

Gas adjustment (Conversion to LPG and gas adjustment) 30-32

My appliance isn’t working correctly 32-33

Baumatic Ltd. conditions of guarantee 34

Contact details 35

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

IMPORTANT SAFETY INFORMATION

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Technical

Department.

General Information

oThis appliance is designed for domestic household use and can

be built into a standard kitchen cabinet or housing unit.

oIMPORTANT: The adjacent furniture or housing and all

materials used in the installation must be able to withstand a

minimum temperature of 85°C above the ambient temperature

of the room it is located in, whilst in use.

oCertain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouration at

temperatures below the guidelines given above.

oAny damage caused by the appliance being installed in

contravention of this temperature limit, or by placing adjacent

cabinet materials closer than 4mm to the appliance, will be the

liability of the owner.

oFor use in leisure accommodation vehicles, please refer to

the appropriate information given in the installation instructions

for this appliance.

oIMPORTANT: Baumatic Ltd. DO NOT recommend that this

appliance is installed on any type of marine vessel.

oThe use of this appliance for any other purpose or in any other

environment without the express agreement of Baumatic Ltd.

will invalidate any warranty or liability claim.

oYour new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of Guarantee. The foregoing does not

affect your statutory rights.

oRepairs may only be carried out by Baumatic Service

Engineers or their authorised service agent.

Warning and safety instructions

oThis appliance complies with all current European safety

legislation. Baumatic do wish to emphasise that this compliance

does not remove the fact that the appliance surfaces will

become hot during use and retain heat after operation.

Child Safety

oBaumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowed

to touch the appliance at any time. During and after use, all

surfaces will become hot.

oIf it is necessary for younger family members to be in the

kitchen, please ensure that they are kept under close supervision

at all times.

General Safety

Make sure that you understand the controls before using the

appliance.

Check that all of the controls on the appliance are turned off

after use.

Always stand back when opening the oven door, this will allow

heat to disperse.

Take care when removing items from the oven, as the contents

may be hot.

Always keep the oven doors closed when the oven is not in use.

Always follow the basic principles of food handling and hygiene,

this will prevent the possibility of bacterial growth.

Always keep ventilation slots clear of obstructions.

Keep fingers away from the hinge areas when closing the door,

otherwise you may trap them.

Oven gloves should be used when placing food in the oven cavity

and when removing it. Care should be taken to avoid direct

contact with any of the elements in the appliance.

oDO NOT LEAVE THE APPLIANCE UNATTENDED WHILST IN

USE.

oDo not place heavy objects on the oven door or lean on the

oven door when it is open, as this can cause damage to the oven

door hinges. Nobody should be allowed to sit or stand on any

part of the oven.

oDo not heat up unopened food containers, as pressure can build

up which may cause the container to burst.

oDo not place flammable or plastic items in the oven.

oDo not leave heated oil or fat unattended, as this is a fire risk.

oDo not allow fat or oil to build up in the oven trays, grill pan or

oven base.

oDo not place pans or baking trays directly on the base of the

oven cavity, or line it with aluminium foil.

oDo not grill food containing fat without using the grill trivet. The

grill trivet should never be covered with aluminium foil.

oDo not place hot enamel parts in water, leave them to cool first.

oDo not allow vinegar, coffee, milk, saltwater, lemon, tomato

juice or any liquid with high sugar content to remain in contact

with the enamel parts of the appliance. Spillages should be

wiped up immediately.

oDo not allow electrical fittings or cables to come into contact

with areas on the appliance that get hot.

oDo not use the appliance to heat the room it is located in or to

dry clothing. No clothing should be placed over or near to the

oven door.

oDo not install the appliance next to curtains or soft furnishings.

oDo not attempt to lift or move cooking appliances by using the

oven door or handle, as this may cause damage to the appliance

or result in injury to the person lifting the appliance.

oDo not store chemicals, food stuffs, pressurised containers in or

on the oven or in cabinets immediately above or next to the

oven.

Cleaning

oCleaning of the oven should be carried out on a regular basis.

oGreat care should be taken whilst using this appliance and when

following the cleaning procedure.

oIMPORTANT: The appliance must be disconnected from the

mains before following the cleaning procedure.

Installation

This appliance must be correctly installed by a

suitably qualified person, strictly in accordance

with the manufacturer’s instructions. Please see

the specific section of this booklet that refers to

installation.

oBaumatic Ltd. declines any responsibility for injury or

damage, to person or property, as a result of improper

use or installation of this appliance.

oHeat, steam and moisture will be created during use of the

appliance, take care to avoid injury and ensure that the room is

adequately ventilated. If the appliance is going to be used for

prolonged periods of time, then additional ventilation may be

required.

oPlease consult with your qualified installer if you are in any doubt

about the amount of ventilation that you will require.

Declaration of conformity

This appliance complies with the following European Directives:

-73/23/EEC regarding “low voltage”

-89/336/EEC regarding “electromagnetic disturbances”

-90/396/EEC regarding “gas appliances”

-89/109/EEC regarding “materials in contact with food”.

oThe above directives comply with 93/68/EEC regarding CE

marking.

oThe manufacturer declares that the oven is built using certified

materials and requires the appliance to be installed in

accordance with the standards currently in force. This appliance

must be used by a trained person for domestic purposes only.

Specifications

(IMPORTANT: The above drawing does not show the ventilation

requirements that are necessary for installing this appliance, please

refer to the installation instructions for this information).

Product Dimensions Aperture Dimensions

Height: 591 mm 580 mm – 583 mm

Width: 597 mm 556 mm - 560 mm

Depth: 525 mm 550 mm

Cooling fan

oA tangential cooling fan is fitted inside of this appliance, to make

the internal temperature of the oven stable and the external

surface temperature lower.

Product specifications

oOven capacity: 47 litres

oMinute minder

oLED minute minder (B609.1SS only)

oCooling fan

oGas grill

oFlame failure safety device

oAuto-ignition

oFan-assisted gas oven with lower burner

oDouble-glazed removable door

Standard accessories

oRemovable side racks

o2 x safety shelves

oEnamelled drip tray with handle

oTrivet

oLPG conversion jets

Optional extras

oBPS1 Pizza stone

Electrical details

Rated Voltage: 230 Vac 50 Hz

Supply Connection: 13 A (double pole switched fused

outlet with 3mm contact gap)

Fuse rating: 3 amp

Max Rated Inputs: 0.075 kW

Mains Supply Lead: 3 x 1.0 mm²

For future reference please record the following information which can

be found on the Rating Plate and the date of purchase which can be

found on your sales invoice. The rating plate for your oven can be

located by opening the oven door and looking on the right hand side of

the oven chassis.

Model Number ……………………………….

Serial Number ……………………………….

Date of Purchase ……………………………….

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Baumatic Ofen Handbücher

Baumatic

Baumatic BO980SS Bedienungsanleitung

Baumatic

Baumatic B900SS-B Bedienungsanleitung

Baumatic

Baumatic OMBRA1BL Bedienungsanleitung

Baumatic

Baumatic B153SS Bedienungsanleitung

Baumatic

Baumatic BT2950 Betriebsanleitung

Baumatic

Baumatic B155.1 Bedienungsanleitung

Baumatic

Baumatic BSO624SS Bedienungsanleitung

Baumatic

Baumatic MEGACHEF B620MC Bedienungsanleitung

Baumatic

Baumatic BO460SS Bedienungsanleitung

Baumatic

Baumatic B602.1BL/W Bedienungsanleitung

Baumatic

Baumatic BCS460SS-AUS Bedienungsanleitung

Baumatic

Baumatic MG1 Bedienungsanleitung

Baumatic

Baumatic BO620SS Bedienungsanleitung

Baumatic

Baumatic BCD901SS Bedienungsanleitung

Baumatic

Baumatic B205SS-A Bedienungsanleitung

Baumatic

Baumatic B151BL-B Bedienungsanleitung

Baumatic

Baumatic BCS460SS Bedienungsanleitung

Baumatic

Baumatic BGS460SS Bedienungsanleitung

Baumatic

Baumatic B910SS-A Bedienungsanleitung

Baumatic

Baumatic BS67MS Bedienungsanleitung

Baumatic

Baumatic MEGACHEF B630MC Bedienungsanleitung

Baumatic

Baumatic BO910SS-AUS Bedienungsanleitung

Baumatic

Baumatic BY9006SS Bedienungsanleitung

Baumatic

Baumatic P650SS Bedienungsanleitung

Beliebte Ofen Handbücher anderer Marken

Bosch

Bosch HVA531NS0 Bedienungsanleitung

Electrolux

Electrolux EOF6P46X Bedienungsanleitung

NEFF

NEFF B44S32 5GB Series Bedienungsanleitung

Combi

Combi BLODGETT BC142GDS Bedienungsanleitung

AEG

AEG COMPETENCE 311704300 Bedienungsanleitung

Falcon

Falcon DOMINATOR PLUS G3106 Series Benutzerhandbuch

Rational

Rational SCC WE 61G Bedienungsanleitung

Smeg

Smeg DOSPA38X Installations- und Betriebshandbuch

Electrolux

Electrolux air-o-convect 20 GN 2/1 Bedienungsanleitung

Miele

Miele HR 1954-2 Bedienungsanleitung

KHIND

KHIND OT50 Bedienungsanleitung

Henny Penny

Henny Penny Smoker Box Bedienungsanleitung

Lang

Lang ECOD-AP Bedienungsanleitung

AEG

AEG BEK455310M Bedienungsanleitung

Frigidaire

Frigidaire FNGE90JGR Bedienungsanleitung

Hotpoint

Hotpoint FE9 S831 JSH IX Bedienungsanleitung

GE Advantium SCB2000 Bedienungsanleitung

AEG

AEG DE401301DM Bedienungsanleitung
