Baumatic BCD901SS Bedienungsanleitung

BCD901SS

90 cm Single cavity

dual fuel cooker

User Manual for your Baumatic

BCD901SS

90 cm Single cavity dual fuel cooker

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 08/07/11

Contents

Environmentalnote 4

Important safety information 5 – 9

Specifications 9 – 12

Dimensions 9

Specifications 9-10

Electricaldetails 10

Gasdetails 10

Controlpanel 11

Oventimer 12

Setting and using the oven programmer/timer 12 - 15

Setting the time of day 12

Setting the minute minder function 13

Setting the duration function 13

Setting the end cook function 14

Setting the start and end time function 14

Returning to manual operation mode 14

Thebuzzer 15

Changing or cancelling a programmed function 15

Using the hob top 16 - 19

Hobsurfacelayout 16

Beforefirstuse 16

Lighting a burner 16 - 17

Optimum use of the burners 17

Hobguidelines 18

Usingtheoven 18 - 25

Beforefirstuse 18-19

Usingthemainoven 19

Cookingfunctions 19-20

Using the grill 20 – 21

Cooking guidelines 21 - 22

Warnings 22

Cooking guide for the main oven 22 - 23

Cooking tips for cakes and bread 24

Cookingtipsformeat 25

Cleaning and maintenance 25 – 30

Cleaning the gas hob top 26

Aftereachuse 26

Cleaning the burners 27

Cleaning the oven 27

Replacing the oven bulb 28

Removing the oven door for cleaning 28 - 29

Removing the inner door glass for cleaning 29

Removing the side racks for cleaning 30

Installation 30 - 41

Positioning 30–32

Ventilation requirements 32 - 33

Securing the back-guard 33 - 34

Fitting the safety chain and hook 34

Electricalconnection 35

Connecting the main supply cable 35 - 36

Gasconnection 36

Gas safety (installation and use) regulations 36 – 37

Gasconnection 37-38

Gas conversion to LPG 38 – 39

Minimum flow adjustment for hob gas taps 39 – 40

Gas tap replacement 40 - 41

My appliance isn’t working correctly 41 – 43

Contactdetails 44

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Advice Line.

General Information

oThis appliance is designed for domestic household use and for

the cooking of domestic foodstuffs.

oIMPORTANT: The adjacent furniture and all materials used in

the installation must be able to withstand a minimum

temperature of 85°C above the ambient temperature of the

room it is located in, whilst in use.

oCertain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouration at

temperatures below the guidelines given above.

oAny damage caused by the appliance being installed in

contravention of this temperature limit, or by placing adjacent

cabinet materials closer than 25 mm to the appliance, will be

the liability of the owner.

oIMPORTANT: Baumatic Ltd. DO NOT recommend that this

appliance is installed on any type of marine vessel.

oThe use of this appliance for any other purpose or in any other

environment without the express agreement of Baumatic Ltd.

will invalidate any warranty or liability claim.

oYour new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of Guarantee. The foregoing does not

affect your statutory rights.

oRepairs may only be carried out by Baumatic service

engineers or their authorised service agents.

Warning and safety instructions

oThis appliance complies with all current European safety

legislation. Baumatic do wish to emphasise that this compliance

does not remove the fact that the appliance surfaces will

become hot during use and retain heat after operation.

Child Safety

oBaumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowed

to touch the appliance at any time. During and after use, all

surfaces will become hot.

oIf it is necessary for younger family members to be in the

kitchen, please ensure that they are kept under close supervision

at all times.

General Safety

Make sure that you understand the controls before using the

appliance.

Check that all of the controls on the appliance are turned off

after use.

Always stand back when opening the oven door, this will allow

heat to disperse.

Take care when removing items from the oven, as the contents

may be hot.

Always keep the oven doors closed when the oven is not in use.

Always follow the basic principles of food handling and hygiene;

this will prevent the possibility of bacterial growth.

Always keep ventilation slots clear of obstructions.

Keep fingers away from the hinge areas when closing the door,

otherwise you may trap them.

Oven gloves should be used when placing food in the oven cavity

and when removing it. Care should be taken to avoid direct

contact with any of the elements in the appliance.

oDO NOT LEAVE THE APPLIANCE UNATTENDED WHILST IN

USE.

oDo not place heavy objects on the oven door or lean on the

oven door when it is open, as this can cause damage to the oven

door hinges. Nobody should be allowed to sit or stand on any

part of the cooker.

oDo not store chemicals, food stuffs, pressurised containers in or

on the cooker or in cabinets immediately above or next to the

cooker.

oDo not heat up unopened food containers, as pressure can build

up which may cause the container to burst.

oDo not place flammable or plastic items on or near the hob

burners, these types of materials should also not be placed in

the oven or the compartment below the oven.

oDo not leave heated oil or fat unattended, as this is a fire risk.

You should not fill a deep fat frying pan more than one third full

of fat or oil; you should also not use a lid.

oDo not allow fat or oil to build up in the oven trays, grill pan or

oven base.

oDo not place pans or baking trays directly on the base of the

oven cavity, or line it with aluminium foil.

oDo not grill food containing fat without using a grill trivet. The

grill trivet should never be covered with aluminium foil.

oDo not place hot parts in water, leave them to cool first.

oDo not allow vinegar, coffee, milk, saltwater, lemon, tomato

juice or any liquid with high sugar content to remain in contact

with the enamel parts of the appliance. Spillages should be

wiped up immediately.

oDo not allow electrical fittings or cables to come into contact

with areas on the appliance that get hot.

oDo not use the appliance to heat the room it is located in or to

dry clothing. No clothing should be placed over or near to the

hob burners or oven door.

oDo not install the appliance next to curtains or soft furnishings.

oDo not attempt to lift or move cooking appliances by using the

oven door or handle, as this may cause damage to the appliance

or result in injury to the person lifting the appliance.

Cleaning

oCleaning of the oven should be carried out on a regular basis.

oGreat care should be taken whilst using this appliance and when

following the cleaning procedure.

oIMPORTANT: The appliance must be disconnected from the

mains before following the cleaning procedure.

oIMPORTANT: Care must be taken when cleaning between

the door glasses, and inside the inner frame as some of

the edges maybe sharp due to the manufacturing process.

Installation

This appliance must be correctly installed by a

suitably qualified person, strictly in accordance

with the manufacturer’s instructions. Please see

the specific section of this booklet that refers to

installation.

oBaumatic Ltd. declines any responsibility for injury or

damage, to person or property, as a result of improper

use or installation of this appliance.

oHeat, steam and moisture will be created during use of the

appliance, take care to avoid injury and ensure that the room is

adequately ventilated. If the appliance is going to be used for

prolonged periods of time, then additional ventilation may be

required.

oPlease consult with your qualified installer if you are in any doubt

about the amount of ventilation that you will require.

Declaration of conformity

This appliance complies with the following European Directives:

2006/95/EC regarding “low voltage”

2004/108/EC regarding “electromagnetic disturbances”

-89/109/EEC regarding “materials in contact with food”.

oThe above directives comply with 93/68/EEC regarding CE

marking.

oThe manufacturer declares that the oven is built using certified

materials and requires the appliance to be installed in

accordance with the standards currently in force. This appliance

must be used by a trained person for domestic purposes only.

Specifications

h= 760 mm

H = 885 - 940 mm

W = 900 mm

D = 600 mm

J = 60 mm

Product specifications:

o5 zone gas hob:

o1 x 3.80 kW triple crown wok burner

o1 x 3.00 kW rapid burner

o2 x 1.80 kW semi-rapid burners

o1 x 1.00 kW auxiliary burner

oFlame failure safety device on each burner

oAutomatic ignition

oHeavy duty cast iron pan stands

oEnergy efficiency class: A

oLED full programmer

oThermostatically controlled grill

oDouble-glazed removable “cool touch” door

oRemovable full inner glass

oWipe Clean enamelled cavity

oAdjustable feet

Multifunction oven

o8 functions

oNet oven capacity: 85 litres

oGross oven capacity: 112 litres

Standard accessories:

oTrivet

oWipeClean enamelled baking tray with handle

o2 x Safety shelves

oRemovable side racks

oLPG conversion jets

oWok stand

Optional extras:

oBPS2 Pizza Stone

oBT2GRID Griddle Plate With Handles

Electrical details

Rated Voltage: 230 Vac 50 Hz

Supply Connection: 20 A (double pole switched fused

outlet with 3mm contact gap)

Max Rated Inputs: 3.20 kW

Mains Supply Lead: 3 core x 1.5 mm² (not supplied)

Oven Light Bulb: E14 15 W/300°C screw type pygmy

Gas details

Gas Connection Type: 1/2” BSP

Gas Type (Natural Gas): 20 mbar

For future reference please record the following information which can

be found on the rating plate and the date of purchase which can be

found on your sales invoice. The rating plate for your oven can be

located by opening the door of the storage compartment.

Model Number ……………………………….

Serial Number ……………………………….

Date of Purchase ……………………………….

Inhaltsverzeichnis

Andere Baumatic Ofen Handbücher

Baumatic

Baumatic B900BL Bedienungsanleitung

Baumatic

Baumatic B153SS Bedienungsanleitung

Baumatic

Baumatic MEGACHEF B600MC Bedienungsanleitung

Baumatic

Baumatic BT2745SS Bedienungsanleitung

Baumatic

Baumatic BT3400SS Betriebsanleitung

Baumatic

Baumatic BO7C Bedienungsanleitung

Baumatic

Baumatic BO600BL SS Bedienungsanleitung

Baumatic

Baumatic BCS460SS Bedienungsanleitung

Baumatic

Baumatic PD659SS-ANZ Bedienungsanleitung

Baumatic

Baumatic BO616.6 SS Bedienungsanleitung

Baumatic

Baumatic BO980SS Bedienungsanleitung

Baumatic

Baumatic BT2460 Betriebsanleitung

Baumatic

Baumatic B902 Betriebsanleitung

Baumatic

Baumatic MEGACHEF B620MC Bedienungsanleitung

Baumatic

Baumatic B205SS-A Bedienungsanleitung

Baumatic

Baumatic P619SS-ANZ Bedienungsanleitung

Baumatic

Baumatic BYO600.5SS Bedienungsanleitung

Baumatic

Baumatic BAU91GG Bedienungsanleitung

Baumatic

Baumatic B724SS-A Bedienungsanleitung

Baumatic

Baumatic B240SS-A Bedienungsanleitung

Baumatic

Baumatic AS14 Betriebsanleitung

Baumatic

Baumatic B725SS Bedienungsanleitung

Baumatic

Baumatic BYO152.5SS Bedienungsanleitung

Baumatic

Baumatic BOS65MS Bedienungsanleitung

Beliebte Ofen Handbücher anderer Marken

Bosch

Bosch HVA531NS0 Bedienungsanleitung

Electrolux

Electrolux EOF6P46X Bedienungsanleitung

NEFF

NEFF B44S32 5GB Series Bedienungsanleitung

Combi

Combi BLODGETT BC142GDS Bedienungsanleitung

AEG

AEG COMPETENCE 311704300 Bedienungsanleitung

Falcon

Falcon DOMINATOR PLUS G3106 Series Benutzerhandbuch

Rational

Rational SCC WE 61G Bedienungsanleitung

Smeg

Smeg DOSPA38X Installations- und Betriebshandbuch

Electrolux

Electrolux air-o-convect 20 GN 2/1 Bedienungsanleitung

Miele

Miele HR 1954-2 Bedienungsanleitung

KHIND

KHIND OT50 Bedienungsanleitung

Henny Penny

Henny Penny Smoker Box Bedienungsanleitung

Lang

Lang ECOD-AP Bedienungsanleitung

AEG

AEG BEK455310M Bedienungsanleitung

Frigidaire

Frigidaire FNGE90JGR Bedienungsanleitung

Hotpoint

Hotpoint FE9 S831 JSH IX Bedienungsanleitung

GE Advantium SCB2000 Bedienungsanleitung

AEG

AEG DE401301DM Bedienungsanleitung
