BCS 615L Bedienungsanleitung
Operating Instructions
Before commissioning the machine, read operating instructions
and observe warning and safety instructions.
PLEASE ALSO READ ORIGINAL
BCS INSTRUCTION MANUAL
Crusader Power Scythes
Manufactured by BCS S.p.A.
Models 615L ●615SL ●630
BCS Crusader Power Scythes
Page 2 CPS/MAX/0617
No liability will be accepted for any damage caused to persons or property
through failure to observe the operating and safety instructions.
!
IMPORTANT READ CAREFULLY
Contents
Page 3 Safety
Page 4 Controls - 615L
Page 5 Controls - 615SL
Page 6 Controls - 630
Page 7 Assembly Instructions
Page 9 Safety Precautions
Page 10 Operating Hints
Page 11 Starting the Engine
Page 12 Operation
Page 13 Stopping the Engine
Page 14 Blade Holder Adjustment
Page 15 Blade Replacement
Page 16 Replacement of Traction Pin
Page 17 Maintenance Guide
Page 19 Risk Assessment
Page 20 Spare Parts
Page 21 Sound & Vibration Levels
Page 23 Manufacturer Information
BCS Crusader Power Scythes
CPS/MAX/0617 Page 3
Safety
ALWAYS read the original manufacturer’s manual rst
ALWAYS start the engine in the open air
DO NOT smoke when refuelling
DO NOT mix OIL with the fuel
ALWAYS stop the engine before making any adjustments, refuelling, moving or
cleaning, or when the unit is unattended
USE ONLY fuel from containers designed for this purpose - refuel outdoors only and
replace the tank cap securely
IN CASE of petrol spillage move the machine away from the area of spillage and
allow the petrol vapours to dissipate before starting the engine
DO NOT remove any safety guards that are tted
DO NOT touch any moving parts or attempt any maintenance whilst the machine is
running - KEEP HANDS AND FEET AWAY
BEFORE starting work clear the work area of any objects that could damage the
machine
DO NOT allow children or anyone uninstructed to operate the machine - KEEP
ANIMALS AWAY
DO NOT use on slopes or banks of more than 20o
ALWAYS wear suitable clothing to give personal protection including footwear that
offers a good grip
AVOID wearing loose garments that may catch in moving parts
KNOW how to stop the machine in an emergency
NEVER interfere with any control settings on the engine
NEVER select reverse gear with your back to a wall or other immovable object
IF A FAULT develops DO NOT attempt any repair - immediately contact the supplier
from whom the machine was obtained
VISUALLY INSPECT the machine before use - ensure all blades, nuts and bolts are
tight and not worn or damaged and replace blades if necessary
KEEP IN MIND the operator is responsible for accidents or hazards occurring to
people or property
BCS Crusader Power Scythes
Page 4 CPS/MAX/0617
Controls
BCS 615L
Forward / Reverse Lever Engine Stop (OPC) Lever
Throttle Lever
Handlebar Offset
Lever
Wheel Speed
Lever
Handlebar Height
Adjustment Lever
PTO Lever
Clutch Lever
Locking Clip
BCS Crusader Power Scythes
CPS/MAX/0617 Page 5
Controls
Forward / Reverse Lever
Throttle Lever
Handlebar Offset
Lever
Wheel Speed
Lever
Handlebar Height
Adjustment Lever
PTO Lever
Clutch Lever
Locking Clip
Differential
Lever
BCS 615SL
Engine Stop (OPC) Lever
BCS Crusader Power Scythes
Page 6 CPS/MAX/0617
Controls Description
Forward /
Reverse
Lever
Engine Stop (OPC) Lever
Throttle Lever
Handlebar
Offset Lever
Wheel Speed Lever
Handlebar Height
Adjustment Lever
Parking Brake
Lever
Clutch Lever
Locking Clip
BCS 630
Differential Lever
Left Steering
Brake Lever
Right Steering
Brake Lever
PTO Lever
BCS Crusader Power Scythes
CPS/MAX/0617 Page 7
Assembly Instructions
1. Remove the bar from the box and CHECK THE TIGHTNESS
of all bolts and mounting studs.
2. Fittheskidstothetopofthebar(gure2).
3. Fit the drive assembly (A) to the bar (B) using RED
LOCTITE on the two nuts. Ensure washers are tted
correctly(gure3).Ifapplicablechecktheoillevelin
the oil bath.
4. Fitcovermountingbracket(C)todriveunit(gure4).
Ensure locating pin on bracket ts into the lower of
the two holes. Secure the bracket with the nut & bolt
provided. If applicable t the spacers provided under
the front cover
5. Fitplasticprotectioncovertodriveunit(gure4).Nip
the bolt tight at this stage but do not overtighten.
6. Fit bracket (D) to plastic cover.
7. Fit brackets (C) and (D) together. This will normally be
through the bottom set of holes in bracket (D).
8. Tighten all nuts and bolts on the brackets and cover.
9. Read the manual thoroughly before making any
adjustments.
Figure 2
Figure 3
Figure 4
Figure 5
D
C
NO YES
BCS Crusader Power Scythes
Page 8 CPS/MAX/0617
ATTACHING THE BLADE HOLDER
1. Remove the bolt in the lower side of the blade holder
(gure9).
2. Screw the M8 x 20 bolt provided in the upper part of the
bladeholderallthewaydown(gure10).
3. Installthelocknutthatlockstheboltinplace(gure11)
andmountthebladeholderagain(gure12).
4. Adjustthebladeholder(gure13).Seepage6formore
on blade holder adjustment.
It is now possible to attach the cutter bar onto the
ange of the machine.
Figure 10
Figure 11
Figure 12
Figure 13
Assembly Instructions
Figure 9
BCS Crusader Power Scythes
CPS/MAX/0617 Page 9
Safety Precautions
During transportation of the machine, or when it is not in
use,installthebladeguard(A)onthebar(gure14).
Always wear HEAVY GLOVES to protect your hands whilst
working on the equipment.
READ and observe all warning labels on the machine and
implements(gure15).
Always wear appropriate work clothes whilst operating the
machine, always wear safety footwear.
DO NOT USEthemachinenearchildrenoranimals(gure
16).
The machine operator is responsible for any damage to
persons or property.
Always walk with the machine - DO NOT RUN.
NEVER work on slopes of more than 20oand always work
across the face of a slope (side to side), NEVER up and
down. NEVER use the machine on a bank where there is a
possibility of the machine sliding down the slope.
Always disengage the power take-off (PTO) when changing
direction or location of operation.
DO NOT replace the blades or attempt to undertake any
maintenance of the cutter bar while the engine is running.
ONLYqualiedpersonsshouldoperatethemachine.
If any abnormal vibrations occur STOP the engine immediately
and visually inspect the machine and implement for any signs
of damage.
IMPORTANT: Read all machine and implement manuals
thoroughly before using the cutter bar.
Figure 14
Figure 15
Figure 16
BCS Crusader Power Scythes
Page 10 CPS/MAX/0617
Operating Hints
IMPORTANT: Read all machine and implement manuals thoroughly before using the cutter bar.
Always familiarise yourself with the machine’s operation before commencing work.
Best results are obtained with the engine at a low throttle setting, which enables the bar to
cut cleanly and gives less wear and tear on the reciprocating parts, which in turn reduces
maintenance.
NB: If you are working on a slope, always work across the slope - never up or down.
On rough terrain, the bar should be raised by the height adjuster skids to prevent the blades
from digging into the ground.
WARNING: If any abnormal vibrations or sounds occur, STOP the engine immediately and
check the machine and the cutter bar. If you have any concerns contact your supplier.
!
IMPORTANT
NEVER USE MORE THAN ¼ THROTTLE
WHEN THE CUTTER BAR IS OPERATING
