PEDESTAL FAN & WALL FAN
OWNER’S MANUAL
Model: FSB75 COMBO
AIR COMPRESSOR
OPERATORS MANUAL
Version 5.1
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
FSB75 COMBO
FSB75 COMBO
Page 1
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
SAFETY INSTRUCTIONS
This product is intended for indoor use only.
Always operate the product from a power source of the same voltage, frequency
and rating as indicated on the product identication plate.
To reduce the risk of electric shock, do not use this fan with any solid state speed
control device.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
Do not insert ngers or any other foreign object through the front and rear guard
and into the blade.
Close supervision is necessary when any product is used by or near children or
inrm persons. Do not allow children to use it as a toy.
Do not operate any product with a damaged cord or plug, after the product
malfunctions, is dropped or appears damaged in any way. Return the complete
product to the place of purchase for inspection, repair or replacement.
To reduce the risk of electric shock, do not immerse or expose the product or
exible cord to rain, moisture or any liquid.
This product should not be used in the immediate vicinity of water, such as sinks,
bathtub, washbowls, swimming pool etc. where the likelihood of immersion or
splashing could occur.
Switch off and unplug from outlet when not in use, before assembling or
disassembling parts and before cleaning. Fully assemble the fan before switching
on.
Avoid contact with moving parts. Do not insert any object through the grill when
the fan is operating.
Do not cover the grill, or operate in close proximity to curtains, etc. Always
disconnect the fan when moving it from one location to another.
The use of attachments or accessories not recommended or sold by the product
distributor may cause personal or property hazards or injuries.
Never attempt to make any modications to or repair the product yourself. Have
it repaired by a qualied person only.
Place the appliance on a at and dry surface.
Manufacturer takes no responsibility for any damage caused by incorrect use.
Precautions must be taken to avoid the back-ow of gases into the room from the
open ow of gas or other fuel-burning appliances
Page 2
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
FAN DIMENSIONS
PAGE 10 PAGE 3
Pedestal
Wall
Page 3
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
PEDESTAL FAN ASSEMBLY
PAGE 4 PAGE 9
1. Fit REAR GUARD of fan onto the MOTOR and
secure with 4 screws provided. Ensure screws
are tight to avoid vibration noise
2. Fit BLADE to shaft and lock blade SET
SCREW.
3. Fit FRONT GUARD to rear guard using clips
provided.
4. Fit OUTER TUBE onto CAST IRON BASE and
secure with the BOLT. Then t COVER RING
onto CAST COUPLING.
5. Screw out PLASTIC KNOB on column then t
INNER TUBE. Secure grub screw with key.
6. Fit MOTOR onto MALE SUPPORTER. Adjust to
suitable height at coupling then lock the MALE
SUPPORTER SET SCREW.
7. Secure locking screw on FEMALE SUPPORTER
for desired head angle/ tilt. To adjust the head
tilt, loosen the nut above the female support,
then re-secure the nut after adjustment.
Page 4
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
WALL FAN ASSEMBLY
1. Complete points 1-3 on page 4.
2. Attach the wall mount base to the wall by drilling two holes with a M 10*80 drill
bit. Secure with the two M12 screws provided.
NOTE: Installation height should be a minimum of 2.5 metres from the ground.
IMPORTANT: Check wall is suitable for mounting and supporting the wall fan.
3. Insert the BEND TUBE through the two “U” shape slots provided in the wall
mount base & lock them into position using the two screws provided.
NOTE: The Bend tube can be positioned either upwards or downwards. You
must orient female support upward by removing the screw, repositioning &
resecuring. Never attach the fan so it is hanging below the female supporter.
PAGE 8 PAGE 5
FSB-75
FSB-75
Install the screw
Cement
Fixing
bolts
Wall
Bend Tube
Wall mount base
Washer
Spring Washer
Nut
Page 5
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
4. Insert the motor into the female support and secure with the screw.
PAGE 6 PAGE 7
5. Secure locking screw on FEMALE SUPPORTER for desired head angle/ tilt. To
adjust the head tilt, loosen the nut above the female support, then re-secure
the nut after adjustment.
WARNING! Make sure all parts are assembled correctly and connections are tight.
WARN ING! If supply cable to too tight the oscillating motion can cause damage -
ensure sufcient section of cable to avoid damage.
ENVIRONMENT OF USE
1. The max relative humidity is 90%(when in 25°C);
2. Below 1000 metres altitude.
FEMALE SUPPORTER
FAN HEAD
LOCATING SCREW
Page 6
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
OPERATION
1. Make sure the Fans voltage is in accordance with local voltage before use.
2. The fan is recommended for use in ordinary indoor situations, but not at high
humidity.
3. To turn on select the desired speed setting
0 - Off
1 - Slow
2 - Medium
3 - Fast
4. For xed air ow ensure the swing arm is not connected to the fan motor
5. For oscillating air ow ensure the swing arm is connected to the fan motor by
rotating the oscillating adjustment screw in an anti-clockwise direction.
6. Unplug the fan when not in use.
PAGE 6 PAGE 7
Page 7
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
MAINTENANCE
1. To ensure prolonged safe use ensure you have this unit inpected, cleaned &
moving parts lubricated by a qualied person aher every 1000 hours of use.
2. Regularly inspect the cord & plug & do not use if damaged. A lisenced
electrician is required to repair or replace the cord & plug.
3. Any other repairs or maintenance must be performed by a qualied person.
SPECIFICATION
ELECTRICAL DIAGRAM
Model Description Size
(mm)
Volt
(V~)
Freq
(Hz)
Watts
(W
Air Flow
(m3/min)
FSB-75 Pedestal Fan 750 220-240 50 280 290
FSB-75 Wall Fan 750 220-240 50 280 290
The data above is for reference only and may change without notice
PAGE 8 PAGE 5
FSB-75
FSB-75
Page 8
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
EXPLOSION VIEW & PARTS BREAKDOWN
PAGE 4 PAGE 9
Page 9
POWER EQUIPMENT
POWER EQUIPMENT
FSB75 COMBO OWNER’S MANUAL
EXPLOSION VIEW & PARTS BREAKDOWN
PAGE 10 PAGE 3
Pedestal
Wall
