Beckhoff CU8810-0010 Bedienungsanleitung

Installation- and Operating instructions for

CU8810-0010

DVI Splitter for CP29xx-0000, CP39xx-0000, CP69xx-0010 and

CP79xx-0010

Version: 1.0

Date: 2023-09-19

 Table of contents

CU8810-0010 1
Table of contents
1Foreword 3
1 Notes on the Documentation 3
1.1 Liability Conditions 3
1.2 Trademarks 3
1.3 Patent Pending 3
1.4 Copyright 3
1.5 State at Delivery 3
1.6 Delivery conditions 3
2 Description of safety symbols 4
3 Operator’s obligation to exercise diligence 4
2Product Description 5
1 Product Overview 5
2 Connections 6
2.1 Power Supply (X10) 6
2.2 Data Connectors 6
3 LED-Diagnostics 8
3Installation 9
1 Transport and Unpacking 9
1.1 Transport 9
1.2 Unpacking 9
2 Mounting / Unmounting 10
2.1 Mounting the DVI Splitter 10
2.2 Unmounting the DVI Splitter 10
3 Connecting devices 11
3.1 Connecting cables 11
3.2 Connecting Power Supply 11
4Operation 12
1 Configuration 12
1.1 Opening the enclosure 12
1.2 DIP Switch 1 (SW1) 13
1.3 DIP Switch 2 (SW2) 15
1.4 DIP-Switch 3 (SW3) 16
2 Architecture Description 18
2.1 Version 1 18
2.2 Version 2 18
2.3 Version 3 18

Table of contents

2CU8810-0010
2.4 Version 4 19
3 Maintenance 20
3.1 Cleaning 20
3.2 Maintenance 20
4 Shutting down 20
4.1 Disposal 20
5Dimensions 21
6Technical Data 22
7Appendix 23
1 Beckhoff Support and Service 23
1.1 Beckhoff branches and partner companies 23
1.2 Beckhoff company headquarters 23
2 Approvals for USA and Canada 24
3 FCC Approval for USA 24
4 FCC Approval for Canada 24


Foreword

CU8810-0010 3

1 Foreword

1.1 Notes on the Documentation

This description is only intended for the use of trained specialists in control and automation engineering

who are familiar with the applicable national standards. It is essential that the following notes and

explanations are followed when installing and commissioning these components.

The responsible staff must ensure that the application or use of the products described satisfy all the

requirements for safety, including all the relevant laws, regulations, guidelines and standards.

1.1.1 Liability Conditions

The documentation has been prepared with care. The products described are, however, constantly under

development. For that reason the documentation is not in every case checked for consistency with

performance data, standards or other characteristics. In the event that it contains technical or editorial

errors, we retain the right to make alterations at any time and without warning. No claims for the

modification of products that have already been supplied may be made on the basis of the data, diagrams

and descriptions in this documentation.

All pictures shown in the documentation are exemplary. Illustrated configurations can differ from standard.

1.1.2 Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, Safety over EtherCAT®, TwinSAFE®and XFC®are registered

trademarks of and licensed by Beckhoff Automation GmbH.

Other designations used in this publication may be trademarks whose use by third parties for their own

purposes could violate the rights of the owners.

1.1.3 Patent Pending

The EtherCAT Technology is covered, including but not limited to the following patent applications and

patents: EP1590927, EP1789857, DE102004044764, DE102007017835 with corresponding applications

or registrations in various other countries.

The TwinCAT Technology is covered, including but not limited to the following patent applications and

patents: EP0851348, US6167425 with corresponding applications or registrations in various other

countries.

1.1.4 Copyright

©Beckhoff Automation GmbH & Co. KG.

The reproduction, distribution and utilization of this document as well as the communication of its contents

to others without express authorization are prohibited. Offenders will be held liable for the payment of

1.1.5 State at Delivery

All the components are supplied in particular hardware and software configurations appropriate for the

application. Modifications to hardware or software configurations other than those described in the

documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.

1.1.6 Delivery conditions

In addition, the general delivery conditions of the company Beckhoff Automation GmbH & Co. KG apply.

Foreword

4CU8810-0010

1.2 Description of safety symbols

The following safety symbols are used in this operating manual. They are intended to alert the reader to

the associated safety instructions.

DANGER

Acute risk of injury!

If you do not adhere the safety advise adjoining this symbol, there is immediate

danger to life and health of individuals!

WARNING

Risk of injury!

If you do not adhere the safety advise adjoining this symbol, there is danger to life and

health of individuals!

CAUTION

Hazard to individuals!

If you do not adhere the safety advise adjoining this symbol, there is obvious hazard to

individuals!

Attention

Hazard to devices and environment

If you do not adhere the notice adjoining this symbol, there is obvious hazard to

materials and environment.

Note

Note or pointer

This symbol indicates information that contributes to better understanding.

1.3 Operator’s obligation to exercise diligence

The operator must ensure that

•the product is only used as intended (see chapter Product Description)

•the product is in a sound condition and in working order during operation (see chapter

Maintenance)

•the product is operated, maintained and repaired only by suitably qualified and authorized

personnel

•the personnel is instructed regularly about relevant occupational safety and environmental

protection aspects, and is familiar with the operating manual and in particular the safety notes

contained herein

•the operation manual is in good condition and complete, and always available for reference at the

location of the product

•none of the safety and warning notes attached to product are removed, and that all notes remain

legible.

Product Description

CU8810-0010 5

2 Product Description

2.1 Product Overview

A common application in machine and plant construction is the simultaneous display of a PC screen on

several monitors. Up to four DVI/USB Control Panels can be connected to a PC via the CU8810-0010

DVI Splitter. Thanks to DVI/USB2.0 extension technology, the Control Panels can each be connected at

distances of 50 m from the DVI Splitter. PCs with two DVI outputs, which are configured as extended

desktops, generate two different screen contents. Both DVI outputs can be fed into the DVI Splitter. Using

DIP switches, the four DVI outputs can each be assigned to one of the two DVI inputs, so that the Control

Panels show either the left or the right half of the desktop, as selected.

Other outstanding features are:

•metal housing for DIN rail installation

•compact industrial design

•2 DVI-D inputs, 4 DVI-D outputs

•assignment of the 4 DVI outputs to the 2 inputs freely configurable via DIP switches

•DVI inputs and outputs with full DVI data range up to 1.65 Gbit/s

•unused DVI input and outputs can be switched off to save energy

•4-port USB hub with 4 USB2.0 Extended outputs as RJ 45 connectors

•USB transfer rate up to 480 Mbit/s and 12 Mbit/s for USB 2.0

•24 V DC power supply.

Product Description

6CU8810-0010

2.2 Connections

2.2.1 Power Supply (X10)

X10

The DVI Splitter will be powered by a 24 VDC power supply (X10). The pins have to be connected as

shown on the front panel of the CU8810-0010 device.

One 3-pole power supply connector is provided, the pin assignment is shown at the imprint beside the

connector. The low resistance protective earthing connection is established via the ground pin.

Note

Malfunction possible with missing ground connection

A proper ground connection of the device is absolutely necessary for the correct

function of the touchscreen.

2.2.2 Data Connectors

The CU8810-0010 has three kinds of connectors: USB type B, RJ45 and DVI. The pin layouts are

described below.

2.2.2.1 USB Typ B Port (X20) (standard cable)

X20

Connector USB TYP-B LP-mount. WS

Signal

VCC

GND

Data -

Shield

Data+

2.2.2.2 RJ 45-Port (X30, X31, X32, X33) (standard CAT5 cable)

X30, X31, X32, X33

BA 1x8pole RJ45 Invers shield 2XLWL Lp-mount. Molex Nr: 43860-0016 Modular Jack

Signal

Assignment

Signal

Assignment

15 V

15 V +

USB RX

GND

USB TX

15 V

15 V +

USB RX

GND

Product Description

CU8810-0010 7

2.2.2.3 DVI Input (DVI-IN X40, X41) (standard DVI cable)

X40, X41

Connector DVI-D 3x8pole Digital LP-mount.

Signal

TMDS Data 2-

n.c.

TMDS Data 2+

+ 5 V Power Supply

TMDS Data2/4 Shield

GND ( +5 V, Analog H/V Sync)

n.c.

Hot Plug Detect

n.c.

TMDS Data 0 -

DDC Clock

TMDS Data 0 +

DDC Data

TMDS Data 0/5 Shield

Analog Vertical Sync

n.c.

TMDS Data 1 -

n.c.

TMDS Data 1 +

TMDS Clock Shield

TMDS Data1/3 Shield

TMDS Clock +

n.c.

TMDS Clock -

2.2.2.4 DVI Output (DVI-OUT X50, X51, X52, X53) (standard DVI cable)

X50, X51, X52, X53

Connector DVI-D 3x8pole Digital LP-mount.

Signal

TMDS Data 2-

n.c.

TMDS Data 2+

+ 5 V Power Supply

TMDS Data2/4 Shield

GND ( +5 V, Analog H/V Sync)

n.c.

Hot Plug Detect

n.c.

TMDS Data 0 -

DDC Clock

TMDS Data 0 +

DDC Data

TMDS Data 0/5 Shield

Analog Vertical Sync

n.c.

TMDS Data 1 -

n.c.

TMDS Data 1 +

TMDS Clock Shield

TMDS Data1/3 Shield

TMDS Clock +

n.c.

TMDS Clock -

Product Description

8CU8810-0010

2.3 LED-Diagnostics

The following table shows the possible states for the LEDs:

LED

Assignment

Status

Meaning

P10

Power Supply

off

No power supply connected

lights green

24 VDC connected

P20

USB/IN

Port

off

USB is operational

lights red

USB is in suspend mode/ no device connected

P30

USB/E

Port-0

off

No 15 V supplied to USB/E Port

lights green

15 V supplied to USB/E Port

P31

USB/E

Port-0

off

No suspend

lights yellow

Suspend

P32

USB/E

Port-1

off

No 15 V supplied to USB/E Port

lights green

15 V supplied to USB/E Port

P33

USB/E

Port-1

off

No suspend

lights yellow

Suspend

P34

USB/E

Port-2

off

No 15 V supplied to USB/E Port

lights green

15 V supplied to USB/E Port

P35

USB/E

Port-2

off

No suspend

lights yellow

Suspend

P36

USB/E

Port-3

off

No 15 V supplied to USB/E Port

lights green

15 V supplied to USB/E Port

P37

USB/E

Port-3

off

No suspend

lights yellow

Suspend

Inhaltsverzeichnis

Andere Beckhoff Touch-Terminal Handbücher

Beckhoff

Beckhoff KS31 2 Series Bedienungsanleitung

Beckhoff

Beckhoff ELX3152 Bedienungsanleitung

Beckhoff

Beckhoff KL3403 Series Bedienerhandbuch

Beckhoff

Beckhoff KL8001 Bedienerhandbuch

Beckhoff

Beckhoff EL28 Series Bedienerhandbuch

Beckhoff

Beckhoff EL1904 Bedienungsanleitung

Beckhoff

Beckhoff KL6811 Bedienerhandbuch

Beckhoff

Beckhoff ELX3202 Bedienungsanleitung

Beckhoff

Beckhoff KL26 Series. KS26 Series Bedienerhandbuch

Beckhoff

Beckhoff KL2602 Series Bedienerhandbuch

Beckhoff

Beckhoff KL400 Series Bedienerhandbuch

Beckhoff

Beckhoff KL4494 Bedienungsanleitung

Beckhoff

Beckhoff KL3356 Bedienerhandbuch

Beckhoff

Beckhoff KS3222 Bedienerhandbuch

Beckhoff

Beckhoff EL6652-00 0 Series Bedienerhandbuch

Beckhoff

Beckhoff KL9020 Bedienerhandbuch

Beckhoff

Beckhoff EL6751 Bedienerhandbuch

Beckhoff

Beckhoff KL4011 Bedienungsanleitung

Beckhoff

Beckhoff EL3773 Bedienerhandbuch

Beckhoff

Beckhoff KL31 2 Series Bedienerhandbuch

Beckhoff

Beckhoff EL3101 Bedienerhandbuch

Beckhoff

Beckhoff KL304 Series Bedienerhandbuch

Beckhoff

Beckhoff EL9930 Bedienungsanleitung

Beckhoff

Beckhoff EL34 Series Bedienerhandbuch

Beliebte Touch-Terminal Handbücher anderer Marken

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Bedienungsanleitung

Ingenico

Ingenico AXIUM EX4000 Bedienungsanleitung

Heisei Electronics

Heisei Electronics Q-POS 815 Bedienungsanleitung

Amano

Amano MTX-15 Bedienungsanleitung

FLOWBIRD

FLOWBIRD CWT Compact Touch Bedienungsanleitung

Demco

Demco SP7 Bedienungsanleitung

Lathem

Lathem PC600 Series Bedienungsanleitung

Partner

Partner MF-2352 Bedienungsanleitung

NCR

NCR RealPOS 7460-2 Handbuch

Simrad

Simrad MS50 Montageanleitung

Unitech

Unitech MR350 MKII Kurzanleitung

Jungheinrich

Jungheinrich WMT 210 Bedienungsanleitung

Motorola

Motorola MTP850 Bedienungsanleitung

YASKAWA

YASKAWA 62H-MDC0 Bedienungsanleitung

MVG industries

MVG industries NeptuLink Bedienungsanleitung

Price Industries Limited

Price Industries Limited FDC Gebrauchsanweisung

Honeywell

Honeywell TemaKey Bedienungsanleitung

EBN

EBN BPC65-B-A16G Bedienungsanleitung
