BEEM Outdoors LLC. MODEL NO. : BMG5
BEEM Outdoors LLC. Natural Gas & LPG
Generator Set Model # BMG5
Operation Instruction & Owner’s Manual
Caution:
Carefully read and understand this Owner’s Manual before starting this generator
1
Congratulations on your purchaseof our generator. We design and build generators to strict
specifications. With proper use and maintenance, this generator will bring you years of satisfying
service.
This unit is LPG or natural gas enginedriven, alternating current (AC) generator. It is designed to
supplyelectrical power for lighting,appliances, tools and similar equipment. Do not use gasoline or
other fuels.
This manualcovers operation and maintenance.All information in this publicationis based on the
latest productinformation available at the time of approval for printing.Every effort has been made
to ensure theaccuracy and completenessof the information in this manual. Wereserve the right to
change,alter and / or improve the products and this documentat any time without prior notice and
without incurring any obligation.
Record the model and serial numberas well as date and places of purchasefor future reference.
Have this information available when ordering parts and when technical or warranty inquiries.
Authorized Sales & Service Distributor:
Model Number:
Engine Serial Number:
Air-Fuel Mixer Serial Number:
Date Of Purchase:
Purchase Location:
Introduction
Introduction
Generator Set
This Booklet
This manual uses the following symbols to help differentiate between different kinds of information.
The safety symbol is used with a key word to alert you to potential hazards in operating and owning
power equipment.
Following all safety messages to avoid or reduce the risk of serious injury or death.
Danger
Danger indicates an imminentlyhazardous situation which, if not avoided, will result in death or
serious injury.
Warning
Warningindicatesa potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Caution
Caution indicatesa potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
Notice
!
!
!
Notice gives helpful information.
Manual Conventions
Manual Conventions
!
2
Safety Rules
Please read and understandthis manualthoroughlybefore operating your generator. Failure to
follow instructions could result in serious injury even death.
Exhaust gas contains poisonous carbon monoxide, which is harmful to the health. Never use the
generator set at the confined places or poor ventilated locations. If it’s necessary to run the
generator set, be sure to provide the adequateventilation.
Generator produces powerful voltage.
1. DO NOT touch bare wires or receptacles.
2. DO NOT use electrical cords that are worn, damaged or frayed.
3. DO NOT operate generator in wet condition or with wet hand.
4. DO NOT allow children or unqualifiedpersons to operate or service thegenerator.
5. DO NOT use a groundfault circuit interrupter (GFCI) in damp areas and areas containing
conductive material such as metal decking.
Use approved transfer equipmentto isolate generator from your electric utility and notify your utility
company before connectingyour generator to your power system.
Sparks can result in fire or electrical shock. Whenservicing the generator, disconnect the spark
plug wire and place it where it cannotcontact the plug. DO NOT check for spark with the plug
removed. Use only approved spark plug testers.
Warning
!
Warning
!
Danger
!
Warning
!
Warning
!
3
Safety Rules
Runningengines produceheat. Severe burnscan occur on contact. Combustiblematerial can catch
fire on contact.
Warning
!
1. Propane (LPG) and natural gas (NG) is highly flammable and explosive. Fire or explosion can
cause severe burns or death if the gas is ignited.
2. Before starting the generator, inspect your LPG tank and NG pipeline and valve for damage
or leaks, attach only approved tanks that have been properly filled by an approved station,
DO NOT light or smoke cigarette.
3. Replace the hose at the first sign of a leak or if age-cracking becomes apparent.
4. Whenstarting the generator DO NOT attempt to start a damagedgenerator, make certain
thatthe LPG tank, air filter, spark plug,fuel lines and exhaust system are properly in place,
make certain that the generator resting firmly on level ground.
5. Whenoperating the generator DO NOT move or tip the generator duringoperation, DO NOT
tip the generator or allow oil to spill.
6. Whentransportingor servicing thegenerator make certain that thegenerator is disconnected
and properly shut off, disconnectthe spark plug wire.
7. Whenstoring the generator store away from sparks, open flames, pilot lights, heat and other
sources of ignition.
Danger
!
1. Rapid retraction of the starter cord will pull hand and arm towards the engine faster than you
can let go. Unintentionalstartup can result in entanglement,traumaticamputationor
laceration. Broken bones, fractures, bruises or sprains could result in.
2. Whenstarting engine,pull the starter cord slowly until resistance is felt and then pull rapidly
to avoid kickback.
3. DO NOT start or stop the enginewith electrical devices pluggedin.
Warning
!
1. The battery contains acid. Acid is strongly corrosive.
2. DO NOT use, store or expose the battery in high temperature situations, as in the direct
sunlight,inside automobiles duringhot weather, directly in front of a heater, etc.
3. Be sure to turn off the equipmentafter use.
Warning
!
1. DO NOT touch hot surfaces.
2. Avoid contact hot exhaust gas.
3. Never touching the equipment until it’s cool.
4. Maintain at least 3 feet (about 1meter) of clearance on all sides to ensure adequate cooling.
5. Maintain at least 5 feet (about 1.5 meters) of clearance from combustiblematerials.
4
Safety Rules
Warning
!
The noise is harmful to your health when the generator set is running.Serious noise will result in
tinnitus,earache, hearing damage even deafness, eye and nervous system damage, etc. Please do
something for noise protection before running the generator set if it’s necessary, like as wearing
hearing protector and so on.
Caution
!
Exceeding the generator’s running capacity can damage the generator and/or electrical devices
connected to it.
Impropertreatment or use of thegenerator can damage it, shorten its life and void your warranty.
Use the generator only for intendeduse.
Caution
!
Use only genius AUTHORIZED SALES& SERVICEDEALER/DISTRIBUTOR parts or their
equivalent. The set of replacement which is not equivalent quality may damageyour generator.
Warning
!
1. DO NOT overload the generator.
2. Start the generator and allow the engine to stabilize before connecting electrical loads.
Connect electrical equipmentin the off position, and then turn them on for operation.
3. Turn electrical equipmentoff and disconnectbefore stoppingthe generator.
4. DO NOT tamperwith the speed governor.
5. DO NOT modify the generator in any way.
1. Operate only on level surfaces.
2. DO NOT expose generator to excessive moisture, dust,or dirt.
3. DO NOT allow any material to block the cooling slots.
4. If connected devices overheat, turn them off and disconnectthem from the generator.
5. DO NOT use the generator if electrical outputis lost, equipmentsparks, smokes or emits
flames and equipmentvibrates excessively.
5
Component Identification
BMG5
Cooling fan
Enginecover
(Front cover)
Alternator
(Generator)
Power output panel
Air-fuel mixer
series number
Auto
choke
valve
Spark plug cap
Air filter
Rubberleg
(Rubber mount)
Low oil sensor
Engineoil drain plug
Engineoil drain hole
Engineoil fill cap
(Dipstick)
Starter
Alternator cover
(Back cover)
Muffler
LPG / NG
Change-Over-Switch
Exhaust outlet
LPG
NG
LPG/NGchange-over-switch
Component Identification
Read this owner’s manual before operating your generator. Familiarize yourself with the location
and function of the controls and features. Save this manualfor future reference.
Oil Fill Cap:
Check and fill engine oil level.
Engine:
Used to power generator (alternator).
Air Cleaner:
Protects the engine by filtering dust and debris from the intake air.
Engine & Air-fuel Mixer Serial Number:
Please have this numberavailable when calling for assistance.
Low Oil Sensor:
Senses the level of oil in the crankcase and shuts the engine down if the level falls too low.
Auto Choke Valve:
Used to control air flow rate.
Bolt:
Used to fix the enginecover (front cover).
Power Output Panel:
Please refer to “Power output Panel” description.
Controls & Features
7
Electric start
Hour meter
Circuit breaker
Voltage meter
AC output
DC fuse
DC output
Gas inlet
Ground terminal
Engineswitch (fuel switch)
Power output panel
Read this owner’s manual before operating your generator. Familiarize yourself with the location
and function of the controls and features. Save this manualfor future reference.
Controls & Features
8
Description Nos.
Generator set 1
Spark plug socket 1
AC plug 2
DC battery cable 1
Gas pipe clip 1
Wrench 1
Vibration mount 4
12V, 15AH battery 1
Cap screw M8*25 4
Cap screw M5*12 2
Washer Φ5 2
Spring Washer Φ5 2
Nut M5 2
Owner’s Manual 1
Certificate of Quality 1
Assembly
Parts Included
Your generator set ships with the following parts.
9
