Behringer CRAVE Montageanleitung

Synthesizers and Samplers

CRAVE

Analog Semi-Modular Synthesizer with

3340 VCO, Classic Ladder Filter, 32-Step

Sequencer and 16-Voice Poly Chain

985-40000-01089 Rev.A

2021-02-16 page 1 of 6

Condential, for internal use only. Not to be reproduced.

User Support Bulletin

1. A digital voltmeter (with more than 4 signicant digits).

2. A Patch Cord

3. Small insulated trimmer screwdriver

4. Accurate, high-quality guitar tuner

Equipment Required

Introduction

The unit is carefully calibrated at the factory. The performance may change over time or due to environmental changes,

and the following recalibration procedures can be used to bring it back to its factory settings.

Synthesizers and Samplers

CRAVE

page 2 of 6page 2 of 6

Press “KYBD” or “STEP” key, set the keyboard octave to 3 (OCTAVE/LOCATION LED 3 will light up), then press “STEP6” key.

VCO TUNING ADJUSTMENT

OSC SCALE

Connect an accurate, high-quality tuner to the VCA/LINE OUTPUT jack.

PANEL DEFAULT SETTING (FIGURE 1)

Set the panel settings as shown in Figure 1.

Remove all unnecessary cables from the unit.

Preparation

Make sure your CRAVE has been powered on for at least 1 hour, and that it is in a place where the temperature will not

change drastically while performing the calibration.

Follow all steps in the order in which they are presented.

Calibration Procedures

Synthesizers and Samplers

CRAVE

page 3 of 6page 3 of 6

Adjust OSC OFFSET trimmer until the pitch is 440Hz (A4). Note that a pitch within 2 to 3 cents of the target frequency

should be ne. If the VCO pitch is still not correct after the adjustment is nished, you can calibrate the KB CV and

adjust it again as shown in the procedures above.

Set the keyboard octave to 6 and press “STEP6” key.

Adjust the panel OSC SCALE trimmer until the pitch is 880Hz (A5). Note that a pitch within 2 to 3 cents of the target

frequency should be ne.

Repeat steps 2 to 5 until output frequency is correct.

OSC OFFSET

Set the keyboard octave to 5 and press “STEP6” key.

Set the FREQUENCY control precisely to the center position.

Adjust the panel FREQUENCY control or OSC OFFSET trimmer until the pitch is 110Hz (A2). Note that a pitch within

2 to 3 cents of the target frequency should be ne; (OSC OFFSET trimmer and OSC SCALE trimmer location shown

in Figure 2).

OSC SCALE trimmer and OSC OFFSET trimmer LOCATION (FIGURE 2)

Synthesizers and Samplers

CRAVE

page 4 of 6page 4 of 6

KB CV CALIBRATION

Button names and LEDs

In the user CV calibration mode, the buttons have new functions as shown in the tables below:

There are three test points A / B / C to be calibrated. Their target voltage is -5 V / 0 V / 5 V respectively.

Button Name Function

HOLD/REST Select test mode A

RESET/ACCENT Select test mode B

ARP/SETEND Select test mode C

PATTERN/BANK —

SHIFT —

PAGE —

PLAY/STOP —

REC Save

Button Name Function

STEP1 Select X1 (about ±1 mV)

STEP2 Select X2 (about ±4.5 mV)

STEP4 Select X3 (about ±9 mV)

STEP4 Select X4 (about ±45 mV)

STEP5 —

STEP6 —

STEP7 —

STEP8 —

KYBD Decrease

STEP Increase

Synthesizers and Samplers

CRAVE

page 5 of 6page 5 of 6

Press “KYBD + STEP” then power up; All the LEDs will light up in the sequencer.

Then press“SHIFT + 1” to enter user CV calibration.

Measure the output of phone jack named “KB CV”.

Synthesizers and Samplers

CRAVE

Condential, for internal use only. Not to be reproduced.

Music Tribe accepts no liability for any loss which may be suered by any person who relies either wholly or in part upon any description, photograph, or statement contained herein.

Technical specications, appearances and other information are subject to change without notice. All trademarks are the property of their respective owners. Midas, Klark Teknik,

Lab Gruppen, Lake, Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera, Oberheim, Auratone and Coolaudio are trademarks or registered trademarks of Music Tribe Global

End of Procedure

Press “HOLD/REST” to select test mode A. You need to watch the multimeter to adjust the KBCV voltage.

You can press “KYBD”or “STEP” to adjust the value until it close to target level“-5 V”(±1 mV).

(Press “STEP1”“STEP2”“STEP3” or “STEP4” to select the speed of adjust “X1”“X2”“X3” or “X4”)

Press “RESET/ACCENT” to select test mode B.

Press “KYBD” or “STEP” to adjust the value until it close to target level “0 V” (±1 mV).

Press “ARP/SETEND” to select test mode C.

Press “KYBD” or “STEP” to adjust the value until it close to target level “5 V” (±1 mV).

Press “REC” to save and nish CV calibration.

Calibration done, power o the CRAVE.
