F8E832-BNDL
User Manual
Wireless Keyboard
and Optical Mouse Bundle
Enjoy the freedom of wireless optical precision
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Compatible Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Quick Installation Guide for PS/2 Connection . . . . . . . . . . . . . .3
Quick Installation Guide for USB Connection . . . . . . . . . . . . . . .4
Software Installation for Windows 98, Me, 2000, and XP . . . . . . .5
USB-PS/2 Standard Keyboard Hot Key Functions . . . . . . . . . . . . .6
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Uninstallation process for Windows 98, Me, 2000, and XP . . . . . .9
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
TABLE OF CONTENTS
Congratulations and thank you for purchasing the Wireless Keyboard
and Optical Mouse bundle from Belkin. We appreciate your business
and are sure you will enjoy years of reliable use with these
high-quality, input devices. Please review this entire User Manual
so you can be sure to get the most reliable performance from your
new equipment.
1
INTRODUCTION
2
INTRODUCTION
Compatible Equipment
Works with all PCs that are compatible with IBM®and equipped with
USB or PS/2 interface
NOTE: Use of these products on a desk made of iron, or other
metal, will negatively impact the operation of your Wireless
Keyboard and Mouse.
Operating Systems
Windows®XP, Me, 2000, 98 SE for USB interface
Windows XP, Me, 2000, 98 SE, 95 for PS/2 interface
Package Contents
Wireless Keyboard
Wireless Optical Mouse
Receiver
2 AAA batteries
2 AA batteries
User Manual
Please read the instructions for installing, operating, and using
the wireless desktop.
3
1. Be sure that your computer is powered off.
2. Connect the receiver to your computer’s PS/2 port. The receiver
has a 2-head connector for the Keyboard and Mouse
connections (purple is for the Keyboard and the USB
connection; the green is for the Mouse). There is also an
illustration on the top connector to identify them. If your
computer does not use the same color scheme, match the plug
with the illustration next to the port.
3. Install the batteries into your Keyboard and Mouse. Please
make sure you follow the indication on the inside compartment
for correct positioning of the batteries.
4. Power on your computer.
5. The receiver will automatically scan and synchronize the
Keyboard and Mouse. The Keyboard and Mouse should now
be functioning.
6. If automatic synchronization does not occur, please refer to
the “Troubleshooting” section of this User Manual.
QUICK INSTALLATION GUIDE FOR PS/2 CONNECTION
4
QUICK INSTALLATION GUIDE FOR USB CONNECTION
1. Be sure that your computer is turned on. If you are running
Windows 98, Me, or 2000, you will need to keep your old
keyboard and mouse connected for installation.
2. Connect only the receiver to your computer through the USB
port. Do not connect the purple PS/2 connection. It is not
needed in a USB environment.
Note: When connecting the USB cable to your computer, Windows
will start a New Hardware Wizard. In Windows XP, it will complete
the Wizard automatically. In Windows 98, Me, and possibly 2000,
you will need to follow through the New Hardware Wizard with your
old keyboard and mouse.
3. Install the batteries into your Keyboard and Mouse. Please
make sure you follow the indication on the inside compartment
for correct positioning of the batteries.
4. Power on your computer.
5. The receiver will automatically scan and synchronize the
Keyboard and Mouse. They should now be functioning.
6. If automatic synchronization does not occur, please refer to
the “Troubleshooting” section of this User Manual.
5
SOFTWARE INSTALLATION FOR
WINDOWS 98, ME, 2000, AND XP
Note: The Keyboard and Mouse should now be functioning.
If they are not, repeat the setup instructions and refer to the
“Troubleshooting” section for help. When the Mouse and
Keyboard are operational, the software can be installed.
Warning: It is recommended that you uninstall any previously
installed keyboard and mouse software prior to installing your
new Belkin software.
1. Be sure your computer is powered on.
2. Insert the CD into your computer’s CD-ROM drive.
3. If you have not previously installed Keyboard and Mouse
software, click “OK” and the installation will begin.
Follow the on-screen instructions.
4. Upon completion of installation, you will be prompted to
restart your computer. You must restart at this time in order
for the software to function.
6
USB-PS/2 STANDARD KEYBOARD
HOT KEY FUNCTIONS
My Documents Launch Microsoft My Document.
My Picture Launch Microsoft My Picture
(Note: This function does not
work in Windows 98.)
My Music Launch Microsoft My Music
(Note: This function does not
work in Windows 98 or 2000.)
Play/Pause Start and stop the playback of
your audio and video applications.
Stop
Volume Down Decrease your system volume.
Volume Mute Mute your system volume.
Volume Up Increase your system volume.
Previous Track Back to the previous track.
Next Track Go to the next track.
My Favorite Open your favorite list.
Refresh Reload the current web page.
Mail Open your system’s default
e-mail application.
WWW Open your system’s default
Internet browser.
7
TROUBLESHOOTING
The Keyboard and/or Mouse is/are not detected or do not
work after installation.
• Make sure the receiver cables are plugged into either the computer’s
PS/2 port or a USB port. If you are connecting via PS/2, make sure
that both plugs are being used (purple keyboard connection and the
USB connection with the green PS/2 adapter). If you are connecting
it via USB, be sure to connect the USB side only.
• For optimal performance, place the receiver at least eight inches
(20cm) away from the computer monitor, the computer, any external
storage devices, or other electrical devices.
• Make sure you have properly installed the batteries. Test the
batteries to make sure they are not dead (you can do this by
installing them into another device).
• You may have other system devices that are conflicting with the
Mouse and/or the Keyboard. Check the IRQ/address setting of these
devices for conflicts and change the settings as required. Please refer
to your computer documentation or the manufacturer’s technical
support for assistance in making these changes.
8
TROUBLESHOOTING
• Make sure you have properly established communication/
synchronization between the receiver and the Mouse and Keyboard.
• If the Keyboard and/or Mouse are not working, make sure that the
LED on the Keyboard and/or Mouse start flashing when you push
any of the Keyboard keys, Mouse buttons, or move the Mouse. If
the LED does not flash, check to make sure you have installed the
batteries correctly.
• When the Keyboard or Mouse LEDs are flashing, the LED on the
receiver should also flash to indicate they are speaking to each
other. If the LED on the receiver does not flash, it means that the
devices have not connected properly. Push the reset buttons on the
Mouse and on the Keyboard.
• If your Mouse pointer becomes choppy on-screen or the Keyboard
does not register keystrokes, replace batteries swith a fresh set.
