Belkin F9K1121v1 Bedienungsanleitung
User Manual
F9K1121v1 8820-01421 Rev. A00
N600 DUAL-BAND
PLUG-IN
Wi-Fi®ROUTER
TABLE OF CONTENTS
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
What’s in the Box ................................................ 1
Initial Setup ...........................................................1
Manually Set Up Your Internet Connection ........................... 10
Additional Capabilities ..........................................22
Guest Access........................................................23
Content Filtering Powered by Norton ................................24
Intellistream QoS ....................................................25
IPv6 Configuration ..................................................28
Getting to Know Your Router ....................................29
Front Panel..........................................................29
Back Panel ..........................................................30
Technical Details ................................................ 31
Technical Features ...................................................31
System Requirements ............................................... 32
Using Your Router ..............................................33
Enabling Auto Update on Your Router ...............................33
Updating the Router’s Firmware via the Web Interface................34
Resetting the Router ................................................37
Restoring the Router to Factory Default .............................37
Troubleshooting, Support, and Warranty .........................40
Troubleshooting.....................................................40
Technical Support ...................................................44
Belkin International, Inc., Limited 2-Year Product Warranty ...........45
Regulatory Information..........................................48
FCC Statement ......................................................48
1
What’s in the Box
N600 Dual-Band Plug-In Wi-Fi Router
Ethernet cable
Network information card (attached to router)
Quick Setup Guide
Initial Setup
Where to Place Your Router
For the best results, place the Router next to your modem in
an open location, away from large metal objects and magnets
such as those found in speakers. Raising the Router above
floor level can improve the strength of your wireless signal.
GETTING STARTED
15 seconds
2
GETTING STARTED
How to Set It Up
Connect Your N600 DB Router
Restart your modem by disconnecting its power supply. Some modems
have a battery backup; this will need to be disconnected at this time
as well.
Wait approximately 15 seconds and then connect the modem’s power
supply back into a power outlet.
Prior to plugging in the Router to a power source, please make a note
of the network ID information from the label on the back of your new
Router.
Plug in the Router to an available outlet and connect it to your modem
using the cable already attached.
3
GETTING STARTED
Connect to Your Router
Retrieve the network ID information from the label
on the back of your new Belkin Router.
Use your computer, tablet, or smartphone to connect to
the wireless network shown on the network label that
you made a note of when setting up the hardware.
For information on how to connect your wireless devices, please
see the “Connect Your Wireless Devices” section on page 20.
When requested, please enter the password
(security key) provided on the label.
When your device has connected to the Router, use
a browser to visit http://router/ or http://192.168.2.1.
The router homepage will appear.
4
GETTING STARTED
If the page does not load, then try visiting
http://192.168.2.1 to see the router homepage.
Click the “Detect my connection” button in green. (If
you would rather set up the Router manually, click the
“set it up manually” link and proceed to page 10.)
After several moments, your Router should automatically detect
your Internet connection and restart. This can take anywhere from
30 seconds to 3 minutes depending on your connection type.
If your Router is unable to establish an Internet connection
on its own, you may be asked to restart your modem or
provide a username and password if your connection requires
one. Follow the on-screen instructions provided.
5
GETTING STARTED
Once your Router is online, it will determine if there is a
firmware update available and offer to install it. Please
allow up to 5 minutes for the firmware to update.
If there are no updates available, then setup will proceed.
6
GETTING STARTED
At the next screen you will be invited to change your
network name and password. Re-using your previous
network name (SSID) and password makes connecting
your existing devices to the new router much easier.
If you decide to change these settings, then enter the
new values and click “Save and Continue.” (Note: The
password must be at least 8 characters long.)
If you changed your network name and password, make note
of it on the service card located on the foot of the Router.
You will then have to connect to the new network.
7
GETTING STARTED
Please take this opportunity to register your Router. This will
help technical support if there is a problem with your Router.
Simply complete each of the required fields and click
“Complete Registration.” If you don’t want to register
right now, click “Register Later” to proceed.
8
GETTING STARTED
At the next screen you can download optional
software that was bundled with your Router.
This screen shows you optional software that is available for your
Router, such as the Belkin Wi-Fi app used to access your router’s
homepage quickly. If you wish to download and install this software
program, simply click on the button appropriate for your device.
