BenQ SNS21 Bedienungsanleitung

Safety precautions Getting started Screen assembly Screen mounting

Digital Projector

Installation Guide

Ambient Light Rejecting Screen | SNS21

IMPORTANT

To install the product properly,

you are strongly recommended

to follow the steps and safety

precautions in this document.

V 1.00

How-to video

Installation guide

Safety precautions Getting started Screen assembly Screen mounting

Topics

Safety precautions

The screen frames may be sharp. Hold the

parts carefully to avoid possible personal

injury or damage to the floor/product.

Make sure the wall for screen mounting

is stable enough to support the weight of

your ambient light rejecting (ALR) screen.

Never fold the screen material. Avoid

any scratches or wrinkles on the screen

material.

To protect the screen, always wear gloves

before touching or moving the screen

material.

Installation tips

Fix all screws halfway so you can make

adjustments easily. Tighten all screws after

adjustments.

Use appropriate tools to fix different

screws.

Fix screws halfway Tighten after adjustment

Safety precautions

Installation tips

Getting started

Screen assembly

Wall mounting

Screen cleaning

Product support

Safety precautions Getting started Screen assembly Screen mounting

Note

• In the illustrations of this document, steps to complete a task are numbered with 1, and order of

installation is marked with

• Items in the package are labeled and mentioned by English letters.

• Illustrations in this document are for reference only. The actual content may vary by the product

supplied for your region.

Getting started

1Prepare the installation space. It should be at least 450 cm x 260 cm with a blanket to protect your floor.

Blanket for protection

177.16” (450 cm)

102.36”

(260 cm)

2Open the package. Start with reading the installation guide. Do not roll out the screen material yet.

Installation

Guide

Installation

Guide

Most of the package contents are inside the rolled screen material. Take package contets out. Be

careful not to fold or scratch the screen material.

Safety precautions Getting started Screen assembly Screen mounting

4Check all package contents.

All package contents

D IF BB FI D

C C

Kx 30 P x 4 U x 2

Lx 24 Q x 2 V x 8

Mx 26 R x 1 Level x 1

Nx 26 S x 2

Installation

Guide Installation

Guide

x 1

Ox 1 T x 2

Safety precautions Getting started Screen assembly Screen mounting

Screen assembly

Box contents for screen assembly

No. Name Picture Quantity

A Long inner frame 4

B Short inner frame 2

C Bracket 4

D Long fiberglass rod 2

E Short fiberglass rod 4

F Long edge trim 2

G Short edge trim 4

H Long outer frame 4

I Short outer frame 2

J Center support bar 1

K M5 x 10 screw 30

L M4 x 4 screw 24

MM4 x 60 screw with washer and

spring 26

N Nuts 26

O Screen material 1

P Corner sleeve 4

Q 3mm hex wrench 2

R Phillips screwdriver 1

S Gloves 2 pairs

Safety precautions Getting started Screen assembly Screen mounting

1. Inner frame assembly.

C C

Connect the left and right parts of the long

inner frame (A). Fasten them with three M5x10

screws (K).

Complete the inner frame assembly of two

long sides.

Insert the bracket (C) to the short inner frame

(B). Fasten them with two M5x10 screws (K).

Complete the inner frame assembly of two

short sides.

Safety precautions Getting started Screen assembly Screen mounting

Align the short inner frame (B) with the brackets (C) on both ends to the long inner

frames (A) together. Fasten them together with M5 x 10 screws (K). Follow the

illustrations to install the other short side and make the inner frame a square.

Align the center support bar (J) to the screw holes on the upper and lower inner

frames. Fasten the center support bar (J) with M4 x 4 screws (L).

5The inner frame is a square now. Leave it aside and free the space for screen material

installation.

Safety precautions Getting started Screen assembly Screen mounting

2. Screen material installation.

Wear the gloves (S) to protect the screen surface.

Roll out the screen material together with the protection of the supplied nonwoven

sheet carefully. The front side of the screen material is facing downwards. It should

be protected by the protection sheet at all times. Do not remove the UP sticker from

the back of the screen material. You will need the indication of the right screen

direction during installation.

F FD D

Insert the fiberglass rods (D & E) through the

openings on the screen material edges. Follow

the illustration to complete the long and the short

sides.

D & E

Snap the edge trims (F & G) to the screen material

edges to hold the screen material and the

fiberglass rods together. Follow the illustration to

complete the long and the short sides.

D & E

F & G

How-to video

Screen assembly

Safety precautions Getting started Screen assembly Screen mounting

5While the screen material is still placed and facing downards on the floor, place the assembled inner

frame gently on top of the screen material. Adjust the edge trims (F & G) so they are alignted with the

inner frame on the same side.

Insert nuts (N) to the edge trims as illustrated. Insert the number of nuts to each side as specified in the

illustration. That will be 8 nuts on each long side, and 4 nuts on each short side. Slide the nuts evenly to

align with the screw holes inside each inner frame as illustrated by the circles.

N x 8

N x 4

N x 8

N x 4

NF & G

F & G

7Flip the trims back towards the inner frame.

Safety precautions Getting started Screen assembly Screen mounting

8Fix the inner frame with the edge trim using the M4 x 60 screws (M). The screws should be fixed from

the screw holes inside the frame all the way out to the nuts just inserted into the edge trims. Follow the

order specified in the illustration to complete fixing 24 screws. Start from the middle of each side (as

indicated by

) in order to stretch the screen material properly.

Note

A standard set of M4 x 60 screw (M) comes with a

screw, a washer and a spring. Check and remove the

cap before use.

UPUPUP

1 2 12 18 23111724

4 3 9 19 22102021

9Lift the screen material and the frame carefully without touching the screen surface. Check if the screen

material is properly stretched.

To adjuist the stretch, work from the screws.

Once the adjustment is done, lay down the screen gently facing downward again (with the protection of

the supplied nonwoven sheet). Secure all screws.
