Installation, Operation and

Maintenance Manual (IOM)

Combination

Air Valve Model

Model C10 /C11

Table of Contents

General .....................................................................Page 2

Safety .......................................................................Page 2

Operational Data ......................................................Page 3

Materials and Connections .......................................Page 3

C10 Parts List (¾"-1" / DN20 - DN25) .........................Page 4

C10 Parts List (2" / DN50) ..........................................Page 5

C11 Parts List (¾"-1" / DN20 - DN25) .........................Page 6

C11 Parts List (2" / DN50) ..........................................Page 7

Surge Protection (SP) – Parts List ..............................Page 8

Inﬂow Prevention (IP) – Parts List ...............................Page 9

Unpacking and post shipment inspection ................Page 10

Site Preparation.......................................................Page 10

Installation ...............................................................Page 11

Operation ................................................................ Page 12

Principles of Operation ............................................ Page 13

Maintenance ........................................................... Page 14

Troubleshooting ...................................................... Page 15

Disassembling C10 / C11 (sizes ¾-1"/ DN25 DN50) ...Page 16

Reassembling C10 / C11 (sizes ¾-1"/ DN25 DN50)....Page 17

Disassembling C10 / C11 (size 2" / DN50)................ Page 20

Reassembling C10 / C11 (size 2" / DN50) ............... Page 21

General

The BERMAD C10 / C11 is a high quality combination

Air Valve for a variety of water networks and operating

conditions. It evacuates air during pipeline filling, allows

efficient release of air pockets from pressurized pipes,

and enables large volume air intake in the event of

network draining.

With its advanced aerodynamic design, this double

orifice valve provides excellent protection again air

accumulation and prevents vacuum formation with

improved sealing at low pressure.

This document serves as the Installation, Operation and

Maintenance Manual (IOM) of this valve; it describes the

procedures required for proper usage of the valve.

Safety

Since Air Valves operate in pressurized water systems

you are required to carefully read this manual before

using the valve. Handle the valve with care and make

sure to comply with all the relevant required safety

instructions and standards, general and local.

Operational Data

Pressure rating ISO PN10, ANSI / ASME 150

Operating pressure range 0.1-10 bar / 1.5-150 psi

Operating temperature Water up to 60° C / 140° F

Materials and Connections

Body material Glass-reinforced Nylon

Inlet diameter ¾", 1", 2" DN20, DN25, DN50

Connections Threaded Male BSPT / NPT

Outlet types

Sideways, Downwards (DN50/ 2" only)

Additional features (2" / DN50 only):

Surge Protection (C10-SP, C11-SP)

Inflow Prevention (C10-IP, C11-IP)

C10 Parts List

Body (#2)

Base (#1)

Float (#3)

O-Ring (#5011)

Kinetic Plug (#6)

Kinetic Plug Legs (#33)

Kinetic Seal (#4)

Peal Seal (#5)

C10 Parts List ¾"-1" / DN20 - DN25

Seals Kit (#60)

Kinetic Plug +

Legs Kit (#40)

Body (#2)

Drain Elbow (#8)

Base (#1)

Float (#3)

Peal Seal (#5)

Kinetic Plug (#6)

Kinetic Seal (#4)

C10 Parts List 2" / DN50

Seals Kit (#60)

O-Ring (#5012)

C11 Parts List ¾"-1" / DN20 - DN25

Body (#2)

Base (#1)

Float (#3)

Kinetic Seal (#4)

Auto Oriﬁce Seal (#18)

Auto Oriﬁce (#14)

Kinetic Plug (#6)

Kinetic Plug Leg (#33)

O-Ring (Base #5012)

O-Ring (Auto Oriﬁce #5000)

Seals Kit (#60)

Kinetic Plug +

Auto Orifice +

Legs Kit (#40)

C11 Parts List 2" / DN50

Body (#2)

Base (#1)

Test Point (#7)

Float (#3)

Auto Oriﬁce (#14)

O-Ring (Auto Orifice #5000)

Kinetic Seal (#4)

O-Ring (Base #5011)

Auto Oriﬁce Seal (#18)

Kinetic Plug (#6)

Seals Kit (#60)

Kinetic Plug +

Auto Orifice +

Legs Kit (#40)

Drain Elbow (#8)

Surge Protection (SP) – Parts List

Surge Seal (#11)

Grid (#10)

Surge Extension (#9)

Drain Elbow (#8)
