7
C. CHA HPF menu, through CHB knob to adjust HPF crossover point, the range is 20Hz-20 Khz,
OFF means close filter and select relevant slope through PC software.
CHA HPF Freq:
20Hz
D. CHA LPF menu, through CHB knob to adjust HPF crossover point, the range is 20Hz-20 Khz,
OFF means close filter and select relevant slope through PC software.
CHA LPF Freq:
OFF
E. CHB HPF menu, through CHB knob to adjust HPF crossover point, the range is 20Hz-20 Khz,
OFF means close filter and select relevant slope through PC software.
CHB HPF Freq:
OFF
F. CHB LPF menu, through CHB knob to adjust HPF crossover point, the range is 20Hz-20 KHz, OFF
means close filter and select relevant slope through PC software.
CHB LPF Freq:
OFF
G. Parameter save menu, save current parameter as Preset one, can recall the preset for next
power on; maximum store 50 presets for this device. Also can be saved and named by relevant PC
software, through CHB knob to select “Yes”or “NO”to determine the saving or not, press CHB
knob to save.
Save as:
Preset 01 No
H. Preset/recall the curve
Press CHA knob for 3 seconds in main menu, shown as above, through CHB knob to select
relevant presets; Press CHB knob to confirm to recall the presets, if successful, the recall curve
will be shown on screen. Press CHA knob to return main menu and cancel the curve recall.
Remark: When selected curve as below, it means this file doesn't include parameter.
Preset Recall:01
. . . . . . . . . . . .
Preset Recall:01
Not Use . . . . . . . .
