Page 1 of 3 06.12.2005

Interface protocol RS 232 serial port

For MCS 50 and MCS 50/64

Current version from 28.8.2003

Standardpin-out ofany RS 232 com port (9pin):

Sub- D

pin# function DataFlow

MCS <-> control

unit

1 - -

2 TxD ->

3 RxD <-

4 - -

5 GND -

6 - -

7 CTS <-

8 RTS ->

9 - -

Parameters:

•9600 Baud

•8 Databit

•NO Parity

•1Stop bit

RTS means ready tosend, normally active(+V);

CTS is waiting for the Clear-to-send signal from the control device(PC), ifno CTS is sent, Pin7

and 8must be shortened inside the connector.

Softwareprotocol:

Dataexchange intrue ASCII-Code. After any command aCarriage Return(0x0D) will be sent.

The Request-to-talk list is handled internally by the MCS 50 unit.

Pleaseuseastraight, standardRS 232 cable.

Page 2 of 3 06.12.2005

List ofInstructions:

Command DataFlow

MCS <-> PC

or control

panel

Function

‘PXXX’,CR <- post status changing, 3different ways:

a) post not speaking will lead topost speaking

b) post on Request-to-talk list will lead topost speaking

(list must be updated too)

c) post speaking will lead topost not speaking

XXX = Post number (000 – 032)

‘RXXX_’,CR -> microphone status not active

post icon on PC is off, no text

XXX = Post number (000 – 032)

_= Space(0x20)

‘PXXXM’,CR -> microphone status active

post icon on PC is on, text Mmeans normal delegate

XXX = Post number (000 – 032), M= MicroNormal Delegate

‘PXXXP’,CR -> microphone status active

post icon on PC is on, text P means chairman

XXX = Post number (000 – 032)

P = Micro“Präsident” (German for chairman)

‘RXXXAN’,CR

-> Microphone status not activebut post inrequest totalk list,

letter A means „Anmeldung“ (German for Request-to-talk)

XXX = Post number (000 – 032)

N = position on the list (1-9): 1means first on the list,

9= last on the list

‘P065’,CR <- MCS 50 Reset.

MCS is set intodefault switch-on mode

MCS 50 sends echo ‘P065’,CR

‘P066’,CR <- clear request totalk list

inside MCS 50 the request-to-talk list is cleared.

MCS 50 sends echo ‘P066’,CR and updates request-totalk-list

‘P067’,CR <- Next Function

station withhighest priority inreq.-to-talk list will be switched on (if

max NOMnot reached yet) and will be erased from this list. MCS

sends echo ‘P067’,CR and updates request-totalk-list

‘P068’,CR <- Clear function

All delegatemics will be cleared, chairmen status stays as it is.

MCS sends echo ‘P068’,CR and updates request-totalk-list

‘P068’,CR

‘R068’,CR -> MCS sends ‘P068’,CR, ‘R068’,CR when clear button is pushed at

any ofthe chairmen stations

‘P069’,CR <- Clear Function

All delegatemics will be cleared. Chairmen status stays as it is.

Noecho will be sent. Internal flag will be set sothat only

‘P069’,CR will be sent when the clear buttons arepushed on the

chairmen stations. This flag enabletohook-up alsonot intelligent

control panels. The flag is cleared when turning off the power on

the MCS 50.

‘P069’,CR -> This command will be sent from the MCS when clear button on

chairman station is pushed and command ‘P069’,CR was sent

beforetothe MCS 50

‘P070’,CR <- Volume – (decrease)

Page 3 of 3 06.12.2005

Output level is lowered gradually

MCS 50 sends echo‘P070’,CR

‘R070’,CR <- stop lowering output level

MCS 50 sends echo‘R070’,CR

‘P071’,CR <- Volume+ (increase)

Output level is increased gradually

MCS 50 sends echo ‘P071’,CR

‘R071’,CR <- stop increasing output level

MCS 50 sends echo ‘R071’,CR

‘P072’,CR <- Change mode intoRequest-to-Talk.

MCS 50 sends echo ‘P072’,CR followed by areset ofMCS 50

‘P073’,CR <- Change mode intoManual.

MCS 50 sends echo ‘P073’,CR followed by areset ofMCS 50

‘P074’,CR <- Change mode intoOverride.

MCS 50 sends echo ‘P074’,CR followed by areset ofMCS 50

‘P075’,CR <- Change mode intoautomatic (voicecontrolled)

MCS 50 sends echo ‘P075’,CR followed by areset ofMCS 50

‘P090’,CR <- Status check

MCS sends ‘OK’, CR

‘P091’,CR -> One ofthe chairmen has pressed his Priority Button first time

(Priority activate).

When Priority situations occurs, the individual stop or start

(status) messages, resulting from Priority actions (hardwareor

softwareactivated) aresent toPC.

‘P092’,CR -> One ofthe chairman has pressed his Priority Button second time

(Priority deactivate)

‘P093’,CR <- Activation ofPriority Status

‘P094’,CR <- Deactivation ofPriority Status

U. Roth, 28.8.2003
