Beyerdynamic MCS-D 2074 Bedienungsanleitung

FEATURES

• Standard microphone stations with special software and navigator

• Allows direct communication with interpreters, chairmen and technicians

• Allows monitoring all audio channels

• Fully digital audio and control

• Removable gooseneck microphone with illuminated ring, with DIN socket

• Alphanumerical display, approx. 48 x 13 mm: 1 line / 8 characters; height of character: 7 mm

• Phone: internal

• Clock

• Menu buttons to operate the menus

• Buttons (on the right hand side) to navigate through the menus and to control the headphone volume

• 10 function buttons

• Language selector

• 2nd language selector for integrated loudspeaker

• Big microphone button

• Integrated 2-way loudspeaker

• Bottom provides conference bus sockets

• Rugged housing

DESCRIPTION

The MCS-D 2074 with removable gooseneck microphone is configured as a service microphone station for a direct communication

between technicians, interpreters and technicians as well as chairmen and technicians. Furthermore, each audio channel of the

system can be monitored or listened to by using the MCS-D 2074.

The MCS-D 2074 provides an integrated 2-way loudspeaker, 8-digit LC-Display, two language selectors for a maximum of 54

languages, headphone connection and 10 function buttons (e.g. for internal telephone line, clock).

Each microphone station provides a four-button-navigator. In normal operation it is used for the channel selection and volume

control of the language selector. In the menu mode the buttons are used to select various functions such as displaying the time,

microphone station ID or voice communication to another microphone station within the meeting. The channel can be

selected for the headphone only; the loudspeaker is permanently set to the original language.

The microphone station is powered by the bus cable and can be placed anywhere in the bus network.

A private voice communication between two microphone stations within a meeting can be established via microphone and head-

phone.

Optionally the microphone station can be equipped with a chip card reader and/or a second language selector with separate

headphone output. The built-in 2-way loudspeaker is disconnected when a second language selector is integrated.

Germany

beyerdynamic GmbH & Co. KG

Theresienstr. 8

D-74072 Heilbronn

Phone +49 (0 )71 31 / 6 17-0

Fax +49 (0 )71 31 / 617-224

E-mail: [email protected]

Internet: www.beyerdynamic.de

United States

beyerdynamic Inc. USA

56 Central Ave.

Farmingdale, NY 11735

Phone +1 (631) 293-3200

Fax +1 (631) 293-3288

E-mail: [email protected]

Internet: www.beyerdynamic.com

Great Britain

beyerdynamic U.K. Ltd.

17 Albert Drive

Burgess Hill RH15 9TN

Phone +44 (0)1444 / 258 258

Fax +44 (0)1444 / 258 444

E-mail: [email protected]

Internet: www.beyerdynamic.co.uk

MCS-D 2074

SERVICE MICROPHONE STATION

Order # 483.052

ARCHITECT’SSPECIFICATIONS

Digital service desktop microphone unit, technician version for operation in the NetRateBus conference network. One button for

switching on/off. 10 number keys for entering the PIN and special functions. 4-button navigator for adjusting the language

channel, volume of the integrated language selector and menu guidance. 8 digit LC display for displaying the address of the

microphone unit, the selected language channel and the telephone function from one microphone unit to another. Technician

function for language channel listening, command announcements and interpreter communication. Detachable capacitor

gooseneck microphone (back electret) with cardiod characteristics, 345 mm total length and 6 mm diameter, red LED illuminating

ring below the microphone head for displaying that the participant is on stand-by to speak. Microphone unit address via network

and storage on the microphone unit. Headphones output with 3.5 mm jack and two-way loudspeaker system. Two push-pull

system-quick plug connections for the conference network. Optional microphone unit extension with chip card scanner or second

language selector. Design: plastic housing with anthracite-coloured, non-glare and scratch-resistant Nextel surface coating.

Dimensions (LxWxH) 250.00x160.5x100.6mm. Weight with microphone 850g.

Manufacturer: beyerdynamic

Type: MCS-D 2074

TECHNICAL SPECIFICATIONS

Frequency response. . . . . . . . . . . . . . . . . . . . . . . . . . . . -6 dB: 32 Hz - 23.5 kHz

-3 dB: 50 Hz - 22.4 kHz

Currrent consumption. . . . . . . . . . . . . . . . . . . . . . . . . . max. 130 mA

T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.1%

Headphone connection . . . . . . . . . . . . . . . . . . . . . . . . 1/8" (3.5 mm) mono jack socket

Volume control headphone . . . . . . . . . . . . . . . . . . . . . in 1.5 dB steps -79 dB - +9 dB

SNR of the headphone connection . . . . . . . . . . . . . . . -70 dB

System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x push-pull for a maximum of 5,000 mating cycles

Minimum impedance . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Ω

Temperature range . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to +40°C

Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250.00 x 160.51 x 100.67 mm

Weight with MIC 23 microphone. . . . . . . . . . . . . . . . . 850 g

E1/beyerdynamic MCS-D 2074 (06.06)

Non-contractual illustrations. Subject to change without notice.
