Blomberg TKF 8451 Bedienungsanleitung

TKF 8451

Dryer

2960310508_EN.indd/041212.1152

This appliance’s packaging material is recyclable. Help recycle it and protect the environment

by dropping it off in the municipal facility provided for this purpose. Your appliance also

contains a great amount of recyclable material. It is marked with this label to indicate

the used appliances that should not be mixed with other waste. This way, the appliance

recycling organised by your manufacturer will be done under the best possible conditions,

in compliance with European Directive 2002/96/EC on Waste Electrical and Electronic

Equipment. Contact your town hall or your retailer for the used appliance collection points

closest to your home. We thank you doing your part to protect the environment.

Please read this user manual first!

Dear Customer,

We hope that you get the best results from the product which has been manufactured

in state-of-the-art plants and passed through a strict quality control procedure.

Therefore, please read the entire user manual carefully before using the product and

keep it as a reference for future use. In case of transferring the product to someone

else, give the manual as well.

The user manual will help you use your product in a fast

and safe way.

• Read the user manual before installing and starting your product.

• Always follow the safety instructions.

• Keep this user manual within easy reach for future reference.

• Read also the other documents supplied with the product.

Remember that this user manual is also applicable for several other models.

Differences between models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

Read the instructions.

CImportant information or useful hints about usage.

AWarning for hazardous situations with regard to life and property.

BWarning for electric shock.

Warning for fire hazard.

Warning for hot surfaces.

3EN

1 Your Dryer 4

Overview .............................................4

Technical Specifications .......................5

2 Important safety instructions 6

General safety .....................................6

Intended use .......................................8

Children’s safety ..................................8

3 Installation 9

Appropriate installation location ...........9

Removing the transportation safety

assembly .............................................9

Under counter installation ..................10

Mounting over a washing machine .....10

Connection to water drain; ................10

Adjusting the feet ...............................10

First use ............................................11

Disposing of packaging material ........11

Transportation of the machine ...........11

Disposing of the old machine .............11

Warnings about sounds.....................11

4 Electrical Connection 12

Attention! ...........................................12

Electrical requirements .......................12

Fitting a different plug .......................12

Washer/dryer combination .................13

5 Preparations for drying 14

Things to be done for energy saving . . 14

Laundry suitable for drying in the

machine ............................................14

Laundry unsuitable for drying in the

machine ............................................14

Preparing laundry for drying ...............15

Correct load capacity ........................15

6 Selecting a Programme and

Operating Your Machine 17

Control panel .....................................17

Preparing the machine .......................18

Programme selection .........................18

Programme selection and consumption

table ..................................................20

Auxiliary function ................................21

Dryness level ...................................21

Anti-creasing ...................................21

Changing the contrast .......................21

Changing the delay time ....................22

Canceling the time delay ....................22

Starting the programme .....................22

Progress of programme .....................23

Changing the programme after it has

started ...............................................23

Child-proof lock .................................23

Canceling the programme .................24

End of programme ............................25

7 Maintenance and cleaning 26

Lint Filter / Loading Door Inner

Surface ..............................................26

Cleaning the sensors ........................26

Draining the water tank; .....................27

Cleaning the filter drawer ..................27

Cleaning the evaporator.....................29

8 Troubleshooting 31

9 Guarantee 32

10 Service 33

TABLE OF CONTENTS

4EN

1 Your Dryer

Overview

1- Control panel

2- Adjustable feet

3-Kick plate

4- Rating plate

5- Fluff filter

6- Power cord

5EN

Specifications of this appliance may change without notice to improve the quality of the

product. Figures in this manual are schematic and may not match your product exactly.

Values stated on the machine labels or in the documentation accompanying it are obtained

in laboratory in accordance with the relevant standards. Depending on operational and

environmental conditions of the appliance, values may vary.

EN 2

Height (adjustable) 84,6 cm

Width 59,5 cm

Depth 59,8 cm

Capacity (max.) 8 kg

Net weight (plastic front door usage) 52 kg

Net weight (glass front door usage) 54,5 kg

Voltage

See type labelRated power input

Model code

Type label is located behind the loading door.

Technical specifications

6EN

2 Important safety instructions

This section contains safety instructions

that will help protect from risk of personal

injury or property damage. Failure to

follow these instructions shall void any

warranty.

General safety

• Never place the product on a carpet-

covered floor; otherwise, lack of

airflow beneath the machine will

cause electrical parts to overheat.

This will cause problems with your

product.

• Do not operate the product if the

power cable / plug is damaged. Call

the Authorised Service Agent.

• Do not make any changes on the

plug supplied with the product. If it is

not compatible with the socket, have

a qualified electrician change the

socket with a suitable one.

• Never touch the plug with wet hands!

Never unplug by pulling on the cable,

always pull out by gripping the plug.

• Connect the product to a grounded

outlet protected by a fuse of suitable

capacity as stated in the technical

specifications table.

• Power cable of this product is

equipped with a conductor and

a grounding plug that allows for

grounding the product. This plug

must be inserted into a socket

which is installed and grounded in

accordance with the local laws and

regulations. Grounding installation

decreases the risk of electric shock

by opening a path with low resistance

for the electricity flow in case of a

malfunction or failure. Do not neglect

to have the grounding installation

made by a qualified electrician.

If you have any suspect about

the grounding installation, have it

checked by a qualified electrician.

Our company shall not be liable for

any damages that will arise when the

product is used without grounding in

accordance with the local regulations.

• The product should not be plugged

in during installation, maintenance,

cleaning and repair works.

• Always have the repair procedures

carried out by the Authorised Service

Agent. Manufacturer shall not be

held liable for damages that may

arise from procedures carried out by

unauthorised persons.

• Do not use electrical devices in the

product.

• You must provide enough ventilation

in order to prevent gases exiting from

devices operating with other types of

fuels including the naked flame from

accumulating in the room due to the

back fire effect.

• Items cleaned or washed with

gasoil/fuel oil, dry-laundry solvents

and other combustible or explosive

materials as well as the items that are

contaminated or spotted with such

materials should not be dried in the

product since they emit flammable or

explosive vapor.

• Pay attention that the air inlet

openings are unobstructed

• Do not dry the laundry cleaned with

industrial chemicals in the dryer.

• Underwear that contains metal

reinforcements should not be dried in

the dryer. Dryer can get damaged if

metal reinforcements come loose and

break off during drying.

• Never attempt to repair the product

yourself. Do not perform any

repair or replacement procedures

on the product even if you know

7EN

or have the ability to perform the

required procedure unless it is

clearly suggested in the operating

instructions or the published service

manual. Otherwise, you will be

putting your life and others' lives in

danger.

• For failures that you cannot remedy

by applying the procedures in safety

instructions, turn off and unplug

the product and call the Authorised

Service Agent.

• Do not reach into the machine when

the drum is spinning.

• Do not use extension cords, multi-

plugs or adaptors to connect the

dryer to power supply in order to

decrease the risk of fire and electric

shock.

• Never wash the product by spreading

or pouring water onto it! There is the

risk of electric shock!

The final step of the drying

programme, namely the cool-down

step is performed without applying

heat to ensure that the laundry items

are kept at a temperature that will

not damage them. If you open the

loading door before the cool-down

step completes, hot vapour will come

out.

ANever stop the dryer before the

programme completes. If you must

do this, remove all laundry quickly

and lay them out to a suitable place

to dissipate the heat.

• Always clean the lint filter before or

after each loading. Never operate the

dryer without the lint filter installed.

• Clean ventilation grid of the product

regularly. Do not allow fibre, dust

and dirt accumulation around the

ventilation grid and at adjacent areas.

• Power cable plug must be within easy

reach after installation.

• Do not dry unwashed items in the

dryer.

• Items soiled with cooking oils,

acetone, alcohol, fuel oil, kerosene,

stain removers, turpentine, paraffin

and paraffin removers must be

washed in hot water with plenty of

detergent before being dried in the

dryer.

• Garments or pillows bolstered with

rubber foam (latex foam), bathing

caps, water resistant textiles,

materials with rubber reinforcement

and rubber foam pads should not be

dried in the dryer.

• Do not use fabric softeners and

anti-static products unless they are

recommended by the manufacturers

of the relevant product.

• Use softeners, anti-static products

and etc. in accordance with the

instructions of their manufacturers.

• Do not install the product behind a

door with a lock, sliding door or a

hinged door which can strike the

product.

• Do not install or leave the dryer in

places where it will be exposed to

outdoor conditions.

• Your product can be operated at

temperatures between +5°C and

+35°C. If the operating conditions fall

outside of this range, operation of the

product will be adversely affected and

it can get damaged.

• Do not tamper with the controls.

• Unplug the product when it is not in

use.

• Remove the loading door of

the drying compartment before

decommissioning or disposing of the

product.

• Check all garments before loading

and make sure that there is no any

lighters, coins, metal pieces, needles,

8EN

and etc. in their pockets or on them.

• Make sure that the pets do not enter

into the product. Check the drum of

the product before using it.

• Make sure that original spare parts

and accessories are used during

maintenance works.

• Do not lean on the loading door when

it is open. The product may tip over.

• Remove all objects from pockets

such as lighters and matches.

• When your machine is not in use

or when you unload the laundry

after completion of drying process,

turn the machine off with the On/

Off button. In cases where the On/

Off button is in On position (while

the machine is energized), keep the

loading door closed.

Intended use

• This product has been designed for

domestic use. It should not be used

for other purposes.

• Product must only be used for

drying of textiles that are marked

accordingly.

• Dry only those articles in your product

that are stated in this manual.

• This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

Children's safety

• Electrical products are dangerous for

the children. Keep children away from

the product when it is operating. Do

not let them tamper with the product.

• Do not allow children sit/climb on or

enter in the product.

• Do not forget to close the loading

door when leaving the room where

the product is located.

• Packaging materials are dangerous

to children. Keep the packaging

materials out of reach of children

or dispose of them by classifying

according to waste directives.

9EN

3 Installation

To make the product ready for use,

make sure that the electricity and water

drainage system are appropriate before

installation. If they are not, call a qualified

technician and plumber to have any

necessary arrangements carried out.

C Preparation of the product’s location

as well as the electrical and waste

water installations is the customer’s

responsibility.

C Manufacturer shall not be held

liable for damages that may arise

from procedures carried out by

unauthorised persons.

A Prior to installation, visually check if

the product has any defects on it. If

so, do not have it installed. Damaged

products cause risks for your safety.

The appliance should be transported

only in a vertical upright position.

If during the course of transport the

appliance has to be transported

horizontally, it must only be laid on

its right hand side. After bringing it

to upright position,it must not be

operated for at least 12 hours to

allow the system to settle.

Failure to comply with the above

instructions could result in damage

occurring to the appliance. The

manufacturer will not be held

responsible if these instructions are

disregarded.

Appropriate installation

location

• Install the product on a stable and

level surface.

• Dryer is heavy. Do not move it by

yourself.

• Operate your product in a well

ventilated, dust-free environment.

• Do not block the air ducts in front of

and under the product with materials

such as long pile rugs or wooden

plinths.

• Do not install the product behind a

door with a lock, sliding door or a

hinged door which can strike the

product.

• Once the product is installed, it

should stay at the same place where

its connections have been made.

When installing the product, make

sure that the rear wall of it does

not touch anywhere (tap, socket,

etc.). Also pay attention to select an

installation location which you will not

be required to change afterwards.

• Place the product at least 1.5

cm away from the edges of other

furniture.

BDo not place the product on the

power cable.

Removing the transportation

safety assembly

Remove the transportation safety

assembly before using the product for

the first time.

1. Open the loading door.

2. There is a nylon bag inside the drum

that contains a piece of styrofoam.

Hold it from its section marked with

XX XX.

3. Pull the nylon towards yourself and

remove the transportation safety

assembly.

10 EN

Make sure that no part of the

transportation safety assembly

remains inside the drum.

Under counter installation

• This product can be installed under a

counter if the height of the counter is

sufficient.

Never operate the dryer without the

top trim is in place.

Dryer Depth 60 cm 54 cm

Stock

number of

under-bench

installation

part

2979700100 2973600100

• Leave at least 3 cm of space around

the sides and the rear wall of the

product when installing it under a

counter or in a cupboard.

Mounting over a washing

machine

• A fixing device should be used

between the two machines when

installing the dryer above a washing

machine. The fixing device can

usually be obtained from a specialist

retailer.

• Total weight of the washing machine

and the dryer -with full load- when

they are placed on top of each other

reaches to approx. 180 kilograms.

Place the products on a solid floor

that has sufficient load carrying

capacity!

Connecting to the drain

In products equipped with condenser

unit, water accumulates in the water tank

during the drying cycle. You should drain

accumulated water after each drying

cycle.

You can directly drain accumulated water

through the water drain hose supplied

with the product instead of periodically

draining the water collected in the water

tank.

Connecting the water drain hose

1. Pull hose in the product by hand in

order to disconnect it from where it is

connected. Do not use any tools to

remove the hose.

2. Connect one end of the drain hose

supplied separately with the product

to the connection point from where

you removed the hose of the product

in previous step.

3. Connect the other end of the drain

hose directly to the wastewater drain

or to the washbasin.

Hose must be securely fixed to

prevent leaks. Your house will be

flooded if the hose comes loose

during water discharge.

CWater drain hose should be attached

to a height of maximum 80 cm.

C Make sure that the water drain hose

is not stepped on and it is not folded

between the drain and the machine.

Adjusting the feet

In order to ensure that the product

operates more silently and vibration-free,

it must stand level and balanced on its

feet. Balance the machine by adjusting

Inhaltsverzeichnis

Andere Blomberg Trockner Handbücher

Blomberg

Blomberg TKF 8451 AG 50 Bedienungsanleitung

Blomberg

Blomberg TKF 8431 A Bedienungsanleitung

Blomberg

Blomberg TAF 7239 Bedienungsanleitung

Blomberg

Blomberg LTK 28021 W Bedienungsanleitung

Blomberg

Blomberg TKF 8439 Bedienungsanleitung

Blomberg

Blomberg TAF 7239 Bedienungsanleitung

Blomberg

Blomberg TKF 7449 Z Bedienungsanleitung

Blomberg

Blomberg LTH3842W Bedienungsanleitung

Blomberg

Blomberg LTK2803B Bedienungsanleitung

Blomberg

Blomberg TROCKNER TKF 7330 A Bedienungsanleitung

Blomberg

Blomberg TGU490RX0 Bedienungsanleitung

Blomberg

Blomberg DHP24404W Bedienungsanleitung

Blomberg

Blomberg TKF 7431 A Bedienungsanleitung

Blomberg

Blomberg TKF 8451 ZGC 50 Bedienungsanleitung

Blomberg

Blomberg TKF 7451 AG 50 Bedienungsanleitung

Blomberg

Blomberg TKF 1330 Bedienungsanleitung

Blomberg

Blomberg LTK 21003W Bedienungsanleitung

Blomberg

Blomberg TKF 1350 Bedienungsanleitung

Blomberg

Blomberg TKF 7350 Bedienungsanleitung

Blomberg

Blomberg TAF 1330 Bedienungsanleitung

Blomberg

Blomberg TKF 8431 Bedienungsanleitung

Blomberg

Blomberg LTP18320W Bedienungsanleitung

Blomberg

Blomberg TROCKNER TAF 7230 A Bedienungsanleitung

Blomberg

Blomberg DTGV7001W Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
