D Bedienungsanleitung

Refrigerator

KFD 9952 XA+

Kühlschrank

Køleskab

Kjøleskap

Kylskåp

Jääkaappi

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future references.

This manual

• Will help you use your appliance in a fast and safe way.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

This product is supplied with the selective sorting symbol for waste electrical

and electronic equipment (WEEE).

This means that this product must be handled pursuant to European Directive

2002/96/EC in order to be recycled or dismantled to minimise its impact on

the environment. For further information, please contact your local or regional

authorities.

Electronic products not included in the selective sorting process are potentially

dangerous for the environment and human health due to the presence of

hazardous substances.

Recycling

1 The refrigerator 3

2 Important Safety

Warnings 4

Intended use .....................................4

General safety ...................................4

Child safety........................................6

HCA Warning ....................................6

Things to be done for energy saving..6

3 Installation 7

Points to be considered when re-

transporting your refrigerator .............7

Before operating your refrigerator ......7

Electric connection ............................8

Disposing of the packaging ...............8

Disposing of your old refrigerator .......8

Placing and Installation ......................9

Floor balance adjustment ..................9

Adjusting the gap between the upper

door ................................................10

Installing Water Filter .......................11

Connection of the Water Pipe to the

Refrigerator .....................................11

Connection of Water Hose to the

Jug .................................................12

Connection of the Water Pipe to the

Cold Water Mains Line ....................13

Prior to first use of Water Dispenser.15

Using the water spring.....................16

Spillage Tray ....................................16

4 Preparation 17

5 Using your refrigerator 18

Indicator Panel.................................18

Door Open Alarm: ..........................20

Things to do to have the filter usage

time calculated automatically...........21

Egg tray...........................................22

Sliding Body Shelves .......................22

Chiller compartment ........................22

Crisper ............................................23

Movable Middle Section .................24

Blue light .........................................24

Telescopic Drawer ..........................25

Dual cooling system: .......................25

Ice maker .......................................................................26

Ice box ............................................................................26

Freezing fresh food..........................27

Recommendations for preservation of

frozen food ......................................27

Placing the food ..............................28

Deep-freeze information ..................28

6 Maintenance and

cleaning 29

Protection of plastic surfaces ..........29

7 Recommended solutions

for the problems 30

CONTENTS

1The refrigerator

A- Fridge compartment

B- Freezer compartment

1- Butter & Cheese shelf

2- Fridge compartment door

shelves

3- Fridge compartment glass

shelves

4- Diffuser cover

5- Illumination lens

6- Movable middle section

7- Chiller compartment

8- Bottle shelf

9- Crisper

10- icebox

11- Movable separators

12- Ice maker

CFigures that take place in this instruction manual are schematic and may

not correspond exactly with your product. If the subject parts are not included in

the product you have purchased, then it is valid for other models.

2Important Safety Warnings

Please review the following

information. If these are not followed,

personal injury or material damage

may occur. Otherwise, all warranty and

reliability commitments will become

invalid.

The usage life of the unit you

purchased is 10 years. This is the

period for keeping the spare parts

required for the unit to operate as

described.

Intended use

• This appliance is intended to be used

in household and similar applications

such as

– staff kitchen areas in shops, offices

and other working environments;

– farm houses and by clients in hotels,

motels and other residential type

environments;

– bed and breakfast type environments;

– catering and similar non-retail

applications.

• It should not be used outdoors. It is

not appropriate to use it outdoor even

if the place is covered with a roof.

General safety

• When you want to dispose/scrap

the product, we recommend you

to consult the authorized service in

order to learn the required information

and authorized bodies.

• Consult your authorized service for

all your questions and problems

related to the refrigerator. Do not

intervene or let someone intervene to

the refrigerator without notifying the

authorized services.

• Do not eat cone ice cream and ice

cubes immediately after you take

them out of the freezer compartment!

(This may cause frostbite in your

mouth.)

• Do not put bottled and canned

liquid beverages in the freezer

compartment. Otherwise, these may

burst.

• Do not touch frozen food by hand;

they may stick to your hand.

• Vapor and vaporized cleaning

materials should never be used in

cleaning and defrosting processes of

your refrigerator. In such cases, the

vapor might get in contact with the

electrical parts and cause short circuit

or electric shock.

• Never use the parts on your

refrigerator such as the door as a

means of support or step.

• Do not use electrical devices inside

the refrigerator.

• Do not damage the cooling circuit,

where the refrigerant is circulating,

with drilling or cutting tools. The

refrigerant that might blow out when

the gas channels of the evaporator,

pipe extensions or surface coatings

are punctured may cause skin

irritations and eye injuries.

• Do not cover or block the ventilation

holes on your refrigerator with any

material.

• Repairs of the electrical appliances

must only be made by qualified

persons. Repairs performed by

incompetent persons may create a

risk for the user.

• In case of any failure or during

a maintenance or repair work,

disconnect your refrigerator’s mains

supply by either turning off the

relevant fuse or unplugging your

appliance.

• Do not pull by the cable when pulling

off the plug.

• Place the beverage with higher proofs

tightly closed and vertically.

• Do not store explosive substances

such as aerosol cans with a

flammable propellant in this

appliance.

• Do not use mechanical devices

or other means to accelerate the

defrosting process, others than those

recommended by the manufacturer.

• This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

• Do not operate a damaged

refrigerator. Consult your service if

you have any doubts.

• Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

• Exposing the product to rain, snow,

sun and wind is dangerous with

respect to electrical safety.

• Contact the authorized service when

there is a power cable damage and

etc. so that it will not create a danger

for you.

• Never plug the refrigerator into

the wall outlet during installation.

Otherwise, risk of death or serious

injury may arise.

• This refrigerator is designed solely for

storing food. It should not be used for

any other purposes.

• The label that describes the technical

specification of the product is

located on the inner left part of the

refrigerator.

• Do not hook up the refrigerator to

electronic energy saving systems as it

may damage the product.

• If the refrigerator has blue light do not

look at the blue light through optical

devices.

• If the power supply is disconnected

in manually controlled refrigerators

please wait for at least 5 minutes

before reconnecting the power.

• This product manual should be

passed to the next owner of the

refrigerator if the owner changes.

• When moving the refrigerator make

sure that you do not damage the

power cord. In order to prevent

fire the power cord should not be

twisted. Heavy objects should not

be placed on the power cord. When

the refrigerator is being plugged do

not handle the power outlet with wet

hands.

• Do not plug the refrigerator if the

electric outlet is loose.

• Do not splash water directly on the

outer or inner parts of the refrigerator

due to safety.

• Do not spray inflammable materials

such as propane gas etc near

refrigerator due to the risk of fire and

explosion.

• Do not place objects filled with water

on top of the refrigerator as it may

result in electric shock or fire.

• Do not overload the refrigerator with

excess food. The excess food may

fall when the door is opened resulting

in injuring you or damaging the

refrigerator. Do not place objects on

top of the refrigerator as the objects

may fall when opening or closing the

refrigerator door.

• Materials that require certain

temperature conditions such as

vaccine, temperature sensitive

medicines, scientific materials etc

should not be kept in refrigerator.

• If refrigerator will not be operated for

an extended period of time it should

be unplugged. A problem in electrical

cable insulation may result in fire.

• The tip of the electric plug should be

cleaned regularly otherwise it may

cause fire.

• The refrigerator may move when the

adjustable feet is not positioned firmly

on the floor. Using the adjustable feet

you can unsure that the refrigerator is

positioned firmly on the floor.

• If the refrigerator has door handle

do not pull the refrigerator via door

handles when moving the product as

it may disconnect the handle from the

refrigerator.

• If you must operate your appliance

adjacent to another refrigerator or

freezer, the distance between the

appliances must be at least 8 cm.

Otherwise condensation may occur

on the side walls facing each other.

• Water mains pressure must not be

below 1 bar. Water mains pressure

must not be above 8 bars.

• Use only drinkable potable water.

Child safety

• If the door has a lock, the key should

be kept away from reach of children.

• Children should be supervised to

ensure that they do not play with the

appliance

HCA Warning

If your product is equipped with

a cooling system that contains

R600a:

This gas is flammable. Therefore, pay

attention to not damaging the cooling

system and piping during usage and

transportation. In the event of damage,

keep your product away from potential

fire sources that can cause the

product catch a fire and ventilate the

room in which the unit is placed.

Ignore the warning if your product

is equipped with a cooling system

that contains R134a.

You can see the gas used in

production of your product on the

rating plate that is located on the left

inner part of it.

Never dispose the product in fire.

Things to be done for energy

saving

• Do not leave the doors of your

refrigerator open for a long time.

• Do not put hot food or drinks in your

refrigerator.

• Do not overload your refrigerator so

that the air circulation inside of it is

not prevented.

• Do not install your refrigerator

under direct sunlight or near heat

emitting appliances such as ovens,

dishwashers or radiators.

• Pay attention to keep your food in

closed containers.

• Maximum amount of food can be

put in your refrigerator’s freezer

compartment when the freezer

compartment shelf or drawer

is removed.Declared energy

consumption value of your

refrigerator was determined when the

freezer compartment shelf or drawer

was removed and under maximum

amount of food load.There is no risk

in using a shelf or drawer according

to the shapes and sizes of the foods

to be frozen.

3Installation

CPlease remember that the

manufacturer shall not be held liable if

the information given in the instruction

manual is not observed.

Points to be considered

when re-transporting your

refrigerator

1. Your refrigerator must be

emptied and cleaned prior to any

transportation.

2. Shelves, accessories, crisper and etc.

in your refrigerator must be fastened

securely by adhesive tape against any

jolt before repackaging.

3. Packaging must be tied with thick

tapes and strong ropes and the

rules of transportation printed on the

package must be followed.

CAlways remember...

Every recycled material is an

indispensable source for the nature

and for our national resources.

If you wish to contribute to recycling

the packaging materials, you can

get further information from the

environmental bodies or local

authorities.

Before operating your

refrigerator

Before starting to use your refrigerator

check the following:

1. Is the interior of the refrigerator dry

and can the air circulate freely in the

rear of it?

2. You can install the 2 plastic wedges

as illustrated in the figure. Plastic

wedges will provide the required

distance between your refrigerator

and the wall in order to allow the air

circulation. (The illustrated figure is

only an example and does not match

exactly with your product.)

3. Clean the interior of the refrigerator as

recommended in the “Maintenance

and cleaning” section.

4. Plug the refrigerator into the wall

outlet. When the door is open the

respective interior light will come on.

5. You will hear a noise as the

compressor starts up. The liquid and

gases sealed within the refrigeration

system may also give rise to noise,

even if the compressor is not running

and this is quite normal.

6. Front edges of the refrigerator may

feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Electric connection

Connect your refrigerator to a

grounded socket which is being

protected by a fuse with the

appropriate capacity.

Important:

BThe connection must be in

compliance with national regulations.

BThe power cable plug must be easily

accessible after installation.

BThe specified voltage must be equal

to your mains voltage.

BExtension cables and multiway plugs

must not be used for connection.

BA damaged power cable must be

replaced by a qualified electrician.

BThe appliance must not be operated

before it is repaired! There is danger

of electric shock!

BWarning against electric voltage.

Disposing of the packaging

AThe packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose them of by

classifying them in accordance

with the waste instructions. Do not

dispose them of along with the normal

household waste.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old machine without

giving any harm to the environment.

AYou may consult your authorized

dealer or waste collection center of

your municipality about the disposal

of your refrigerator.

A Before disposing of your refrigerator,

cut out the electric plug and, if there

are any locks on the door, make them

inoperable in order to protect children

against any danger.

Placing and Installation

ACaution: Never plug the refrigerator

into the wall outlet during installation.

Otherwise, risk of death or serious

injury may arise.

AIf the entrance door of the room

where the refrigerator will be installed is

not wide enough for the refrigerator to

pass through, than call the authorized

service to have them remove the

doors of your refrigerator and pass it

sideways through the door.

1. Install your refrigerator to a place

that allows ease of use.

2. Keep your refrigerator away from

heat sources, humid places and direct

sunlight.

3. There must be appropriate air

ventilation around your refrigerator in

order to achieve an efficient operation.

If the refrigerator is to be placed in a

recess in the wall, there must be at

least 5 cm distance with the ceiling

and at least 5 cm with the wall.

If the floor is covered with a carpet,

your product must be elevated 2.5 cm

from the floor.

4. Place your refrigerator on an even

floor surface to prevent jolts.

5. Do not keep your refrigerator in

ambient temperatures under 10°C.

Floor balance adjustment

AIf your refrigerator is unbalanced;

1- Ventilation cover is removed by

unscrewing its screws as illustrated

in the figure before the procedure.

You can balance your refrigerator by

turning the front legs of it as illustrated

in the figure. The corner where the

leg exists is lowered when you turn

in the direction of black arrow and

raised when you turn in the opposite

direction. Taking help from someone to

slightly lift the refrigerator will facilitate

this process.

2. After the balance issue is remedied,

install back the ventilation cover and

fasten the screws.

A B C

3. Remove the screws fastening the

lower ventilation cover using a Philips

screwdriver.

Andere Handbücher für KFD 9952 XA+

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg DSM 1510 A+ Bedienungsanleitung

Blomberg

Blomberg BRFB1312SS Bedienungsanleitung

Blomberg

Blomberg SOM 1650 + Bedienungsanleitung

Blomberg

Blomberg DSM 4125 Bedienungsanleitung

Blomberg

Blomberg DSM 1510 Bedienungsanleitung

Blomberg

Blomberg TSM 1541 i A+ Bedienungsanleitung

Blomberg

Blomberg SOE 96733 Bedienungsanleitung

Blomberg

Blomberg KND 9950 XA+ Bedienungsanleitung

Blomberg

Blomberg KQD 1253 XN-KQD1254XN Bedienungsanleitung

Blomberg

Blomberg DNE 9887 X A+ Bedienungsanleitung

Blomberg

Blomberg DNE 1870 Bedienungsanleitung

Blomberg

Blomberg FNT 9670 XT Bedienungsanleitung

Blomberg

Blomberg BRFB1052FFBI2 Bedienungsanleitung

Blomberg

Blomberg KSM 9640 A Series Bedienungsanleitung

Blomberg

Blomberg KFD 9950 XA+ Bedienungsanleitung

Blomberg

Blomberg KQE 1010 X Bedienungsanleitung

Blomberg

Blomberg BRFB1052FFBIN Bedienungsanleitung

Blomberg

Blomberg KNE4554EVI Bedienungsanleitung

Blomberg

Blomberg SSM1554P Bedienungsanleitung

Blomberg

Blomberg SSM4450 Bedienungsanleitung

Blomberg

Blomberg LSP3579W Bedienungsanleitung

Blomberg

Blomberg SOM 9650 A+ Bedienungsanleitung

Blomberg

Blomberg SSM 1350 iF Bedienungsanleitung

Blomberg

Blomberg BRFB1050FFBIN Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
