Blomberg KNM4554V Bedienungsanleitung

KNM4554V - KNM4554VPS

User Manual

58 8409 0000/AA

Refrigerator

EN /

Please read these instructions first before using your appliance

Thank you for choosing a Blomberg appliance.

Please take some time to read this user manual before using your appliance, to

ensure you know how to safely operate the controls and functions.

Carefully follow all unpacking and installation instructions to ensure the appliance

is correctly connected and fitted prior to use.

Please write your product model and serial number on the last page of this user

manual, and store in a safe location close to the appliance for easy future reference.

This user manual may also be applicable for several other models. Differences

between models will be listed.

If you have any questions or concerns, please call our contact centre or find help

and information online at www.blomberguk.com

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

SUPPLIER’S NAME MODEL IDENTIFIER (*)

INFORMATION

The model information as stored in the product data base

can be reached by entering following website and searching

for your model identiﬁer (*) found on energy label.

https://eprel.ec.europa.eu/

1 Your refrigerator 4

2 Warnings 5

For models with water dispenser .......6

Electrical Requirements .....................6

Warning! This Appliance Must Be

Earthed .............................................7

Energy Saving Tips............................8

Compliance with WEEE Directive and

Disposing of the Waste Product: .......8

Compliance with RoHS Directive: ......8

Package information..........................8

3 Installation 9

Points to be paid attention to when the

relocation of the refrigerator ...............9

Electrical connection..........................9

Disposing of the packaging .............10

Disposing of your old refrigerator .....10

Placing and Installation ....................10

Adjusting the legs ............................11

Chiller Compartment........................11

Changing the illumination lamp .......11

CONTENTS

4 Preparation 12

Reversing the doors ........................13

5 Using your refrigerator 14

Thermostat setting button................14

Defrost ............................................15

6 Maintenance and cleaning 16

7 Troubleshooting 18

1Your refrigerator

C Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1.Adjustable door shelves

2.Water dispenser filling tank

3.Egg section

4.Water dispenser reservoir

5.Bottle shelf

6.Adjustable Front Feet

7.Freezing and Storage (store fresh food

to be frozen lower down)

8.Salad Crisper

9.Chiller compartment

10. Adjustable shelves

11. Wine rack

12. Thermostat knob

*May not be available in all models

11*

*12

Congratulations on your choice of a BLOMBERG quality Appliance which has

been designed to give you service for many years.

2Warnings

• DO NOT connect your

appliance to the electricity

supply until all packing and

transit protectors have been

removed.

• Leave to stand for at least 4

hours before switching on to

allow compressor oil to settle if

transported horizontally.

• If you are discarding an old

refrigerator with a lock or latch

fitted to the door, disable the

lock/latch, ensure that it is left

in a safe condition to prevent

the entrapment of young

children.

• This appliance must only be

used for its intended purpose

i.e the storing of edible

foodstuff.

• Do not dispose of the

appliance on a fire. At

BLOMBERG, the care and

protection of our environment

is an ongoing commitment.

This appliance which is among

the latest range introduced is

particularly environment friendly.

Your appliance contains non

CFC / HFC natural substances

in the cooling system (Called

R600a) and in the insulation

(Called cyclopentane) which

are potentially flammable if

exposed to fire. Therefore,

take care not to damage, the

cooling circuit / pipes of the

appliance in transportation and

in use. In case of damage do

not expose the appliance to fire

or potential ignition source and

immediately ventilate the room

where the appliance is situated.

• We suggest you contact your

local authority for disposal

information and facilities

available.

• To obtain the best possible

performance and trouble free

operation from your appliance

it is very important to carefully

read these instructions.

• On delivery, check to make

sure that the product is not

damaged and that all the parts

and accessories are in perfect

condition.

• Ensure that the plug remains

readily accessible. Do not use

multiple adapter or extension

cable.

• Failure to observe these

instructions may invalidate your

right to free service during the

guarantee period.

• Keep ventilation openings, in

the appliance enclosure or in

the built-in structure, clear of

obstruction.

• Do not use mechanical devices

or other means to accelerate

the defrosting process, other

than those recommended by

the manufacturer.

• Do not damage the refrigerant

circuit.

• Do not use electrical

appliances inside the food

storage compartments of the

appliance, unless they are of

the type recommended by the

manufacturer.

• We suggest you keep these

instructions in a safe place for

easy reference.

• This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory

or mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use of

the appliance in a safe way

and understand the hazards

involved.

• Children should be supervised

to ensure that they do not play

with the appliance.

For models with water

dispenser

• Pressure for cold water inlet

shall be maximum 90 psi (6.2

bar). If your water pressure

exceeds 80 psi (5.5 bar), use a

pressure limiting valve in your

mains system. If you do not

know how to check your water

pressure, ask for the help of a

professional plumber.

• If there is risk of water hammer

effect in your installation,

always use a water hammer

prevention equipment in

your installation. Consult

Professional plumbers is

you are not sure that there is

water hammer effect in your

installation.

• Do not install on the hot water

inlet. Take precautions against

of the risk of freezing of the

hoses. Water temperature

operating interval shall be 33°F

(0.6°C) minimum and 100°F

(38°C) maximum.

• Use drinking water only.

Electrical Requirements

Before you insert the plug into

the wall socket make sure that

the voltage and the frequency

shown on the rating plate inside

the appliance corresponds to

your electricity supply.

Rating label is on the left hand

side of inner liner.

We recommend that this

appliance be connected to the

mains supply via a

suitable switched and fused

socket. The appliance must be

positioned so that the plug is

accessible.

Should the mains lead of the

appliance become damaged or

should it need

replacing at any time, it must be

replaced by a special purpose

made mains lead which can only

be obtained from a BLOMBERG

Authorised Service Agent.

Warning! This Appliance

Must Be Earthed

If the fitted moulded plug is not

suitable for your socket, then the

plug should be cut off and an

appropriate plug fitted. Destroy

the old plug which is cut off as a

plug with bared cord could cause

a shock hazard if inserted into a

socket elsewhere in the house.

The moulded plug on this

appliance incorporates a 13

A fuse. Should the fuse need

to be replaced an ASTABEAB

approved BS 1362 fuse of the

same rating must be used. Do

not forget to refit the fuse cover.

In the event of losing the fuse

cover the plug must not be used

until a replacement fuse cover

has been fitted. Colour of the

replacement fuse cover must be

the same colour as that visible

on the pin face of the plug. Fuse

covers are available from any

good electrical store.

Important! Fitting A Different

Plug

As the colours of the wires in

the mains lead of this appliance

may not correspond with the

coloured markings identifying the

terminals in your plug proceed

as follows: (See diagram).

1. Connect the green-yellow

or green (Earth) wire to the

terminal in the plug marked

‘E’ or with the symbol or

coloured green and yellow or

green.

2. Connect the blue (Neutral)

wire to the terminal in the plug

marked ‘N’ or coloured black.

3. Connect the brown (Live) wire

to the terminal in the plug

marked ‘L’ or coloured red.

4. With alternative plugs a 13 A

fuse must be fitted either in the

plug or adaptor or in the main

fuse box. If in doubt contact a

qualified electrician.

Energy Saving Tips

1. Ensure your appliance is

installed in a well ventilated

area.

2. Ensure the time between

buying chilled/frozen food and

placing them in your appliance

is kept at minimum, particularly

in summer. We recommend

you use a cool bag or a special

carrier bag to carry perishable

food.

3. Do not leave the door (s) of

your appliance open longer

than necessary and ensure

they are closed properly after

each opening.

4.Defrost frozen food in the fridge,

so that frozen food acts as an

ice pack to assist cooling in

fridge.

Compliance with WEEE

Directive and Disposing of

the Waste Product:

Thisproduct complies

with EU WEEE

Directive (2012/19/

EU). This product

bears a classification

symbol for waste

electrical and electronic

equipment (WEEE).This product

has been manufactured with

high quality parts and materials

which can be reused and are

suitable for recycling. Do not

dispose of the waste product

with normal domestic and other

wastes at the end of its service

life. Take it to the collection center

for the recycling of electrical and

electronic equipment. Please

consult your local authorities to

learn about these collection

centers.

Compliance with RoHS

Directive:

The product you have

purchased complies with EU

RoHS Directive (2011/65/EU).

It does not contain harmful and

prohibited materials specified in

the Directive.

Package information

Packaging materials of the

product are manufactured

from recyclable materials in

accordance with our National

Environment Regulations. Do

not dispose of the packaging

materials together with the

domestic or other wastes. Take

them to the packaging material

collection points designated by

the local authorities.

3Installation

BThe manufacturer will not be liable

for any event caused by disregarding

the information supplied in this user

manual.

Points to be paid attention

to when the relocation of the

refrigerator

1. Your refrigerator should be

unplugged.Before transportation of

your refrigerator, it should be emptied

and cleaned.

2. Before it is re-packaged,

shelves, accessories, crisper, etc.

inside your refrigerator should be

fixed with adhesive tape and secured

against impacts. Package should be

adequate and the transportation rules

on the package should be strictly

observed.

3. Original packaging and foam

materials should be kept for future

transportations or moving.

Before you start the refrigerator,

Check the following before you

start to use your refrigerator:

1. Attach 2 plastic wedges as

illustrated below. Plastic wedges are

intended to keep the distance which

will ensure the air circulation between

your refrigerator and the wall. (The

picture is drawn up as a representation

and it is not identical with your

product.)

2. Clean the interior of the

refrigerator as recommended in the

“Maintenance and cleaning” section.

3. Connect the plug of the

refrigerator to the wall socket. When

the fridge door is opened, fridge

internal lamp will turn on.

4. When the compressor starts to

operate, a sound will be heard. The

liquid and gases sealed within the

refrigeration system may also give rise

to noise, even if the compressor is not

running and this is quite normal.

5. Front edges of the refrigerator

may feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Electrical connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

The connection must be in compliance

with national regulations.

• The power plug must be easily

accessible after installation.

• Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

• The voltage stated on the label

located at left inner side of your

product should be equal to your

network voltage.

• Extension cables and multi plugs

must not be used for connection.

BA damaged power cable must be

replaced by a qualified electrician.

BProduct must not be operated before

it is repaired! There is the risk of

electric shock!

Disposing of the packaging

The packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose of them by

classifying them in accordance with the

waste instructions stated by your local

authorities. Do not throw away with

regular house waste, throw away on

packaging pick up spots designated by

the local authorities.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old refrigerator without

giving any harm to the environment.

• You may consult your authorized

dealer or waste collection center of

your municipality about the disposal

of your refrigerator.

Before disposing of your refrigerator,

cut off the electric plug and, if there

are any locks on the door, make them

inoperable in order to protect children

against any danger.

Placing and Installation

AIf the entrance door of the room

where the refrigerator will be installed

is not wide enough for the refrigerator

to pass through, then carefully remove

the doors of your refrigerator and pass

it sideways through the door.

1. Install your refrigerator to a

place that allows ease of use.

2. Keep your refrigerator away

from heat sources, humid places and

direct sunlight.

3. There must be appropriate air

ventilation around your refrigerator in

order to achieve an efficient operation.

If the refrigerator is to be placed in a

recess in the wall, there must be at

least 5 cm distance with the ceiling

and at least 5 cm with the wall. Do not

place your product on the materials

such as rug or carpet.

4. Place your refrigerator on an

even floor surface to prevent jolts.

5. Your product requires

adequate air circulation to function

efficiently. If the product will be placed

in an alcove, remember to leave at least

5 cm clearance between the product

and the ceiling, rear wall and the side

walls.

If the product will be placed in an

alcove, remember to leave at least 5

cm clearance between the product

and the ceiling, rear wall and the side

walls. Check if the rear wall clearance

protection component is present at its

location (if provided with the product).

If the component is not available, or if

it is lost or fallen, position the product

so that at least 5 cm clearance shall

be left between the rear surface of the

product and the wall of the room. The

clearance at the rear is important for

efficient operation of the product.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg DSM 1510 Bedienungsanleitung

Blomberg

Blomberg FlexiCool X Bedienungsanleitung

Blomberg

Blomberg TSM1750u Produktinformationsblatt

Blomberg

Blomberg KWD 1330 X Bedienungsanleitung

Blomberg

Blomberg KWS 9220 X Bedienungsanleitung

Blomberg

Blomberg KQD 1620 GB Bedienungsanleitung

Blomberg

Blomberg KNM1551i Bedienungsanleitung

Blomberg

Blomberg KFD 9950 XA+ Bedienungsanleitung

Blomberg

Blomberg KQD 1360X Bedienungsanleitung

Blomberg

Blomberg SOE 96733 Bedienungsanleitung

Blomberg

Blomberg KWD 9440 X A+ Bedienungsanleitung

Blomberg

Blomberg KNM4760N Bedienungsanleitung

Blomberg

Blomberg KQD 1253 XN Bedienungsanleitung

Blomberg

Blomberg KQD 1253 XN-KQD1254XN Bedienungsanleitung

Blomberg

Blomberg FRM1970A++ Bedienungsanleitung

Blomberg

Blomberg FRM1940A+ Bedienungsanleitung

Blomberg

Blomberg SSM 1350 iF Bedienungsanleitung

Blomberg

Blomberg BRFD2650SS5VFLR Bedienungsanleitung

Blomberg

Blomberg FNT 1670 XT Bedienungsanleitung

Blomberg

Blomberg KND 9651 A Plus Bedienungsanleitung

Blomberg

Blomberg SSM1554P Bedienungsanleitung

Blomberg

Blomberg KQD 1360X Bedienungsanleitung

Blomberg

Blomberg BRFB 0900 Bedienungsanleitung

Blomberg

Blomberg BFBF2413SS Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
