Blomberg KSM 9641 XA+ Bedienungsanleitung

D Bedienungsanleitung

KSM 9640 A+

KSM 9640 XA+

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future references.

This manual

• Will help you use your appliance in a fast and safe way.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

This product bears the selective sorting symbol for waste electrical and

electronic equipment (WEEE).

This means that this product must be handled pursuant to European Directive

2002/96/EC in order to be recycled or dismantled to minimize its impact on

the environment. For further information, please contact your local or regional

authorities.

Electronic products not included in the selective sorting process are potentially

dangerous for the environment and human heatlh due to the presence of

hazardous substances.

Recycling

1 Your refrigerator 3

Technical specifications of your refrigerator4

2 Warnings 5

General safety .......................................... 5

Starting Up............................................... 6

If there are any children at home............... 6

Intended use ............................................ 6

Safety instructions .................................... 6

Things to be done for energy saving......... 6

3 Installation 7

Preparation............................................... 7

Points to be considered when re-transporting

your refrigerator........................................ 7

Before operating your refrigerator ............. 8

Electric connection ................................... 8

Disposing of the packaging ...................... 8

Disposing of your old refrigerator.............. 9

Adjusting the legs..................................... 9

Replacing the interior light bulb ................ 9

Reversing the doors ............................... 10

4 Using your refrigerator 11

Thermostat setting button ...................... 11

Defrost ................................................... 11

Icematic and ice storage container ......... 12

5 Maintenance and cleaning 13

Protection of plastic surfaces ................. 13

6 Recommended solutions for the

problems 14

CONTENTS

CFigures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1Your refrigerator

A Fridge compartment

B Freezer compartment

Interior light

Thermostat knob

Movable shelves

Wine rack

Defrost water collection channel -

Drain tube

Crisper cover

Salad crisper

Ice bank

Icematic and ice storage container

Freezer compartment

10.

Adjustable front feet

11.

Dairy compartment

12.

Adjustable door shelves

13.

Egg tray

14.

A+

238

175

253

165

59.5

220/50

R600a

Technical specifications of your refrigerator

* (Actual consumption varies depending on where and how the appliance is used)

** (Power failure safety; it is recommended not to consume the food in freezer

compartment after this period.)

CTechnical specifications can be changed to increase the product quality without

being subject to prior notice.

CValues stated on the markings on the product or in the printed materials supplied

with the product are the values obtained in laboratory in accordance with relevant

standards. Such values may vary depending on the usage of the product and the

ambient conditions.

CThe dimensions given on the table describe the minimum required space to place

the unit with doors closed.

Energy Class

Annual Energy Consumption (kWh/year)*

Fridge Compartment Volume (Net-lt)

Total Frozen Food Compartment Volume

(Net-lt)

Star Class

Temperature Increasing Time (hours)**

Freezing Capacity (kg/24 hours)

Climate Class

Noise Level (dB(A))

Total Net Volume (lt)

(H) Height (cm)

(W) Width (cm)

(D) Depth (cm)

Weight (kg)

Total Power (W)

Electric Supply (V/Hz)

Coolant Type

2Warnings

Please review the following informa-

tion. If these are not followed, personal

injury or material damage may occur.

Otherwise, all warranty and reliability

commitments will become invalid.

The usage life of the unit you pur-

chased is 10 years. This is the period

for keeping the spare parts required

for the unit to operate as described.

General safety

• When you want to dispose/scrap

the product, we recommend you

to consult the authorized service in

order to learn the required information

and authorized bodies.

• Consult your authorized service for

all your questions and problems

related to the refrigerator. Do not

intervene or let someone intervene to

the refrigerator without notifying the

authorized services.

• Do not eat cone ice cream and ice

cubes immediately after you take

them out of the freezer compartment!

(This may cause frostbite in your

mouth.)

• Do not put bottled and canned

liquid beverages in the freezer

compartment. Otherwise, these may

burst.

• Do not touch frozen food by hand;

they may stick to your hand.

• Vapor and vaporized cleaning

materials should never be used in

cleaning and defrosting processes

of your refrigerator. In such cases,

the vapor might get in contact with

the electrical parts and cause short

circuit or electric shock.

• Never use the parts on your

refrigerator such as the door as a

means of support or step.

• Do not use electrical devices inside

the refrigerator.

• Do not damage the cooling circuit,

where the refrigerant is circulating,

with drilling or cutting tools. The

refrigerant that might blow out when

the gas channels of the evaporator,

pipe extensions or surface coatings

are punctured may cause skin

irritations and eye injuries.

• Do not cover or block the ventilation

holes on your refrigerator with any

material.

• Repairs of the electrical appliances

must only be made by qualified

persons. Repairs performed by

incompetent persons may create a

risk for the user.

• In case of any failure or during

a maintenance or repair work,

disconnect your refrigerator’s mains

supply by either turning off the

relevant fuse or unplugging your

appliance.

• Do not pull by the cable when pulling

off the plug.

• Place the beverage with higher

proofs tightly closed and vertically.

• Flammable items or products that

contain flammable gases (e.g.

spray) as well as the explosive

materials should never be kept in the

appliance.

• Do not use mechanical devices

or other means to accelerate the

defrosting process, others than those

recommended by the manufacturer.

• This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

• Children should be supervised to

ensure that they do not play with the

appliance

Starting Up

• Do not operate a damaged

refrigerator. Consult your service if

you have any doubts.

• Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

If there are any children at

home...

• Do not allow children play with

your refrigerator. They might harm

themselves and the refrigerator. (E.g.

do not allow them hang from the

door.)

Intended use

• This product is designed for

domestic use.

• It should not be used outdoors. It

is not appropriate to use it outdoor

even if the place is covered with a

roof.

Safety instructions

• Exposing the product to rain, snow,

sun and wind is dangerous with

respect to electrical safety.

• Contact the authorized service when

there is a power cable damage and

etc. so that it will not create a danger

for you.

• Caution: Never plug the refrigerator

into the wall outlet during installation.

Otherwise, risk of death or serious

injury may arise.

AYour product is equipped with a

natural cooling system (R600a)

which does not contain CFC and

HFC gases. This gas is flammable.

Therefore, pay attention to not

damaging the cooling system

and piping during usage and

transportation. In the event of

damage, do not dispose the product

in fire; keep your product away from

potential fire sources that can cause

the product catch a fire and ventilate

the room in which the unit is placed.

Things to be done for energy

saving

CDo not leave the doors of your

refrigerator open for a long time.

CDo not put hot food or drinks in your

refrigerator.

CDo not overload your refrigerator so

that the air circulation inside of it is

not prevented.

CDo not install your refrigerator

under direct sunlight or near heat

emitting appliances such as ovens,

dishwashers or radiators.

CPay attention to keep your food in

closed containers.

3Installation

BPlease remember that the

manufacturer shall not be held

liable if the information given in the

instruction manual is not observed.

Preparation

• Your refrigerator should be installed

at least 30 cm away from heat

sources such as hobs, ovens, central

heater and stoves and at least 5

cm away from electrical ovens and

should not be located under direct

sunlight.

• The ambient temperature of

the room where you install your

refrigerator should at least be 10°C.

Operating your refrigerator under

cooler conditions than this is not

recommended with regard to its

efficiency.

• Please make sure that the interior

of your refrigerator is cleaned

thoroughly.

• If two refrigerators are to be installed

side by side, there should be at least

2 cm distance between them.

• When you operate your refrigerator

for the first time, please observe the

following instructions during the initial

six hours.

- The door should not be opened

frequently.

- It must be operated empty without

any food in it.

- Do not unplug your refrigerator. If

a power failure occurs out of your

control, please see the warnings in

the “Recommended solutions for the

problems” section.

• Original packaging and foam

materials should be kept for future

transportations or moving.

Points to be considered

when re-transporting your

refrigerator

1. Your refrigerator must be

emptied and cleaned prior to any

transportation.

2. Shelves, accessories, crisper and

etc. in your refrigerator must be

fastened securely by adhesive tape

against any jolt before repackaging.

3. Packaging must be tied with thick

tapes and strong ropes and the

rules of transportation printed on the

package must be followed.

Please remember…

Every recycled material is an indis-

pensable source for the nature and for

our national resources.

If you wish to contribute to recycling

the packaging materials, you can get

further information from the environ-

mental bodies or local authorities.

Before operating your

refrigerator

Before starting to use your refrigerator

check the following:

1. Is the interior of the refrigerator dry

and can the air circulate freely in the

rear of it?

2. Insert the 2 plastic wedges between

the wires of the condenser as

illustrated in the following figure.

Plastic wedges will provide the

required distance between your

refrigerator and the wall in order

to allow the air circulation. (The

illustrated figure is only an example

and does not match exactly with your

product.)

3. Clean the interior of the refrigerator as

recommended in the “Maintenance

and cleaning” section.

4. Plug the refrigerator into the wall

outlet. When the fridge door is open

the fridge compartment interior light

will come on.

5. You will hear a noise as the

compressor starts up. The liquid and

gases sealed within the refrigeration

system may also give rise to noise,

even if the compressor is not running

and this is quite normal.

6. Front edges of the refrigerator may

feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Electric connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

• The connection must be in

compliance with national regulations.

• The power cable plug must be easily

accessible after installation.

• Voltage and permitted fuse protection

are indicated in the “Specifications”

section.

• The specified voltage must be equal

to your mains voltage.

• Extension cables and multiway plugs

must not be used for connection.

A damaged power cable must be

replaced by a qualified electrician.

BProduct must not be operated before

it is repaired! There is danger of

electric shock!

Disposing of the packaging

The packing materials may be dan-

gerous for children. Keep the packing

materials out of the reach of children

or dispose them of by classifying them

in accordance with the waste instruc-

tions. Do not dispose them of along

with the normal household waste.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old machine without

giving any harm to the environment.

• You may consult your authorized

dealer or waste collection center of

your municipality about the disposal

of your refrigerator.

Before disposing of your refrigerator,

cut out the electric plug and, if there

are any locks on the door, make them

inoperable in order to protect children

against any danger.

Adjusting the legs

If your refrigerator is unbalanced;

You can balance your refrigerator by

turning the front legs of it as illustrated

in the figure. The corner where the leg

exists is lowered when you turn in the

direction of black arrow and raised

when you turn in the opposite direc-

tion. Taking help from someone to

slightly lift the refrigerator will facilitate

this process.

Replacing the interior light

bulb

Should the light fail to work, proceed

as follows.

1- Switch off at the socket outlet and

pull out the mains plug.

You may find it useful to remove shel-

ves for easy access.

2- Use a flat tipped screwdriver to

remove the light diffuser cover.

3- First check that the bulb hasn’t

worked loose by ensuring it is screwed

securely in the holder. Replace the

plug and switch on.

If the bulb works, replace the light co-

ver by inserting the rear lug and pus-

hing up to locate the front two lugs.

4- If the light still fails to work, switch

off at the socket outlet and pull out

the mains plug. Replace the bulb with

a new 15 watt (max) screw cap (SES)

bulb.

5- Carefully dispose of the burnt-out

light bulb immediately.

Replacement light bulb can easily be

obtained from a good local electrical

or DIY store.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg BBBF2410IM Bedienungsanleitung

Blomberg

Blomberg KFD 9952 XA+ Bedienungsanleitung

Blomberg

Blomberg SOM 9650 A+ Bedienungsanleitung

Blomberg

Blomberg SSM 1550 Bedienungsanleitung

Blomberg

Blomberg DNE 9887 X A+ Bedienungsanleitung

Blomberg

Blomberg BRFB1050FFBIN Bedienungsanleitung

Blomberg

Blomberg TSM 1541 i A+ Bedienungsanleitung

Blomberg

Blomberg SSM4543 Bedienungsanleitung

Blomberg

Blomberg DNM 9650 T Bedienungsanleitung

Blomberg

Blomberg SST3455I Bedienungsanleitung

Blomberg

Blomberg KSM 9640 A Series Bedienungsanleitung

Blomberg

Blomberg KND 9950 XDA+ Bedienungsanleitung

Blomberg

Blomberg KND 9920 PD Bedienungsanleitung

Blomberg

Blomberg brfd2230ss Bedienungsanleitung

Blomberg

Blomberg KSM 1520 Bedienungsanleitung

Blomberg

Blomberg SST4455VI Bedienungsanleitung

Blomberg

Blomberg KND464VPS Bedienungsanleitung

Blomberg

Blomberg SSM4450 Bedienungsanleitung

Blomberg

Blomberg KND 9950 Bedienungsanleitung

Blomberg

Blomberg BRFD2652SS Bedienungsanleitung

Blomberg

Blomberg DSM 9511 A+ Bedienungsanleitung

Blomberg

Blomberg KWD 1330 X Bedienungsanleitung

Blomberg

Blomberg SOM 9673P Bedienungsanleitung

Blomberg

Blomberg KSM 1640 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
